Synovial Sarcoma: A Clinical Review

Department of Surgery, Division of Orthopaedic Surgery, McMaster University, Hamilton, ON L8V 1C3, Canada
Department of Pathology and Molecular Medicine, McMaster University, Hamilton, ON L8S 4L8, Canada
Department of Radiology, McMaster University, Hamilton, ON L8V 1C3, Canada
Author to whom correspondence should be addressed.
Curr. Oncol. 2021, 28(3), 1909-1920;
Received: 23 April 2021 / Revised: 16 May 2021 / Accepted: 17 May 2021 / Published: 19 May 2021
(This article belongs to the Section Surgical Oncology)


Synovial sarcomas (SS) represent a unique subset of soft tissue sarcomas (STS) and account for 5–10% of all STS. Synovial sarcoma differs from other STS by the relatively young age at diagnosis and clinical presentation. Synovial sarcomas have unique genomic characteristics and are driven by a pathognomonic t(X;18) chromosomal translocation and subsequent formation of the SS18:SSX fusion oncogenes. Similar to other STS, diagnosis can be obtained from a combination of history, physical examination, magnetic resonance imaging, biopsy and subsequent pathology, immunohistochemistry and molecular analysis. Increasing size, age and tumor grade have been demonstrated to be negative predictive factors for both local disease recurrence and metastasis. Wide surgical excision remains the standard of care for definitive treatment with adjuvant radiation utilized for larger and deeper lesions. There remains controversy surrounding the role of chemotherapy in the treatment of SS and there appears to be survival benefit in certain populations. As the understanding of the molecular and immunologic characteristics of SS evolve, several potential systematic therapies have been proposed.

1. Introduction

Synovial sarcoma is a relatively rare malignancy representing a soft tissue sarcoma (STS) of uncertain differentiation. It accounts for 5–10% of all STS [1,2,3]. The age-adjusted incidence is 0.81/1,000,000 in children and 1.42/1,000,000 in adults with approximately 1000 patients diagnosed with synovial sarcoma in the United States each year [4]. Synovial sarcoma is unique from other STS as it presents at a younger mean age of onset and commonly occurs in adolescents and young adults (mean age of 39 years at diagnosis) and affects both sexes equally [5]. Synovial sarcoma is the most common non-rhabdomyosarcoma STS in children, representing 30% of STS diagnosed in childhood [4,6].

2. Clinical Presentation

2.1. Location

Although many synovial sarcomas originate near articular structures, the name synovial sarcoma is a misnomer in that these lesions do not originate from intra-articular synovium, but from primitive mesenchymal cells [7]. Synovial sarcomas most commonly present as soft tissue masses but cases of primary synovial sarcoma of bone have been reported [8]. These lesions can occur anywhere in the body, with the majority arising in the extremities, particularly in the lower extremity in the anatomic structures adjacent to the knee joint [4,9]. Synovial sarcomas are considered the most common STS of the foot [6,10,11].

2.2. Signs and Symptoms

Synovial sarcomas often do not present with the typical STS presentation of a large and quickly growing painless mass [9]. Instead, the majority of synovial sarcomas are slow growing and the mean duration of symptoms before diagnosis is approximately 2 years [12]. In comparison to other STS, the duration of symptoms are long and patients may have pain or joint contractures that precede swelling [13]. Only half of patients have clinical findings consistent with STS according to the National Institute for Health and Care Excellence (NICE) guidelines [12,13]. Given the insidious onset, younger age at presentation and atypical presenting symptoms, these patients may be initially clinically misdiagnosed with benign processes including myositis, synovitis, bursitis or tendonitis.

3. Imaging

3.1. Plain Radiographs

Plain radiographs are not required for diagnosis but are typically performed as part of the initial workup and can identify adjacent bony remodeling, bone invasion or calcification of the soft tissue mass (Figure 1) [14,15,16]. Typically, synovial sarcoma presents as a well-defined or lobulated soft tissue mass on plain radiographs. Punctate calcifications, particularly around the periphery of the lesion, are visualized in one third of patients [17]. Occasionally, more extensive calcification can be visualized and can mimic bone forming tumors including osteosarcoma and myositis ossificans [17].

3.2. Cross-Sectional Imaging

Similar to other STS, magnetic resonance imaging (MRI) with and without contrast is the gold standard for diagnostic imaging for synovial sarcoma (Figure 2) [17]. MRI defines the local extent of the soft tissue mass and surrounding edema and provides excellent visualization of the mass with respect to the surrounding anatomy, which is critical for preoperative planning. The utilization of gadolinium contrast can differentiate between hemorrhagic or necrotic areas and areas of solid viable tumor. As with most STS, synovial sarcomas are typically heterogenous with low intensity on T1 and high intensity on T2-weighted images with post-gadolinium enhancement [17].
Although synovial sarcomas generally present as a non-specific heterogenous mass, there are some unique features, which can aid in differentiation from other STS. Synovial sarcomas predominately present as well-defined, heterogeneously enhancing solid tumors that are multilobulated in nature [17]. A triple signal intensity demonstrating areas of hyperintensity, isointensity and hypointensity indicating the mix of cystic and hemorrhagic areas, cellular elements and fibrotic areas can be characteristic [17]. Smaller tumors, particularly those smaller than 5 cm in diameter, often show homogeneous enhancement which can be mistaken for a benign process [18]. Several findings on MRI have been found to be predictive of high-grade lesions including the absence of calcifications and presence of hemorrhage and the triple signal intensity [19].
Computed tomography (CT) with contrast can be utilized when an MRI is contraindicated or unavailable. Synovial sarcoma appears hypointense compared to muscle with heterogeneity in larger lesions [20]. CT allows for better visualization of soft-tissue calcifications and local bone reaction [17].

4. Diagnosis and Staging

4.1. Biopsy

A biopsy and pathologic assessment are required to differentiate synovial sarcoma from other STS subtypes and define the tumor grade. As with all STS, a biopsy should be performed prior to definitive surgery to avoid inadequate resection and misdiagnosis [21]. Options for biopsy include incisional biopsies, core needle biopsies and fine needle aspirations (FNA).
Historically, open incisional biopsies have been considered the gold standard for soft tissue lesions as they provide larger volumes of tissue. When compared to CNB and FNA, IB tend to have higher diagnostic accuracy but this comes with a higher rates of complications when compared to percutaneous techniques [22]. Core needle biopsies retrieve more tissue than FNA and have higher diagnostic accuracy [23]. Fine needle aspirates are rarely used in STS due to the small quantity of sample material obtained and a limited ability to assess lesional architecture [22]. Advances in diagnostic imaging has allowed for image guided percutaneous biopsies which has improved the diagnostic accuracy of these techniques [24]. Given the lower morbidity and relatively high diagnostic accuracy of CNB, image guided CNB are the preferred method of biopsy, particularly for deeper tumors. When open biopsies are performed, the biopsy principles must be observed to reduce biopsy-related complications [25].

4.2. Staging

Staging investigations are imperative and allow for a better understanding of disease prognosis and risk of recurrence or metastases. The tumor stage also helps to formulate a treatment plan by a multidisciplinary sarcoma team. Staging of synovial sarcoma involves cross-sectional imaging of the affected extremity, systematic staging with a chest CT, and pathologic assessment. The two most commonly utilized staging systems are the American Joint Committee on Cancer (AJCC) system and the Enneking staging system [26,27]. The Enneking staging system has remained largely unchanged since its introduction in 1980 while the AJCC system has evolved significantly and is currently on its Eighth edition. The Enneking staging system relies on tumor grade, local extent of disease and presence of metastases. The AJCC staging system is based on anatomical site of primary tumor and tumor size (pT) tumor grade, nodal involvement (N), and presence of metastases (M) [27].
Synovial sarcomas are malignant and metastasize, most commonly to the lungs with up to 13% of patients having distant metastases at the time of diagnosis [5]. Historically, it was thought that synovial sarcoma had a predilection for metastases to lymph nodes, necessitating the need for further advanced imaging and possible sentinel node biopsy [28]. However, these findings were based on small case series and more recent Surveillance, Epidemiology and End Results (SEER) database findings suggest that the rates of lymph node metastases are in line with other STS and do not require additional workup beyond thorough physical examination [29].

5. Diagnostic and Molecular Pathology

5.1. Pathology

The gross pathology appearance of synovial sarcoma is usually tan or grey and may be multinodular or multicystic [7]. Most synovial sarcomas are 3–10 cm in diameter. Smaller lesions (<1 cm) can occur in hands and feet [3,30]. Histologically, synovial sarcoma is a monomorphic spindle cell sarcoma with variable epithelial differentiation (Figure 3) [3]. It presents as one of three variants: monophasic, biphasic or poorly differentiated. In the monophasic variant, the tissue is comprised entirely of spindle-cells whereas in biphasic synovial sarcoma, there are epithelial and spindle-cell components present [7]. In one third of synovial sarcomas, areas of calcifications and/or ossification can be found. In both monophasic and biphasic variants, there may be poorly differentiated areas with increased cellularity, greater nuclear atypia and high mitotic activity (6 mitoses/mm2 >10 mitoses per 1.7 mm2) [3]. Occasionally, the entire tumor shows poorly differentiated morphology. On immunohistochemistry, diffuse expression of bcl-2 is typically seen. In 60% of cases, these tumours stain positive for CD99 [3]. Immunohistochemistry also demonstrates strong and diffuse nuclear staining for the transcriptional corepressor TLE1 found in the large majority of synovial sarcomas [3]. NY-ESO-1 is also expressed strongly in most synovial sarcomas and can help differentiate it from other spindle cell neoplasms [31].

5.2. Molecular Pathology

Synovial sarcoma is characterized by a pathognomonic translocation t(X:18) which is present in >95% of cases (Figure 4) [32]. This translocation leads to the expression of different SS18:SSX oncogenic fusion proteins, which drive sarcomagenesis. Subtypes include SS18:SSX1 and SS18:SSX2 and less commonly SS18:SSX4 [33]. Both fluorescence in situ hybridization (FISH) and reverse transcription polymerase chain reaction (RT-PCR) testing have been validated in the diagnosis of this translocation [34]. Almost all SS18-SSX2 synovial sarcomas show monophasic morphology and are significantly more common in women. Rare cases are associated with t(X;20) and SS18L1-SSX1 fusion transcript [3].

6. Treatment

As with all sarcomas, the treatment plan for synovial sarcoma is individualized to each patient. Both patient and tumor variables are taken into account in a multidisciplinary setting to determine the ideal treatment strategy for each patient.

6.1. Surgical Management

The mainstay of treatment for synovial sarcoma remains surgical excision with negative margins with the addition of radiotherapy and/or chemotherapy based on patient and tumour characteristics [21]. Historically, patients were often treated with amputation but advances in adjuvant therapy and cross-sectional imaging have allowed the majority of patients to be treated with limb-salvage surgery [35].
The goal of limb-salvage surgery in synovial sarcoma is to achieve oncologic control of the tumour while providing the patient with a functional limb postoperatively. Negative surgical margins are of upmost importance as they predict both local recurrence and overall survival [36,37,38]. While no specific guidelines exist regarding ideal negative margins in synovial sarcoma, surgical management is similar to that of other STS. For superficial tumors or small (<5 cm) deep tumors not intimately associated with critical structures, a wide excision with negative margins (1–2 cm) alone could be considered sufficient [39]. In tumours that are closely associated with neurovascular structures or bone, the epineurium, adventitia or periosteum is utilized as the margin to allow for a functional limb postoperatively [38,40]. In these cases, very close or microscopically positive margins may occur and radiotherapy is essential to decrease local recurrence risk [41,42]. Carefully planned microscopically positive margins on a fixed structure (bone, nerve, vessel) have been shown to not increase the risk for local recurrence in setting of neoadjuvant radiotherapy [42]. Given the heterogeneity and lack of standardization in the literature, recommendations regarding margin management must be taken into context of the individual patient. Both tumor and anatomic factors should be taken into consideration when determining acceptable surgical margins [43].
Due to its atypical presentation (slow-growing, painful mass), synovial sarcomas have a high rate of presentation following an unplanned excision, with up to 50% of patients presenting after unplanned excision [12,44]. Unplanned excisions of synovial sarcomas result in high rates of residual disease, particularly for larger and deeper tumors and increased risk for local recurrence even after re-excision [44,45]. In the case of referral following unplanned excision, patients should be re-staged, and the original histology reviewed at a sarcoma referral center. Tumor bed excision should be performed in patients with residual disease with the goal of complete tumor resection and negative margins [46]. Typically, these resections are extensive in nature given that areas of potential contamination must be removed, with may necessitate reconstructive procedures [45]. There is a paucity of data to guide the utilization of radiotherapy in this population; however, radiotherapy is recommended as it would be in a primary presentation [46].
In select cases, limb-salvage techniques are not recommended and primary amputation may be required [35]. Amputation is considered in patients with tumour location that necessitates excision of vital structures which would result in poor limb function [35]. Patients who present following an unplanned excision may require amputation if there is extensive contamination of vital structures or major joints [35]. Finally, older patients or those with extensive medical comorbidities may not be able to tolerate a major operation and amputation can be considered [35].

6.2. Radiation Therapy

Neoadjuvant or adjuvant radiation therapy is recommended for larger tumors (>5 cm), or in any case where a close margin may be required to preserve a major neurovascular structure or bone [21]. In large registry database studies, radiotherapy has been shown to improve local control and may have overall survival benefit in patients with synovial sarcoma [47,48,49]. Radiotherapy can be administered pre or postoperatively with differing protocols. Preoperative radiation is associated with higher wound complication rates whereas postoperative radiation can case fibrosis and joint stiffness which may lead to worse long term functional outcomes [50]. Regardless of timing, intensity-modulated radiation therapy (IMRT) is becoming the preferred method of radiation delivery in patients with STS [21,51]. Intensity-modulated radiation therapy allows for a higher dose of radiation to more closely contour the tumor, which reduces the volume of radiation to the surrounding normal tissues. The utilization of preoperative IMRT for STS has been shown to reduce wound complications and need for reconstructive soft-tissue flaps [52]. Radiation therapy may be considered in isolation in patients with multiple medical comorbidities or patients with metastatic disease where the risks of surgery outweigh the potential benefits [53].

6.3. Systemic Therapies

Unlike the majority of STS, synovial sarcoma appears to be more chemosensitive, although there is still controversy surrounding which subgroups of patients benefit from systemic therapy [54]. In general, chemotherapy is reserved for patients with high-risk tumors or advanced disease and is thought to be more effective in younger patients [55,56].
In children and adolescents with intermediate or high-risk tumours (i.e., >5 cm, nodal involvement, positive margins), adjuvant or neoadjuvant chemotherapy is generally undertaken with the most common agents being ifosfamide and doxorubicin. In the absence of available RCTs, prospective multicentred cohort studies have demonstrated adequate response to chemotherapy [57]. Recent data has demonstrated that pediatric or adolescent patients with low risk tumors (Grade 2 or Grade 3 < 5 cm) can be successfully treated with surgical intervention without systemic therapy [39].
The role of chemotherapy in adult patients with synovial sarcoma is less clear. Eilber et al. (2007) demonstrated that chemotherapy improved distant relapse-free survival in patients with high-risk synovial sarcoma [54]. Their group also published a synovial sarcoma specific nomogram that supported survival benefit of ifosfamide-based chemotherapy for certain adult patient populations [55]. Similarly, pooled data from 15 trials on advanced STS demonstrated significantly better response to chemotherapy and survival rates when compared to other STS [56]. Contrary to this, the French Sarcoma Group recently demonstrated no overall survival benefit with neoadjuvant or adjuvant chemotherapy in adult patients with synovial sarcoma [58]. However, this study included patients with low-risk tumor characteristics in which chemotherapy is unlikely to be of benefit.
Chemotherapy is also considered in metastatic or unresectable disease [56,59]. In general, anthracycline-based chemotherapy is first line for advanced STS and the addition of ifosfamide is dependent on the subtype of STS. Ifosfamide has well documented efficacy in synovial sarcoma in the palliative setting and should be considered in patients who undergo chemotherapy if the toxicities can be tolerated [59,60]. Spurrell et al. demonstrated median survival of 22 months in patients with advanced disease treated with a combination of doxorubicin and ifosfamide which was superior to either agent given in isolation [59].

6.4. Novel Agents

There has been interest in the development of targeted medical therapies in the treatment of synovial sarcoma [61]. New agents including receptor tyrosine kinase inhibitors, epigenetic modifiers and immunotherapies have been investigated in clinical trials. Thus far, only pazopanib, a receptor tyrosine kinase inhibitor is approved for clinical use. Pazopanib has been investigated in patients with advanced disease and has demonstrated improved progression free survival in a Phase III trial [59,62]. There has been recent advances in cell-based therapies targeting the cancer testis antigen, NY-ESO-1. Early work examining the utility of adoptive T-cell therapy with autologous T cells that have been engineered to expressive NY-ESO-1, have been promising in patients with metastatic disease [63]. However, although several larger agents have demonstrated preclinical success, clinical trials are needed to determine the role of these novel agents in the treatment of synovial sarcoma.

7. Prognosis

The current literature suggests the five-year survival rates ranges from 59–75% [4,5,9,62,64]. There has been a trend for improved survival over time with early cohorts from the 1960s quoting a 25–51% five-year survival rate. Local and metastatic relapse of soft-tissue sarcomas generally occur in the first two years following treatment and thus surveillance and follow-up is most intensive in this period [65]. However, synovial sarcoma is unique in this regard in that it tends to recur much later. Krieg et al. (2011) demonstrated that local recurrence occurred after a mean of 3.6 years (range 0.5–15 years) and metastases occurred at a mean of 5.7 years (range 0.5–16.3 years) [66].
There are several well documented key prognostic factors including tumor size, grade and anatomical location, patient age at diagnosis, negative surgical margins and adjuvant radiotherapy [38,55,64,67,68,69]. Osseous or neurovascular invasion, adult age, large tumour size and unplanned excision have been linked to worse prognosis [64,67,68,69,70]. The role of the subtype of oncogene protein is conflicting and does not appear to have a definite impact on outcomes [32,71,72,73]. Recent data suggests that histologic subtype appears to be prognostic, with the biphasic subtype demonstrating the highest survival rates at both five and ten years [73]. Synovial sarcomas with >20% poorly differentiated areas show more aggressive behaviour. The best outcomes are seen with tumors with histologic features <6 mitoses/mm2 and no necrosis [3,74].
Similar to other STS, tumor size and grade has repeatedly been shown to have prognostic value in patients with synovial sarcoma [48,54,67]. In a cohort of 1189 patients, Naing et al. (2014) demonstrated that size predicted worse overall survival [48]. Tumor location has been also been demonstrated to be of predictive value, with non-extremity based synovial sarcomas tending to have worse overall survival [5,75]. However, this may be in part due to the lack of early symptoms and later stage of presentation.
Although synovial sarcoma has a similar clinical presentation in children and adults, there is a growing evidence that they have different outcomes, with children having significantly better survival rates [4,9,39]. Utilizing registry data, Sultan et al. (2009) demonstrated the five-year survival rate for children and adolescents to be 83% compared to 62% in adults [4]. Similarly, Smolle et al. (2019) demonstrated an 89% five-year cancer specific survival rate in children compared to 75% in adults [9]. Vlenterie et al. (2015) demonstrated a clear stepwise reduction in survival with age, regardless of tumor site, size and treatment [68].

8. Conclusions

Synovial sarcomas (SS) represent a unique subset of STS and account for 5–10% of all STS. Synovial sarcoma differs from other STS by the relatively young age at diagnosis, anatomic location (peri-articular) and clinical presentation (slow-growing, painful lesions). Given this unique presentation, it is important for orthopaedic surgeons to recognize synovial sarcoma and avoid inappropriate interventions. Synovial sarcomas have unique genomic characteristics and are driven by a pathognomonic t(X;18) chromosomal translocation and subsequent formation of the SS18:SSX fusion oncogenes. Surgical excision remains the mainstay of treatment with radiation therapy utilized in high-risk tumors. Chemotherapy appears to have benefit in high-risk tumors in younger patients but there remains conflicting data in the adult population. Synovial sarcoma requires longer follow-up due to its risk of late recurrence.

Author Contributions

Conceptualization, A.M.G., D.W. and M.G.; investigation, A.M.G., S.M., S.P., N.P.; resources, S.M., S.P., N.P.; data curation, A.M.G.; writing—original draft preparation, A.M.G.; writing—review and editing, A.M.G., S.M., S.P., N.P., M.G., D.W.; supervision, M.G. All authors have read and agreed to the published version of the manuscript.


No funding was received in the preparation of this manuscript.

Conflicts of Interest

One author (M.G.) declares personal fees from Wright Medical, personal fees from Amgen, grants from the Canadian Institutes of Health Research, grants from the Canadian Cancer Society, grants from Hamilton Academic Health Sciences, outside the submitted work. All other authors have no conflicts to declare.


  1. Toro, J.R.; Travis, L.B.; Wu, H.J.; Zhu, K.; Fletcher, C.D.M.; Devesa, S.S. Incidence patterns of soft tissue sarcomas, regardless of primary site, in the surveillance, epidemiology and end results program, 1978–2001: An analysis of 26,758 cases. Int. J. Cancer 2006, 119, 2922–2930. [Google Scholar] [CrossRef] [PubMed]
  2. Mastrangelo, G.; Coindre, J.-M.; Ducimetière, F.; Tos, A.P.D.; Fadda, E.; Blay, J.-Y.; Buja, A.; Fedeli, U.; Cegolon, L.; Frasson, A.; et al. Incidence of soft tissue sarcoma and beyond. Cancer 2012, 118, 5339–5348. [Google Scholar] [CrossRef]
  3. WHO. Classification of Tumours Editorial. In Soft Tissue and Bone Tumours, 5th ed.; IARC Press: Lyon, France, 2020; ISBN 978-92-832-4502-5. [Google Scholar]
  4. Sultan, I.; Rodriguez-Galindo, C.; Saab, R.; Yasir, S.; Casanova, M.; Ferrari, A. Comparing children and adults with synovial sarcoma in the surveillance, epidemiology, and end results program, 1983 to 2005. Cancer 2009, 115, 3537–3547. [Google Scholar] [CrossRef]
  5. Aytekin, M.N.; Öztürk, R.; Amer, K.; Yapar, A. Epidemiology, incidence, and survival of synovial sarcoma subtypes: SEER database analysis. J. Orthop. Surg. 2020, 28, 2309499020936009. [Google Scholar] [CrossRef]
  6. McGrory, J.E.; Pritchard, D.J.; Arndt, C.A.; Nascimento, A.G.; Remstein, E.D.; Rowland, C.M. Nonrhabdomyosarcoma soft tissue sarcomas in children: The mayo clinic experience. Clin. Orthop. Relat. Res. 2000, 374, 247–258. [Google Scholar] [CrossRef] [PubMed]
  7. Jo, V.Y.; Fletcher, C.D.M. WHO Classification of soft tissue tumours: An update based on the 2013 (4th) edition. Pathology 2014, 46, 95–104. [Google Scholar] [CrossRef]
  8. Caracciolo, J.T.; Henderson-Jackson, E.; Binitie, O. Synovial sarcoma of bone: Sarcoma typically of soft Tissues presenting as a primary bone tumor. Radiol. Case Rep. 2018, 14, 204–207. [Google Scholar] [CrossRef] [PubMed]
  9. Smolle, M.A.; Parry, M.; Jeys, L.; Abudu, S.; Grimer, R. Synovial sarcoma: Do children do better? Eur. J. Surg. Oncol. 2019, 45, 254–260. [Google Scholar] [CrossRef] [PubMed]
  10. Deshmukh, R.; Mankin, H.J.; Singer, S. Synovial sarcoma: The importance of size and location for survival. Clin. Orthop. Relat. Res. 2004, 419, 155–161. [Google Scholar] [CrossRef]
  11. Chaparro, E.C.; Rodriguez, A.M.C.; Soriano, E.L.; González, L.E.; Ollero, A.R.; García, J.A. Synovial Sarcoma: Imaging Findings and Prognostic Features. Available online: (accessed on 13 December 2020).
  12. Chotel, F.; Unnithan, A.; Chandrasekar, C.R.; Parot, R.; Jeys, L.; Grimer, R.J. Variability in the presentation of synovial sarcoma in children. J. Bone Jt. Surg. Br. Vol. 2008, 90, 1090–1096. [Google Scholar] [CrossRef] [PubMed]
  13. Silva, M.V.C.D.; Barrett, A.; Reid, R. Premonitory Pain Preceding Swelling: A Distinctive Clinical Presentation of Synovial Sarcoma Which May Prompt Early Detection. Available online: (accessed on 13 December 2020).
  14. Bakri, A.; Shinagare, A.B.; Krajewski, K.M.; Howard, S.A.; Jagannathan, J.P.; Hornick, J.L.; Ramaiya, N.H. Synovial sarcoma: Imaging features of common and uncommon primary sites, metastatic patterns, and treatment response. Am. J. Roentgenol. 2012, 199, W208–W215. [Google Scholar] [CrossRef] [PubMed]
  15. Bixby, S.D.; Hettmer, S.; Taylor, G.A.; Voss, S.D. Synovial sarcoma in children: Imaging features and common benign mimics. Am. J. Roentgenol. 2010, 195, 1026–1032. [Google Scholar] [CrossRef] [PubMed]
  16. Kao, S.C. Overview of the clinical and imaging features of the most common non-rhabdomyosarcoma soft-tissue sarcomas. Pediatr. Radiol. 2019, 49, 1524–1533. [Google Scholar] [CrossRef] [PubMed]
  17. O’Sullivan, P.J.; Harris, A.C.; Munk, P.L. Radiological features of synovial cell sarcoma. BJR 2008, 81, 346–356. [Google Scholar] [CrossRef] [PubMed]
  18. Liang, C.; Mao, H.; Tan, J.; Ji, Y.; Sun, F.; Dou, W.; Wang, H.; Wang, H.; Gao, J. Synovial sarcoma: Magnetic resonance and computed tomography imaging features and differential diagnostic considerations. Oncol. Lett. 2015, 9, 661–666. [Google Scholar] [CrossRef][Green Version]
  19. Tateishi, U.; Hasegawa, T.; Beppu, Y.; Satake, M.; Moriyama, N. Synovial sarcoma of the soft tissues: Prognostic significance of imaging features. J. Comput. Assist. Tomogr. 2004, 28, 140–148. [Google Scholar] [CrossRef]
  20. Baheti, A.D.; Tirumani, S.H.; Sewatkar, R.; Shinagare, A.B.; Hornick, J.L.; Ramaiya, N.H.; Jagannathan, J.P. Imaging features of primary and metastatic extremity synovial sarcoma: A single institute experience of 78 patients. BJR 2015, 88, 20140608. [Google Scholar] [CrossRef][Green Version]
  21. Von Mehren, M.; Randall, R.L.; Benjamin, R.S.; Boles, S.; Bui, M.M.; Conrad, E.U.; Ganjoo, K.N.; George, S.; Gonzalez, R.J.; Heslin, M.J.; et al. Soft tissue sarcoma, version 2.2016, NCCN clinical practice guidelines in oncology. J. Natl. Compr. Cancer Netw. 2016, 14, 758–786. [Google Scholar] [CrossRef][Green Version]
  22. Kasraeian, S.; Allison, D.C.; Ahlmann, E.R.; Fedenko, A.N.; Menendez, L.R. A comparison of fine-needle aspiration, core biopsy, and surgical biopsy in the diagnosis of extremity soft tissue masses. Clin. Orthop. Relat. Res. 2010, 468, 2992–3002. [Google Scholar] [CrossRef][Green Version]
  23. Yang, Y.J.; Damron, T.A. Comparison of needle core biopsy and fine-needle aspiration for diagnostic accuracy in musculoskeletal lesions. Arch. Pathol. Lab. Med. 2004, 128, 759–764. [Google Scholar] [CrossRef]
  24. Narvani, A.A.; Tsiridis, E.; Saifuddin, A.; Briggs, T.; Cannon, S. Does image guidance improve accuracy of core needle biopsy in diagnosis of soft tissue tumours? Acta Orthop. Belg. 2009, 75, 239. [Google Scholar]
  25. Mankin, H.J.; Mankin, C.J.; Simon, M.A. The hazards of the biopsy, revisited. For the members of the musculoskeletal tumor society. JBJS 1996, 78, 656–663. [Google Scholar] [CrossRef]
  26. Enneking, W.F. A system of staging musculoskeletal neoplasms. Instr. Course Lect. 1988, 37, 3. [Google Scholar] [CrossRef] [PubMed]
  27. Amin, M.B.; Edge, S.B. AJCC Cancer Staging Manual; Springer: Amsterdan, The Netherelands, 2017. [Google Scholar]
  28. Maduekwe, U.N.; Hornicek, F.J.; Springfield, D.S.; Raskin, K.A.; Harmon, D.C.; Choy, E.; Rosenberg, A.E.; Nielsen, G.P.; DeLaney, T.F.; Chen, Y.-L. Role of sentinel lymph node biopsy in the staging of synovial, epithelioid, and clear cell sarcomas. Ann. Surg. Oncol. 2009, 16, 1356. [Google Scholar] [CrossRef] [PubMed]
  29. Jacobs, A.J.; Morris, C.D.; Levin, A.S. Synovial sarcoma is not associated with a higher risk of lymph node metastasis compared with other soft tissue sarcomas. Clin. Orthop. Relat. Res. 2018, 476, 589–598. [Google Scholar] [CrossRef]
  30. Michal, M.; Fanburg-Smith, J.C.; Lasota, J.; Fetsch, J.F.; Lichy, J.; Miettinen, M. Minute synovial sarcomas of the hands and feet: A clinicopathologic study of 21 tumors less than 1 cm. Am. J. Surg. Pathol. 2006, 30, 721–726. [Google Scholar] [CrossRef] [PubMed]
  31. Lai, J.-P.; Robbins, P.F.; Raffeld, M.; Aung, P.P.; Tsokos, M.; Rosenberg, S.A.; Miettinen, M.M.; Lee, C.-C.R. NY-ESO-1 expression in synovial sarcoma and other mesenchymal tumors: Significance for NY-ESO-1-based targeted therapy and differential diagnosis. Mod. Pathol. 2012, 25, 854–858. [Google Scholar] [CrossRef]
  32. Stegmaier, S.; Leuschner, I.; Poremba, C.; Ladenstein, R.; Kazanowska, B.; Ljungman, G.; Scheer, M.; Blank, B.; Bielack, S.; Klingebiel, T.; et al. The prognostic impact of SYT-SSX fusion type and histological grade in pediatric patients with synovial sarcoma treated according to the CWS (cooperative weichteilsarkom studie) trials. Pediatric Blood Cancer 2017, 64, 89–95. [Google Scholar] [CrossRef]
  33. Santos, N.R.D.; Bruijn, D.R.H.D.; Van Kessel, A.G. Molecular mechanisms underlying human synovial sarcoma development. Genes Chromosomes Cancer 2001, 30, 1–14. [Google Scholar] [CrossRef]
  34. Amary, M.F.C.; Berisha, F.; Bernardi, F.D.C.; Herbert, A.; James, M.; Reis-Filho, J.S.; Fisher, C.; Nicholson, A.G.; Tirabosco, R.; Diss, T.C.; et al. Detection of SS18-SSX fusion transcripts in formalin-fixed paraffin-embedded neoplasms: Analysis of conventional RT-PCR, QRT-PCR and dual color FISH as diagnostic tools for synovial sarcoma. Mod. Pathol. 2007, 20, 482–496. [Google Scholar] [CrossRef]
  35. Ghert, M.A.; Abudu, A.; Driver, N.; Davis, A.M.; Griffin, A.M.; Pearce, D.; White, L.; O’Sullivan, B.; Catton, C.N.; Bell, R.S.; et al. The indications for and the prognostic significance of amputation as the primary surgical procedure for localized soft tissue sarcoma of the extremity. Ann. Surg. Oncol. 2005, 12, 10–17. [Google Scholar] [CrossRef]
  36. Biau, D.J.; Ferguson, P.C.; Chung, P.; Griffin, A.M.; Catton, C.N.; O’Sullivan, B.; Wunder, J.S. Local recurrence of localized soft tissue sarcoma: A new look at old predictors. Cancer 2012, 118, 5867–5877. [Google Scholar] [CrossRef]
  37. Bilgeri, A.; Klein, A.; Lindner, L.H.; Nachbichler, S.; Knösel, T.; Birkenmaier, C.; Jansson, V.; Baur-Melnyk, A.; Dürr, H.R. The effect of resection margin on local recurrence and survival in high grade soft tissue sarcoma of the extremities: How far is far enough? Cancers 2020, 12, 2560. [Google Scholar] [CrossRef] [PubMed]
  38. Guadagnolo, B.A.; Zagars, G.K.; Ballo, M.T.; Patel, S.R.; Lewis, V.O.; Pisters, P.W.T.; Benjamin, R.S.; Pollock, R.E. Long-term outcomes for synovial sarcoma treated with conservation surgery and radiotherapy. Int. J. Radiat. Oncol. Biol. Phys. 2007, 69, 1173–1180. [Google Scholar] [CrossRef] [PubMed]
  39. Ferrari, A.; Chi, Y.-Y.; Salvo, G.L.D.; Orbach, D.; Brennan, B.; Randall, R.L.; McCarville, M.B.; Black, J.O.; Alaggio, R.; Hawkins, D.S.; et al. Surgery alone is sufficient therapy for children and adolescents with low-risk synovial sarcoma: A joint analysis from the European paediatric soft tissue sarcoma study group and the children’s oncology group. Eur. J. Cancer 2017, 78, 1–6. [Google Scholar] [CrossRef] [PubMed]
  40. Kawaguchi, N.; Ahmed, A.R.; Matsumoto, S.; Manabe, J.; Matsushita, Y. The concept of curative margin in surgery for bone and soft tissue sarcoma. Clin. Orthop. Relat. Res. 2004, 419, 165–172. [Google Scholar] [CrossRef] [PubMed]
  41. Gundle, K.R.; Gupta, S.; Kafchinski, L.; Griffin, A.M.; Kandel, R.A.; Dickson, B.C.; Chung, P.W.; Catton, C.N.; O’Sullivan, B.; Ferguson, P.C.; et al. An analysis of tumor- and surgery-related factors that contribute to inadvertent positive margins following soft tissue sarcoma resection. Ann. Surg. Oncol. 2017, 24, 2137–2144. [Google Scholar] [CrossRef] [PubMed]
  42. O’Donnell, P.W.; Griffin, A.M.; Eward, W.C.; Sternheim, A.; Catton, C.N.; Chung, P.W.; O’Sullivan, B.; Ferguson, P.C.; Wunder, J.S. The effect of the setting of a positive surgical margin in soft tissue sarcoma. Cancer 2014, 120, 2866–2875. [Google Scholar] [CrossRef] [PubMed]
  43. Sambri, A.; Caldari, E.; Fiore, M.; Zucchini, R.; Giannini, C.; Pirini, M.G.; Spinnato, P.; Cappelli, A.; Donati, D.M.; Paolis, M.D. Margin assessment in soft tissue sarcomas: Review of the literature. Cancers 2021, 13, 1687. [Google Scholar] [CrossRef]
  44. Chandrasekar, C.R.; Wafa, H.; Grimer, R.J.; Carter, S.R.; Tillman, R.M.; Abudu, A. The effect of an unplanned excision of a soft-tissue sarcoma on prognosis. J. Bone Jt. Surg. Br. Vol. 2008, 90, 203–208. [Google Scholar] [CrossRef][Green Version]
  45. Potter, B.K.; Adams, S.C.; Pitcher, J.D.; Temple, H.T. Local recurrence of disease after unplanned excisions of high-grade soft tissue sarcomas. Clin. Orthop. Relat. Res. 2008, 466, 3093–3100. [Google Scholar] [CrossRef] [PubMed][Green Version]
  46. Pretell-Mazzini, J.; Barton, M.D.J.; Conway, S.A.; Temple, H.T. Unplanned excision of soft-tissue sarcomas: Current concepts for management and prognosis. JBJS 2015, 97, 597–603. [Google Scholar] [CrossRef]
  47. Gingrich, A.A.; Marrufo, A.S.; Liu, Y.; Li, C.-S.; Darrow, M.A.; Monjazeb, A.M.; Thorpe, S.W.; Canter, R.J. Radiotherapy is associated with improved survival in patients with synovial sarcoma undergoing surgery: A national cancer database analysis. J. Surg. Res. 2020, 255, 378–387. [Google Scholar] [CrossRef]
  48. Naing, K.W.; Monjazeb, A.M.; Li, C.-S.; Lee, L.-Y.; Yang, A.; Borys, D.; Canter, R.J. Perioperative radiotherapy is associated with improved survival among patients with synovial sarcoma: A SEER analysis. J. Surg. Oncol. 2015, 111, 158–164. [Google Scholar] [CrossRef] [PubMed][Green Version]
  49. Song, S.; Park, J.; Kim, H.J.; Kim, I.H.; Han, I.; Kim, H.-S.; Kim, S. Effects of adjuvant radiotherapy in patients with synovial sarcoma. Am. J. Clin. Oncol. 2017, 40, 306–311. [Google Scholar] [CrossRef] [PubMed]
  50. Davis, A.M.; O’Sullivan, B.; Turcotte, R.; Bell, R.; Catton, C.; Chabot, P.; Wunder, J.; Hammond, A.; Benk, V.; Kandel, R.; et al. Late radiation morbidity following randomization to preoperative versus postoperative radiotherapy in extremity soft tissue sarcoma. Radiother. Oncol. 2005, 75, 48–53. [Google Scholar] [CrossRef]
  51. Wang, J.; Song, Y.; Liu, X.; Jin, J.; Wang, W.; Yu, Z.; Liu, Y.; Li, N.; Fang, H.; Ren, H.; et al. Comparison of outcome and toxicity of postoperative intensity-modulated radiation therapy with two-dimensional radiotherapy in patients with soft tissue sarcoma of extremities and trunk. Cancer Med. 2019, 8, 902–909. [Google Scholar] [CrossRef][Green Version]
  52. O’Sullivan, B.; Griffin, A.M.; Dickie, C.I.; Sharpe, M.B.; Chung, P.W.M.; Catton, C.N.; Ferguson, P.C.; Wunder, J.S.; Deheshi, B.M.; White, L.M.; et al. Phase 2 study of preoperative image-guided intensity-modulated radiation therapy to reduce wound and combined modality morbidities in lower extremity soft tissue sarcoma. Cancer 2013, 119, 1878–1884. [Google Scholar] [CrossRef]
  53. Ramu, E.M.; Houdek, M.T.; Isaac, C.E.; Dickie, C.I.; Ferguson, P.C.; Wunder, J.S. Management of soft-tissue sarcomas; Treatment strategies, staging, and outcomes. Sicot-j 2017, 3, 20. [Google Scholar] [CrossRef][Green Version]
  54. Eilber, F.C.; Brennan, M.F.; Eilber, F.R.; Eckardt, J.J.; Grobmyer, S.R.; Riedel, E.; Forscher, C.; Maki, R.G.; Singer, S. Chemotherapy is associated with improved survival in adult patients with primary extremity synovial sarcoma. Ann. Surg. 2007, 246, 105–113. [Google Scholar] [CrossRef] [PubMed]
  55. Canter, R.J.; Qin, L.-X.; Maki, R.G.; Brennan, M.F.; Ladanyi, M.; Singer, S. A synovial sarcoma-specific preoperative nomogram supports a survival benefit to ifosfamide-based chemotherapy and improves risk stratification for patients. Clin. Cancer Res. 2008, 14, 8191–8197. [Google Scholar] [CrossRef] [PubMed][Green Version]
  56. Vlenterie, M.; Litière, S.; Rizzo, E.; Marréaud, S.; Judson, I.; Gelderblom, H.; Cesne, A.L.; Wardelmann, E.; Messiou, C.; Gronchi, A.; et al. Outcome of chemotherapy in advanced synovial sarcoma patients: Review of 15 clinical trials from the european organisation for research and treatment of cancer soft tissue and bone sarcoma group; Setting a new landmark for studies in this entity. Eur. J. Cancer 2016, 58, 62–72. [Google Scholar] [CrossRef] [PubMed]
  57. Ferrari, A.; Salvo, G.L.D.; Brennan, B.; Van Noesel, M.M.; Paoli, A.D.; Casanova, M.; Francotte, N.; Kelsey, A.; Alaggio, R.; Oberlin, O.; et al. Synovial sarcoma in children and adolescents: The european pediatric soft tissue sarcoma study group prospective trial (EpSSG NRSTS 2005). Ann. Oncol. 2015, 26, 567–572. [Google Scholar] [CrossRef]
  58. Italiano, A.; Penel, N.; Robin, Y.-M.; Bui, B.; Cesne, A.L.; Piperno-Neumann, S.; Tubiana-Hulin, M.; Bompas, E.; Chevreau, C.; Isambert, N.; et al. Neo/adjuvant chemotherapy does not improve outcome in resected primary synovial sarcoma: A study of the french sarcoma group. Ann. Oncol. 2009, 20, 425–430. [Google Scholar] [CrossRef] [PubMed]
  59. Spurrell, E.L.; Fisher, C.; Thomas, J.M.; Judson, I.R. Prognostic Factors in Advanced Synovial Sarcoma: An Analysis of 104 Patients Treated at the Royal Marsden Hospital. Ann. Oncol. 2005, 16, 437–444. [Google Scholar] [CrossRef]
  60. Sleijfer, S.; Ouali, M.; Van Glabbeke, M.; Krarup-Hansen, A.; Rodenhuis, S.; Cesne, A.L.; Hogendoorn, P.C.W.; Verweij, J.; Blay, J.-Y. Prognostic and predictive factors for outcome to first-line ifosfamide-containing chemotherapy for adult patients with advanced soft tissue sarcomas: An exploratory, retrospective analysis on large series from the European organization for research and treatment of cancer-soft tissue and bone sarcoma group (EORTC-STBSG). Eur. J. Cancer 2010, 46, 72–83. [Google Scholar] [CrossRef]
  61. Desar, I.M.; Fleuren, E.D.; Van der Graaf, W.T. Systemic treatment for adults with synovial sarcoma. Curr. Treat. Options Oncol. 2018, 19, 1–17. [Google Scholar] [CrossRef] [PubMed][Green Version]
  62. Trassard, M.; Le Doussal, V.; Hacène, K.; Terrier, P.; Ranchère, D.; Guillou, L.; Fiche, M.; Collin, F.; Vilain, M.-O.; Bertrand, G. Prognostic Factors in Localized Primary Synovial Sarcoma: A Multicenter Study of 128 Adult Patients. J. Clin. Oncol. 2001, 19, 525–534. [Google Scholar] [CrossRef]
  63. D’Angelo, S.P.; Melchiori, L.; Merchant, M.S.; Bernstein, D.; Glod, J.; Kaplan, R.; Grupp, S.; Tap, W.D.; Chagin, K.; Binder, G.K. Antitumor activity associated with prolonged persistence of adoptively transferred NY-ESO-1 C259T cells in synovial sarcoma. Cancer Discov. 2018, 8, 944–957. [Google Scholar] [CrossRef][Green Version]
  64. Lewis, J.J.; Antonescu, C.R.; Leung, D.H.; Blumberg, D.; Healey, J.H.; Woodruff, J.M.; Brennan, M.F. Synovial sarcoma: A multivariate analysis of prognostic factors in 112 patients with primary localized tumors of the extremity. J. Clin. Oncol. 2000, 18, 2087–2094. [Google Scholar] [CrossRef]
  65. Wilson, D.A.; Gazendam, A.; Visgauss, J.; Perrin, D.; Griffin, A.M.; Chung, P.W.; Catton, C.N.; Shultz, D.; Ferguson, P.C.; Wunder, J.S. Designing a rational follow-up schedule for patients with extremity soft tissue sarcoma. Ann. Surg. Oncol. 2020, 27, 1–9. [Google Scholar] [CrossRef]
  66. Krieg, A.H.; Hefti, F.; Speth, B.M.; Jundt, G.; Guillou, L.; Exner, U.G.; Von Hochstetter, A.R.; Cserhati, M.D.; Fuchs, B.; Mouhsine, E.; et al. Synovial sarcomas usually metastasize after >5 years: A multicenter retrospective analysis with minimum follow-up of 10 years for survivors. Ann. Oncol. 2011, 22, 458–467. [Google Scholar] [CrossRef] [PubMed]
  67. Ferrari, A.; Gronchi, A.; Casanova, M.; Meazza, C.; Gandola, L.; Collini, P.; Lozza, L.; Bertulli, R.; Olmi, P.; Casali, P.G. Synovial sarcoma: A retrospective analysis of 271 patients of all ages treated at a single institution. Cancer Interdiscip. Int. J. Am. Cancer Soc. 2004, 101, 627–634. [Google Scholar] [CrossRef] [PubMed]
  68. Vlenterie, M.; Ho, V.K.Y.; Kaal, S.E.J.; Vlenterie, R.; Haas, R.; Van der Graaf, W.T.A. Age as an independent prognostic factor for survival of localised synovial sarcoma patients. Br. J. Cancer 2015, 113, 1602–1606. [Google Scholar] [CrossRef][Green Version]
  69. Ferguson, P.C.; Griffin, A.M.; O’Sullivan, B.; Catton, C.N.; Davis, A.M.; Murji, A.; Bell, R.S.; Wunder, J.S. Bone invasion in extremity soft-tissue sarcoma: Impact on disease outcomes. Cancer 2006, 106, 2692–2700. [Google Scholar] [CrossRef]
  70. Singer, S.; Baldini, E.H.; Demetri, G.D.; Fletcher, J.A.; Corson, J.M. Synovial sarcoma: Prognostic significance of tumor size, margin of resection, and mitotic activity for survival. JCO 1996, 14, 1201–1208. [Google Scholar] [CrossRef]
  71. Takenaka, S.; Ueda, T.; Naka, N.; Araki, N.; Hashimoto, N.; Myoui, A.; Ozaki, T.; Nakayama, T.; Toguchida, J.; Tanaka, K. Prognostic implication of SYT-SSX fusion type in synovial sarcoma: A multi-institutional retrospective analysis in Japan. Oncol. Rep. 2008, 19, 467–476. [Google Scholar] [CrossRef][Green Version]
  72. Guillou, L.; Benhattar, J.; Bonichon, F.; Gallagher, G.; Terrier, P.; Stauffer, E.; De Saint, A.S.N.; Michels, J.-J.; Jundt, G.; Vince, D.R. Histologic grade, but not SYT-SSX fusion type, is an important prognostic factor in patients with synovial sarcoma: A multicenter, retrospective analysis. J. Clin. Oncol. 2004, 22, 4040–4050. [Google Scholar] [CrossRef]
  73. Xiong, L.; Chen, Z.; Zhou, Y.; Li, H.; Xiao, T. The survival and prognosis analysis of synovial sarcoma subtypes: A surveillance, epidemiology, and end results population-based analysis. Int. Orthop. 2020, 44, 2779–2786. [Google Scholar] [CrossRef]
  74. Van de Rijn, M.; Barr, F.G.; Xiong, Q.-B.; Hedges, M.; Shipley, J.; Fisher, C. Poorly differentiated synovial sarcoma: An analysis of clinical, pathologic, and molecular genetic features. Am. J. Surg. Pathol. 1999, 23, 106–112. [Google Scholar] [CrossRef]
  75. Ferrari, A.; Bisogno, G.; Alaggio, R.; Cecchetto, G.; Collini, P.; Rosolen, A.; Meazza, C.; Indolfi, P.; Garaventa, A.; De Sio, L. Synovial sarcoma of children and adolescents: The prognostic role of axial sites. Eur. J. Cancer 2008, 44, 1202–1209. [Google Scholar] [CrossRef] [PubMed]
Figure 1. AP (A) and lateral (B) radiographs of the right (R) knee and lower leg in a 31-year-old male demonstrate coarse calcifications within the soft tissues adjacent to the posteromedial tibial plateau, corresponding to a biopsy proven synovial sarcoma. No significant articular abnormality. Adjacent bony structures appear unremarkable.
Figure 1. AP (A) and lateral (B) radiographs of the right (R) knee and lower leg in a 31-year-old male demonstrate coarse calcifications within the soft tissues adjacent to the posteromedial tibial plateau, corresponding to a biopsy proven synovial sarcoma. No significant articular abnormality. Adjacent bony structures appear unremarkable.
Curroncol 28 00177 g001
Figure 2. Sagittal MR images in the same patient demonstrate a periarticular soft tissue mass situated posteromedial to the proximal tibia, in close relation to the pes anserine tendons. The mass demonstrates intermediate signal on T1 weighted images (A), and heterogeneously high signal on T2 weighted fat-saturated images (B). T1 weighted fat-saturated after gadolinium administration (C), demonstrates heterogeneously avid enhancement. Known areas of calcification are low signal on all sequences (arrow).
Figure 2. Sagittal MR images in the same patient demonstrate a periarticular soft tissue mass situated posteromedial to the proximal tibia, in close relation to the pes anserine tendons. The mass demonstrates intermediate signal on T1 weighted images (A), and heterogeneously high signal on T2 weighted fat-saturated images (B). T1 weighted fat-saturated after gadolinium administration (C), demonstrates heterogeneously avid enhancement. Known areas of calcification are low signal on all sequences (arrow).
Curroncol 28 00177 g002
Figure 3. (A) Microscopic images showing biphasic tumor composed of spindle cell (S) and epithelioid (E) component; H&E ×100 and (B) occasional calcifications (arrow); H&E ×200). (C) Microscopic image showing poorly differentiated morphology (H&E ×400). (D) Immunohistochemistry demonstrating diffuse and strong nuclear staining for the transcriptional corepressor TLE1 (×200).
Figure 3. (A) Microscopic images showing biphasic tumor composed of spindle cell (S) and epithelioid (E) component; H&E ×100 and (B) occasional calcifications (arrow); H&E ×200). (C) Microscopic image showing poorly differentiated morphology (H&E ×400). (D) Immunohistochemistry demonstrating diffuse and strong nuclear staining for the transcriptional corepressor TLE1 (×200).
Curroncol 28 00177 g003
Figure 4. Molecular study using fluorescence in situ hybridization (FISH) break apart probe confirmed a diagnosis of synovial sarcoma detecting the SS18 gene arrangement (split red and green signal) (×200).
Figure 4. Molecular study using fluorescence in situ hybridization (FISH) break apart probe confirmed a diagnosis of synovial sarcoma detecting the SS18 gene arrangement (split red and green signal) (×200).
Curroncol 28 00177 g004
