Battery-Supercapacitor Energy Storage Systems for Electrical Vehicles: A Review
Abstract
:1. Introduction
2. Batteries for Electrified Vehicles
2.1. Lead-Acid Batteries
2.2. Nickel-Based Batteries
2.3. Lithium Batteries
3. Supercapacitors for Electrified Vehicles
3.1. Electric Double-Layer Capacitors
3.2. Pseudocapacitors
3.3. Hybrid Capacitors
4. Hybrid Energy Storage Systems
4.1. Battery–SC HESS Topologies
4.2. Energy Management
5. Conclusions
Author Contributions
Funding
Conflicts of Interest
References
