This paper addresses the critical challenge of time management in wireless sensor networks (WSNs) applied to industrial process control. Although wireless technologies have gained ground in industrial monitoring, their adoption in control applications remains limited due to concerns around reliability and timing accuracy. This study proposes a practical, low-cost solution based on commercial off-the-shelf (COTS) components, leveraging the IEEE 802.15.4-2020 standard in Time-Slotted Channel-Hopping (TSCH) mode. A custom time management algorithm is developed and implemented on STM32 microcontrollers paired with AT86RF212B transceivers. The proposed system ensures a sub-millisecond synchronization drift across nodes by dividing communication into a structured slot frame and implementing precise scheduling and enhanced beacon-based synchronization. Validation is performed through experimental setups monitored with logic analyzers, demonstrating a time drift consistently below 600 microseconds. The results confirm the feasibility of using synchronized wireless nodes for real-time industrial control tasks, suggesting that further improvements in hardware precision could enable even tighter synchronization and broader applicability in fast and critical processes. Full article

Industry 4.0 has transformed manufacturing and automation by integrating cyber–physical systems with the Industrial Internet of Things (IIoT) for real-time monitoring, intelligent control, and data-driven decision making. The IIoT increasingly relies on IEEE 802.15.4e Time-Slotted Channel Hopping (TSCH) to achieve reliable, low-latency, and energy-efficient industrial communications. The 6TiSCH protocol stack integrates scheduling and routing to optimize transmissions for resource-constrained devices, enhancing Quality of Service (QoS) in IIoT deployments. This paper proposes an innovative adaptive and cross-layer slotframe allocation technique for 6TiSCH networks, dynamically scheduling cells based on node hop distance, queue backlog, predicted traffic load, and link quality metrics. By dynamically adapting to these parameters, the proposed method significantly improves key QoS metrics, including end-to-end latency, packet delivery ratio, and network lifetime. The mechanism integrates real-time queue backlog monitoring, link performance analysis, and energy harvesting awareness to optimize cell scheduling decisions proactively. The results demonstrate that the proposed strategy reduces end-to-end latency by up to 32%, enhances PDR by up to 27%, and extends network lifetime by up to 10% compared to state-of-the-art adaptive scheduling solutions. Full article

The emergence of the Internet of Things (IoT) has attracted significant attention in industrial environments. These applications necessitate meeting stringent latency and reliability standards. To address this, the IEEE 802.15.4e standard introduces a novel Medium Access Control (MAC) protocol called Time Slotted Channel Hopping (TSCH). Designing a centralized scheduling system that simultaneously achieves the required Quality of Service (QoS) is challenging due to the multi-objective optimization nature of the problem. This paper introduces a novel optimization algorithm, QoS-aware Multi-objective enhanced Differential Evolution optimization (QMDE), designed to handle the QoS metrics, such as delay and packet loss, across multiple services in heterogeneous networks while also achieving the anticipated service throughput. Through co-simulation between TSCH-SIM and Matlab, R2023a we conducted multiple simulations across diverse sensor network topologies and industrial QoS scenarios. The evaluation results illustrate that an optimal schedule generated by QMDE can effectively fulfill the QoS requirements of closed-loop supervisory control and condition monitoring industrial services in sensor networks from 16 to 100 nodes. Through extensive simulations and comparative evaluations against the Traffic-Aware Scheduling Algorithm (TASA), this study reveals the superior performance of QMDE, achieving significant enhancements in both Packet Delivery Ratio (PDR) and delay metrics. Full article

The Internet of Things (IoT) presents immense opportunities for driving Industry 4.0 forward. However, in scenarios involving networked control automation, ensuring high reliability and predictable latency is vital for timely responses. To meet these demands, the contemporary wireless protocol time-slotted channel hopping (TSCH), also referred to as IEEE 802.15.4-2015, relies on precise transmission schedules to prevent collisions and achieve consistent end-to-end traffic flow. In the realm of diverse IoT applications, this study introduces a new traffic-aware autonomous multi-objective scheduling function called OPTIMAOrchestra. This function integrates slotframe and channel management, adapts to varying network sizes, supports mobility, and reduces collision risks. The effectiveness of two versions of OPTIMAOrchestra is extensively evaluated through multi-run experiments, each spanning up to 3600 s. It involves networks ranging from small-scale setups to large-scale deployments with 111 nodes. Homogeneous and heterogeneous network topologies are considered in static and mobile environments, where the nodes within a network send packets to the server with the same and different application packet intervals. The results demonstrate that OPTIMAOrchestra_ch4 achieves a current consumption of 0.72 mA while maintaining 100% reliability and 0.86 mA with a 100% packet delivery ratio in static networks. Both proposed Orchestra variants in mobile networks achieve 100% reliability, with current consumption recorded at 6.36 mA. Minimum latencies of 0.073 and 0.02 s are observed in static and mobile environments, respectively. On average, a collision rate of 5% is recorded for TSCH and RPL communication, with a minimum of 0% collision rate observed in the TSCH broadcast in mobile networks. Overall, the proposed OPTIMAOrchestra scheduler outperforms existing schedulers regarding network efficiency, time, and usability, significantly improving reliability while maintaining a balanced latency–energy trade-off. Full article

The 6TiSCH protocol (IEEE 802.15.4e) is crucial for the Industrial Internet of Things (IIoT), utilizing a time-slotted channel hopping (TSCH) mode based on node distribution. In this study, we propose an innovative cell allocation strategy based on node position clustering using the K-means algorithm, specifically designed to address congestion and optimize resource distribution in the 6TiSCH network. Our mechanism effectively groups nodes into clusters, allowing for dynamic adjustment of cell capacities in congested areas by analyzing traffic patterns and the spatial distribution of nodes. This clustering approach enhances the efficiency of slot frame utilization and minimizes communication delays by reducing interference and improving routing stability. The proposed strategy leverages the clustering results to improve cell usage efficiency and reduce communication latency between nodes. By tailoring cell allocation to the specific traffic needs of each cluster, we significantly reduce packet loss, manage congestion more effectively, and enhance data transmission reliability. We evaluated the clustering method using the K-means algorithm through experiments with the 6TiSCH simulator. Additionally, we considered using objective functions in Routing Protocol for Low-Power and Lossy Networks (RPL), such as OF0 and MRHOF, to assess clustering results and their impact on throughput and packet delivery. Our method resulted in significantly improved average performance metrics. Under the OF0 routing protocol, we achieved a 30.01% latency reduction, a 15.95% faster joining time, an 8% higher packet delivery ratio, and a 13.82% throughput increase. Similarly, we observed a 12.34% improvement in packet delivery ratio, 21.06% latency reduction, 12.68% faster joining time, and 25.97% higher throughput speed with the MRHOF routing protocol. These findings highlight the effectiveness of the improved cell allocation strategy in congested 6TiSCH environments, offering a better solution for enhancing network performance in IIoT applications. Full article

Accurate localization of devices within Internet of Things (IoT) networks is driven by the emergence of novel applications that require context awareness to improve operational efficiency, resource management, automation, and safety in industry and smart cities. With the Integrated Localization and Communication (ILAC) functionality, IoT devices can simultaneously exchange data and determine their position in space, resulting in maximized resource utilization with reduced deployment and operational costs. Localization capability in challenging scenarios, including harsh environments with complex geometry and obstacles, can be provided with robust, reliable, and energy-efficient communication protocols able to combat impairments caused by interference and multipath, such as the IEEE 802.15.4 Time-Slotted Channel Hopping (TSCH) protocol. This paper presents an enhancement of the TSCH protocol that integrates localization functionality along with communication, improving the protocol’s operational capabilities and setting a baseline for monitoring, automation, and interaction within IoT setups in physical environments. A novel approach is proposed to incorporate a hybrid localization by integrating Direction of Arrival (DoA) estimation and Multi-Carrier Phase Difference (MCPD) ranging methods for providing DoA and distance estimates with each transmitted packet. With the proposed enhancement, a single node can determine the location of its neighboring nodes without significantly affecting the reliability of communication and the efficiency of the network. The feasibility and effectiveness of the proposed approach are validated in a real scenario in an office building using low-cost proprietary devices, and the software incorporating the solution is provided. The experimental evaluation results show that a node positioned in the center of the room successfully estimates both the DoA and the distance to each neighboring node. The proposed hybrid localization algorithm demonstrates an accuracy of a few tens of centimeters in a two-dimensional space. Full article

Time slotted channel hopping (TSCH) has become the standard multichannel MAC protocol for low-power lossy networks. The procedure for associating nodes in a TSCH-based network is not included in the standard and has been defined in the minimal 6TiSCH configuration. Faster network formation ensures that data packet transmission can start sooner. This paper proposes a dynamic beacon transmission schedule over the TSCH mechanism that achieves a shorter network formation time than the default minimum 6TiSCH static schedule. A theoretical model is derived for the proposed mechanism to estimate the expected time for a node to get associated with the network. Simulation results obtained with different network topologies and channel conditions show that the proposed mechanism reduces the average association time and average power consumption during network formation compared to the default minimal 6TiSCH configuration. Full article

Although wireless devices continuously gain communication capabilities, even state-of-the-art Industrial Internet of Things (IIoT) architectures, such as Internet Protocol version 6 over the Time-Slotted Channel Hopping (TSCH) mode of IEEE 802.15.4 (6TiSCH), continue to use network-wide, fixed link configurations. This presents a missed opportunity to (1) forego the need for rigorous manual setup of new deployments; and (2) provide full coverage of particularly heterogeneous and/or dynamic industrial sites. As such, we devised the Multi-Modal Minimal Scheduling Function (3MSF) for the TSCH link layer, which, combined with previous work on the routing layer, results in a 6TiSCH architecture able to dynamically exploit modern multi-modal hardware on a per-link basis through variable-duration timeslots, simultaneous transmission, and routing metric normalization. This paper describes, in great detail, its design and discusses the rationale behind every choice made. Finally, we evaluate three basic scenarios through simulations, showcasing both the functionality and flexibility of our 6TiSCH implementation. Full article

The Time-Slotted Channel Hopping (TSCH) protocol is known for its suitability in highly reliable applications within industrial wireless sensor networks. One of the most significant challenges in TSCH is determining a schedule with a minimal slotframe size that can meet the required throughput for a heterogeneous network. We proposed a Priority-based Customized Differential Evolution (PCDE) algorithm based on the determination of a collision- and interference-free transmission graph. Our schedule can encompass sensors with different data rates in the given slotframe size. This study presents a comprehensive performance evaluation of our proposed algorithm and compares the results to the Traffic-Aware Scheduling Algorithm (TASA). Sufficient simulations were performed to evaluate different metrics such as the slotframe size, throughput, delay, time complexity, and Packet Delivery Ratio (PDR) to prove that our approach achieves a significant result compared with this method. Full article

Given the improvements to network flexibility and programmability, software-defined wireless sensor networks (SDWSNs) have been paired with IEEE 802.15.4e time-slotted channel hopping (TSCH) to increase network efficiency through slicing. Nonetheless, ensuring the quality of service (QoS) level in a scalable SDWSN remains a significant difficulty. To solve this issue, we introduce the application-aware (AA) scheduling approach, which isolates different traffic types and adapts to QoS requirements dynamically. To the best of our knowledge, this approach is the first to support network scalability using shared timeslots without the use of additional hardware while maintaining the application’s QoS level. The AA approach is deeply evaluated compared with both the application traffic isolation (ATI) approach and the application’s QoS requirements using the IT-SDN framework and by varying the number of nodes up to 225. The evaluation process took into account up to four applications with varying QoS requirements in terms of delivery rate and delay. In comparison with the ATI approach, the proposed approach enhanced the delivery rate by up to 28% and decreased the delay by up to 57%. Furthermore, even with four applications running concurrently, the AA approach proved capable of meeting a 92% delivery rate requirement for up to 225 nodes and a 900 ms delay requirement for up to 144 nodes. Full article

Wireless sensor networks (WSNs) are becoming increasingly prevalent in numerous fields. Industrial applications and natural-disaster-detection systems need fast and reliable data transmission, and in several cases, they need to be able to cope with changing traffic conditions. Thus, time-slotted channel hopping (TSCH) offers high reliability and efficient power management at the medium access control (MAC) level; TSCH considers two dimensions, time and frequency when allocating communication resources. However, the scheduler, which decides where in time and frequency these communication resources are allotted, is not part of the standard. Orchestra has been proposed as a scheduler which allocates the communication resources based on information collected through the IPv6 routing protocol for low-power and lossy networks (RPL). Orchestra is a very elegant solution, but does not adapt to high traffic. This research aims to build an Orchestra-based scheduler for applications with unpredictable traffic bursts. The implemented scheduler allocates resources based on traffic congestion measured for the children of the root and RPL subtree size of the same nodes. The performance analysis of the proposed scheduler shows lower latency and higher packet delivery ratio (PDR) compared to Orchestra during bursts, with negligible impact outside them. Full article

This paper presents a multiple concurrent slotframe scheduling (MCSS) protocol for wireless power transfer (WPT)-enabled wireless sensor networks. The MCSS supports a cluster-tree network topology composed of heterogeneous devices, including hybrid access points (HAPs) serving as power transmitting units and sensor nodes serving as power receiving units as well as various types of traffic, such as power, data, and control messages (CMs). To this end, MCSS defines three types of time-slotted channel hopping (TSCH) concurrent slotframes: the CM slotframe, HAP slotframe, and WPT slotframe. These slotframes are used for CM traffic, inter-cluster traffic, and intra-cluster traffic, respectively. In MCSS, the length of each TSCH concurrent slotframe is set to be mutually prime to minimize the overlap between cells allocated in the slotframes, and its transmission priority is determined according to the characteristics of transmitted traffic. In addition, MCSS determines the WPT slotframe length, considering the minimum number of power and data cells required for energy harvesting and data transmission of sensor nodes and the number of overprovisioned cells needed to compensate for overlap between cells. The simulation results demonstrated that MCSS outperforms the legacy TSCH medium access control protocol and TSCH multiple slotframe scheduling (TMSS) for the average end-to-end delay, aggregate throughput, and average harvested energy. Full article

In this paper, we present and evaluate an ultra-wideband (UWB) indoor processing architecture that allows the performing of simultaneous localizations of mobile tags. This architecture relies on a network of low-power fixed anchors that provide forward-ranging measurements to a localization engine responsible for performing trilateration. The communications within this network are orchestrated by UWB-TSCH, an adaptation to the ultra-wideband (UWB) wireless technology of the time-slotted channel-hopping (TSCH) mode of IEEE 802.15.4. As a result of global synchronization, the architecture allows deterministic channel access and low power consumption. Moreover, it makes it possible to communicate concurrently over multiple frequency channels or using orthogonal preamble codes. To schedule communications in such a network, we designed a dedicated centralized scheduler inspired from the traffic aware scheduling algorithm (TASA). By organizing the anchors in multiple cells, the scheduler is able to perform simultaneous localizations and transmissions as long as the corresponding anchors are sufficiently far away to not interfere with each other. In our indoor positioning system (IPS), this is combined with dynamic registration of mobile tags to anchors, easing mobility, as no rescheduling is required. This approach makes our ultra-wideband (UWB) indoor positioning system (IPS) more scalable and reduces deployment costs since it does not require separate networks to perform ranging measurements and to forward them to the localization engine. We further improved our scheduling algorithm with support for multiple sinks and in-network data aggregation. We show, through simulations over large networks containing hundreds of cells, that high positioning rates can be achieved. Notably, we were able to fully schedule a 400-cell/400-tag network in less than 11 s in the worst case, and to create compact schedules which were up to 11 times shorter than otherwise with the use of aggregation, while also bounding queue sizes on anchors to support realistic use situations. Full article

Industrial Wireless Sensor Networks (IWSN) are becoming increasingly popular in production environments due to their ease of deployment, low cost and energy efficiency. However, the complexity and accuracy demanded by these environments requires that IWSN implement quality of service mechanisms that allow them to operate with high determinism. For this reason, the IEEE 802.15.4e standard incorporates the Time Slotted Channel Hopping (TSCH) protocol which reduces interference and increases the reliability of transmissions. This standard does not specify how time resources are allocated in TSCH scheduling, leading to multiple scheduling solutions. Schedulers can be classified as autonomous, distributed and centralised. The first two have prevailed over the centralised ones because they do not require high signalling, along with the advantages of ease of deployment and high performance. However, the increased QoS requirements and the diversity of traffic flows that circulate through the network in today’s Industry 4.0 environment require strict, dynamic control to guarantee parameters such as delay, packet loss and deadline, independently for each flow. That cannot always be achieved with distributed or autonomous schedulers. For this reason, it is necessary to use centralised protocols with a disruptive approach, such as Software Defined Networks (SDN). In these, not only is the control of the MAC layer centralised, but all the decisions of the nodes that make up the network are configured by the controller based on a global vision of the topology and resources, which allows optimal decisions to be made. In this work, a comparative analysis is made through simulation and a testbed of the different schedulers to demonstrate the benefits of a fully centralized approach such as SDN. The results obtained show that with SDN it is possible to simplify the management of multiple flows, without the problems of centralised schedulers. SDN maintains the Packet Delivery Ratio (PDR) levels of other distributed solutions, but in addition, it achieves greater determinism with bounded end-to-end delays and Deadline Satisfaction Ratio (DSR) at the cost of increased power consumption. Full article

Concepts such as Industry 4.0 and Cyber-Physical Systems may bring forward a new industrial revolution. These concepts require extensive connectivity far beyond what is provided by traditional industrial networks. The Industrial Internet of Things (IIoT) bridges this gap by employing wireless connectivity and IP networking. In order for wireless networks to meet the strict requirements of the industrial domain, the Time Slotted Channel Hopping (TSCH) MAC is often employed. The properties of a TSCH network are defined by the schedule, which dictates transmission opportunities for all nodes. We survey the literature for these schedulers, describe and organize them according to their operation: Centralized, Collaborative, Autonomous, Hybrid, and Static. For each category and the field as a whole, we provide a holistic view and describe historical trends, highlight key developments, and identify trends, such as the attention towards autonomous mechanisms. Each of the 76 schedulers is analyzed into their common components to allow for comparison between schedulers and a deeper understanding of functionality and key properties. This reveals trends such as increasing complexity and the utilization of centralized principles in several collaborative schedulers. Further, each scheduler is evaluated qualitatively to identify its objectives. Altogether this allows us to point out challenges in existing work and identify areas for future research, including fault tolerance, scalability, non-convergecast traffic patterns, and hybrid scheduling strategies. Full article
