Search Results (9)

This paper presents an innovative and cost-effective solution for the absolute localization of mobile robots using ultrasound beacons. The proposed system addresses the challenge of precise positioning within a controlled environment by employing Differential Time-of-Flight (ToF) measurements to determine the relative distances between the robot and optimally placed beacons. Unlike other ToF methods that require synchronization pulses, the proposed approach eliminates this requirement, significantly simplifying the setup and reducing system complexity. Furthermore, the system achieves a higher sampling rate than conventional synchronization-based systems, enhancing real-time performance. Detailed analysis and simulation demonstrate the system’s ability to provide accurate and reliable localization. The results highlight the potential for broad application in various robotic environments, offering a robust solution for absolute positioning without complex synchronization strategies. This work underscores the advantages of using ToF measurements with ultrasound beacons and contributes to the ongoing development of efficient and cost-effective robotic localization systems. Full article

The development of the GPS (Global Positioning System) and related advances have made it possible to conceive of an outdoor positioning system with great accuracy; however, for indoor positioning, more efficient, reliable, and cost-effective technology is required. There are a variety of techniques utilized for indoor positioning, such as those that are Wi-Fi, Bluetooth, infrared, ultrasound, magnetic, and visual-marker-based. This work aims to design an accurate position estimation algorithm by combining raw distance data from ultrasonic sensors (Marvelmind Beacon) and acceleration data from an inertial measurement unit (IMU), utilizing the extended Kalman filter (EKF) with UDU factorization (expressed as the product of a triangular, a diagonal, and the transpose of the triangular matrix) approach. Initially, a position estimate is calculated through the use of a recursive least squares (RLS) method with a trilateration algorithm, utilizing raw distance data. This solution is then combined with acceleration data collected from the Marvelmind sensor, resulting in a position solution akin to that of the GPS. The data were initially collected via the ROS (Robot Operating System) platform and then via the Pixhawk development card, with tests conducted using a combination of four fixed and one moving Marvelmind sensors, as well as three fixed and one moving sensors. The designed algorithm is found to produce accurate results for position estimation, and is subsequently implemented on an embedded development card (Pixhawk). The tests showed that the designed algorithm gives accurate results with centimeter precision. Furthermore, test results have shown that the UDU-EKF structure integrated into the embedded system is faster than the classical EKF. Full article

For many applications, drones are required to operate entirely or partially autonomously. In order to fly completely or partially on their own, drones need to access location services for navigation commands. While using the Global Positioning System (GPS) is an obvious choice, GPS is not always available, can be spoofed or jammed, and is highly error-prone for indoor and underground environments. The ranging method using beacons is one of the most popular methods for localization, especially for indoor environments. In general, the localization error in this class is due to two factors: the ranging error, and the error induced by the relative geometry between the beacons and the target object to be localized. This paper proposes OPTILOD (Optimal Beacon Placement for High-Accuracy Indoor Localization of Drones), an optimization algorithm for the optimal placement of beacons deployed in three-dimensional indoor environments. OPTILOD leverages advances in evolutionary algorithms to compute the minimum number of beacons and their optimal placement, thereby minimizing the localization error. These problems belong to the Mixed Integer Programming (MIP) class and are both considered NP-hard. Despite this, OPTILOD can provide multiple optimal beacon configurations that minimize the localization error and the number of deployed beacons concurrently and efficiently. Full article

Monitoring and tracking issues related to autonomous mobile robots are currently intensively debated in order to ensure a more fluent functionality in supply chain management. The interest arises from both theoretical and practical concerns about providing accurate information about the current and past position of systems involved in the logistics chain, based on specialized sensors and Global Positioning System (GPS). The localization demands are more challenging as the need to monitor the autonomous robot’s ongoing activities is more stringent indoors and benefit from accurate motion response, which requires calibration. This practical research study proposes an extended calibration approach for improving Omnidirectional Mobile Robot (OMR) motion response in the context of mechanical build imperfections (misalignment). A precise indoor positioning system is required to obtain accurate data for calculating the calibration parameters and validating the implementation response. An ultrasound-based commercial solution was considered for tracking the OMR, but the practical observed errors of the readily available position solutions requires special processing of the raw acquired measurements. The approach uses a multilateration technique based on the point-to-point distances measured between the mobile ultrasound beacon and a current subset of fixed (reference) beacons, in order to obtain an improved position estimation characterized by a confidence coefficient. Therefore, the proposed method managed to reduce the motion error by up to seven-times. Reference trajectories were generated, and robot motion response accuracy was evaluated using a Robot Operating System (ROS) node developed in Matlab-Simulink that was wireless interconnected with the other ROS nodes hosted on the robot navigation controller. Full article

Indoor positioning systems have become a feasible solution for the current development of multiple location-based services and applications. They often consist of deploying a certain set of beacons in the environment to create a coverage volume, wherein some receivers, such as robots, drones or smart devices, can move while estimating their own position. Their final accuracy and performance mainly depend on several factors: the workspace size and its nature, the technologies involved (Wi-Fi, ultrasound, light, RF), etc. This work evaluates a 3D ultrasonic local positioning system (3D-ULPS) based on three independent ULPSs installed at specific positions to cover almost all the workspace and position mobile ultrasonic receivers in the environment. Because the proposal deals with numerous ultrasonic emitters, it is possible to determine different time differences of arrival (TDOA) between them and the receiver. In that context, the selection of a suitable fusion method to merge all this information into a final position estimate is a key aspect of the proposal. A linear Kalman filter (LKF) and an adaptive Kalman filter (AKF) are proposed in that regard for a loosely coupled approach, where the positions obtained from each ULPS are merged together. On the other hand, as a tightly coupled method, an extended Kalman filter (EKF) is also applied to merge the raw measurements from all the ULPSs into a final position estimate. Simulations and experimental tests were carried out and validated both approaches, thus providing average errors in the centimetre range for the EKF version, in contrast to errors up to the meter range from the independent (not merged) ULPSs. Full article

Indoor location and positioning systems (ILPS) are used to locate and track people, as well as mobile and/or connected targets, such as robots or smartphones, not only inside buildings with a lack of global navigation satellite systems (GNSS) signals but also in constrained outdoor situations with reduced coverage. Indoor positioning applications and their interest are growing in certain environments, such as commercial centers, airports, hospitals or factories. Several sensory technologies have already been applied to indoor positioning systems, where ultrasounds are a common solution due to its low cost and simplicity. This work proposes a 3D ultrasonic local positioning system (ULPS), based on a set of three asynchronous ultrasonic beacon units, capable of transmitting coded signals independently, and on a 3D mobile receiver prototype. The proposal is based on the aforementioned beacon unit, which consists of five ultrasonic transmitters oriented towards the same coverage area and has already been proven in 2D positioning by applying hyperbolic trilateration. Since there are three beacon units available, the final position is obtained by merging the partial results from each unit, implementing a minimum likelihood estimation (MLE) fusion algorithm. The approach has been characterized, and experimentally verified, trying to maximize the coverage zone, at least for typical sizes in most common public rooms and halls. The proposal has achieved a positioning accuracy below decimeters for 90% of the cases in the zone where the three ultrasonic beacon units are available, whereas these accuracies can degrade above decimeters according to whether the coverage from one or more beacon units is missing. The experimental workspace covers a large volume, where tests have been carried out at points placed in two different horizontal planes. Full article

The paper proposes an improved method for calculating the position of a movable tag whose distance to a (redundant) set of fixed beacons is measured by some suitable physical principle (typically ultra wide band or ultrasound propagation). The method is based on the multilateration technique, where the contribution of each individual beacon is weighed on the basis of a recurring, self-supported calibration of the measurement repeatability of each beacon at a given distance range. The work outlines the method and its implementation, and shows the improvement in measurement quality with respect to the results of a commercial Ultra-Wide-Band (UWB) system when tested on the same set of raw beacon-to-tag distances. Two versions of the algorithm are proposed: one-dimensional, or isotropic, and 3D. With respect to the standard approach, the isotropic solution managed to reduce the maximum localization error by around 25%, with a maximum error of $0.60$ m, while the 3D version manages to improve even further the localization accuracy, with a maximum error of $0.45$ m. Full article

This paper proposes an algorithm for calibrating the position of beacons which are placed on the ceiling of an indoor environment. In this context, the term calibration is used to estimate the position coordinates of a beacon related to a known reference system in a map. The positions of a set of beacons are used for indoor positioning purposes. The operation of the beacons can be based on different technologies such as radiofrequency (RF), infrared (IR) or ultrasound (US), among others. In this case we are interested in the positions of several beacons that compose an Ultrasonic Local Positioning System (ULPS) placed on different strategic points of the building. The calibration proposal uses several distances from a beacon to the neighbor walls measured by a laser meter. These measured distances, the map of the building in a vector format and other heuristic data (such as the region in which the beacon is located, the approximate orientation of the distance measurements to the walls and the equations in the map coordinate system of the line defining these walls) are the inputs of the proposed algorithm. The output is the best estimation of the position of the beacon. The process is repeated for all the beacons. To find the best estimation of the position of the beacons we have implemented a numerical minimization based on the use of a Genetic Algorithm (GA) and a Harmony Search (HS) methods. The proposal has been validated with simulations and real experiments, obtaining the positions of the beacons and an estimation of the error associated that depends on which walls (and the angle of incidence of the laser) are selected to make the distance measurements. Full article

Many studies utilize the signal strength of short-range radio systems (such as WiFi, ultrasound and infrared) to build a radio map for indoor localization, by deploying a large number of beacon nodes within a building. The drawback of such an infrastructure-based approach is that the deployment and calibration of the system are costly and labor-intensive. Some prior studies proposed the use of Pedestrian Dead Reckoning (PDR) for indoor localization, which does not require the deployment of beacon nodes. In a PDR system, a small number of sensors are put on the pedestrian. These sensors (such as a G-sensor and gyroscope) are used to estimate the distance and direction that a user travels. The effectiveness of a PDR system lies in its success in accurately estimating the user’s moving distance and direction. In this work, we propose a novel waist-mounted based PDR that can measure the user’s step lengths with a high accuracy. We utilize vertical acceleration of the body to calculate the user’s change in height during walking. Based on the Pythagorean Theorem, we can then estimate each step length using this data. Furthermore, we design a map matching algorithm to calibrate the direction errors from the gyro using building floor plans. The results of our experiment show that we can achieve about 98.26% accuracy in estimating the user’s walking distance, with an overall location error of about 0.48 m. Full article
