Fundamentals and Advances in Elastohydrodynamics: The Role of Ramsey Gohar

Abstract

This paper commemorates Ramsey Gohar by acknowledging his contributions to the fields of contact mechanics and elastohydrodynamic lubrication (EHL) within the context of the developments of these subjects. A historical discourse is provided on elastohydrodynamics, from its inception in the 1940s to present. We demonstrate that Ramsey Gohar was not only a pioneer in the discoveries and fundamentals of the subject, but also led or contributed significantly to continual advances in the understanding of EHL and its diverse applications.

1. Introduction

Dr. Ramsey Gohar was one of the pioneers in the field of elastohydrodynamic lubrication (EHL). After obtaining his bachelor’s degree in Mechanical Engineering in 1951, Ramsey spent time in the industry, working on an assortment of industrial lubrication problems. From his time at D. Napier & Son, manufacturers of aircraft, automotive and marine engines (Figure 1), he attained valuable practical experience in contact mechanics and lubrication. In the late 1950s, Ramsey worked on gyroscopes in the research laboratories of General Electric, which inspired his lifelong interest in rigid body dynamics. His association with the Lubrication Laboratory at Imperial College led to his MSc dissertation in 1959 on the lubricated contact of ellipsoidal solids of revolution [1]. This dissertation was very timely, as research on elastohydrodynamic lubrication was still in its infancy.

Since the publication of Osborne Reynolds’ theory of hydrodynamic lubrication [2], the absence of wear in contacts with hydrodynamic films of seemingly insufficient thickness [3] had been puzzling. There were many suppositions for the apparent increased load carrying capacity of the lubricant film separating the contiguous surfaces. These included the piezo-viscous effect of the lubricant under increased pressures [4,5] and the localised deformation of surfaces based on the Hertzian contact theory, proposed by Ertel and Grubin [6,7,8]. Ramsey’s MSc and subsequent research led to his seminal contributions to the fields of contact mechanics and elastohydrodynamic lubrication.

2. Fundamentals of Elastohydrodynamic Lubrication

Throughout his 60-year research career, Ramsey contributed to the understanding of the fundamentals of fluid-film lubrication, by developing means of observation, precision measurement techniques and numerical and analytical methods of prediction. He published numerous outstanding contributions, only a sample of which are highlighted here within the context of developments in elastohydrodynamic lubrication, and its application to concentrated contacts, particularly in bearings.

2.1. Observation and Measurements of Elastohydrodynamic Conditions

A fundamental understanding of any phenomenon requires careful observations and precise measurements. The development of EHL theory and predictive methods is no exception. Ramsey provided some pioneering contributions in this regard. His PhD research contributed significantly to both measurements and theoretical developments in EHL [9].

Following early works on EHL [6,7,8], Petrusevich included both the effect of lubricant piezoviscous behaviour, and localised elastic deformation of surfaces [10]. A first iterative numerical solution was provided by Dowson and Higginson [11] for the case of EHL of line contacts. The predictions obtained in [11] were confirmed using capacitive measurement of the thin lubricant films by Crook [12], and by Sibley and Orcutt using an X-ray technique [13]. Other early solutions include [14,15]. Brief historical accounts of these solutions are provided in [16,17].

By the early 1960s, it had become clear that both iterative numerical solutions and methods of observation and measurement were much more complicated for the general case of a lubricated concentrated elliptical point contact than for a line contact. Thus, Ramsey directed his research towards the numerical solution of point contact EHL and its verification, through observation and precise measurements. This work culminated in his PhD thesis [9].

Regarding observations and measurement of film thickness, Shultz [18] had already reported an interferometric method for very thin evaporated films. This method was improved by Tolansky [19] and used by Kirk [20] for hydrodynamic films between a pair of crossed perspex cylinders. Kirk [20] noted the importance of direct observation of lubricated contacts using transparent contacting bodies that form fringes to measure lubricant film thickness. Shortly afterwards, some of the interferometric results of EHL of circular point contact for a rotating ball against a flat glass disc from Ramsey’s research were published [21]. Detailed optical interferometric studies of EHL contacts was born with this seminal contribution. In time, the interferometric and spectroscopic methods of measurements of lubricant films improved the use of colour fringes, and led to the inclusion of spacer layers in glass races to measure ultra-thin films. The literature describing various conditions and applications includes [22,23,24,25]. An optical interferometric study for end-closure films in finite line contact of roller-to-races was initially presented by Gohar and Cameron [26], Bahadoran and Gohar [27], and Wymer and Cameron [28]. More recent interferometric studies of various EHL contact conjunctions were reported in [29,30,31,32].

The measurement of elastohydrodynamic conditions was promoted with the development of deposited miniature micro-transducers in the tiny footprint areas of concentrated contacts. Initially, these transducers were typically a few hundred micrometres in dimension with a thickness of the order of a few hundred Angstroms. Therefore, they did not significantly affect the contact conditions. They were capacitive or pressure-sensitive in nature, measuring lubricant film thickness of the order of a few tenths of a micrometre or high pressures of a few giga-Pascals.

Whilst optical interferometry proved to be the most established and refined method of obtaining interferograms of lubricated contacts and the lubricant film thickness, the measurement of high contact pressures under EHL was a much tougher proposition. The measurement of high pressures in minute contact conjunctions received an impetus with the pioneering work of Bridgman [33], using pressure sensitive bulk manganin with low temperature sensitivity. Later, bulk manganin powder was deposited using a flash-evaporation technique to form ultra-thin pressure sensitive transducers in EHL contacts [34,35]. The preliminary results were fitted rather crudely to calculate Hertzian pressure profiles, as the centre of contact pressure distribution could not be precisely ascertained in the measurements. Nevertheless, a new precise method of measurement of high elastohydrodynamic pressures had now been established. At this stage the transducer width was of the order of several hundred micrometres, so further refinements were required to resolve the important EHL contact features, such as the exit pressure spike. Kannel [36], Hamilton and Moore [37] fabricated micro-transducers that were capable of monitoring EHL pressures in line-contact conditions when deposited on a disc in a disc machine. Significantly improved manganin micro-transducers with active element dimensions of 5 × 10 µm² and thickness between 100–300 Å were developed through RF sputtering of bulk manganin powder, under high vacuum at Imperial College. They were used for line contact conditions in roller bearings or in a disc machine [38,39,40,41]. More importantly, they were employed for the circular-point contact of a ball on a flat glass race in pure rolling [42,43], as well as for a sphere impacting and rebounding on an oily plate [44]. The ultra-thin active element of the micro-transducer allowed for the precise resolution of the EHL pressure spike, which had eluded all methods of measurement thus far. These precise measurements later allowed for the verification of highly improved and detailed numerical analyses, such as those presented by Gohar and his co-workers [45].

2.2. Numerical Predictions of Contact Mechanics and Elastohydrodynamic Lubrication

2.2.1. Elliptical Point Contacts

Another ground-breaking contribution from Ramsey was the development of an iterative numerical method for the prediction of the point contact EHL problem [46], which was part of his doctoral research [9]. This was the first general solution of 2D-point contact EHL, and paved the way for the development of many other solutions. The most notable include those of Hamrock and Dowson [47,48,49,50], who considered various inlet boundary conditions; flooded or starved, as well as the contact footprint aspect ratio for elliptical point contacts. Vakilzadeh and Gohar [51] presented predictions for circular point contact EHL with inlet starvation. Thorp and Gohar [24] and Mostofi and Gohar [52] considered the general case of elliptical point contacts with angled inlet flow into the contact, a condition which occurs in rolling and sliding contacts such as in hypoid gear teeth meshing. Other solutions for angled inlet flow into the contact conjunction were provided by Chittenden et al. [53,54], and Evans and Snidle [55], who also presented an inverse method to solve EHL conditions at high loads [56]. Other early solutions include EHL of contacts of low elastic modulus [57,58,59] as well as EHL of wavy or rough surfaces [60,61,62,63,64].

Since the proposal of the aforementioned numerical EHL solutions, there have been improvements in the methods of discretisation of the computational domain and iterative procedures, particularly under transient conditions. Ramsey contributed to the earlier developments of these methods, including the use of low-relaxation effective influence Newton-Raphson method [65,66,67] and multi-grid techniques [68,69,70,71]. Detailed analyses of EHL contacts under steady state and transient conditions with various formulation and solution methods were provided comprehensively by Ramsey [72,73]. He verified his various solutions for the EHL of circular [9,21,69] and elliptical [24,66] point contacts with his earlier optical interferometric studies. Other recent solutions have also used Ramsey’s optical interferometric studies for circular point contacts and for elliptical point contacts with rolling and sliding pairs with angled inlet flow conditions [74]. Ramsey’s measurements of the lubricated impact of a sphere [44] have also been used to validate predictive transient EHL analyses [75]. Since then, many solutions have been proposed for the EHL of point contacts across various applications, such as bearings and gears under transient, thermal and non-Newtonian conditions. They include those described in [16,72,73,74,75,76,77,78,79,80,81,82,83,84,85]. Some researchers have employed alternative methods of formulation and solution, including finite elements, the complementarity approach or computational fluid dynamics (CFD) [86,87,88,89], including an early contribution by Ramsey and his co-workers [90].

2.2.2. Finite Line Contacts

Original solutions of EHL problems proposed the lubrication of rollers and involute spur gears at high loads. The contact footprint for these conditions is a thin rectangular strip with very large length-to-width ratio. Therefore, an infinite line contact was initially considered for contact mechanics analyses by Hertz [91], with an elliptical pressure distribution along the width of the contact and a uniform pressure along its length. However, it became immediately clear that, because the actual length of the contact is finite and, because there are abrupt changes at the edges of a roller profile, edge stress discontinuities occur. This leads to the generation of high pressures in these regions, reducing the fatigue life of such contacts, not initially considered in bearing-design analysis, based on Hertzian predictions [92]. Clearly, the axial profile of finite length bodies in contact, such as rollers in bearings, affects the generated pressures as does any misalignment. This was already noted by Palmgren [93]. Lundberg [94] discussed the effect of axial profile of rollers on generated pressures in finite line contact, pointing to pressure spikes at the edge of the contact, which may be reduced by form-relieving. The ideal axial profile is composed of a series of intersecting logarithmic curves. Earlier numerical analyses of finite line contacts provided solutions of a boundary integral equation, relating the generated pressures to the localised deformation of contacting surfaces under load, by assembling a matrix of influence coefficients [95,96]. Ramsey engaged in sustained research regarding contact mechanics of cylindrical rollers with different axial profiles, using finite difference discretisation techniques, including arithmetic, geometric and singularity elements to accurately predict edge stress discontinuities [97,98,99,100]. He also dealt with complex direct and moment loading conditions [101,102]. In addition, Ramsey extended his contact mechanics studies to the case of tapered roller bearings under complex loading [103,104]. A brief review of contact mechanics analysis, under elastostatic conditions, from semi-infinite to the case of bonded, layered solids (such as coatings) is provided in [105].

With his extensive contribution to contact mechanics during 1959–1977, Ramsey was regarded as the leading analyst in ball and rolling element bearing analysis, culminating in the presentation of optimal design criteria for rolling elements in a seminal paper in the New Scientist [106]. Incidentally, this contribution makes Ramsey Gohar the rara avis of his generation of tribologists, having published not only in Nature, but in Proceedings of the Royal Society as well as in the New Scientist; such was the quality of his seminal contributions.

Ramsey continued his research into the mechanics of finite line contacts by studying their EHL. His work included optical interferometric studies of rollers [27], and the first ever measurement of pressure between a roller and a plate in relative motion, using a pressure transducer mounted in a hole filled by lubricant [107]. These were conducted prior to the measurement of pressure in a disc machine, using a micro-miniature transducer [41]. His initial numerical prediction of the EHL of finite line contact was included in a research note, in collaboration with Bahadoran [108], describing an approximate theory to determine the shape of the surfaces at the end-closure of contact of profiled rollers. His research in finite line EHL concentrated on the effect of the roller axial profile on the generated high pressures at the contact extremities, as well as the absolute minimum film thickness at these extremities, termed as the side exit lubricant film thickness, which agreed well with experimental observations [109]. It was shown that under EHL conditions, the pressure spikes at the edges of the contact exceed even those under elastostatic conditions. Some explanations for this phenomenon were provided. Later, finite line elastohydrodynamics of profiled rollers under aligned and misaligned conditions were studied in detail and were in good agreement with experimental optical interferometric studies [110]. This work was extended to cam-tappet contact [111] and rollers-to-races contacts in bearings, with the rollers subjected to combined rolling, tilting and squeeze-film motions under transient conditions [112].

Since the earlier contributions by Ramsey and his co-workers, the EHL of finite line contacts occurring in many applications under various operating conditions has been studied extensively. A representative sample can be found in [113,114,115,116,117].

2.2.3. Sub-Surface Stresses and Contact Fatigue

Ramsey discussed the importance of the effect of generated pressures upon the sub-surface-stress field in concentrated contacts [72,73]. These are often responsible for contact fatigue through inelastic deformation [73]. There has been a significant volume of research on sub-surface contact stresses, particularly for the case of concentrated non-conforming contacts of semi-infinite elastic solids. The first solution was provided by Huber and Fuchs [118]. For bearings and gears, Ioannides and Harris [119] pointed out that cyclic reversing orthogonal stresses often represent the limiting factor for failure. Lyman [120] was the first to study reversing orthogonal shear stresses in rolling contacts, while Poritsky [121] investigated their effect in gears and locomotive wheels. Ramsey and his co-worker, Johns-Rahnejat [42,122], developed detailed models for the evaluation of three-dimensional sub-surface stress fields under elastohydrodynamic point contacts. They favoured orthogonal shear stress criterion for the failure of ductile materials and the Tresca criterion for the case of hard and brittle contacting surfaces. Johnson [123,124] provided a detailed review as well as the fundamentals of contact mechanics of non-conforming concentrated contacts. A more up-to-date review of predictive methods and recent contributions is provided by Sadeghi [16]. A generic semi-analytical method for all contacts of varying conformity is provided in [125], based on the general approach of Muskhelishvili [126]. The predictive contact mechanics analysis of sub-surface stress fields has received much attention. This includes cases of thin bonded or unbonded elastic or viscoelastic layers [127,128,129].

A novel approach was developed by Ramsey and his co-workers in representing generated contact pressures as a series of Fourier waves, applied over the contact footprint, penetrating the contacting layered bonded solids, such as coatings on an elastic substrate [130]. The resulting sub-surface stress field indicated that soft layers transmit the generated stresses into lower layers, whilst harder layers retain their effects. This approach allows for the design and fabrication of coated contacting surfaces. Clearly, thin hard bonded layers/coatings generate much higher pressures than those generated for semi-infinite solids [73,131].

2.3. Tribo-Dynamics of Shaft and Bearing Systems

Most tribologists’ concerns with dynamics phenomena relate to transient conditions, as represented by the normal approach and separation of contacting surfaces (the squeeze film effect in Reynolds’ equation). All other dynamics’ phenomena, such as changes in applied loads in, for example, rolling elements-to-races contacts and their orbital motion into and out of the loaded zone of a bearing, are usually determined through dry contact dynamics. Then, their effect upon lubricant film thickness is measured through a subsequent lubrication analysis. This serial and non-iterative linkage between tribology and dynamics’ analyses can be regarded as quasistatic in nature [73]. In reality, a combined integrated tribo-dynamic analysis is required. Ramsey was very interested in such an approach for his favoured topic of ball and rolling element bearing dynamics. He and his co-workers used extrapolated oil film thickness formulae, obtained through a regression of numerical results [7,11,14,49,53]. However, these formulae rarely included the effect of squeeze-film motion, and were thus not suitable for inclusion in a tribo-dynamics’ analysis. This addition was provided by Mostofi and Gohar [52,132], for the case of elliptical point contacts, also including the effect of angled-flow entrainment into the contact, similar to [53]. The oil-film thickness equations for line contact geometry [7,11] were extended for the realistic case of finite-line contact [73,133].

Rahnejat and Gohar [73,134] re-arranged the lubricant film thickness equations to identify the relationship between the applied contact load, film thickness (gap, localised deformation and any waviness) and contact kinematics. This relationship was linked to dynamics of the system such as shaft and bearings, through applied external loading or movement of the centres of retaining shafts [134]. A step-by-step integration algorithm, such as Newmark’s integration algorithm [135], was adopted to solve the tribo-dynamic equations of motion, thereby determining the transient state of contact dynamics [136]. This approach yielded the first ever solution of lubricated contact dynamics of balls-to-races contacts in orbital paths undergoing iso-viscous, piezo-viscous and EHL time histories [134]. Most contributions in shaft and bearing dynamics’ problems assume dry contact conditions such as Hertzian or neo-Hertzian conditions, as evidenced in [137,138,139,140,141]. Such an assumption can be a good approximation for EHL contact conditions with no emerging clearances in the bearing. This approach was also used by Ramsey and his co-workers [142,143,144,145,146]. Although the methods of dynamics analysis and further features such as flexible multi-body analysis have emerged, remarkably, only a limited number of solutions have incorporated lubricated contacts subjected to rolling, sliding and normal approach and the separation of surfaces, with most solutions being provided by Ramsey and his co-workers [147,148,149,150,151,152].

3. Concluding Remarks

Ramsey Gohar provided sustained contributions to the fundamental understanding and applications of EHL, throughout a research career spanning nearly 60 years. Here, only a sample of his work is cited within the context of developments in tribology during his career. His pioneering research included the development of precise methods of observation and measurement, as well as the establishment of fundamental theories and methods of solution. He studied many applications of contact mechanics and elastohydrodynamics to bearings, gears and other highly loaded concentrated contacts. The breadth of his research extends to the integration of dynamics and tribology, as highlighted in his books [72,73], aimed at the broad audience of undergraduates, practicing engineers, and both budding and established researchers. He will be remembered for his outstanding contributions to the field of tribology as well as for his abilities as a caring educator.
