An important question for turbomachine designers is how to deal with blade and flowpath geometric variabilities stemming from the manufacturing process or erosion during the component lifetime. The challenge consists of identifying where stringent manufacturing tolerances are absolutely necessary and where looser tolerances can be used as some geometric variations have little or no effects on performance while others do have a significant impact. Because numerical simulations based on Reynolds-averaged Navier–Stokes (RANS) equations are computationally expensive for a stochastic analysis, an alternative approach is proposed in which these simulations are complemented by cheaper through-flow simulations to provide a finer exploration of the range of variations, in particular in the context of robust design. The overall goal of the present study is to evaluate the adequacy of a viscous time-marching through-flow solver to predict geometric variability effects on compressor performance and, in particular, to capture the main trends. Although the computational efficiency of such a low-fidelity solver is useful for parametric studies, it is known that the involved assumptions and approximations associated with the through-flow (TF) approach introduce errors in the performance prediction. Thus, we first evaluate the model with respect to its underlying assumptions and correlations. To accomplish this, TF simulations are compared to RANS simulations applied to a modern low-pressure compressor designed by Safran Aero Boosters. On the one hand, the TF simulations are fed with the exact radial distribution of the correlation parameters using RANS input data in order to isolate the modeling error from correlation empiricism. Moreover, in the context of multi-fidelity optimization, such distributions can be predicted using the more detailed RANS simulations that are performed on selected operating points. On the other hand, correlations from the literature are assessed and improved. It is shown that the solver provides realistic predictions of performance but is highly sensitive to the underlying correlations. Then, two modeling aspects linked to the blade leading edge, namely incidence correction and camber line computation, are discussed. As geometric variability precisely at the blade leading edge has a significant impact on the performance, we assess how these two aspects influence the variability propagation in this region. Moreover, we propose a strategy to mitigate these model uncertainties, and geometric variabilities are introduced at the blade leading edge in order to quantify the resulting variation in performance. Finally, within the scope of this preliminary study, perturbations of the three-dimensional position of undeformed stator blades and deformations of the hub and shroud contours are introduced one factor at a time per simulation. Their range is defined based on the tolerance limits typically imposed in the industry and on observed manufacturing variability. It is found that the through-flow model broadly provides realistic predictions of performance variations resulting from the imposed geometric variations. These results are a promising first step towards the use of the through-flow modeling approach for geometric uncertainty quantification. Full article

The influence of the throughflow and gravity fluctuation on thermosolutal convection in an anisotropic porous bed with the Darcy–Brinkman effect is considered numerically. The critical Rayleigh numbers for the onset of stationary and oscillatory modes have been found via linear instability analysis. The impact of various gravitational functions in the presence of throughflow on stability is studied. The analysis has been carried out for decreasing and increasing gravity fluctuations. The convective problem has been numerically analyzed using a single-term Galerkin approach. The results show that the mechanical anisotropy parameter and Lewis number have a destabilizing effect, while the thermal anisotropy parameter, Darcy number, solutal Rayleigh number, throughflow parameter, and gravity parameter have a stabilizing effect on stationary and oscillatory convection. It is clear that the system changes in a way that makes it more stable for case (iii) gravity fluctuation and more unstable for case (iv) gravity fluctuation. Full article

Three-dimensional throughflow models represent a turbomachinery cascade via a force distribution without the need for detailed geometric modelling in the numerical solution, saving consistent computational resources. In this paper, we present the application of a body force method on an axial transonic fan implemented into an in-house tool for axisymmetric throughflow simulations. By a systematic comparison of local and integral quantities with a validated numerical solution, the capabilities and limitations of the model are discussed for different operating regimes. The implementation is first validated at the peak efficiency calibration point, providing a good duplication of blade flow variables and radial profiles. The design total pressure is matched with a 0.6% absolute difference and a slightly higher slope of the characteristic towards the stall. The isentropic efficiency curve is penalised after the choking mass flow rate calibration, presenting an absolute difference close to 2%, although with a consistent off-design trend. In general, the model provides a satisfactory representation of the flow field and the outflow spanwise distributions, with locally larger discrepancies near the endwalls. Finally, the method is applied to simulate the fan and outlet guide vanes installed into an isolated turbofan nacelle. The onset of intake stall at a high angle of attack is compared between the body force and a boundary conditions-based approaches, highlighting the importance of adopting fully coupled solution methods to study fan/airframe interaction problems. Full article

Turbomachinery with double counter-rotating impellers offers more degrees of freedom in the choice of design and control parameters compared to conventional machines. For these innovative machines, the literature review shows that more publications concerning axial type turbomachines are available than centrifugal ones. This work deals with a design and experimental performance analysis, applied to two counter-rotating impellers of a centrifugal compressor “CRCC”. CRCC was designed with a specifically developed tool based on mean-line approach coupled with optimization algorithms and a stream-curvature through-flow method to satisfy the design criteria. This paper presents an experimental validation of the CRCC design tool and its performances against the baseline “SR”, composed of one centrifugal impeller and a volute for which experimental data are available. CRCC numeric simulations are also validated by experimental data. For a fair comparison between CRCC and SR, the same volute is used for both configurations. The CRCC studied here includes a first conventional impeller with an axial inlet and a radial outlet, while the second impeller is parametrically designed and can be considered a rotating bladed diffuser with a radial inlet and outlet. The obtained results show that CRCC can deliver a pressure rise increase of two compared to SR, along with an increase of isentropic efficiency and also validate the design method of this novel layout. The experimental results also show that the speed ratio of CRCC has a positive effect on the surge and shock margin. Full article

The long-wave dynamics of the Lombok Strait, which is the most important link of the West Indonesian throughflow connecting the Pacific and Indian Ocean waters, was simulated and analyzed. A feature of the strait is its extremely complex relief, on which water transport creates a field of pronounced vertical velocities, which requires consideration of the nonhydrostatic component of pressure. The work presents a 3-D nonhydrostatic model in curvilinear coordinates, which is verified on a test problem. Particular attention is paid to the method of solving the 3-D elliptical solver for a nonhydrostatic problem in boundary-matched coordinates and a vertical σ level. The difference in transport through the Lombok Strait is determined by the difference in atmospheric pressure over the Pacific and Indian Oceans. Based on the results of the global simulation, the role of these factors in terms of their variability is analyzed, and the value of nonhydrostatic pressure in the dynamics of the Lombok Strait is revealed and evaluated. The vertical dynamics of the Lombok Strait are considered in detail based on hydrostatic and nonhydrostatic approaches. Full article

Objective: Analysis and presentation of the capabilities of the new ultrasound technique —the index of volume remodeling (IRV), which allows comprehensive assessing of pathological remodeling of the heart as an integrated functional anatomical system. Materials and methods: For this study 316 patients with acquired mitral valve disease (MVD) were examined prior to and following mitral valve replacement with bileaflet, disc-, and bioprostheses. Key parameters of the heart were measured in classical echocardiographic projections (end systolic area, end-diastolic area, end systolic volume, and end diastolic volume of ventricles, ventricular ejection fraction, atrial volume, and the ratio of ventricular to atrial volumes). The patients were examined 1–2 days prior to and following the surgery—before discharge, 6 months later, 1 year later, and then annually within next 5 years. The examination data were collected in one- and two-dimensional modes by using Philips EpiQ-7, iE33, HDI, Siemens Acuson, and HP Sonos 2500 diagnostic ultrasound machines equipped with 2.5 and 3.5 MHz transthoracic sensors. Results: A comprehensive study of structural geometric remodeling parameters of heart cavities in the context of acquired MVD allowed identifying new patterns in changes of the heart chambers geometry. These changes are reflected in the IRV, a digital indicator of the severity of cardiac pathological remodeling. Analysis of the dynamics of post-operative vs. pre-operative IRV-based remodeling data also showed that the index is highly sensible to the hemodynamic features of through-flows in various designs of prostheses. The IRV has a pronounced prognostic power and allows predicting the long-term outcome of surgical treatment with an accuracy of 82.35%. Conclusions: The IRV predictive accuracy formed the basis of the original classification of types of cardiac remodeling, which can assist both in determining the optimal timing for surgery, and in conjunction with other clinical diagnostic data, in predicting the long-term outcome of heart geometry restoration depending on the type of surgical correction. The IRV can be used in evaluation of the heart geometry for any cardiac pathology. It makes the approach to the analysis of pathological remodeling of the heart understandable, consistent, and universal, and also opens up opportunities for further expanding the diagnostic capabilities of radiology in cardiac surgery at all stages of the diagnostic process. Full article

Two-dimensional design and analysis issues on the meridional surface, which is important in the preliminary design procedure of compressors, are highly dependent on the accuracy of empirical models, such as the prediction of total pressure loss model and turning flow angle. Most of the widely used models are derived or improved from experimental data of some specific cascades with low-loading and low-speed airfoil types. These models may work for most conventional compressors but are incapable of accurately estimating the performance for some specific cases like transonic compressors. The errors made by these models may mislead the final design results. Therefore, surrogate models are developed in this work to reduce the errors and replace the conventional empirical models in the through-flow calculation procedure. A group of experimental data considering a two-stage transonic compressor is used to generate the airfoils database for training the surrogate models. Sensitivity analysis is applied to select the most influential features. Two supervised learning approaches including support vector regression (SVR) and Gaussian process regression (GPR) are used to train the models with a Bayesian optimization algorithm to obtain the optimal hyper parameters. The trained models are integrated into the through-flow code based on streamline curvature method (SLC) to predict the overall performance and internal flow field of the transonic compressor on five rotational speed lines for validation. The predictions are compared with the experimental data and the results of conventional empirical models. The comparison shows that SVR and GPR respectively reduce the predicted error of empirical models by 62.2% and 55.2% for the total pressure ratio and 48.4% and 50.1% for adiabatic efficiency on average. This suggests that the surrogate models constitute an alternative way to predict the performance of airfoils in through-flow calculation where empirical models are inefficient. Full article

The district heating (DH) demand of various systems has been simulated in several studies. Most studies focus on the temporal aspects rather than the spatial component. In this study, the DH demand for a medium-sized DH network in a city in southern Germany is simulated and analyzed in a spatially explicit approach. Initially, buildings are geo-located and attributes obtained from various sources including building type, ground area, and number of stories are merged. Thereafter, the annual primary energy demand for heating and domestic hot water is calculated for individual buildings. Subsequently, the energy demand is aggregated on the segment level of an existing DH network and the water flow is routed through the system. The simulation results show that the distribution losses are overall the highest at the end segments (given in percentage terms). However, centrally located pipes with a low throughflow are also simulated to have high losses. The spatial analyses are not only useful when addressing the current demand. Based on a scenario taking into account the refurbishment of buildings and a decentralization of energy production, the future demand was also addressed. Due to lower demand, the distribution losses given in percentage increase under such conditions. Full article
