Communication

High-Density Microalgae Cultivation in Open Thin-Layer Cascade Photobioreactors with Water Recycling

1
Institute of Biochemical Engineering, Technical University of Munich, Boltzmannstr. 15, 85748 Garching, Germany
2
TUM-AlgaeTec Center, Department of Aerospace and Geodesy, Technical University of Munich, Ludwig Bölkow Campus, Willy Messerschmitt Str. 1, 82024 Taufkirchen, Germany
3
University Hospital, Division of Infectious Diseases and Tropical Medicine, Ludwig-Maximilians-University Munich, Leopoldstr. 5, 80802 Munich, Germany
4
German Center for Infection Research (DZIF), Partner Site Munich, 38124 Braunschweig, Germany
5
Institute of Hydrochemistry, Technical University of Munich, Marchioninistr. 17, 81377 Munich, Germany
6
Werner Siemens-Chair of Synthetic Biotechnology, Technical University of Munich, Lichtenbergstr. 4, 85748 Garching, Germany
*
Author to whom correspondence should be addressed.
Appl. Sci. 2020, 10(11), 3883; https://doi.org/10.3390/app10113883
Received: 14 May 2020 / Revised: 29 May 2020 / Accepted: 2 June 2020 / Published: 3 June 2020
(This article belongs to the Special Issue Algal Biorefinery and Microbial Fuel Cells)
(1) Background: Recycling of water and non-converted nutrients is considered to be a necessity for an economically viable production of microalgal biomass as a renewable feedstock. However, medium recycling might also have a negative impact on algal growth and productivity due to the accumulation of growth-inhibiting substances. (2) Methods: Consecutive batch processes with repeated water recycling after harvesting of algal biomass were performed with the saline microalga Microchloropsis salina in open thin-layer cascade photobioreactors operated at a physically simulated Mediterranean summer climate. The impact of water recycling on culture performance was studied and the composition of the recycled water was analyzed. (3) Results: Water recycling had no adverse effect on microalgal growth and biomass productivity (14.9−21.3 g m−2 d−1) if all necessary nutrients were regularly replenished and KNO3 was replaced by urea as the nitrogen source to prevent the accumulation of K+ ions. Dissolved organic carbon accumulated in recycled water, probably promoting mixotrophic growth. (4) Conclusion: This study shows that repeated recycling of water is feasible even in high-density cultivation processes with M. salina of more than 30 g L−1 cell dry weight, increasing culture performance while reducing nutrient consumption and circumventing wastewater production. View Full-Text
Keywords: microalgae; Microchloropsis salina; open photobioreactor; thin-layer cascade; water recycling microalgae; Microchloropsis salina; open photobioreactor; thin-layer cascade; water recycling
Show Figures

Figure 1
