The detection, observation, recognition, and statistics of marine plankton are the basis of marine ecological research. In recent years, digital holography has been widely applied to plankton detection and recognition. However, the recording and reconstruction of digital holography require a strictly controlled laboratory environment and time-consuming iterative computation, respectively, which impede its application in marine plankton imaging. In this paper, an intelligent method designed with digital holography and deep learning algorithms is proposed to detect and recognize marine plankton (IDRMP). An accurate integrated A-Unet network is established under the principle of deep learning and trained by digital holograms recorded with publicly available plankton datasets. This method can complete the work of reconstructing and recognizing a variety of plankton organisms stably and efficiently by a single hologram, and a system interface of YOLOv5 that can realize the task of the end-to-end detection of plankton by a single frame is provided. The structural similarities of the images reconstructed by IDRMP are all higher than 0.97, and the average accuracy of the detection of four plankton species, namely, Appendicularian, Chaetognath, Echinoderm and Hydromedusae,, reaches 91.0% after using YOLOv5. In optical experiments, typical marine plankton collected from Weifang, China, are employed as samples. For randomly selected samples of Copepods, Tunicates and Polychaetes, the results are ideal and acceptable, and a batch detection function is developed for the learning of the system. Our test and experiment results demonstrate that this method is efficient and accurate for the detection and recognition of numerous plankton within a certain volume of space after they are recorded by digital holography. Full article

This study presents a novel simultaneous double-exposure contact mirror-based method for fabricating holographic multi-notch filters with dual operational central wavelengths. The proposed method leverages coupled wave theory, the geometric relationships of K-vectors, and a reflection-type recording setup, incorporating additional reflecting mirrors to guide the recording beams. To validate the approach, a holographic notch filter was fabricated using photopolymer recording materials, resulting in operational wavelengths of 531.13 nm and 633.01 nm. The measured diffraction efficiencies at these wavelengths were η_s = 52.35% and η_p = 52.45% for 531.13 nm, and η_s = 67.30% and η_p = 67.40% for 633.01 nm. The component’s performance was analyzed using s- and p-polarized spectral transmission intensities at various reconstruction angles, revealing polarization-independent characteristics under normal incidence and polarization-dependent behavior under oblique incidence. The study also explored the relationships between recording parameters, such as incident angle, wavelength, emulsion expansion, and dispersion. The findings demonstrate that the first operational central wavelength is primarily influenced by the recording wavelength, while the second is primarily determined by the incident angle, covering a range from visible light to near-infrared. This method offers significant potential for cost-effective, mass-produced filters in optoelectronic applications. Full article

Background: Three-dimensional reconstructions of state-of-the-art high-resolution imaging are progressively being used more for preprocedural assessment in thoracic surgery. It is a promising tool that aims to improve patient-specific treatment planning, for example, for minimally invasive or robotic-assisted lung resections. Increasingly available mixed-reality hardware based on video pass-through technology enables the projection of image data as a hologram onto the patient. We describe the novel method of real-time 3D surgical planning in a mixed-reality setting by presenting three representative cases utilizing volume rendering. Materials: A mixed-reality system was set up using a high-performance workstation running a video pass-through-based head-mounted display. Image data from computer tomography were imported and volume-rendered in real-time to be customized through live editing. The image-based hologram was projected onto the patient, highlighting the regions of interest. Results: Three oncological cases were selected to explore the potentials of the mixed-reality system. Two of them presented large tumor masses in the thoracic cavity, while a third case presented an unclear lesion of the chest wall. We aligned real-time rendered 3D holographic image data onto the patient allowing us to investigate the relationship between anatomical structures and their respective body position. Conclusions: The exploration of holographic overlay has proven to be promising in improving preprocedural surgical planning, particularly for complex oncological tasks in the thoracic surgical field. Further studies on outcome-related surgical planning and navigation should therefore be conducted. Ongoing technological progress of extended reality hardware and intelligent software features will most likely enhance applicability and the range of use in surgical fields within the near future. Full article

The paper proposes an equivalent optical scheme of an in-line digital holographic system for particle recording and a mathematical model that establishes a one-to-one correspondence between the dimensional and spatial parameters of a digital holographic image of a particle and the imaged particle itself. The values of the model coefficients used to determine the real size and longitudinal coordinate of a particle according to its holographic image are found by calibration. The model was tested in field and laboratory conditions to calibrate a submersible digital holographic camera designed to study plankton in its habitat. It was shown that four calibration measurements are sufficient enough to determine the model coefficients, and the developed design of the submersible digital holographic camera makes it possible to perform these measurements during the recording of each hologram. In addition, this neither requires data on the refractive index of the medium with particles nor on the parameters of the optical elements of the scheme. The paper presents the results of marine experiments in the Kara Sea and the Laptev Sea, as well as in fresh water in laboratory conditions and in Lake Baikal. The error in measuring the particle size in seawater without the use of the model is 53.8%, while the error in determining their longitudinal coordinates is 79.3%. In fresh water, the same errors were 59% and 54.5%, respectively. The error in determining the position of a particle with the use of the designed mathematical model does not exceed 1.5%, and the error in determining the size is 4.8%. The model is sensitive to changes in the optical properties of the medium, so it is necessary to perform calibration in each water area, and one calibration is quite sufficient within the same water area. At the same time, the developed design of the submersible holographic camera allows, if necessary, calibration at each holographing of the medium volume with particles. Full article

Central data systems require mass storage systems for big data from many fields and devices. Several technologies have been proposed to meet this demand. Holographic data storage (HDS) is at the forefront of data storage innovation and exploits the extraordinary characteristics of light to encode and retrieve two-dimensional (2D) data from holographic volume media. Nevertheless, a formidable challenge exists in the form of 2D interference that is a by-product of hologram dispersion during data retrieval and is a substantial barrier to the reliability and efficiency of HDS systems. To solve these problems, an equalizer and target are applied to HDS systems. However, in previous studies, the equalizer acted only as a linear convolution filter for the received signal. In this study, we propose a nonlinear equalizer using a convolutional neural network (CNN) for HDS systems. Using a CNN-based equalizer, the received signal can be nonlinearly converted into the desired signal with higher accuracy. In the experiments, our proposed model achieved a gain of approximately 2.5 dB in contrast to conventional models. Full article

The paper studies the influence of coherent noises on the quality of images of particles reconstructed from digital holograms. Standard indicators (for example, signal-to-noise ratio) and such indicators as the boundary contrast and boundary intensity jump previously proposed by the authors are used to quantify the image quality. With the use of these parameters, for examples of some known methods of suppressing coherent noises in a holographic image (eliminating the mutual influence of virtual and real images in in-line holography, and time averaging), the features and ranges of applicability of such correction were determined. It was shown that the use of the complex field amplitude reconstruction method based on the Gerchberg–Saxton algorithm and the spatial-frequency method improves the quality of determining the particle image boundary (by boundary intensity jump) starting from the distance between a hologram and a particle, which is about twice the Rayleigh distance. In physical experiments with model particles, averaging methods were studied to suppress non-stationary coherent noises (speckles). It was also shown that averaging over three digital holograms or over three holographic images is sufficient to provide a quality of particle image boundary suitable for particle recognition. In the case of multiple scattering, when it is necessary to impose a limit on the working volume length (depth of scene) of the holographic camera, the paper provides estimates that allow selecting the optimal working volume length. The estimates were made using the example of a submersible digital holographic camera for plankton studies. Full article

We study the use of two dynamic thick holograms to realize isotropic two-dimensional (2D) differentiation under Bragg diffraction. Acousto-optic modulators (AOMs) are used as dynamic volume holograms. Using a single volume hologram, we can accomplish a first-order derivative operation, corresponding to selective edge extraction of an image. Since the AOM is a 1D spatial light modulator, filtering of the image only occurs along the direction of the sound propagation. To achieve 2D image processing, two AOMs are used within a Mach–Zehnder interferometer (MZI). By aligning one AOM along the x-direction on the upper arm of the interferometer and another AOM along the y-direction on the lower arm, we accomplish the sum of two first-derivative operations, leading to isotropic edge extraction. We have performed both computer simulations and optical experiments to verify the proposed idea. The system provides additional operations in optical computing using AOMs as dynamic holograms. Full article

Light sheet microscopy in live cells requires minimal excitation intensity and resolves three-dimensional (3D) information rapidly. Lattice light sheet microscopy (LLSM) works similarly but uses a lattice configuration of Bessel beams to generate a flatter, diffraction-limited z-axis sheet suitable for investigating subcellular compartments, with better tissue penetration. We developed a LLSM method for investigating cellular properties of tissue in situ. Neural structures provide an important target. Neurons are complex 3D structures, and signaling between cells and subcellular structures requires high resolution imaging. We developed an LLSM configuration based on the Janelia Research Campus design or in situ recording that allows simultaneous electrophysiological recording. We give examples of using LLSM to assess synaptic function in situ. In presynapses, evoked Ca²⁺ entry causes vesicle fusion and neurotransmitter release. We demonstrate the use of LLSM to measure stimulus-evoked localized presynaptic Ca²⁺ entry and track synaptic vesicle recycling. We also demonstrate the resolution of postsynaptic Ca²⁺ signaling in single synapses. A challenge in 3D imaging is the need to move the emission objective to maintain focus. We have developed an incoherent holographic lattice light-sheet (IHLLS) technique to replace the LLS tube lens with a dual diffractive lens to obtain 3D images of spatially incoherent light diffracted from an object as incoherent holograms. The 3D structure is reproduced within the scanned volume without moving the emission objective. This eliminates mechanical artifacts and improves temporal resolution. We focus on LLS and IHLLS applications and data obtained in neuroscience and emphasize increases in temporal and spatial resolution using these approaches. Full article

Volume reflection hologram-based sensors are designed to visibly change colour in response to a target stressor or analyte. However, reflection holograms fabricated in thick photopolymer films are highly angularly selective, making these sensors challenging to view and interpret by non-experts. Here, the use of speckle holography to improve the visibility of reflection holograms is presented. A novel recording approach combining speckle recording techniques with Denisyuk reflection recording geometry is described. The recorded speckle reflection grating operates as a series of multiplexed reflection gratings with a range of spatial frequencies, capable of reflecting light at a wider range of angles. A comparative study of the angular and wavelength selectivity of speckle and standard reflection gratings was conducted. The FWHM of the angular selectivity curves of the speckle reflection gratings is doubled (4°) in comparison to standard 4500 lines/mm reflection gratings (2°). The wavelength selectivity FWHM is also doubled from 4.2 to 8.6 nm. The comparative ability of the speckle and standard reflection gratings to act as colour-changing compressional pressure sensors in the 0.88–5.31 MPa range is described. Finally, we present a prototype reflection hologram viewer which enables the easy observation of angularly specific reflection holograms by non-experts. Full article

Holographic data storage (HDS) is an emerging technology that promises to revolutionize digital data storage and access. Unlike traditional storage media such as hard drives and flash memory, HDS uses light to write and read page-oriented two-dimensional (2D) data from volume media. This allows for significantly higher densities and faster data transfer rates in HDS systems. However, 2D interference is a serious issue in HDS due to hologram dispersion during the reading process. Therefore, we present a novel detection algorithm based on maximum a posteriori (MAP) detection to mitigate 2D interference. In our proposed model, we inherited the structure of the serial generalized partial response target to design the serial structure for MAP detection. The simulation results show that the proposed model can achieve a high bit error rate performance. Full article

In the present work, we consider an optical design of a slitless spectrograph for an existing 0.5 m-class telescope. This design concept has a number of advantages such as compact size, simplicity, and simultaneous coverage of a large field of view. A challenge with this design is correcting aberrations caused by placing a dispersing element in a converging beam. To overcome this issue, we propose to use a composite grism, which represents a combination of a prism and a volume-phase holographic grating, the latter which is split into zones with independently optimized parameters. We demonstrate two designs of such a grism. In both designs, the spectrograph operates in the range of 450–950 nm in an $F/6.8$ beam and covers a field of view of 35.6${}^{\prime }$ × 7.2${}^{\prime }$. Through advanced modeling, it is shown that a composite grism having four rectangular zones with different thickness and index modulation depth of the hologram and recorded with an auxiliary deformable mirror decreases the astigmatic elongation by a factor of 85, increases the spectral resolving power by 4.4 times, and reaches $R1389$ while increasing the average diffraction efficiency by a factor of $1.31$. If we reduce the number of zones to only two, replace the deformable mirror with two static corrector plates, and fix the hologram thickness, the corresponding performance gains still remain high: the astigmatism is reduced by a factor of 61, the spectral resolving power is up to $1.7$ times higher, reaching $R1067$, and the efficiency is increased by a factor of $1.27$. This shows that the proposed design allows the construction of a simple and compact instrument, providing high performance over the entire field of view and spectral range. Full article

The subject of this investigation is light diffraction from a structure formed at the lateral projection of structured light on the surface of a 3D object. It is demonstrated that the patterns of vertically structured light fringes change their structure during the lateral illumination of a 3D object, and take on the properties of holograms. The diffraction of light from this structure forms several diffraction orders, and one of them can restore the image of the 3D object. Results of the numerical experiment demonstrating the possibility to restore 3D holographic images by these patterns at a wavelength corresponding to Bragg conditions are presented. The obtained result allows an order of magnitude higher compression of the holographic information about a 3D object to be transmitted along the communication channel, in a volume that is sufficient for visual perception, and for the observation of both the horizontal and vertical continuous parallax. Results of the experiments on the transmission of this compressed information are presented to demonstrate that the TV frame rate frequency of the 3D holographic video sequence is quite achievable. Full article

To date, planar waveguides are under development for augmented reality systems with waveguide combiners. The next step of their development is the transition to curved waveguides, which could make the combiners more ergonomic. In the present work, a method has been developed that makes it possible to minimize aberrations of a virtual image during its in-coupling to and out-coupling from a cylindrical waveguide. The method is based on the use of in-coupling and out-coupling diffractive optical elements (DOE) with a variable grating period, which provide virtual image pre-aberration when radiation is in-coupled into the waveguide and compensation of the waveguide curvature at the out-coupling. Analytical laws are derived for the period variation of the in-coupling and out-coupling DOEs for an arbitrary curvature of a cylindrical waveguide. These dependences were optimized to minimize virtual image aberrations when using a radiation source with finite dimensions. Samples of cylindrical concentric PMMA waveguides with a curvature radius of 150 mm and in-coupling/out-coupling holographic optical elements (HOEs) have been created. The transmission of test monochrome virtual images through these waveguides without doubling and breaks in the field of view has been experimentally demonstrated. Full article

A hologram, measured by using appropriate coherent illumination, records all substantial volumetric information of the measured sample. It is encoded in its interference patterns and, from these, the image of the sample objects can be reconstructed in different depths by using standard techniques of digital holography. We claim that a 2D convolutional network (CNN) cannot be efficient in decoding this volumetric information spread across the whole image as it inherently operates on local spatial features. Therefore, we propose a method, where we extract the volumetric information of the hologram by mapping it to a volume—using a standard wavefield propagation algorithm—and then feed it to a 3D-CNN-based architecture. We apply this method to a challenging real-life classification problem and compare its performance with an equivalent 2D-CNN counterpart. Furthermore, we inspect the robustness of the methods to slightly defocused inputs and find that the 3D method is inherently more robust in such cases. Additionally, we introduce a hologram-specific augmentation technique, called hologram defocus augmentation, that improves the performance of both methods for slightly defocused inputs. The proposed 3D-model outperforms the standard 2D method in classification accuracy both for in-focus and defocused input samples. Our results confirm and support our fundamental hypothesis that a 2D-CNN-based architecture is limited in the extraction of volumetric information globally encoded in the reconstructed hologram image. Full article

To reveal the fundamental characteristic of the volume holographic waveguide for a head-mounted display (HMD), we analyzed the resolution of a virtual image. We built a mathematical model considering the off-Bragg diffraction for each ray angle of the signal light ray. The display resolution performance of the HMD depended on the thickness of the waveguide and the ray angle. At the lowest-resolution ray angle, the input-point image was broadened more than 0.1° in a viewing angle for a 1-mm-thick waveguide. Conversely, our previously proposed line-symmetric image-input method, in which the input images were symmetrically arranged with respect to the center line, improved the resolution performance and luminance uniformity. We observed that the spread of the point image was suppressed to 0.01°, which was a sufficient resolution for a person with a visual acuity of 0.8. Full article
