Search Results (30)

In this paper, the thermal insulation performance of a wooden house was evaluated with infrared thermographies which were captured by a non-contact and non-destructive method. Heat transmissions were determined by the difference between surface temperature of outdoor and indoor sides of the walls, which were measured with an IR ray signal, and indoor and outdoor air temperatures. The heat transmission coefficient, which was determined by IR thermography, was compared to the coefficient calculated with thermal conductivities of wall component materials. The heat transmission coefficient calculated through wall components was 0.24 W/m²·K, while the coefficients determined with IR thermography ranged from 0.27 to 4.61 W/m²·K. The invisible thermal insulation defects in the wall, such as heat losses from the premature deterioration of thermal insulation material and air leakage through windows, were observed by IR thermography. It is expected that the results of this study could be used effectively not only for improving thermal insulation performance but also for suppressing decay occurrence in wooden building materials. Full article

The Alattu–Päkylä gold occurrence is located in the Northern Lake Ladoga area, in the Raaha-Ladoga suprasubduction zone, at the Karelian Craton (AR)—Svecofennian foldbelt (PR₁) boundary. Its gold ore mineral associations are of two types of mineralization: (1) copper–molybdenum–porphyry with arsenopyrite and gold (intrusion-related) and (2) gold–arsenopyrite–sulfide in shear zones. Optical and scanning electron microscopy, X-ray fluorescence spectrometry, inductively coupled plasma mass spectrometry (ICP-MS), instrumental neutron activation analysis (INAA) and fire analysis with AAS finishing were used to study them. Type 1 was provoked by shallow-depth tonalite intrusion (~1.89 Ga) and type 2 by two stages of Svecofennian metamorphism (1.89–1.86 and 1.83–1.79 Ga) with the possible influence of the impactogenesis of the Janisjärvi astrobleme (age ~1 Ga). Intrusive and host rocks were subjected to shearing accompanied by the formation of ore-bearing metasomatic rocks of the propylite-beresite series (depending on substrate) and quartz–sericite, quartz and sericite–tourmaline veins and streaks. Ore mineralization is present as several consecutive mineral associations: pyritic–molybdenite with arsenopyrite and gold; gold–arsenopyrite; quartz–arsenopyrite with antimony sulfosalts of lead; gold–polysulfide with tetrahedrite –argentotetrahedrite series minerals and gold–antimony with Pb–Sb–S system minerals and native antimony. Arsenopyrite contains invisible (up to 234 ppm) and visible gold. Metamorphosed domains in arsenopyrite and rims with visible gold around it are usually enriched in As, indicating higher (up to >500 °C) temperatures of formations than original arsenopyrite with invisible gold (<500 °C). A paragenetic sequence associated with the deposition of invisible and visible gold established at the Alattu–Päkylä ore occurrence: pyrrhotite + unaltered arsenopyrite (with invisible gold) → altered arsenopyrite (As-enriched) + pyrite ± pyrrhotite + visible gold. Gold, associated with gudmundite, sphalerite and native antimony, seems to be due to cainotypic rhyodacitic porphyry cutting tonalite intrusion or with a retrograde stage in post-Svecofennian metamorphism. The isotopic composition of Pb and ²³⁸U/²⁰⁴Pb (9.4–9.75) for the feldspar of the tonalite intrusion and the pyrite of gold mineralization, εNd (−4 up to −5) for tonalites and ẟ³⁴S values of −2.10–+4.99 for arsenopyrite, indicate the formation of gold occurrence provoked by Svecofennian magmatic and tectono-thermal processes with the involvement of matter from a mantle-lower crustal reservoir into magma formation and mineralization. Full article

No matter where we reside, the issue of greenhouse gas emissions impacts us all. Their influence has a disastrous effect on the earth’s climate, producing global warming and many other irreversible environmental impacts, even though it is occasionally invisible to the independent eye. Phase change materials (PCMs) can store and release heat when it is abundant during the day (e.g., from solar radiation), for use at night, or on chilly days when buildings need to be heated. As a consequence, buildings use less energy to heat and cool, which lowers greenhouse gas emissions. Consequently, research on thermally active medium-density fiberboard (MDF) with PCMs is presented in this work. MDF is useful for interior design and furniture manufacturing. The boards were created using pine (Pinus sylvestris L.) and spruce (Picea abies L.) fibers, urea–formaldehyde resin, and PCM powder, with a phase transition temperature of 22 °C, a density of 785 kg m⁻³, a latent heat capacity of 160 kJ kg⁻¹, a volumetric heat capacity of 126 MJ m⁻³, a specific heat capacity of 2.2 kJ kgK⁻¹, a thermal conductivity of 0.18 W mK⁻¹, and a maximum operating temperature of 200 °C. Before resination, the wood fibers were divided into two outer layers (16%) and an interior layer (68% by weight). Throughout the resination process, the PCM particles were solely integrated into the inner layer fibers. The mats were created by hand. A hydraulic press (AKE, Mariannelund, Sweden) was used to press the boards, and its operating parameters were 180 °C, 20 s/mm of nominal thickness, and 2.5 MPa for the maximum unit pressing pressure. Five variants of MDF with a PCM additive were developed: 0%, 5%, 10%, 30%, and 50%. According to the study, scores at the MOR, MOE, IB, and screw withdrawal resistance (SWR) tests decreased when PCM content was added, for example, MOE from 3176 to 1057 N mm⁻², MOR from 41.2 to 11.5 N mm⁻², and IB from 0.78 to 0.27 N mm⁻². However, the results of the thickness swelling and water absorption tests indicate that the PCM particles do not exhibit a substantial capacity to absorb water, retaining the dimensional stability of the MDF boards. The thickness swelling positively decreased with the PCM content increase from 15.1 to 7.38% after 24 h of soaking. The panel’s thermal characteristics improved with the increasing PCM concentration, according to the data. The density profiles of all the variations under consideration had a somewhat U-shaped appearance; however, the version with a 50% PCM content had a flatter form and no obvious layer compaction on the panel surface. Therefore, certain mechanical and physical characteristics of the manufactured panels can be enhanced by a well-chosen PCM addition. Full article

Contemporary architecture is shaped by the paradigm of sustainability and is characteristic of many solutions determined by a relevant set of principles related to shaping the environment based on the ecology of systems focused on the flow of energy. These design principles concern gaining energy from renewable resources, protection against the loss of thermal energy from buildings, protection against the excess of thermal energy in buildings, and proper distribution of thermal energy in buildings. This paper presents a proposal for a method to analyze some building components used as sustainability-related elements given their formal similarity to historic architectural details or some artworks integrated with buildings. It aims to emphasize the potential of a different perspective from which to perceive and assess buildings, and specifically their architectural details, given their spatial and aesthetic values associated with sustainable technical solutions. This study is based on a few differentiated examples. It proves the relations mentioned above true, given the sustainability paradigm epitomized in technical solutions to contemporary buildings and the related aesthetic features characterizing the relevant architectural detailing. Such a perception of buildings is intended to promote unconventional viewing and assessment of them by the public and professionals in the area of architecture and art. It would make them discover new types of aesthetic values, which are usually invisible. Full article

Light is an electromagnetic radiation that has visible and invisible wavelength spectrums. Visible light can only be detected by the eyes through the optic pathways. With the presence of the scalp, cranium, and meninges, the brain is seen as being protected from direct exposure to light. For that reason, the brain can be viewed as a black body lying inside a black box. In physics, a black body tends to be in thermal equilibrium with its environment and can tightly regulate its temperature via thermodynamic principles. Therefore, a healthy brain inside a black box should not be exposed to light. On the contrary, photobiomodulation, a form of light therapy for the brain, has been shown to have beneficial effects on some neurological conditions. The proposed underlying mechanisms are multiple. Herein, we present our intraoperative findings of rapid electrocorticographic brainwave changes when the brain was shone directly with different wavelengths of light during awake brain surgery. Our findings provide literature evidence for light’s ability to influence human brain energy and function. Our proposed mechanism for these rapid changes is the presence of plasma-like energy inside the brain, which causes fast brain activities that are akin to lightning strikes. Full article

Archaeological landscapes can be obscured by environmental factors, rendering conventional visual interpretation of optical data problematic. The absence of evidence can lead to seemingly empty locations and isolated monuments. This, in turn, influences the cultural–historical interpretation of archaeological sites. Here, we assess the potential of integrating thermal and magnetic remote sensing methods in the detection and mapping of buried archaeological structures. The area of interest in an alluvial plain in Tuva Republic makes the application of standard methods like optical remote sensing and field walking impractical, as natural vegetation features effectively hide anthropogenic structures. We combined drone-based aerial thermography and airborne and ground-based magnetometry to establish an approach to reliably identifying stone structures concealed within alluvial soils. The data integration led to the discovery of nine buried archaeological structures in proximity to an Early Iron Age royal tomb, shedding light on ritual land use continuity patterns. Full article

In this paper, analytic modeling for the design of a transient thermal invisibility cloak with imperfect interfaces is presented together with numerical simulations. In contrast to steady-state conditions, it is shown that an object can only be made partially invisible under a transient-state condition with either ideal or imperfect interfaces. The thermal visibility of an object to the external region can be optimally suppressed under certain conditions referred to as the “weak invisibility conditions” for the transient response, which are different from the “strong invisibility conditions” that can completely conceal an object in a steady state. In the formulation, a homogeneous metamaterial with constant volumetric heat capacity and constant anisotropic conductivity tensor is employed. It can be demonstrated that the interface’s bonding conditions will have a significant effect on the design of metamaterials. Two typical types of imperfect interfaces, referred to as low-conductivity- and high-conductivity-type interfaces, are considered. Conditions, that render an object mostly undetectable, are analytically found and expressed in simple forms under quasi-static approximations. Within the quasi-static limit, the thermal localization in the target region can be tuned with the anisotropy of the conductivity tensor. Thermal shielding or concentrating effects in the target region are exemplified based on finite element simulations to demonstrate the manipulation of heat flux in the target region. The present findings make new advances in theoretical fundamentals and numerical simulations on the effect of the imperfect interface in the transient regime and can serve as guidelines in the design of thermal metamaterials through the entire conduction process. Full article

Over the past two decades, effective control of physical fields, such as light fields or acoustics fields, has greatly benefited from transforming media. One of these rapidly growing research areas is transformation thermotics, especially embodied in the thermal conductive and radiative modes. On the other hand, transformation media in thermal convection has seldom been studied due to the complicated governing equations involving both fluid motion and heat transfer terms. The difficulty lies in the robustness of form invariance in the Navier–Stokes equations or their simplified forms under coordinate transformations, which determines whether the transformation operations can be executed on thermal convection to simultaneously regulate the flow and thermal fields. In this work, we show that thermal convection in two-dimensional Hele–Shaw cells keeps form-invariance, while its counterpart in general creeping flows or general laminar flows does not. This conclusion is numerically verified by checking the performances of invisible devices made of transformation media in convective environments. We further exploit multilayered structures constituted of isotropic homogeneous natural materials to realize the anisotropic inhomogeneous properties required for transformation media. Our results clarify the long-term confusion about the validation of the transformation method in thermal convection and provide a rigorous foundation and classical paradigm on inspiring various fascinating metadevices in both thermal and flow fields. Full article

Few studies have been conducted on thermal plant images. This is because of the difficulty in extracting and analyzing various color-related patterns and features from the plant image obtained using a thermal camera, which does not provide color information. In addition, the thermal camera is sensitive to the surrounding temperature and humidity. However, the thermal camera enables the extraction of invisible patterns in the plant by providing external and internal heat information. Therefore, this study proposed a novel plant classification method based on both the thermal and visible-light plant images to exploit the strengths of both types of cameras. To the best of our knowledge, this study is the first to perform super-resolution reconstruction using visible-light and thermal plant images. Furthermore, a method to improve the classification performance through generative adversarial network (GAN)-based super-resolution reconstruction was proposed. Through the experiments using a self-collected dataset of thermal and visible-light images, our method shows higher accuracies than the state-of-the-art methods. Full article

Researchers are trying to work out how to make a broadband response metamaterial absorber (MMA). Electromagnetic (EM) waves that can pass through the atmosphere and reach the ground are most commonly used in the visible frequency range. In addition, they are used to detect faults, inspect tapped live-powered components, electrical failures, and thermal leaking hot spots. This research provides a numerical analysis of a compact split ring resonator (SRR) and circular ring resonator (CRR) based metamaterial absorber (MMA) using a three-layer substrate material configuration for wideband visible optical wavelength applications. The proposed metamaterial absorber has an overall unit cell size of 800 nm × 800 nm × 175 nm in both TE and TM mode simulations and it achieved above 80% absorbance in the visible spectrums from 450 nm to 650 nm wavelength. The proposed MA performed a maximum absorptivity of 99.99% at 557 nm. In addition, the steady absorption property has a broad range of oblique incidence angle stability. The polarization conversion ratio (PCR) is evaluated to ensure that the MMA is perfect. Both TM and TE modes can observe polarization insensitivity and wide-angle incidence angle stability with 18° bending effects. Moreover, a structural study using electric and magnetic fields was carried out to better understand the MMA’s absorption properties. The observable novelty of the proposed metamaterial is compact in size compared with reference paper, and it achieves an average absorbance of 91.82% for visible optical wavelength. The proposed MMA also has bendable properties. The proposed MMA validation has been done by two numerical simulation software. The MMA has diverse applications, such as color image, wide-angle stability, substantial absorption, absolute invisible layers, thermal imaging, and magnetic resonance imaging (MRI) applications. Full article

When direct flow velocity measurements are not feasible, the use of tracers can be a valuable tool. In the present study, both laboratory and field experiments were conducted to evaluate the applicability of quinine as a fluorescent tracer for estimating mean sheet flow velocities in different ambient light and surface morphology conditions. Quinine excels in low-light conditions when exposed to UVA light. This tracer was compared with dye and thermal tracers, all in liquid form. In these tracing techniques the tracers were injected into the flow, after which surface velocity was estimated by tracking the leading edge of the tracer plumes and applying a correction factor to calculate the mean velocity (in a water column). The visibility of the tracers was evaluated by measuring the relative luminance and contrast ratio of the quinine and dye tracer plumes. Results show that the quinine tracer can be used to estimate sheet flow velocities over a wide variety of soil and urban surfaces; it has better visibility in comparison to the dye tracer but, in some conditions, lower visibility than the thermal tracer. Although quinine is invisible under bright ambient light conditions, this tracer technique requires low-cost experimental setup and is useful in low-light conditions (e.g., night; twilight; shielded environments). Full article

The bonding strength of the bond coat plays an important role in the composite action between the wearing surface and the deck plate of the orthotropic steel deck system. Poor bonding results in the delamination of the wearing surface from the deck plate. Graphene oxide (GO) possesses outstanding mechanical and thermal properties, as well as impressive multifunctional groups, which makes it an ideal reinforcement candidate for polymer matrices. In this study, graphene oxide was used to improve the bonding strength and toughness of the epoxy asphalt bond coat (EABC). The dispersion, hydrophobicity, viscosity–time behavior, phase-separated morphology, dynamic mechanical properties, pull-off strength, shear strength and mechanical performance of GO-modified EABCs were investigated using various techniques. The inclusion of GO improved the hydrophobicity of the unmodified EABC. The viscosity of the unmodified EABC was lowered with the addition of GO during curing. Moreover, the allowable construction time for the modified EABCs was extended with the GO loading. The incorporation of GO enhanced the stiffness of the unmodified EABC in the glassy and rubbery states. However, graphene oxide lowered the glass transition temperature of the asphalt of the unmodified EABC. Confocal microscopy observations revealed that GO was invisible in both the asphalt and epoxy phases of the EABC. The inclusion of GO improved the bonding strength, particularly at 60 °C, and mechanical properties of the unmodified EABC. Full article

The present research deals with the investigation of the influence of aqueous solutions of chemical substances in combination with temperature on the change of material properties of polymer composites based on epoxy resins reinforced with carbon fibers. The aim of the research was to investigate and evaluate the impact of degradation processes due to the influence of chemical environments of different temperatures and time of their action on changes in the material properties and macrostructure of carbon composite with epoxy resin. The chemical and thermal influence of the environment on the experimental material was evaluated by monitoring changes in mechanical properties, glass transition temperature, and material surface macrostructure. The achieved results show different behavior of the experimental composite material in different environments, while it was demonstrated that the degradation effect of chemical and thermal influences on changes in material properties increase with increasing temperature. Among the investigated environments (NaCl, NaOH, and H₂SO₄), exposure to 10% NaOH, and 15% H₂SO₄ had the greatest degradation influence on the polymer composite, and exposure to 20% NaCl had the smallest influence, which is also confirmed by invisible changes in material surface macrostructure and decrease of tensile strength by about 20%. Exposure to 10% NaOH resulted in significant surface roughening of the epoxy resin, white deposit creation on the surface, and a decrease of tensile strength by 35%. Opposite that, exposure to 15% H₂SO₄ resulted in the highlighting of the fiber yarns of the carbon fiber fabric, yellowing of the surface, surface pore occurrence, and a decrease of tensile strength by 35%. Full article

Mid-infrared metamaterial absorbers have many applications in the field of infrared detection, infrared thermal energy utilization, radiation refrigeration, invisible camouflage, etc. In this study, we designed an ultra-broadband mid-infrared metamaterial absorber based on multi-sized resonators. The structure of the absorber consisted of a gold substrate and nine resonators. The simulated results showed that the absorptivity of the absorber was higher than 90% in the 8.33–15.09 μm waveband with an average absorptivity of 95.17%. The energy distributions of the electric and magnetic fields were introduced to investigate the physics of broadband absorption. Moreover, we combined the multi-layer structure with the plane random arrangement structure to achieve a balance between thickness and width. Our study further illustrates the potential application of multi-sized resonators in metamaterial absorbers to realize high absorptivity and ultra-broadband to improve the performance of devices applied in infrared detection, radiation refrigeration, and other fields. Full article

In recent years, the remote sensing of marine plastic litter has been rapidly evolving and the technology is most advanced in the visible (VIS), near-infrared (NIR), and short-wave infrared (SWIR) wavelengths. It has become clear that sensing using VIS-SWIR bands, based on the surface reflectance of sunlight, would benefit from complementary measurements using different technologies. Thermal infrared (TIR) sensing shows potential as a novel method for monitoring macro plastic litter floating on the water surface, as the physics behind surface-leaving TIR is different. We assessed a thermal radiance model for floating plastic litter using a small UAV-grade FLIR Vue Pro R 640 thermal camera by flying it over controlled floating plastic litter targets during the day and night and in different seasons. Experiments in the laboratory supported the field measurements. We investigated the effects of environmental conditions, such as temperatures, light intensity, the presence of clouds, and biofouling. TIR sensing could complement observations from VIS, NIR, and SWIR in several valuable ways. For example, TIR sensing could be used for monitoring during the night, to detect plastics invisible to VIS-SWIR, to discriminate whitecaps from marine litter, and to detect litter pollution over clear, shallow waters. In this study, we have shown the previously unconfirmed potential of using TIR sensing for monitoring floating plastic litter. Full article
