Recent Advances on the Application of Layered Double Hydroxides in Concrete—A Review
Abstract
:1. Introduction
2. Chloride Induced Steel Corrosion in Concrete
3. Chloride Binding in Concrete
4. Layered Double Hydroxides
4.1. Preparation Methods
4.2. Ion Exchange Property Of LDH
5. ompatibility of Ldh with Cementitious Environments
5.1. Effect on Mechanical Properties
5.2. Effect of LDH Dosage on Microstructure
5.3. Effect ON Hydration
6. Ion Exchange Property and Self Protection of Concrete
6.1. Chloride Entrapment and Corrosion Performance
6.2. Role of Ldh in Carbonation Control
7. Conclusions
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
Abbreviations
LDH | Layered Double Hydroxide |
CSE | Copper sulphate electrode |
pAB | P-aminobenzoate |
CA | tricalcium aluminate |
CAF | tetracalcium alumino-ferrite |
AFm | aluminate monosulphate |
CSH | calcium silicate hydrate |
References
