Highly Integrated Elastic Island-Structured Printed Circuit Board with Controlled Young’s Modulus for Stretchable Electronics

1
Division of Advanced Materials, Korea Research Institute of Chemical Technology (KRICT), 141 Gajeongro, Daejeon 305-600, Korea
2
Department of Materials Science & Engineering, Yonsei University, Yonsei-ro Seodaemun-gu, Seoul 03722, Korea
3
Department of Chemical Convergence Materials, Korea University of Science and Technology (UST), 217 Gajeongro, Yuseong-gu, Daejeon 305-350, Korea
*
Authors to whom correspondence should be addressed.
Micromachines 2020, 11(6), 617; https://doi.org/10.3390/mi11060617
Received: 4 May 2020 / Revised: 22 June 2020 / Accepted: 24 June 2020 / Published: 25 June 2020
(This article belongs to the Special Issue Deformable Bioelectronics Based on Functional Micro/nanomaterials)
A stretchable printed circuit board (PCB), which is an essential component of next-generation electronic devices, should be highly stretchable even at high levels of integration, as well as durable under repetitive stretching and patternable. Herein, an island-structured stretchable PCB composed of materials with controlled Young’s modulus and viscosity by adding a reinforcing agent or controlling the degree of crosslinking is reported. Each material was fabricated with the most effective structures through a 3D printer. The PCB was able to stretch 71.3% even when highly integrated and was patterned so that various components could be mounted. When fully integrated, the stress applied to the mounted components was reduced by 99.9% even when stretched by over 70%. Consequently, a 4 × 4 array of capacitance sensors in a stretchable keypad demonstration using our PCB was shown to work, even at 50% stretching of the PCB. View Full-Text
Keywords: stretchable printed circuit board (PCB); substrate; island structure; 3D nozzle printing; degree of integration stretchable printed circuit board (PCB); substrate; island structure; 3D nozzle printing; degree of integration
Show Figures

Figure 1
