Improvement of Spatial Modeling of Cr, Pb, Cd, As and Ni in Soil Based on Portable X-ray Fluorescence (PXRF) and Geostatistics: A Case Study in East China
Abstract
:1. Introduction
2. Materials and Methods
2.1. Study Area and Soil Sampling
2.2. Samples Analyses
2.2.1. ICP-AES
2.2.2. PXRF
2.3. Pollution Assessment
2.4. Geostatistics Models
2.4.1. Ordinary Kriging (OK)
2.4.2. Co-Ordinary Kriging (COK)
2.4.3. Getis-Ord Index
2.4.4. Multi-Variables Indicator Kriging (MVIK)
- Define indicator codes for target variables:
- The MVIK is the weighted results of several univariate indicator krigings:
3. Results and Discussion
3.1. Summary of PXRF and ICP-AES Measurements
3.2. Assessment of Soil Heavy Metals Pollution Status
3.3. Spatial Modeling of Soil PTEs Based on Secondary Variables from Predicted Value of PXRF
3.3.1. Spatial Pattern of Soil Heavy Metals Content
3.3.2. Model Accuracy
3.3.3. Hotspots of Soil Heavy Metals Pollution
3.4. Multi-Heavy Metals Pollution Risk in Study Area
4. Conclusions
Supplementary Materials
Author Contributions
Funding
Acknowledgments
Conflicts of Interest
References
- Chen, S.C.; Liang, Z.Z.; Webster, R.; Zhang, G.L.; Zhou, Y.; Teng, H.F.; Hu, B.F.; Arrouays, D.; Shi, Z. A high-resolution map of soil pH in China made by hybrid modelling of sparse soil data and environmental covariates and its implications for pollution. Sci. Total Environ. 2019, 655, 273–283. [Google Scholar] [CrossRef] [PubMed]
- Marchant, B.P.; Saby, N.P.A.; Arrouays, D. A survey of topsoil arsenic and mercury concentrations across France. Chemosphere 2017, 181, 635–644. [Google Scholar] [CrossRef] [PubMed]
- Rambeau, C.M.C.; Baize, D.; Saby, N.P.A.; Matera, V.; Adatte, T.; Föllmi, K.B. High cadmium concentrations in Jurassic limestone as the cause for elevated cadmium levels in deriving soils: A case study in Lower Burgundy, France. Environ. Earth Sci. 2010, 61, 1573–1585. [Google Scholar] [CrossRef]
- Jia, X.L.; Hu, B.F.; Marchant, B.P.; Zhou, L.Q.; Shi, Z.; Zhu, Y. A methodological framework for identifying potential sources of soil heavy metal pollution based on machine learning: A case study in the Yangtze Delta, China. Environ. Pollut. 2019, 250, 601–609. [Google Scholar] [CrossRef] [PubMed]
- Zhou, Y.; Biswas, A.; Ma, Z.; Lu, Y.; Chen, Q.; Shi, Z. Revealing the scale-specific controls of soil organic matter at large scale in Northeast and North China Plain. Geoderma 2016, 271, 71–79. [Google Scholar] [CrossRef]
- Peng, J.; Biswas, A.; Jiang, Q.S.; Zhao, R.Y.; Hu, J.; Hu, B.F.; Shi, Z. Estimating soil salinity from remote sensing and terrain data in southern Xinjiang Province, China. Geoderma 2019, 337, 1309–1319. [Google Scholar] [CrossRef]
- Hu, B.F.; Jia, X.L.; Hu, J.; Xu, D.Y.; Xia, F.; Li, Y. Assessment of heavy metal pollution and health risks in the soil-plant-human system in the Yangtze River delta, China. Int. J. Environ. Res. Public Health 2017, 14, 1042. [Google Scholar] [CrossRef] [PubMed]
- Lacarce, E.; Saby, N.P.A.; Martin, M.P.; Ben, P.M.; Line, B.; Jeroen, M.; Claudy, J.; Antonio, B.; Dominique, A. Mapping soil Pb stocks and availability in mainland France combining regression trees with robust geostatistics. Geoderma 2012, 170, 359–368. [Google Scholar] [CrossRef]
- Lequy, E.; Saby, N.P.A.; Ilyin, I.; Bourin, A.; Sauvage, S.; Leblond, S. Spatial analysis of trace elements in a moss bio-monitoring data over France by accounting for source, protocol and environmental parameters. Sci. Total Environ. 2017, 590, 602–610. [Google Scholar] [CrossRef]
- Shao, S.; Hu, B.F.; Fu, Z.Y.; Wang, J.Y.; Lou, G.; Zhou, Y.; Jin, B.; Li, Y.; Shi, Z. Source Identification and Apportionment of Trace Elements in Soils in the Yangtze River Delta, China. Int. J. Environ. Res. Public Health 2018, 15, 1240. [Google Scholar] [CrossRef]
- Saby, N.P.A.; Thioulouse, J.; Jolivet, C.C.; Ratie, C.; Boulonne, L.; Bispo, A.; Arrouays, D. Multivariate analysis of the spatial patterns of 8 trace elements using the French soil monitoring network data. Sci. Total Environ. 2009, 407, 5644–5652. [Google Scholar] [CrossRef] [PubMed]
- Schneider, A.R.; Morvan, X.; Saby, N.P.A.; Cancès, B.; Ponthieu, M.; Gommeaux, M.; Marin, B. Multivariate spatial analyses of the distribution and origin of trace and major elements in soils surrounding a secondary lead smelter. Environ. Sci. Pollut. Res. 2016, 23, 15164–15174. [Google Scholar] [CrossRef] [PubMed]
- Chen, H.Y.; Teng, Y.G.; Lu, S.J.; Wang, Y.Y.; Wang, J.S. Contamination features and health risk of soil heavy metals in China. Sci. Total Environ. 2015, 512, 143–153. [Google Scholar] [CrossRef] [PubMed]
- Hu, B.F.; Wang, J.Y.; Jin, B.; Li, Y.; Shi, Z. Assessment of the potential health risks of heavy metals in soils in a coastal industrial region of the Yangtze River Delta. Environ. Sci. Pollut. Res. 2017, 24, 19816–19826. [Google Scholar] [CrossRef] [PubMed]
- NSPCIR; Ministry of Environmental Protection; Ministry of Land and Resources. The National Soil Pollution Condition Investigation Report. 2014. Available online: http://www.zhb.gov.cn/gkml/hbb/qt/201404/t20140417270670.htm (accessed on 17 April 2014).
- Zhao, Y.-F.; Shi, X.-Z.; Huang, B.; Yu, D.-S.; Wang, H.-J.; Sun, W.-X.; Oboern, I.; Blombck, K. Spatial distribution of heavy metals in agricultural soils of an industry-based peri-urban area in Wuxi, China. Pedosphere 2007, 17, 44–51. [Google Scholar] [CrossRef]
- Saby, N.P.A.; Arrouays, D.; Boulonne, L.; Pochot, C.J. Geostatistical assessment of Pb in soil around Paris, France. Sci. Total Environ. 2006, 367, 212–221. [Google Scholar] [CrossRef] [PubMed]
- Cao, S.; Lu, A.; Wang, J.; Huo, L. Modeling and mapping of cadmium in soils based on qualitative and quantitative auxiliary variables in a cadmium contaminated area. Sci. Total Environ. 2017, 580, 430–439. [Google Scholar] [CrossRef] [PubMed]
- Palanques, A.; Lopez, L.; Guillén, J.; Puig, P.; Masque, P. Decline of trace metal pollution in the bottom sediments of the Barcelona City continental shelf (NW Mediterranean). Sci. Total Environ. 2017, 579, 755–767. [Google Scholar] [CrossRef] [PubMed]
- Villanneau, E.J.; Saby, N.P.A.; Marchant, B.P.; Jolivet, C.C.; Boulnne, L.; Caria, G.; Barriuso, E.; Bispo, A.; Briand, O.; Arrouays, D. Which persistent organic pollutants can we map in soil using a large spacing systematic soil monitoring design? A case study in Northern France. Sci. Total Environ. 2011, 409, 3719–3731. [Google Scholar] [CrossRef] [PubMed]
- Ene, A.; Bosneaga, A.; Georgescu, L. Determination of heavy metals in soils using XRF technique. Rom. J. Phys. 2010, 55, 815–820. [Google Scholar]
- Sacristán, D.; Rossel, R.A.V.; Recatalá, L. Proximal sensing of Cu in soil and lettuce using portable X-ray fluorescence spectrometry. Geoderma 2016, 265, 6–11. [Google Scholar] [CrossRef]
- Wan, M.X.; Hu, W.Y.; Qu, M.K.; Tian, K.; Zhang, H.D.; Wang, Y.; Huang, B. Application of arc emission spectrometry and portable X-ray fluorescence spectrometry to rapid risk assessment of heavy metals in agricultural soils. Ecol. Indic. 2019, 101, 583–594. [Google Scholar] [CrossRef]
- Brent, R.N.; Wines, H.; Luther, J.; Irving, N.; Collins, J.; Drake, B. Validation of handheld X-ray fluorescence for in situ measurement of mercury in soils. J. Environ. Chem. Eng. 2017, 5, 768–776. [Google Scholar] [CrossRef]
- Hu, B.F.; Chen, S.C.; Hu, J.; Xia, F.; Xu, J.F.; Li, Y.; Shi, Z. Application of portable XRF and VNIR sensors for rapid assessment of soil heavy metal pollution. PLoS ONE 2017, 12, e0172438. [Google Scholar] [CrossRef] [PubMed]
- Goovaerts, P. Using elevation to aid the geostatistical mapping of rainfall erosivity. Catena 1999, 34, 227–242. [Google Scholar] [CrossRef]
- Goovaerts, P. Geostatistical approaches for incorporating elevation into the spatial interpolation of rainfall. J. Hydrol. 2000, 228, 113–129. [Google Scholar] [CrossRef]
- Kim, H.-R.; Kim, K.-H.; Yu, S.; Moniruzzaman, M.; Hwang, S.; Lee, G.-T.; Yun, S.-T. Better assessment of the distribution of As and Pb in soils in a former smelting area, using ordinary co-kriging and sequential Gaussian co-simulation of portable X-ray fluorescence (PXRF) and ICP-AES data. Geoderma 2019, 341, 26–38. [Google Scholar] [CrossRef]
- China National Environmental Protection Agency. Technical Specification for Soil Environmental Monitoring; HJ/T166-2004; China National Environmental Protection Agency: Beijing, China, 2002.
- China National Environmental Protection Agency. Environmental Quality Standard for Soils; Report No. GB15618-1995; China National Environmental Protection Agency: Beijing, China, 1995.
- SEPAC (State Environment Protection Administration of China). Technical Guidelines for Risk Assessment of Contaminated Sites; SEPAC (State Environment Protection Administration of China): Beijing, China, 2009. Available online: www.mep.gov.cn/gkml/hbb/bgth/200910/W020091009550671751947.pdf (accessed on 24 July 2019).
- Webster, R.; Oliver, M. Geostatistics for Environmental Scientists; John Wiley & Sons, Ltd.: New York, NY, USA, 2001; p. 271. [Google Scholar]
- McBratney, A.B.; Odeh, I.O.A.; Bishop, T.F.A.; Dunbar, M.S.; Shatar, T.M. An overview of pedometric techniques for use in soil survey. Geoderma 2000, 97, 293–327. [Google Scholar] [CrossRef]
- Cressie, N.; Gotway, C.A.; Grondona, M.O. Spatial prediction from networks. Chemom. Intell. Lab. Syst. 1990, 7, 251–271. [Google Scholar] [CrossRef]
- Liu, X.M.; Wu, J.J.; Xu, J.M. Characterizing the risk assessment of heavy metals and sampling uncertainty analysis in paddy field by geostatistics and GIS. Environ. Pollut. 2006, 141, 257–264. [Google Scholar] [CrossRef]
- Ord, J.K.; Getis, A. Local spatial autocorrelation statistics: Distributional issues and an application. Geogr. Anal. 1995, 27, 286–306. [Google Scholar] [CrossRef]
- Hu, B.F.; Shao, S.; Fu, Z.Y.; Li, Y.; Ni, H.; Chen, S.C.; Zhou, Y.; Jin, B.; Shi, Z. Identifying heavy metal pollution hot spots in soil-rice systems: A case study in South of Yangtze River Delta, China. Sci. Total Environ. 2019, 658, 614–625. [Google Scholar] [CrossRef] [PubMed]
- Hu, B.F.; Zhao, R.Y.; Chen, S.C.; Zhou, Y.; Jin, B.; Li, Y.; Shi, Z. Heavy Metal Pollution Delineation Based on Uncertainty in a Coastal Industrial City in the Yangtze River Delta, China. Int. J. Environ. Res. Public Health 2018, 15, 710. [Google Scholar] [CrossRef] [PubMed]
- Smith, J.L.; Halvorson, J.J.; Papendick, R.I. Using multiple-variable indicator kriging for evaluating soil quality. Soil. Sci. Soc. Am. J. 1993, 57, 743–749. [Google Scholar] [CrossRef]
- Diodato, N.; Ceccarelli, M. Multivariate indicator kriging approach using a GIS to classify soil degradation for Mediterranean agricultural lands. Ecol. Indic. 2004, 4, 177–187. [Google Scholar] [CrossRef]
- Lars, H. An ecological risk index for aquatic pollution control. A sedimentological approach. Water Res. 1980, 14, 975–1001. [Google Scholar]
- China National Environmental Monitoring Center (CNEMC). The Background Concentrations of Soil Elements of China; China Environmental Science Press: Beijing, China, 1990. (In Chinese) [Google Scholar]
- Dong, Y.X.; Zheng, W.; Zhou, J. Soil Geochemical Background Value of Zhejiang Province; Geolgical Publishing House: Beijing, China, 2007. (In Chinese) [Google Scholar]
- Lin, L.I.K. A concordance correlation coefficient to evaluate reproducibility. Biometrics 1989, 45, 255–268. [Google Scholar] [CrossRef] [PubMed]
- Wu, L.H.; Pan, X.; Chen, L.K.; Huang, Y.J.; Teng, Y.; Luo, Y.M.; Chirste, P. Occurrence and distribution of heavy metals and tetracyclines in agricultural soils after typical land use change in east China. Environ. Sci. Pollut. Res. 2013, 20, 8342–8354. [Google Scholar] [CrossRef]
- Tang, W.Z.; Zhang, H.; Shan, B.Q.; Li, S.S. Accumulation and risk assessment of sedimentary trace metals in response to industrialization from the tributaries of Fuyang River System. Environ. Earth Sci. 2015, 73, 1975–1982. [Google Scholar] [CrossRef]
- Liu, M.P.; Xu, J.; Krogh, P.H.; Song, J.; Wu, L.H.; Luo, Y.M.; Ke, X. Assessment of toxicity of heavy metal-contaminated soils toward Collembola in the paddy fields supported by laboratory tests. Environ. Sci. Pollut. Res. 2018, 25, 16969–16978. [Google Scholar] [CrossRef] [PubMed]
- Chen, H.F.; Li, Y.; Wu, H.X.; Li, F. Characteristics and Risk Assessment of Heavy Metals Pollution of Farmland Soils Relative to Type of Land Use. J. Ecol. Rural Environ. 2013, 29, 164–169. (In Chinese) [Google Scholar]
- Knotters, M.; Brus, D.J.; Voshaar, J.H.O. A comparison of kriging, co-kriging and kriging combined with regression for spatial interpolation of horizon depth with censored observations. Geoderma 1995, 67, 227–246. [Google Scholar] [CrossRef]
- Goovaerts, P. Geostatistics in soil science: State-of-the-art and perspectives. Geoderma 1999, 89, 1–45. [Google Scholar] [CrossRef]
Statistics | Method | MEAN | SD | MIN | MAX | CV% | SBC1 | SBC2 |
---|---|---|---|---|---|---|---|---|
pH | 5.8 | 1.1 | 3.8 | 8.01 | 18.9 | |||
Cd | ICP-AES | 0.37 | 0.24 | 0.1 | 1.53 | 64.81 | 0.07 | 0.097 |
PXRF | 0.41 | 0.2 | 0.15 | 1.6 | 48.65 | |||
As | ICP-AES | 12.59 | 6.77 | 2.36 | 35.39 | 53.73 | 9.2 | 11.2 |
PXRF | 12.73 | 5.11 | 1.69 | 25.68 | 40.17 | |||
Pb | ICP-AES | 22.68 | 14.64 | 3.59 | 97.24 | 64.53 | 23.7 | 26 |
PXRF | 22.59 | 10.12 | 5.63 | 62.01 | 44.79 | |||
Cr | ICP-AES | 43.79 | 16.86 | 13.1 | 87.32 | 38.5 | 52.9 | 61 |
PXRF | 43.86 | 13.64 | 6.14 | 85.34 | 31.1 | |||
Ni | ICP-AES | 20.31 | 8.27 | 5.62 | 38.02 | 40.74 | 24.6 | 26.9 |
PXRF | 21.18 | 8.01 | 0.86 | 52.03 | 37.8 |
Element | ||||||
---|---|---|---|---|---|---|
As | Sample Number | 93 | 4 | 0 | 0 | 0 |
Percentage | 95.88% | 4.12% | 0 | 0 | 0 | |
Cd | Sample Number | 64 | 28 | 2 | 3 | 0 |
Percentage | 65.98% | 28.86% | 2.06% | 3.09% | 0 | |
Cr | Sample Number | 97 | 0 | 0 | 0 | 0 |
Percentage | 100% | 0 | 0 | 0 | 0 | |
Pb | Sample Number | 96 | 1 | 0 | 0 | 0 |
Percentage | 98.97% | 1.03% | 0 | 0 | 0 | |
Ni | Sample Number | 97 | 0 | 0 | 0 | 0 |
Percentage | 100% | 0 | 0 | 0 | 0 |
Pollution Grade | Count | Proportion |
---|---|---|
Safety | 52 | 53.61% |
Alert | 27 | 27.84% |
Slight pollution | 15 | 15.46% |
Moderate pollution | 2 | 2.06% |
Severe pollution | 1 | 1.03% |
Element | R2 | Concordance | RMSE | |
---|---|---|---|---|
Cr | OK | 0.706 | 0.83 | 8.76 |
COK XRF | 0.714 | 0.83 | 8.70 | |
Differences (%) | +1.13% | 0 | −0.68% | |
Pb | OK | 0.456 | 0.655 | 8.60 |
COK XRF | 0.514 | 0.696 | 8.21 | |
Differences (%) | +12.72% | +4.66% | −4.54% | |
Cd | OK | 0.624 | 0.766 | 0.13 |
COK XRF | 0.687 | 0.818 | 0.12 | |
Differences (%) | +10.10% | +6.79% | −7.70% | |
As | OK | 0.450 | 0.65 | 4.75 |
COK XRF | 0.480 | 0.67 | 4.64 | |
Differences (%) | +6.67% | +3.08% | −2.32% | |
Ni | OK | 0.715 | 0.84 | 4.64 |
COK XRF | 0.722 | 0.84 | 4.63 | |
Differences (%) | +0.98% | 0 | +0.22% |
