Search Results (16)

Verticality inspection of square tower structures is of great significance for ensuring structural operational safety, extending service life, and optimizing maintenance strategies. However, conventional verticality inspection methods still exhibit deficiencies in point cloud noise suppression, removal of internal redundant points, and stable geometric feature extraction, which often lead to fluctuations in axis fitting results and fail to meet the requirements of non-contact, high-precision, and holistic perception-based verticality inspection for square tower structures. To address the above issues, this paper proposes a Dual-Cuboid Constraint Method with Marching Cubes-Based Contour Extraction for Verticality Inspection of Square Tower Structures. First, raw point cloud data of the surface of square tower structures were acquired through terrestrial LiDAR multi-station scanning. After preprocessing, including point cloud registration, coordinate system unification, redundancy removal, and denoising, high-precision effective point cloud data were obtained in a unified station-centered spatial coordinate system. Subsequently, the initial body center point coordinates and principal axis directions of the standard segment point clouds were determined using the principal axis projection method. Based on these results, a dual-cuboid constraint frame was constructed, and the shell point clouds of the standard segments were extracted through outer-frame enclosure and inner-frame exclusion. The principal axis projection method was then applied again to calculate the body center point coordinates of the shell point cloud for each standard segment. The central axis of the body center point set was subsequently fitted using the least squares method to determine the unit direction vector of the structural central axis. Finally, within the station-centered spatial coordinate system, vector operations were performed between the unit direction vector and the $x$-axis and $z$-axis, respectively, to calculate the tilt attitude parameters of the square tower structure, including the azimuth angle of inclination, the inclination angle, and the verticality. The detection results obtained from different schemes were then comparatively evaluated using the relative error metric. Field validation was conducted on a tower crane at a construction site in Beijing. Four dual-cuboid constraint frame schemes with dimensional errors of 20 mm, 40 mm, 60 mm, and 80 mm were designed. Furthermore, based on the experimental process of the method presented in this paper, an unconstrained solution was established as a comparison experiment, and it was compared with the two reference experiments based on the Marching Square algorithm and the RANSAC algorithm. The results indicated that the tower-body verticality values obtained using the four dual-cuboid constraint frame schemes with different dimensional errors were 3.48‰, 3.63‰, 3.60‰, and 3.82‰, respectively, with a mean value of 3.63‰ and a range of only 0.34‰. The verticality results obtained from the four constrained schemes were generally consistent and showed good agreement with those obtained from 3.03‰ and 3.14‰, and reasonable proximity to the result obtained from 2.82‰, respectively. The results further suggest that the proposed dual-cuboid constraint frame contributes to improving the stability of point cloud feature extraction and central axis fitting, and yields generally consistent detection results across different dimensional error parameters, indicating that the method exhibits robustness to variations in the constraint-frame dimensions within the tested parameter ranges. Full article

Transmission towers are typically composed of angle steel members connected by ordinary bolts to form spatial truss systems, in which joint slip under axial loading can significantly influence structural performance. In subsidence areas, corrective lifting of tilted towers may cause internal force redistribution, transforming some compression members into tension members and resulting in joints subjected to both compressive and tensile forces. To investigate the slip deformation behavior of angle steel bolted connections under bidirectional axial loading, a series of experiments was conducted on specimens with different angle sizes and bolt numbers, complemented by finite element analysis. The results show that the load–slip relationship exhibits distinct staged characteristics, which can be divided into an initial linear stage, a slip stage, and a hole-bearing stage. The initial slip displacement is generally less than 1 mm, while the slip load and ultimate capacity increase significantly with bolt number, with the ultimate capacity under tension increasing by up to approximately 160% as the number of bolts increases from one to three. Although the slip evolution under compression and tension is generally similar, pronounced differences appear near the ultimate state, indicating a clear directional asymmetry. Based on these findings, a three-stage piecewise mechanical model is established, and a simplified bidirectional slip model is proposed by introducing asymmetric ultimate displacement and capacity parameters. Finite element simulations reproduce the failure modes and load–slip responses with good agreement, confirming the validity of the proposed model. The findings provide a useful reference for the design and performance evaluation of angle steel bolted connections in transmission tower structures. Full article

Conducting regular verticality inspections for thin tower structures is essential for ensuring structural safety, extending service life, and optimizing operation and maintenance strategies. However, the traditional theodolite inspection method, as a commonly used technique for verticality assessment, still has certain limitations, including strict requirements for station setup, the need for high-altitude contact-based operations, and difficulty in accurately resolving the tilt azimuth of the central axis. More importantly, the conventional method provides insufficient understanding of the overall verticality geometric characteristics of thin tower structures, particularly lacking in systematic approaches for characterizing the axis morphology under non-contact, full three-dimensional (3D) perception conditions. Therefore, this study proposes a refined method for inspecting the verticality of thin tower structures using the Marching Square algorithm. The tower body of a tower crane was selected as the experimental subject. Firstly, ground-based LiDAR was employed to scan and acquire the raw point cloud data of the tower crane. After point cloud registration and denoising, high-precision and valid point cloud data of the tower body were obtained. Secondly, a cross-sectional slicing segmentation strategy was designed for the point cloud of the tower body standard sections, and a slice-polygon-contour extraction method based on the Marching Square algorithm was proposed to extract the contour vertices and compute the coordinates of the contour centroids. Finally, a spatial line-fitting algorithm based on the least squares method was proposed to fit a 3D line to the coordinates of the contour centroids, thereby determining the direction vector of the central axis. The direction vector was then subjected to vector operations with the x-axis and z-axis in the station-center space coordinate system to derive the tilt azimuth and tilt angle of the central axis, thereby providing the verticality inspection results of the tower crane. The experimental results indicate that the four cross-section slicing segmentation schemes designed using the proposed method in this study yielded tower crane verticality values of 2.45‰, 2.35‰, 2.20‰, and 2.18‰. All verticality values meet the verticality requirement of no more than 4‰ specified in GB/T 5031-2019 (Tower Cranes). This verifies that the proposed method is feasible and effective, providing a novel, high-precision, and non-contact inspection method for inspecting the anti-overturning stability of thin tower structures. Full article

Transmission towers located above mined-out areas may experience collapse or instability due to mining-induced ground subsidence and deformation, which poses significant risks to the safe operation of power transmission lines. To clearly evaluate the deformation resistance and failure threshold of transmission towers under mining-induced ground deformation, this article examines a typical 220 kV self-supporting transmission tower located in a mining area of Northern Shaanxi Province through a detailed three-dimensional finite element model constructed and simulated using ANSYS 2022. The mechanical response and failure process of the tower structure were systematically simulated under five typical deformation conditions: tilt, horizontal compression, horizontal tension, tilt–compression, and tilt–tension. The results indicate that under individual deformation conditions, the critical deformation values of the tower are 35 mm/m for tilt, 10 mm/m for horizontal compression, and 8 mm/m for horizontal tension, demonstrating that the structure is most sensitive to horizontal tensile deformation. Under combined deformation conditions, the critical deformation values for the combined tilt–compression and tilt–tension conditions exhibited a marked reduction, reaching 8 mm/m and 6 mm/m. Compared to individual deformation conditions, transmission towers demonstrate a significantly higher susceptibility to structural failure under combined deformation conditions. The displacement at the tower head and the tower tilt angle exhibit a linear positive correlation with the values of ground surface deformation. Under individual deformation conditions, the tilt of the tower was approximately 0.903 times the tilt deformation value and 0.089 times the values of horizontal compression and tension deformation, indicating that tilt deformation exerts a more pronounced influence on the inclination of the tower. Under combined deformation conditions, the tilt of the tower reached approximately 0.981 times that of the tilt–compression deformation value and 0.829 times that of the tilt–tension deformation value. Compared to the tower tilt induced individually by horizontal compression or tension deformation, the tilt under combined deformation conditions demonstrated a significantly greater value. Under mining-induced ground deformation, a redistribution of support reactions occurs, exhibiting either nonlinear or linear increasing trends depending on the type of deformation. The findings of this article provide a theoretical basis and data support for disaster prevention and control, safety evaluation, and structural design of transmission lines in mining areas. Full article

Wind energy’s crucial role in global sustainability necessitates efficient wind turbine maintenance, traditionally hindered by labor-intensive, risky manual inspections. UAV-based inspections offer improvements yet often lack adaptability to dynamic conditions like blade pitch and wind. To overcome these limitations and enhance inspection efficacy, we introduce the Dynamic Trajectory Adaptation Method (DyTAM), a novel approach for automated wind turbine inspections using UAVs. Within the proposed DyTAM, real-time image segmentation identifies key turbine components—blades, tower, and nacelle—from the initial viewpoint. Subsequently, the system dynamically computes blade pitch angles, classifying them into acute, vertical, and horizontal tilts. Based on this classification, DyTAM employs specialized, parameterized trajectory models—spiral, helical, and offset-line paths—tailored for each component and blade orientation. DyTAM allows for cutting total inspection time by 78% over manual approaches, decreasing path length by 17%, and boosting blade coverage by 6%. Field trials at a commercial site under challenging wind conditions show that deviations from planned trajectories are lowered by 68%. By integrating advanced path models (spiral, helical, and offset-line) with robust optical sensing, the DyTAM-based system streamlines the inspection process and ensures high-quality data capture. The dynamic adaptation is achieved through a closed-loop control system where real-time visual data from the UAV’s camera is continuously processed to update the flight trajectory on the fly, ensuring optimal inspection angles and distances are maintained regardless of blade position or external disturbances. The proposed method is scalable and can be extended to multi-UAV scenarios, laying a foundation for future efforts in real-time, large-scale wind infrastructure monitoring. Full article

Armillary spheres were developed in the East and the West for a long time. They independently developed various functions for astronomy. In this article, we discuss the differences in mechanical structures, appearance, and functions between the armillary spheres in ancient China and Europe. The earliest armillary sphere in ancient China was invented by Luo Xia Hong (落下閎) between 156 BC and 87 BC. Then, the armillary sphere in ancient China improved with the historical development of astronomy. The famous armillary sphere was built in an astronomical clock tower (水運儀象台) by Su Song (蘇頌) in the Song (宋) dynasty. This armillary sphere was an astronomical apparatus for the observation of celestial phenomena and the correction of time standards. However, the armillary sphere in Europe had different applications, even though the structures were similar. The armillary spheres in Europe simulated the sun’s trajectory in one day to predict the sunrise and sunset positions. They adjusted the tilting angle of the celestial sphere with the altitude of observation to observe the path of the stars around the ecliptic. Through this review, the armillary spheres in ancient China and Europe are defined clearly. Full article

Unlike traditional building structures, transmission tower foundations endure significant vertical and horizontal loads, with particularly high uplift resistance requirements in complex terrains. Moreover, challenges such as difficult material transport and low construction efficiency arise in these regions. This study, based on practical projects, proposes a novel high uplift resistance prestressed concrete prefabricated foundation (HURPCPF) tailored for transmission line systems in complex terrains. A refined finite element model is developed using ABAQUS to analyze its performance under uplift, compressive, and horizontal loads. Comparative studies with cast-in-situ concrete foundations evaluate the HURPCPF’s bearing capacity, while parametric analysis explores the impacts of foundation depth and dimensions. The results show that the proposed HURPCPF exhibits a linear load–displacement relationship, with uniform deformation and good integrity under compressive and uplift conditions. During overturning, the tilt angle is less than 1/500, meeting safety standards. The design of prestressed steel strands and internal reinforcement effectively distributes tensile stress, with a maximum stress of 290 MPa, well below the yield stress of 400 MPa. Compared to cast-in-situ concrete foundations, the displacement at the top of the HURPCPF’s column differs by less than 7%, indicating comparable bearing performance. As foundation depth and size increase, vertical displacement of the HURPCPF decreases, enhancing its uplift resistance. Full article

This study introduces a novel approach to wind energy by investigating a novel Active Axis Wind Turbine design. The turbine is neither a horizontal nor vertical axis wind turbine but has an axis of operation that can actively change during operation. The design features a rotor with a single blade capable of dynamic pitch and tilt control during a single rotor rotation. This study examines the potential to balance the centrifugal and aerodynamic lift forces acting on the rotor blade assembly, significantly reducing blade, tower, foundation and infrastructure costs in larger-scale devices and decreasing the levelised cost of energy for wind energy. The design of a laboratory prototype rotor assembly is optimised by varying the masses and lengths in a lumped mass model to achieve equilibrium between centrifugal and lift forces acting on the turbine’s rotor assembly. The method involves an investigation of the variation of blade pitch angle to provide a balance between centrifugal and aerodynamic forces, thereby facilitating the cost advantages and opening the opportunity to improve the turbine efficiency across a range of operation conditions. The implication of this study extends to different applications of wind turbines, both onshore and offshore, introducing insight into innovation for sustainable energy and cost-effective solutions. Full article

Ensuring the safety of transmission line towers is vital for human safety, power supply, economic development, and environmental protection. This study specifically examines how temperature affects tower inclination. Multifractal detrended cross-correlation analysis (MF-DCCA) is a combination of multifractal detrended fluctuation analysis (MF-DFA) and DCCA that reveals the multifractal features of two cross-correlated non-stationary signals. This paper adopts the MF-DCCA tool to investigate the cross-correlations between the internal temperature of an inclination sensor device and the posture of a transmission line tower. The tilt angle data in the x- and y-axes are used to measure the posture of the transmission line tower. We start by using Pearson correlation to assess the relationship between temperature and two inclination angles, followed by verifying their correlation with a p-value below $0.05$ using first-order linear fitting. We initially assess the multifractal features of three time series using MF-DFA before MF-DCCA analysis. All exhibit multifractal traits with $H\left(2\right)<0.5$, indicating negative persistence, especially notable in the temperature series. Finally, we adopt the MF-DCCA approach to examine the multifractal cross-correlation between tilt-angle time series and temperature time series, and the results indicate the negative persistence of the cross-correlation between the time series. Furthermore, the multifractal cross-correlation of temperature and inclination data on the y-axis was also found to be stronger than on the x-axis based on features of the scaling exponent and symmetry exponent. Full article

Field-tower-based observations were used to estimate the Doppler velocity of deep water plunging breaking waves. About 1000 breaking wave events observed by a synchronized video camera and dual-polarization Doppler continuous-wave Ka-band radar at incidence angles varying from 25 to 55 degrees and various azimuths were analyzed using computer vision methods. Doppler velocities (DVs) associated with breaking waves were, for the first time, directly compared to whitecap optical velocities measured as the line-of-sight projection of the whitecap velocity vector (LOV). The DV and LOV were found correlated; however, the DV was systematically less than the LOV with the ratio dependent on the incidence angle and azimuth. The largest DVs observed at up-wave and down-wave directions were accompanied by an increase of the cross-section polarization ratio, HH/VV, up to 1, indicating a non-polarized backscattering mechanism. The observed DV was qualitatively reproduced in terms of a combination of fast specular (coherent) and slow non-specular (incoherent) returns from two planar sides of an asymmetric wedge-shaped breaker. The difference in roughness and tilt between breaker sides (the front face was rougher than the rear face) explained the observed DV asymmetry and was consistent with previously reported mean sea surface Doppler centroid data and normalized radar cross-section measurements. Full article

The stability of transmission tower bases is key to ensuring the safe operation of power lines. This paper proposes a joint displacement-control technique for foundation-inclined piles and prestressed foundation tie beams to address the problem of tower base displacement and durability degradation caused by environmental factors. A finite element model of an exposed-pile transmission tower conforming to the structural characteristics of the actual line tower was established based on the current situation of Tower 292 of the ±800 kV Tianzhong line in Xinjiang, China. Three different displacement-control schemes were analyzed under the combined effects of tower line load, ice-cover load, and wind load, including changing exposed pile height, changing inclined pile tilt angle, and increasing the prestressed foundation tie beam. The analysis shows that the combined displacement-control technology of foundation-inclined piles and prestressed foundation tie beams can reduce the horizontal displacement of EHV tower foundations by more than 50%, which greatly reduces safety problems caused by tower displacement and effectively improves tower durability. Full article

In this paper, a classification recognition algorithm for tower mechanical faults is proposed, and a multiclass central segmentation hyperplane support vector machine (CSH-SVM) is proposed to improve the existing multiclass support vector machine for problems in which a certain sample satisfies multiple hyperplanes at the same time. The tilt angle change and wind direction data were extracted using the tilt sensors and anemometers attached to the tower, and the temperature and humidity sensors, as well as real-time rainfall and water accumulation information, were combined to construct a sample of the original dataset during the operation of the tower. The unbalanced samples were improved using the synthetic minority oversampling technique (SMOTE) algorithm to construct a balanced dataset suitable for machine learning and improve the prediction accuracy of machine learning. At the same time, the support vector machine hyperplane under the one-vs-all classification principle was additionally computed, and the new hyperplane was computed via the existing hyperplane not only to solve the classification problem of the transition area under the one-vs-all classification so that the samples located in this area no longer meet two hyperplane equations at the same time, but also to reduce the probability of incorrect classification to a certain extent. Through verification, CSH-SVM can classify 15 out of 77 misclassified samples into the correct category with slightly higher computational power than the traditional one-vs-all classification SVM, which can improve the classification prediction accuracy for unbalanced tower mechanical failure datasets and make an accurate judgment on the current state of the tower through the tower data as to when the tower may generate mechanical failure, thus reducing economic loss and personal safety threats. Full article

Because wind power is connected to the grid on a large scale, frequency fluctuation in the power grid, which is defined as a system safety risk to the power grid, occurs from time to time. According to the grid code rules of China, wind turbines are required to be equipped with primary frequency modulation or inertia response control capability, which are used to support the safe and stable operation of the power grid. During the traditional frequency modulation process of the wind turbine, power limiting operation or pitch angle reservation is generally adopted to ensure that the reserved energy can be released at any time to support the frequency change in the power grid. However, the frequency support method leads to a large loss of power generation, and does not consider the coordination between mechanical load characteristics control and primary frequency modulation. In this paper, a mechanical load optimization control strategy for a wind turbine during the primary frequency modulation process, based on LIDAR (light detection and ranging) feed forward control technology, is proposed and verified. Through LIDAR feed forward control, the characteristics of incoming wind speed can be sensed in advance, with the consequence that the wind turbine can participate in, and actively control, the primary frequency modulation procedure. According to the characteristics of incoming wind, for instance the amplitude and turbulence, simultaneously, the size of the reserved pitch angle can be adjusted in real time. This kind of method, coordinating with the mechanical load of the wind turbine, can be used to reduce both the ultimate load and fatigue damage as much as possible. Finally, the mechanical load characteristics of the wind turbine with and without the control strategy are compared and studied through simulation. The research results show that the load optimization control strategy based on LIDAR feed-forward control technology can effectively reduce the fatigue and ultimate loads of the wind turbine while supporting the frequency change in the power grid; especially for the fatigue load of tower base tilt and roll bending moments, the reducing proportion will be about 4.3% and 6.3%, respectively. Full article

Transmission towers are easily affected by various meteorological and geological disasters. In this paper, a transmission tower tilt state assessment approach—based on high precision and dense point cloud from UAV LiDAR—was proposed. First, the transmission tower point cloud was rapidly located and extracted from the 3D point cloud obtained by UAV-LiDAR line patrol. A robust histogram local extremum extraction method with additional constraints was proposed to achieve adaptive segmentation of the tower head and tower body point cloud. Second, an accurate and efficient extraction and simplification strategy of the contour of the feature plane point cloud was proposed. The central axis of the tower was constrained by the contour of the feature plane through the four-prism structure to calculate the tilt angle of the tower and evaluate the state of the tower. Finally, the point cloud of tower head from UAV-based LiDAR was accurately matched with the designed tower head model from database, and a tower head state evaluation model based on matching offset parameters was proposed to evaluate tower head tilt state. The experimental results of simulation and measured data showed that the calculation accuracy of the tilt parameters of transmission tower body was better than 0.5 degrees, that the proposed method can effectively evaluate the risk of tower head with complex structure, and improve the rapid and mass intelligent perception level of the risk state of the transmission line tower, which has a wide prospects for application. Full article

With the development of the Internet of Things and information technology, a large number of inexpensive sensors are needed to monitor the state of the object. A wide variety of sensors with a low cost can be made using the difference in charge attractiveness between flexible polymers and other materials. Compared to the two solid materials, a sensor made of a solid polymer-liquid has a large contact area and low friction. A motion-balanced sensor is presented based on the polytetrafluoroethene pipe and nano-iron suspension. The effect of the concentration and volume of the nano-iron suspension on the output voltage of the sensor is analyzed. The motion-balanced sensor can be used to measure the tilt angle of the object and there is a linear relationship between the output voltage and the tilt angle. A comparison test is performed to a commercial acceleration sensor with PZT-5. The test results show that the frequency characteristics and amplitude characteristics of the motion-balanced sensor are consistent with those of the acceleration sensor. The motion-balanced sensor can be used to determine the state of exercise such as walking, running, etc. The motion-balanced sensor has broad application prospects for monitoring the bridges and power towers balance, stroke patients’ health assessment, etc. Full article
