We present a low-noise (<10 µ$\mathrm{rad}/\sqrt{\mathrm{Hz}}$) broadband Faraday Rotation Spectroscopy method which is feasible for near-ultraviolet through near-infrared wavelengths. We demonstrate this in the context of a high-precision spectroscopy experiment using a heated Pb vapor cell and two different lasers, one in the UV (368 nm) and a second in the IR (1279 nm). A key element of the experimental technique is the use of a uniaxial single crystal CeF₃ Faraday modulator with excellent transmission and optical rotation properties across the aforementioned wavelength range. Polarimeter performance is assessed as a function of crystal orientation and alignment, AC modulation amplitude, laser power, and laser wavelength. Crystal-induced distortion of the ${\left(6p^2\right)}^3{P}_0\to {\left(6p^2\right)}^3{P}_1$ (1279 nm) and ${\left(6p^2\right)}^3{P}_1\to {\left(6p7s\right)}^3{P}_0$ (368 nm) spectral lines due to misalignment-induced birefringence is discussed and modeled using the Jones calculus. Full article

In this paper, we study the propagation properties of twisted Hermite–Gaussian Schell- model (THGSM) beams propagating in a uniaxial crystal orthogonal to the optical axis. We derive the concrete analytical expression of the cross-spectral density (CSD) function in the crystal and simulate the evolution characteristics of such beams, including normalized spectral intensity, the spectral degree of coherence (DOC), and effective beam width. We find that the spectral intensity distribution exhibits a non-circular symmetric self-splitting while rotating, and the distribution of the spectral DOC is non-circular symmetric rotationally distorted, which is quite different from that in an isotropic medium. The initial beam parameters and crystal parameters both affect the distribution of spectral intensity and DOC. Furthermore, increasing the twist factor and adjusting the ratio of the extraordinary light refractive index and the ordinary light refractive index n_e/n_o of the uniaxial crystal can suppress the beam expansion as propagating in the crystal. Our results show that the uniaxial crystal can be used to determine whether light beams carry a twist phase or not, and to modulate the characteristics of light beams. Full article

The operating attitude of a shearer based on a three-dimensional (3D) space scale is the necessary basic information for realizing intelligent mining. Aiming to address the problem of the insufficient perception accuracy of shearers, in this paper, the rotation model of the actual turning mechanism of the strapdown inertial navigation system (SINS) of shearers is established, and the error propagation characteristics of different single-axis rotation modulation schemes are revealed. Through theory and simulation, the optimal rotation modulation scheme is determined to be the improved four-position turn–stop modulation with a rotation of <360°. The experiment shows that the 24 h positioning error of this scheme is 3.7 nmile, and the heading angle changes by 0.06°, which proves that this scheme can effectively improve the attitude perception accuracy of the inertial navigation system (INS). The field application of the shearer operating attitude perception based on this scheme shows that the positioning error after error compensation is 17% of that before compensation, and the heading angle error is 75% of that before compensation, which verifies that this scheme can significantly improve the accuracy of shearer operating attitude perception in field applications. This scheme can achieve higher precision perception accuracy based on SINS and has broad application prospects in the field of high-precision pose perception of coal mining machines, roadheaders, and other equipment. Full article

Cables or slip-rings are often used to power loads on a rotating unit in the rotation modulated inertial navigation system (RMINS). However, these power supply methods have the disadvantages of cable winding and slip ring friction and wear, which reduces the reliability and life of the RMINS. Therefore, this paper applies magnetic coupling resonant wireless power transfer (MCRWPT) technology to the RMINS to avoid the shortcomings of the above power supply methods. Furthermore, according to the structure and working characteristics of the RMINS, a simple design method of the MCRWPT system without any feedback control is proposed. Based on the ANSYS simulation, the magnetic shielding structure is designed to reduce magnetic leakage, and the efficiency of the MCRWPT system is optimized by designing the excitation frequency. Experiments verify the effectiveness of the proposed method. The experimental results show that the designed MCRWPT system can achieve an efficiency of 74.6% with an output power of 10 W and has been successfully applied to the uniaxial rotation module inertial navigation system. Finally, the design method of the MCRWPT system is simple, and it has guiding significance for the design of the wireless power transfer system in the RMINS. Full article

Calibration and compensation techniques are essential to improve the accuracy of the strap-down inertial navigation system. Especially for the new uniaxial rotation module inertial navigation system (URMINS), replacing faulty uniaxial rotation modules introduces installation errors between modules and reduces navigation accuracy. Therefore, it is necessary to calibrate these systems effectively and compensate for the installation error between modules. This paper proposes a new self-calibration and compensation method for installation errors without additional information and equipment. Using the attitude, velocity, and position differences between the two sets of navigation information output from URMINS as measurements, a Kalman filter is constructed and the installation error is estimated. After URMINS is compensated for the installation error, the average of the demodulated redundant information is taken to calculate the carrier’s navigation information. The simulation results show that the proposed method can effectively assess the installation error between modules with an estimation accuracy better than 5”. Experimental results for static navigation show that the accuracy of heading angle and positioning can be improved by 73.12% and 81.19% after the URMINS has compensated for the estimated installation errors. Simulation and experimental results further validate the effectiveness of the proposed self-calibration and compensation method. Full article

The alignment of nanowires (NWs) has been actively pursued for the production of electrical devices with high-operating performances. Among the generally available alignment processes, spin-coating is the simplest and fastest method for uniformly patterning the NWs. During spinning, the morphology of the aligned NWs is sensitively influenced by the resultant external drag and inertial forces. Herein, the assembly of highly and uniaxially aligned silicon nanowires (Si NWs) is achieved by introducing an off-center spin-coating method in which the applied external forces are modulated by positioning the target substrate away from the center of rotation. In addition, various influencing factors, such as the type of solvent, the spin acceleration time, the distance between the substrate and the center of rotation, and the surface energy of the substrate, are adjusted in order to optimize the alignment of the NWs. Next, a field-effect transistor (FET) incorporating the highly aligned Si NWs exhibits a high effective mobility of up to 85.7 cm² V⁻¹ s⁻¹, and an on-current of 0.58 µA. Finally, the single device is enlarged and developed in order to obtain an ultrathin and flexible Si NW FET array. The resulting device has the potential to be widely expanded into applications such as wearable electronics and robotic systems. Full article

Conventional uniaxial techniques generally require shifting objects or projection grating with the assistance of a high-precision mechanical moving component. To overcome this limitation, we propose a novel uniaxial 3-D shape measurement system with auto-synchronous phase-shifting and defocusing by using a tilted and fixed projection grating. The tilted focused image plane (FIP), which is reflected by a mirror at about 90 degrees, could be shifted across the measured surface by slightly rotating the mirror within a small angle range. This procedure will simultaneously introduce the change in defocusing and phase-shifting of the fringe. The modulation curve of each point can be deciphered by Fourier fringe analysis after a sequence of fringe intensities is acquired. Since both the measured object and projection grating are fixed, the proposed method could make the measurement system more compact and flexible. Both computer simulation and experiments are carried out to demonstrate the validity of this proposed system. Full article

In this study, we demonstrate the use of parallel plate far field electrospinning (pp-FFES) based manufacturing system for the fabrication of polyacrylonitrile (PAN) fiber reinforced polyvinyl alcohol (PVA) strong polymer thin films (PVA SPTF). Parallel plate far field electrospinning (also known as the gap electrospinning) is generally used to produce uniaxially aligned fibers between the two parallel collector plates. In the first step, a disc containing PVA/H₂O solution/bath (matrix material) was placed in between the two parallel plate collectors. Next, a layer of uniaxially aligned sub-micron PAN fibers (filler material) produced by pp-FFES was directly collected/embedded in the PVA/H₂O solution by bringing the fibers in contact with the matrix. Next, the disc containing the matrix solution was rotated at 45° angular offset and then the next layer of the uniaxial fibers was collected/stacked on top of the previous layer with now 45° rotation between the two layers. This process was continued progressively by stacking the layers of uniaxially aligned arrays of fibers at 45° angular offsets, until a periodic pattern was achieved. In total, 13 such layers were laid within the matrix solution to make a helicoidal geometry with three pitches. The results demonstrate that embedding the helicoidal PAN fibers within the PVA enables efficient load transfer during high rate loading such as impact. The fabricated PVA strong polymer thin films with helicoidally arranged PAN fiber reinforcement (PVA SPTF-HA) show specific tensile strength 5 MPa·cm³·g⁻¹ and can sustain specific impact energy (8 ± 0.9) mJ·cm³·g⁻¹, which is superior to that of the pure PVA thin film (PVA TF) and PVA SPTF with randomly oriented PAN fiber reinforcement (PVA SPTF-RO). The novel fabrication methodology enables the further capability to produce even further smaller fibers (sub-micron down to even nanometer scales) and by the virtue of its layer-by-layer processing (in the manner of an additive manufacturing methodology) allowing further modulation of interfacial and inter-fiber adherence with the matrix materials. These parameters allow greater control and tunability of impact performances of the synthetic materials for various applications from army combat wear to sports and biomedical/wearable applications. Full article
