Open AccessArticle
Remote Sens. 2018, 10(1), 21;

The VIS/NIR Land and Snow BRDF Atlas for RTTOV: Comparison between MODIS MCD43C1 C5 and C6

Météo-France, CMS, Lannion F-22300, France
Météo-France—CNRS, CNRM, UMR 3589, CEN, Saint Martin d’Hères F-38400, France
MetOffice, Exeter EX1 3PB, UK
Author to whom correspondence should be addressed.
Received: 27 November 2017 / Revised: 20 December 2017 / Accepted: 21 December 2017 / Published: 23 December 2017
Full-Text   |   PDF [2239 KB, uploaded 27 December 2017]   |


A monthly mean land and snow Bidirectional Reflectance Distribution Function (BRDF) atlas for visible and near infrared parts of the spectrum has been developed for Radiative Transfer for Television Infrared Observation Satellite (TIROS) Operational Vertical sounder (TOVS) (RTTOV). The atlas follows the methodology of the RTTOV University of Wisconsin infrared land surface emissivity (UWIREMIS) atlas, i.e., it combines satellite retrievals and a principal component analysis on a dataset of hyper-spectral surface hemispherical reflectance or albedo. The current version of the BRDF atlas is based on the Collection 5 of the Moderate Resolution Imaging (MODIS) MCD43C1 Climate Modeling Grid BRDF kernel-driven model parameters product. The MCD43C1 product combines both Terra and Aqua satellites over a 16-day period of acquisition and is provided globally at 0.05° of spatial resolution. We have improved the RTTOV land surface BRDF atlas by using the last Collection 6 of MODIS product MCD43C1. We firstly found that the MODIS C6 product improved the quality index of the BRDF model as compared with that of C5. When compared with clear-sky top of atmosphere (TOA) reflectance of Spinning Enhanced Visible and InfraRed Imagers (SEVIRI) solar channels over snow-free land surfaces, we showed that the reflectances are simulated with an absolute accuracy of 3% to 5% (i.e., 0.03–0.05 in reflectance units) when either the satellite zenith angle or the solar zenith angle is below 70°, regardless of the MODIS collection. For snow-covered surfaces, we showed that the comparison with in situ snow spectral albedo is improved with C6 with an underestimation of 0.05 in the near infrared. View Full-Text

Graphical abstract

This is an open access article distributed under the Creative Commons Attribution License which permits unrestricted use, distribution, and reproduction in any medium, provided the original work is properly cited (CC BY 4.0).
