Search Results (19)

In response to the challenges of detecting and forecasting adverse geological bodies and water inrush risks in long tunnels, this paper, based on the comprehensive analysis of seismic reflection waves and electroseismic effect coupling, has achieved a long-distance tunnel construction process, adverse geological detection, and early warning, and has realized precise forecasting of the scale and location of adverse water-containing bodies. Meanwhile, the transient electromagnetic theory and technology for detecting the position and scale of water-containing bodies have been proposed, achieving medium-distance water inrush risk detection. Finally, for water-containing bodies that are close, ground penetrating radar methods are used for detection and forecasting to achieve the purpose of close-range detection and forecasting. Ultimately, a comprehensive detection and forecasting theory and technology for adverse geological bodies and water inrush in long tunnels using electromagnetic, seismic wave, and electroseismic multi-means at long, medium, and short distances have been established. This technology has been applied to the detection and forecasting of adverse geology and water inrush in a tunnel in Fuzhou, and good application effects have been achieved through on-site excavation verification. By multi-means comprehensive forecasting technology and early warning systems, fine detection of adverse geology and water inrush during the tunnel construction process can be achieved, providing guidance and support for the safe construction of tunnels. Full article

Modern, large bridges and tunnels represent important nodes in transportation arteries and have a significant impact on the development of transportation. The health and safety monitoring of these structures has always been a significant concern and is reliant on various types of sensors. Distributed acoustic sensing (DAS) with telecommunication fibers is an emerging technology in the research areas of sensing and communication. DAS provides an effective and low-cost approach for the detection of various resources and seismic activities. In this study, field experiments are elucidated, using DAS for the Hong Kong–Zhuhai–Macao Bridge, and for studying vehicle trajectories, earthquakes, and other activities. The basic signal-processing methods of filtering and normalization are adopted for analyzing the data obtained with DAS. With the proposed DAS technology, the activities on shore, vehicle trajectories on bridges and in tunnels during both day and night, and microseisms within 200 km were successfully detected. Enabled by DAS technology and mass fiber networks, more studies on sensing and communication systems for the monitoring of bridge and tunnel engineering are expected to provide future insights. Full article

Traditional seismic wave-based tunnel advanced geological forecasting techniques are primarily designed for drill and blast method construction tunnels. However, given the fast excavation speed and limited prediction space in tunnel boring machine (TBM) construction tunnels, traditional methods have significant technical limitations. This study analyzes the characteristics of different types of TBM construction tunnels and, considering the practical construction conditions, identifies an effective observation system and data acquisition method. To address the challenges in advanced forecasting for TBM construction tunnels, a method of ellipsoid positioning velocity analysis, which takes into account the constraints of three-component data directions, is proposed. Based on the characteristics of the advanced forecasting observation system, this method compares the maximum values on the spatial isochronous ellipsoidal surface to determine the average velocity of the geological layer rays, thereby enabling accurate inversion of the spatial distribution ahead. Utilizing numerical simulation, a model for the advanced detection of typical unfavorable geological formations is established by obtaining the wave field response characteristics of seismic waves in three-dimensional space, and the velocity structure of the model is retrieved through this velocity analysis method. In the engineering example, the fracture property, water content, and weathering degree of the surrounding rock are predicted accurately. Full article

A novel design of a MEMS (Micro-Electromechanical System) capacitive accelerometer fabricated by surface micromachining, with a structure enabling precise auto-calibration during operation, is presented. Precise auto-calibration was introduced to ensure more accurate acceleration measurements compared to standard designs. The standard mechanical structure of the accelerometer (seismic mass integrated with elastic suspension and movable plates coupled with fixed plates forming a system of differential sensing capacitors) was equipped with three movable detection electrodes coupled with three fixed electrodes, thus creating three atypical tunneling displacement transducers detecting three specific positions of seismic mass with high precision, enabling the auto-calibration of the accelerometer while it was being operated. Auto-calibration is carried out by recording the accelerometer indication while the seismic mass occupies a specific position, which corresponds to a known value of acting acceleration determined in a pre-calibration process. The diagram and the design of the mechanical structure of the accelerometer, the block diagram of the electronic circuits, and the mathematical relationships used for auto-calibration are presented. The results of the simulation studies related to mechanical and electric phenomena are discussed. Full article

Tunnel excavation induces the stress redistribution of surrounding rock. In this excavation process, the elastic strain in the rock is quickly released. When the maximum stress on the tunnel lining exceeds the concrete’s load-bearing capacity, it causes cracking of the lining. Comprehensive geophysical exploration methods, including seismic computerized tomography, the high-density electrical method, and the ultrasonic single-plane test, indicated the presence of incomplete distribution of broken rock along the tunnel axis. Based on the geophysical exploration results, a carbon-fiber-strengthened tunnel simulation model was established to analyze the mechanical characteristics of the structure and provide a theoretical basis for sensor deployment. Fiber Bragg grating (FBG) strain sensors were used to measure the stress and strain changes in the second lining concrete after carbon reinforcement. Meanwhile, one temperature sensor was installed in each section to enable temperature compensation. The monitoring results demonstrated that the stress–strain of the second lining fluctuated within a small range, and the lining did not show any crack expansion behavior, which indicated that carbon-fiber-reinforced polymer (CFRP) played an effective role in controlling the structural deformation. Therefore, the combined detection of physical exploration and FBG sensors for the structure provided an effective monitoring method for evaluating tunnel stability. Full article

The accurate detection of P-wave FAP (First-Arrival Picking) in seismic signals is crucial across various industrial domains, including coal and oil exploration, tunnel construction, hydraulic fracturing, and earthquake early warning systems. At present, P-wave FAP detection relies on manual identification by experts and automated methods using Short-Term Average to Long-Term Average algorithms. However, these approaches encounter significant performance challenges, especially in the presence of real-time background noise. To overcome this limitation, this study proposes a novel P-wave FAP detection method that employs the U-Net model and incorporates spectrogram transformation techniques for seismic signals. Seismic signals, similar to those encountered in South Korea, were generated using the stochastic model simulation program. Synthesized WGN (White Gaussian Noise) was added to replicate background noise. The resulting signals were transformed into 2D spectrogram images and used as input data for the U-Net model, ensuring precise P-wave FAP detection. In the experimental result, it demonstrated strong performance metrics, achieving an MSE of 0.0031 and an MAE of 0.0177, and an RMSE of 0.0195. Additionally, it exhibited precise FAP detection capabilities in image prediction. The developed U-Net-based model exhibited exceptional performance in accurately detecting P-wave FAP in seismic signals with varying amplitudes. Through the developed model, we aim to contribute to the advancement of microseismic monitoring technology used in various industrial fields. Full article

During the construction of a diversion tunnel, geological problems often include faults, fragile strata, hard rock formations, karst landforms, etc., which may have adverse effects on the excavation and construction of the diversion tunnel. Based on the analysis of the engineering overview, this study designed a new construction technology for the excavation of water diversion tunnels in hard rock layers and high-karst areas. Based on tunnel seismic prediction (TSP) technology to achieve advanced geological prediction, combined with actual geological conditions, construction difficulties are analyzed. Then, detection technology is used to collect two-way travel time, amplitude, and waveform data. By processing and analyzing the detection image, the spatial orientation and length of the main tunnel during the construction of the diversion tunnel are calculated. After completing the construction ventilation and wind, water, and electricity layout, the excavation construction procedure is designed. In the specific excavation design, the tunnel curtain excavation technology, tunnel body excavation and support technology, excavation grouting technology, important unfavorable geological tunnel section excavation technology, upper/lower flat section excavation technology, upper/lower curved section excavation technology, and vertical shaft section excavation technology were elaborated. Finally, a plan was made for the reuse process of slag material and a construction quality control system was established. During the testing process, it was found that the antidamage coefficient of the side wall was above 0.9 after using the technology described in this article. Therefore, it indicates that the excavation construction technology designed in this article can ensure the support capacity of the side wall of the diversion tunnel, which is suitable for the excavation of the main tunnel during the construction of the diversion tunnel. Full article

It is still challenging to anticipate with accuracy how tunnels will behave and if they will fail when subjected to an earthquake load. In this study, assuming nonlinear material behavior and a three-dimensional inelastic rock medium, the theory of damage mechanics is applied to numerical simulation to build a curved tunnel-surrounding rock model, whose correctness was verified in laboratory experiments. To better understand the influence of surrounding rock strength on the seismic performance of a curved tunnel, the stratum parameters of the curved tunnel-surrounding rock system are quantified. The findings demonstrate that the damage process in curved tunnels is a circular process of damage change, and the model accurately captures these structural aspects of the damage evolution process. In addition, structural damage can be identified using displacement detection because the displacement of a curved tunnel is directly related to its compression damage. Finally, the seismic response of the curved tunnel-surrounding rock system is studied parametrically to determine the extent to which different parameters affect the seismic response. These parameters, including elastic modulus, friction angle, cohesion, and Poisson’s ratio, are characteristics of rock-medium materials. We then created multi-factor evaluation formulas to direct the surrounding rock to reinforce. Full article

There are considerable challenges involved in studying the behavior of subterranean rodents owing to the underground nature of their ecotope. Seismic communication plays a crucial role in the behavior of subterranean rodents, particularly solitary ones. The plateau zokor (Eospalax baileyi), a solitary subterranean rodent species endemic to the Qinghai–Tibet Plateau, will usually occupy empty neighboring tunnels in order to extend their territory. Little is known, however, about the process of territorial occupation or the function of animal communication when occupation is taking place. Based on previous studies of subterranean rodent communication, we hypothesized that plateau zokors use seismic signals to detect neighboring tunnels and then occupy them when it was found their neighbors were absent. To test this, we placed artificial tunnels close to active original zokor tunnels to simulate the availability of an empty neighboring tunnel, and then the seismic signals when a zokor chose to occupy the empty artificial tunnel were recorded. The results showed that the frequency of zokors occupying artificial empty tunnels within 48 h was 7/8, In all of these instances, the zokors generated seismic signals before and after occupation of the empty artificial tunnel. The number of seismic signals generated by the zokors increased significantly (p = 0.024) when they detected and occupied the artificial tunnels, compared to those generated in their original tunnels without the presence of an artificial tunnel alongside. Inside the original tunnels, the inter-pulse time interval of the seismic signals was significantly higher (p < 0.001), the peak frequency of these signals was significantly higher (p < 0.01), and the energy of the signals was significantly lower (p = 0.006), compared with those when an artificial tunnel was positioned next to the original. The results of this study suggest that plateau zokors first generate seismic signals to detect empty neighboring tunnels and that they are empty. In the absence of neighbor plateau zokors, they occupy the empty tunnels to extend their own territory. Full article

Linear infrastructures, such as railways, tunnels, and pipelines, play essential roles in economic and social development worldwide. However, under the influence of geohazards, earthquakes, and human activities, linear infrastructures face the potential risk of damage and may not function properly. Current monitoring systems for linear infrastructures are mainly based on non-contact detection (InSAR, UAV, GNSS, etc.) and geotechnical instrumentation (extensometers, inclinometers, tiltmeters, piezometers, etc.) techniques. Regarding monitoring sensitivity, frequency, and coverage, most of these methods have some shortcomings, which make it difficult to perform the accurate, real-time, and comprehensive monitoring of linear infrastructures. Distributed acoustic sensing (DAS) is an emerging sensing technology that has rapidly developed in recent years. Due to its unique advantages in long-distance, high-density, and real-time monitoring, DAS arrays have shown broad application prospects in many fields, such as oil and gas exploration, seismic observation, and subsurface imaging. In the field of linear infrastructure monitoring, DAS has gradually attracted the attention of researchers and practitioners. In this paper, recent research and the development activities of applying DAS to monitor different types of linear infrastructures are critically reviewed. The sensing principles are briefly introduced, as well as the main features. This is followed by a summary of recent case studies and some critical problems associated with the implementation of DAS monitoring systems in the field. Finally, the challenges and future trends of this research area are presented. Full article

The Einstein Telescope will be a gravitational wave observatory comprising six nested detectors, three optimized to collect low-frequency signals, and three for high frequency. It will be built a few hundred meters under Earth’s surface to reduce direct seismic and Newtonian noise. A critical issue with the Einstein Telescope design are the three corner stations, each hosting at least one sensitive component of all six detectors in the same hall. Maintenance, commissioning, and upgrade activities on a detector will cause interruptions of the operation of the other five, in some cases for years, thus greatly reducing the Einstein Telescope observational duty cycle. This paper proposes a new topology that moves the recombination and input–output optics of the Michelson interferometers, the top stages of the seismic attenuation chains and noise-inducing equipment in separate excavations far from the tunnels where the test masses reside. This separation takes advantage of the shielding properties of the rock mass to allow continuing detection with most detectors even during maintenance and upgrade of others. This configuration drastically improves the observatory’s event detection efficiency. In addition, distributing the seismic attenuation chain components over multiple tunnel levels allows the use of effectively arbitrarily long seismic attenuation chains that relegate the seismic noise at frequencies farther from the present low-frequency noise budget, thus keeping the door open for future upgrades. Mechanical crowding around the test masses is eliminated allowing the use of smaller vacuum tanks and reduced cross section of excavations, which require less support measures. Full article

Ahead geological prospecting, which can estimate adverse geology ahead of the tunnel face, is necessary in the process of tunnel construction. Due to its long detection range and good recognition effect on the interface, the seismic method is widely used in tunnel ahead prospecting. However, the observation space in tunnels is quite narrow compared to ground seismic prospecting, which leads to some problems in the acquisition of wave velocity, including: the velocity of the direct wave is used to replace the wave velocity of the forward rock approximately; the arrival time information of seismic waves is the main factor in time-travel inversion or the tomography method, which is sufficient to provide a simple model rather than deal with complex geological conditions. In view of the above problems, the frequency domain full waveform inversion method in ground prospecting is introduced to tunnel seismic prospecting. In addition, the optimized difference format is given according to the particularity of the tunnel environment. In this method, the kinematics and dynamics of the seismic wavefield are fully used to obtain more accurate wave velocity results. Simultaneously, forward modeling and inversion simulations on tunnel samples with typical adverse geological bodies are given here, which verified the validity and reliability of the proposed method. Full article

The accurate prediction of the geological conditions ahead of a tunnel plays an important role in tunnel construction. Among all forward geological prospecting methods, the seismic detection method is widely applied. However, due to the characteristics of the tunnel and the complexity of the geological conditions, the seismic wavefield is complicated. Carrying out a more realistic forward modeling method is vital for fully understanding the law of seismic wave propagation and the characteristics of seismic wavefield in the tunnel. In this paper, the 3D staggered-grid finite-difference scheme in the cylindrical coordinate system based on the decoupled nonconversion elastic wave equation is used to carry out the numerical simulation. This method can avoid the diffraction interferences produced at the edges of the tunnel face in the Cartesian coordinate system. Based on this forward modeling method, the characteristics of wavefield and propagation laws of seismic waves under three kinds of common typical unfavorable geological models were explored, which can provide theoretical guidance to seismic data interpretation of tunnel seismic forward prospecting in practice. Full article

Development of synthetic aperture radar (SAR) technology and the dedicated suite of processing tools have aided the evolution of remote sensing techniques for various Earth Observation (EO) applications. Interferometric SAR (InSAR) is a relatively new geodetic technique which provides high-speed and reliable geographic, geologic, and hazards information allowing the prognosis of future environmental and urban planning. In this study, we explored the applicability of two differential interferometry techniques, conventional and advanced differential InSAR (A-DInSAR), for topographic mapping and long-term geotechnical monitoring by exploiting satellite data, particularly Sentinel-1 SAR data, which is publicly shared. We specifically used the open-source tools of SeNtinel Application Platform (SNAP) and Stanford Method for Persistent Scatterers (StaMPS) for interferometric data processing to implement A-DInSAR. This study presents various applications, which include generation of a digital elevation model (DEM), mapping of seismically induced displacement and associated damages, and detection and long-term monitoring of tunneling-induced ground deformation and rainfall-induced landslide. Geometric and temporal decorrelations posed challenges and limitations in the successful implementation of Sentinel-1 SAR interferometry specifically in vegetated areas. The presented results proved the validity and reliability of the exploited SAR data and InSAR techniques for addressing geotechnical engineering related problems. Full article

The tunnel seismic method allows for the detection of the geology in front of a tunnel face for the safety of tunnel construction. Conventional geophones have problems such as a narrow spectral width, low sensitivity, and poor coupling with the tunnel wall. To tackle issues above, we propose a semi-automatic coupling geophone equipped with a piezoelectric sensor with a spectral range of 10–5000 Hz and a sensitivity of 2.8 V/g. After the geophone was manually pushed into the borehole, it automatically coupled with the tunnel wall under the pressure of the springs within the device. A comparative experiment showed that the data spectrum acquired by the semi-automatic coupling geophone was much higher than that of the conventional geophone equipped with the same piezoelectric sensor. The seismic data were processed in combination with forward modeling. The imaging results also show that the data acquired by the semi-automatic coupling geophone were more in line with the actual geological conditions. In addition, the semi-automatic coupling geophone’s installation requires a lower amount of time and cost. In summary, the semi-automatic coupling geophone is able to efficiently acquire seismic data with high fidelity, which can provide a reference for tunnel construction safety. Full article
