Fish passage facilities are essential for restoring river connectivity and protecting ecosystems, effectively balancing economic and ecological benefits. Systematic and comprehensive monitoring, assessment, and optimized management are therefore crucial. This study quantitatively evaluated the entire upstream migration process of fish from the downstream river to the entrance and exit of the fishway and investigated the upstream movement patterns of fish under various environmental factors. A total of 19 fish species were monitored in the Heishuihe River downstream of the dam, with 15 species reaching the fishway entrance and 12 species successfully passing through it. The entrance attraction and passage rates of the vertical-slot fishway at the Songxin hydropower station were 15.7% and 40.42%, respectively. The best upstream performance was observed in May, with fish demonstrating better upstream timing and speed during nighttime compared to daytime. Specifically, the highest entrance attraction efficiency was recorded at a flow rate of 6–7 m³/s and a temperature of 19–20 °C, while the optimal passage efficiency was observed at a flow rate of 0–0.5 m³/s and a temperature of 17–20 °C. Additionally, a multifactorial Cox proportional hazards regression model was constructed to identify key factors influencing the probability of fishway entrance attraction and successful passage. The model elucidated the impact patterns of these key factors on fish upstream migration, ultimately generating an alignment diagram for prediction and control. This study provides a theoretical foundation and data support for developing optimized operational schedules for fishways. The findings offer a more comprehensive and systematic approach for monitoring and evaluating fish passage facilities, serving as a scientific basis for ecological restoration and fish conservation in this region and similar areas. Full article

The mean and turbulent flow characteristics of a vertical slot fish pass, with and without brush blocks, were investigated at the Cataloluk Small Hydropower Plant on the Tekir River, located in the Ceyhan River Basin of Turkey. Within the scope of the project, three-dimensional velocity measurements were performed at different hydraulic conditions. The prototype flow measurements showed that by placing brush blocks and the substrate in the vertical-slot pool: (i) the maximum velocity observed downstream of the slot was reduced by 39%; (ii) the maximum lateral component of the Reynolds shear stress observed in the slot region was reduced by a factor of 3; and (iii) the spatially averaged resultant velocity was reduced by 20%. With brush blocks, the turbulent jet region was reduced and recirculation regions disappeared. Furthermore, the spatially-averaged lateral component of the Reynolds shear stress was 3.3 times higher than the spatially-averaged streamwise component of the Reynolds shear stress because of the lateral velocity gradient and mixing in the pool. The present findings will contribute to potential improvements in the non and less efficiently-functioning vertical slot fish pass and other fish pass types by adding brush blocks. Full article

Habitat loss and overfishing are the most significant threats to diadromous fish, most of them of high socioeconomic and conservationist importance, such as Alosa alosa, Alosa fallax, Petromyzon marinus and Anguilla anguilla. The main objective of the LIFE Águeda project (LIFE16 ENV/PT/000411) is the removal of hydro-morphological pressures towards the reestablishment of conditions for a good ecological status, as required by the Water Framework Directive (WFD) and associated River Basin Management Plans. Actions to achieve the project’s objectives include the restoration of river morphology through the construction of nature-like fish passes, removal of river obstacles and re-naturalization of the riverbed. Aside from these interventions, the project also contemplates riparian habitat restoration, design and operation of a pilot translocation program directed to European eel juveniles, management of recreational and commercial fisheries, and stakeholders’ engagement, safeguarding compatibility of ecosystem uses. To reestablish longitudinal connectivity in rivers Agueda and Alfusqueiro, a total of five fish passes (two modular and temporary vertical-slot and three nature-like fish passes) will be installed in obstacles where current uses need to be secured and removal is not an option. Obsolete or illegally built obstacles are to be completely or partially removed, in a total of eight interventions in both rivers. By placing PIT antennas in the most upstream fishways planned to be built in both rivers, and by monitoring the movements of tagged fish from target species, the efficiency of these habitat restoration actions, and the reestablishment of longitudinal connectivity, will be assessed. Full article

To establish good ecological status in European rivers, firstly there is the question of how to re-establish unhindered migration for fish at barriers. This article documents a project to re-establish longitudinal connectivity at a large epipotamal river at the Schwabeck Hydro Power Plant, Carinthia/Austria, from the selection of an appropriate fish pass system to the final function control. Instead of a standard vertical slot, the innovative enature^® fish pass shape with a significant reduction of flow, velocities, energy dissipation rate, and turbulences, but with a clear enhancement of fish passage capability, was chosen. Using 2D hydraulic modelling and a statistical evaluation of fish passage, physical and ecological effects were reviewed, with the clear result that there is no identifiable, positive ecological effect on the number of fish migrating with an increase of concurrent flow in the fish pass. Passability and findability were monitored with the new FishCam, an automatic, precise, and constant (24/7 24 h a day, seven days a week) collection and pre-evaluation field data survey method which does not involve trapping of, contact with, or stress for fish. It was shown that the enature^® fish pass enables an unhindered migration for all available fish species. As >99% of fish migrate from April to November, there is no ecological need to operate a fully functional fish pass year-round. Combining all the individual factors together, the fish pass at the Schwabeck Hydro Power Plant is an almost exemplary solution for a fully functioning restauration of the continuum with a minimized loss of generation of electricity. Full article

Vertical slot fishways are increasingly common structures for the passage of a wide variety of migratory fish and contribute to the maintenance of fish diversity in fragmented rivers. These structures are designed with several geometric arrangements and, consequently, flow patterns through them can be shaped to present suitable characteristics for the fish species. To aid in the design of vertical slot fishways, a three-dimensional numerical model was used to simulate the flow for different geometric configurations. An existing vertical slot fishway with nonstandard dimensions was initially modeled and validated. This geometry was used as a reference design. Modifications to the reference design, such as the insertion of cylinders, changes in the baffle shape and position of the vertical slots, as possible rehabilitation measures, were proposed and tested. In summary, five different designs were evaluated with several slopes, totaling 17 geometries. Hydraulic parameters, flow patterns, maximum velocities, velocity fields and turbulence kinetic energy in the pools were analyzed. The results indicate that the maximum velocity values were between 9% and 68% higher than those obtained by the theoretical equation. This indicates that maximum velocities can be underestimated for nonstandard vertical slot fishways if a simplified evaluation is conducted. The insertion of cylinders in the region close to the slot reduces the maximum velocity up to 8.2%. The positioning of the vertical slots on alternating sides increases the maximum values of turbulence kinetic energy and the regions subjected to higher values. However, this configuration provided greater energy dissipation and reduction of velocities by up to 27%. Thus, modifications in nonstandard vertical slot fishways can be useful in future design or rehabilitation of existing structures in order to provide velocities and turbulence more friendly for a higher number of fish species. Full article

Fish screens at hydroelectric dams help to protect rearing and migrating fish by preventing them from passing through the turbines and directing them towards the bypass channels by means of a sweeping flow parallel to the screen. However, fish screens may actually be harmful to fish if the fish become impinged on the surface of the screen or become disoriented due to poor flow conditions near the screen. Recent modifications to the vertical barrier screens (VBS) in the gate wells at the Bonneville Dam second powerhouse (B2) were intended to increase the guidance of juvenile salmonids into the juvenile bypass system but have resulted in higher mortality and descaling rates of hatchery subyearling Chinook salmon during the 2008 juvenile salmonid passage season. To investigate the potential cause of the high mortality and descaling rates, an in situ water velocity measurement study was conducted using acoustic Doppler velocimeters in the gate well slots at turbine units 12A and 14A of B2. From the measurements collected, the average approach velocity, sweep velocity, and the root mean square value of the velocity fluctuations were calculated. The approach velocities measured across the face of the VBS were variable and typically less than 0.3 m/s, but fewer than 50% were less than or equal to 0.12 m/s. There was also large variance in sweep velocities across the face of the VBS with most measurements recorded at less than 1.5 m/s. Results of this study revealed that the approach velocities in the gate wells exceeded criteria intended to improve fish passage conditions that were recommended by National Marine Fisheries Service and the Washington State Department of Fish and Wildlife. The turbulence measured in the gate well may also result in suboptimal fish passage conditions but no established guidelines to contrast those results have been published. Full article
