Digital twin models utilising point cloud data have received significant attention for efficient bridge maintenance and performance assessment. There are some studies that show finite element (FE) models from point cloud data. While most of those approaches focus on modelling by solid elements, modelling of some civil structures, such as bridges, requires various uses of beam and shell elements. This study proposes a systematic approach for constructing shell element FE models from point cloud data of thin-walled structural members. The proposed methodology involves k-means clustering for point cloud segmentation into individual plates, principal component analysis for neutral plane estimation, and edge detection based on normal vector variations for geometric structure determination. Validation experiments using point cloud data of a steel corner specimen revealed dimensional errors up to 5 mm and angular errors up to 6°, but static load analysis demonstrated good accuracy with maximum displacement errors within 3.8% and maximum stress errors within 7.7% compared to nominal models. Additionally, the influence of point cloud data quality on FE model geometry and analysis results was evaluated based on geometric accuracy and point cloud density metrics, revealing that significant variations in density within the same surface lead to reduced neutral plane estimation accuracy. Furthermore, toward practical application to actual bridge structures, on-site measurements and quality evaluation of point cloud data from a steel plate girder bridge were conducted. The results showed that thickness errors in the bridge data reached up to 2 mm, while surface deviation RMSE ranged from 3 to 5 mm. This research contributes to establishing practical FE modelling procedures from point cloud data and providing a model validation framework that ensures appropriate abstraction in structural analysis. Full article

The dynamic characteristics of super-large-diameter twin tunnels under train vibration loads have become a critical issue affecting not only the engineering safety of their own tunnels but also adjacent tunnels. A numerical model of super-large-diameter (D = 15.2 m) twin tunnels was established by the discrete element method (DEM) to analyze the static and dynamic responses of adjacent tunnel structures and surroundings under train-induced vibrations. Three parameters were considered: internal walls, absolute and relative spacing, and water pressure. The results indicate that internal walls in super-large twin tunnels can significantly reduce the static and dynamic responses in both the structures and surroundings of the adjacent tunnel. The vehicular lane board (wall2) plays a determinative role, followed by the smoke exhaust board (wall1), while the left and right partition walls (wall3 and wall4) exhibit the least effectiveness. The static–dynamic responses of the liners and surroundings of adjacent tunnels in super-large twin tunnels are significantly greater than those in smaller twin tunnels when the absolute spacing is identical. Moreover, the significant differences in displacement and velocity between the liners and surroundings can lead to cracks, leakage, or even instability. Appropriate water pressure (149 kPa) can effectively mitigate dynamic responses in adjacent tunnel structures and surroundings. The dynamic characteristics of super-large-diameter twin tunnels differ markedly from those of small-diameter twin tunnels, with internal walls, twin tunnel spacing, and water pressure all influencing their static and dynamic behaviors. This study provides theoretical guidance for the design and operation of super-large-diameter twin tunnels. Full article

Background: In recent years, more and more numerical tools have been utilized in medicine in or-der to assist the evaluation and decision-making processes for complex clinical cases. Towards this direction, Finite Element Models (FEMs) have emerged as a pivotal tool in medical research, particularly in simulating and understanding the complex fluid and structural behaviors of the circulatory system. Furthermore, this tool can be used for the calculation of certain risks regarding the function of the blood vessels. Methods: The current study developed a computational tool utilizing the finite element method in order to numerically evaluate stresses in aortas with abdominal aneurysms and provide the necessary data for the creation of a patient-specific digital twin of an aorta. More specifically, 12 different cases of aortas with abdominal aneurysms were examined and evaluated. Results: The first step was the 3D reconstruction of the aortas trans-forming the DICOM file into 3D surface models. Then, a finite element material model was developed simulating accurately the mechanical behavior of aortic walls. Conclusions: Through the results of these finite element analyses the values of tension, strain, and displacement were quantified and a rapid risk assessment was provided revealing that larger aneurysmatic regions elevate the risk of aortic rupture with some cases reaching an above 90% risk. Full article

Optimizing energy efficiency in existing buildings can yield substantial savings, though collecting the necessary data for energy modelling often poses challenges. This study developed a flexible, room-level framework for evaluating retrofit strategies using simplified energy models. The approach, based on the RC model, estimated parameters from readily available data such as solar radiation, indoor and outdoor temperatures, and heating system characteristics. The model was validated through case studies of an office and a daycare room in Denmark, guiding energy retrofit decisions. Results showed that adding roof insulation provided greater energy savings compared to wall insulation. A multi-objective optimization was employed to balance energy efficiency and thermal comfort, achieving a 6.58% reduction in energy demand during January while maintaining occupant comfort for 744 h. This framework not only facilitates building–energy retrofitting but also supports the development of digital twins and operational optimization, improving both energy performance and indoor environmental quality. Full article

Given the significant damage caused by earthquakes over the years, accurate prediction and assessment of the extent of structural damage is critical to ensure safety and guide post-disaster recovery efforts. This study examines the effectiveness and reliability of various damage indexes for reinforced concrete buildings, particularly in the context of seismic events. It highlights the potential of these indexes for future use in digital twin applications or for direct analysis of sensor data recorded during an earthquake, with the ultimate goal of improving real-time damage assessment and decision making. A comprehensive literature review was carried out looking at the damage indexes developed over the last decades. These indexes were applied to a case study involving an RC building with three different structural configurations: a pre-code moment-resisting frame, a code-compliant moment-resisting frame, and a code-compliant shear wall system, both bare and infilled with masonry. The seismic performance of these configurations was evaluated using Multi-Stripe Analyses (MSA) to account for the variability of the seismic input. The results of applying the damage indexes highlight the versatility of these indexes in detecting damage, although some limitations were noted, particularly with cycle-related indicators and their application to infilled structures. The study emphasizes the importance of refining these tools to improve their accuracy and reliability in different structural contexts, ultimately contributing to more accurate seismic damage assessment and damage prediction for specific seismic scenarios. Full article

The need to refuel future missions to Mars and the Moon via in situ resource utilization (ISRU) requires the development of LOX/LCH4 engines, which are complex and expensive to develop and improve. This paper discusses how the use of digital engineering—specifically physics-based modeling (PBM)—can aid in developing, testing, and validating a LOX/LCH4 engine. The model, which focuses on propulsion performance and heat transfer through the engine walls, was created using Siemens’ STAR-CCM+ CFD tool. Key features of the model include Eulerian multiphase physics (EMP), complex chemistry (CC) using the eddy dissipation concept (EDC), and segregated solid energy (SSE) for heat transfer. A comparison between the complete GRI 3.0 and Lu’s reduced combustion mechanisms was performed, with Lu’s mechanism being chosen for its cost-effectiveness and similar output to the GRI mechanism. The model’s geometry represents 1/8th of the engine’s volume, with a symmetric rotational boundary. The performance of this engine was investigated using NASA’s chemical equilibrium analysis (CEA) and STAR-CCM+ simulations, focusing on thrust levels of 125 lbf and 500 lbf. Discrepancies between theoretical predictions and simulations ranged from 1.4% to 28.5%, largely due to differences in modeling assumptions. While NASA CEA has a zero-dimensional, steady-state approach based on idealized conditions, STAR-CCM+ accounts for real-world factors such as multiphase flow, turbulence, and heat loss. For the 125 lbf case, a 9.2% deviation in combustion chamber temperature and a 15.0% difference in thrust were noted, with simulations yielding 113.48 lbf compared to the CEA’s 133.52 lbf. In the 500 lbf case, thrust reached 488 lbf, showing a 2.4% deviation from the design target and an 8.6% increase over CEA predictions. Temperature and pressure deviations were also observed, with the highest engine wall temperature at the nozzle throat. Monte Carlo simulations revealed that substituting LNG for LCH4 affects combustion dynamics. The findings emphasize the need for advanced modeling approaches to enhance the prediction accuracy of rocket engine performance, aiding in the development of digital twins for the CROME. Full article

The continuous retained-mandrel rolling process is a promising method for titanium tube production with high efficiency and a short process. The importance of mandrel as a deformation tool supporting the inner wall is crucial. This paper thoroughly examines the influence of mandrel velocity on the deformation characteristics at the groove vertex using three approaches: numerical simulation, shear-deformation observation experiments, and microstructure analysis. The following conclusions are drawn: Decreasing the mandrel velocity enhances the penetration of shear deformation into the inner wall of the titanium tube, improves thickness uniformity, and shifts the deformation mechanism near the inner wall from twinning to dislocation slip. As a result, the volume fraction of recrystallization increases from 18.4% to 42.3%. However, the mean shear strain increases first and then decreases to a certain value as the mandrel speed decreases, which is attributed to the combined influence of the cross-shear zone and the rolling force. Full article

Brittle fractures of iron and steel above twinning temperatures are caused by cementite grain boundary wall cracks. These were revealed by an Atomic Force Microscope (AFM). At temperatures below the ductile–brittle transition (DBT), cracks must propagate longitudinally within cementite walls until the stress is sufficiently high for the cracks to propagate across ferrite grains. Calculations using these concepts correctly predict the stress and temperature at the DBT required for fractures to occur. At temperatures above the DBT for hypoeutectoid ferritic steels, dislocations must fracture the walls transversely. That will permit pent-up dislocations to pass through the fractured region of the walls into the adjoining grains. Subsequently, there is rapid multiplication of dislocations at the opposite side of the walls by emission. This causes a rapid drop in stress toward the lower yield point. Here, the walls completely surround all of the grains. Where the walls are segmented, such as in iron, dislocations can pass around the walls, resulting in a gradual change from elastic to plastic deformation. The Cottrell atmosphere theory of yielding is not supported experimentally. It was the best available until later experiments, including those using the AFM, were performed. Methods are presented here giving yield strength versus temperature and also the parameters for the Hall–Petch and Griffith equations. Full article

A novel Ni-Co-Cr-based medium-entropy superalloy with a high Si content (7.5 at%) strengthened by an L1₂ phase was developed. The pure L1₂ phase, characterized by an average size of 50 nm and a volume fraction of 46%, was precipitated within the FCC matrix. This alloy exhibits excellent mechanical properties over a wide range of temperatures from 77 K to 1073 K. A yield strength of 1005 MPa, an ultimate tensile strength of 1620 MPa, and a tensile elongation of 36% were achieved at 77 K, with a maximum value of 4.8 GPa at the second stage of the work-hardening rate. The alloy maintains a basically consistent yield strength of approximately 800 MPa from 298 K to 973 K, showcasing significant strain-hardening capabilities, with values of 2.5 GPa, 3.7 GPa, and 4.8 GPa at 873 K, 298 K, and 77 K, respectively. Microscopic analysis revealed that at room and cryogenic temperatures, multilayer stacking faults (SFs), SF bands, and SF networks, rather than twins, effectively stored a large number of dislocations and impeded dislocation movement, thereby enhancing the work-hardening ability of the alloy. Furthermore, at 773 K, the primary deformation mechanism involved high-density dislocation walls (HDDWs) consisting of dislocation tangles and SF lines. As the temperature rose to 973 K, the work-hardening process was influenced by the APB shearing mechanism (in the form of dislocation pairs), SF lines, and microtwins generated through atomic rearrangement. This study not only provides valuable insights for the development of new oxidation-resistant superalloys but also enhances our understanding of high-temperature deformation mechanisms. Full article

Pinch milling is a new technique for slender and long blade machining, which can simultaneously improve the machining quality and efficiency. However, two-cutter orientation planning is a major challenge due to the irregular blade surfaces and the structural constraints of nine-axis machine tools. In this paper, a method of twin-tool smoothing orientation determination is proposed for a thin-walled blade with pinch milling. Considering the processing status of the two cutters and workpiece, the feasible domain of the twin-tool axis vector and its characterization method are defined. At the same time, an evaluation algorithm of global and local optimization is proposed, and a smoothing algorithm is explored within the feasible domain along the two tool paths. Finally, a set of smoothly aligned tool orientations are generated, and the overall smoothness is nearly globally optimized. A preliminary simulation verification of the proposed algorithm is conducted on a turbine blade model and the planning tool orientation is found to be stable, smooth, and well formed, which avoids collision interference and ultimately improves the machining accuracy of the blade with difficult-to-machine materials. Full article

Aluminum–magnesium (Al–Mg) alloys, known for their lightweight properties, are extensively utilized and crucial in the advancement of wire and arc additive manufacturing (WAAM) for direct high-quality printing—a focal point in additive manufacturing research. This study employed 1.2 mm ER5356 welding wire as the raw material to fabricate two sets of 30-layer thin-walled structures. These sets were manufactured using two distinct welding modes, speed-twin pulse (STP) and twin pulse (TP). Comparative evaluations of the surface quality, microstructures, and mechanical properties of the two sets of samples indicated that both the STP and TP modes were suitable for the WAAM of Al–Mg alloys. Analyses of grain growth in the melt pools of both sample sets revealed a non-preferential grain orientation, with a mixed arrangement of equiaxed and columnar grains. The STP mode notably achieved a refined surface finish, a reduced grain size, and a slight increase in tensile strength compared to the TP mode. From the comparison of the tensile data at the bottom, middle, and top of the two groups of samples, the additive manufacturing process in the STP mode was more stable. Full article

Stainless steel (SS) exhibits excellent ductility; however, its low strength hinders its practical applications. To achieve good synergy between strength and ductility, a heterogeneous structure was introduced into a newly developed nitrogen-alloyed low-nickel austenitic steel, QN1803. The received QN1803 was cold-rolled and annealed at 993 K for different durations, and the microstructural evolution and tensile mechanical properties were investigated. The yield strength (1130 MPa) of the QN1803 annealed at a temperature of 993 K for 15 min was approximately three times higher than that of the as-received sample (314 MPa). The short annealing time of 15 min yielded a heterogeneous structure with grain size distributions ranging from nanoscale to micron-scale. The annealed QN1803 exhibited typical dislocation cells and dislocation walls caused by slipping after cold rolling. During annealing, a step-like lamellar structure is formed. The high yield strength was obtained from the large number of twins and hard ultrafine grains. The good ductility is due to the large number of dislocations generated in the soft grains and the GNDs around the heterogeneous interfaces. Additionally, the lamella structure of the material also contributes to improved ductility to a certain degree. The aim of this paper is to develop new materials with both high yield strength and excellent toughness based on more economical materials cost. Full article

Fe-Mn-Al-C lightweight steels have been of significant interest due to their excellent mechanical properties and unique microstructures. However, there has been limited focus on the dynamic deformation. Here, we systematically investigate the mechanical responses over various strain rates and corresponding microstructure evolution in quasi-static and dynamic compression to reveal the transition of deformation mechanisms. The present lightweight steel exhibits a significant strain rate effect, with the yield strength increasing from 735.8 to 1149.5 MPa when the strain rate increases from 10⁻³ to 3144 s⁻¹. The deformation in ferrite under high-strain-rate loading is dominated by wave slip, forming a cellular structure (cell block). Meanwhile, the deformation in austenite is dominated by planar slip, forming dislocation substructures such as high-density dislocation walls and microbands. In addition, the deformation twinning (including secondary twinning)- and microband-induced plasticity effects are responsible for the excellent dynamic compression properties. This alloy delays damage location while maintaining high strength, making it ideal for shock loading and high-strain-rate applications. The Johnson–Cook (J–C) constitutive model is used to predict the deformation behavior of lightweight steel under dynamic conditions, and the J–C model agrees well with the experimental results. Full article

An intraluminal thrombus (ILT) is present in the majority of abdominal aortic aneurysms, playing a crucial role in their growth and rupture. Although most computational studies do not include the ILT, in the present study, this is taken into account, laying out the whole simulation procedure, namely, from computed tomography scans to medical image segmentation, geometry reconstruction, mesh generation, biomaterial modeling, finite element analysis, and post-processing, all carried out in open software. By processing the tomography scans of a patient’s aneurysm before and after rupture, digital twins are reconstructed assuming a uniform aortic wall thickness. The ILT and the aortic wall are assigned different biomaterial models; namely, the first is modeled as an isotropic linear elastic material, and the second is modeled as the Mooney–Rivlin hyperelastic material as well as the transversely isotropic hyperelastic Holzapfel–Gasser–Ogden nonlinear material. The implementation of the latter requires the designation of local Cartesian coordinate systems in the aortic wall, suitably oriented in space, for the proper orientation of the collagen fibers. The composite aneurysm geometries (ILT and aortic wall structures) are loaded with normal and hypertensive static intraluminal pressure. Based on the calculated stress and strain distributions, ILT seems to be protecting the aneurysm from a structural point of view, as the highest stresses appear in the thrombus-free areas of the aneurysmal wall. Full article

Climate-change-induced unpredictable weather patterns are adversely affecting global agricultural productivity, posing a significant threat to sustainability and food security, particularly in developing regions. Wealthier nations can invest substantially in measures to mitigate climate change’s impact on food production, but economically disadvantaged countries face challenges due to limited resources and heightened susceptibility to climate change. To enhance climate resilience in agriculture, technological solutions such as the Internet of Things (IoT) are being explored. This paper introduces a digital twin as a technological solution for monitoring and controlling temperatures in a greenhouse tunnel situated in Stellenbosch, South Africa. The study incorporates an aeroponics trial within the tunnel, analysing temperature variations caused by the fan and wet wall temperature regulatory systems. The research develops an analytical model and employs a support vector regression algorithm as an empirical model, successfully achieving accurate predictions. The analytical model demonstrated a root mean square error (RMSE) of 2.93 °C and an $R^2$ value of 0.8, while the empirical model outperformed it with an RMSE of 1.76 °C and an $R^2$ value of 0.9 for a one-hour-ahead simulation. Potential applications and future work using these modelling techniques are then discussed. Full article
