Search Results (18)

In recent years, smart devices have proven their effectiveness in monitoring mental health issues and have played a crucial role in providing therapy. The ability to embed sensors in fabrics opens new horizons for mental healthcare, addressing the growing demand for innovative solutions in monitoring and therapy. The objective of this review is to understand mental health, its impact on the human body, and the latest advancements in the field of smart textiles (sensors, electrodes, and smart garments) for monitoring physiological signals such as respiration rate (RR), electroencephalogram (EEG), electrodermal activity (EDA), electrocardiogram (ECG), and cortisol, all of which are associated with mental health disorders. Databases such as Web of Science (WoS) and Scopus were used to identify studies that utilized smart textiles to monitor specific physiological parameters. Research indicates that smart textiles provide promising results compared to traditional methods, offering enhanced comfort for long-term monitoring. Full article

In this work, a flexible textile-based capacitive respiratory sensor, based on a capacitive sensor structure, that does not require direct skin contact is designed, optimised, and evaluated using both computational modelling and empirical measurements. In the computational study, the geometry of the sensor was examined. This analysis involved observing the capacitance and frequency variations using a cylindrical model that mimicked the human body. Four designs were selected which were then manufactured by screen printing multiple functional layers on top of a polyester/cotton fabric. The printed sensors were characterised to detect the performance against phantoms and impacts from artefacts, normally present whilst wearing the device. A sensor that has an electrode ratio of 1:3:1 (sensor, reflector, and ground) was shown to be the most sensitive design, as it exhibits the highest sensitivity of 6.2% frequency change when exposed to phantoms. To ensure the replicability of the sensors, several batches of identical sensors were developed and tested using the same physical parameters, which resulted in the same percentage frequency change. The sensor was further tested on volunteers, showing that the sensor measures respiration with 98.68% accuracy compared to manual breath counting. Full article

This article presents an in-depth investigation of wearable microwave antenna sensors (MASs) used for vital sign detection (VSD) and lung water level (LWL) monitoring. The study looked at two different types of MASs, narrowband (NB) and ultra-wideband (UWB), to decide which one was better. Unlike recent wearable respiratory sensors, these antennas are simple in design, low-profile, and affordable. The narrowband sensor employs an offset-feed microstrip transmission line, which has a bandwidth of 240 MHz at −10 dB reflection coefficient for the textile substrate. The UWB microwave sensor uses a CPW-fed line to excite an unbalanced U-shaped radiator, offering an extended simulated operating bandwidth from 1.5 to 10 GHz with impedance matching ≤−10 dB. Both types of microwave sensors are designed on a flexible RO 3003 substrate and textile conductive fabric attached to a cotton substrate. The specific absorption rate (SAR) of the sensors is measured at different resonant frequencies on 1 g and 10 g of tissue, according to the IEEE C95.3 standard, and both sensors meet the standard limit of 1.6 W/kg and 2 W/kg, respectively. A simple peak-detection algorithm is used to demonstrate high accuracy in the detection of respiration, heartbeat, and lung water content. Based on the experimental results on a child and an adult volunteer, it can be concluded that UWB MASs offer superior performance when compared to NB sensors. Full article

Flexible wearable sensors are integral in diverse applications, particularly in healthcare and human–computer interaction systems. This paper introduces a resistive stretch sensor crafted from shape memory polymers (SMP) blended with carbon nanotubes (CNTs) and coated with silver paste. Initially, the sensor’s characteristics underwent evaluation using a Universal Testing Machine (UTM) and an LCR meter. These sensors showcased exceptional sensitivity, boasting a gauge factor of up to 20 at 5% strain, making them adept at detecting subtle movements or stimuli. Subsequently, the study conducted a comparison between SMP-CNT conductors with and without the silver coating layer. The durability of the sensors was validated through 1000 cycles of stretching at 4% ∆R/R₀. Lastly, the sensors were utilized for monitoring respiration and measuring human breathing. Fourier transform and power spectrum density (PSD) analysis were employed to discern frequency components. Positioned between the chest and abdominal wall for contact-based respiration monitoring, the sensors revealed a dominant frequency of approximately 0.35 Hz. Signal filtering further enhanced their ability to capture respiration signals, establishing them as valuable tools for next-generation personalized healthcare applications. Full article

As the focus on physical health increases, the market demand for flexible wearable sensors increases. Textiles combined with sensitive materials and electronic circuits can form flexible, breathable high-performance sensors for physiological-signal monitoring. Carbon-based materials such as graphene, carbon nanotubes (CNTs), and carbon black (CB) have been widely utilized in the development of flexible wearable sensors due to their high electrical conductivity, low toxicity, low mass density, and easy functionalization. This review provides an overview of recent advancements in carbon-based flexible textile sensors, highlighting the development, properties, and applications of graphene, CNTs, and CB for flexible textile sensors. The physiological signals that can be monitored by carbon-based textile sensors include electrocardiogram (ECG), human body movement, pulse and respiration, body temperature, and tactile perception. We categorize and describe carbon-based textile sensors based on the physiological signals they monitor. Finally, we discuss the current challenges associated with carbon-based textile sensors and explore the future direction of textile sensors for monitoring physiological signals. Full article

This study presents a respiration sensor that is dependent on a parallel capacitor, including connection lines and electrodes embroidered on textiles. First, characterizations of the respiration capacitor using a silver thread, including a combination of porous Eco-flex simulating air in the lungs due to respiration, were evaluated using an LCR meter. Second, the effects of air gaps on the detection of respiration motions according to the change in electrode distance under pressure were presented. The data values were measured from 1 to 300 kHz using an LCR meter and dielectric test fixture. Third, actual breathing was examined in four patterns: normal breathing, deep breathing, hyperventilation, and apnea. The test was performed after fabricating a clothing-type breathing sensor. Finally, the change in capacitance for actual respiration was determined by wearing a clothing-type respiration sensor based on the data collected. The effectiveness of the respiration sensor was demonstrated by measuring it to discern all waveforms, cycles, and ranges associated with the breathing pattern. Full article

The advancement of smart textiles has led to significant interest in developing wearable textile sensors (WTS) and offering new modalities to sense vital signs and activity monitoring in daily life settings. For this, textile fabrication methods such as knitting, weaving, embroidery, and braiding offer promising pathways toward unobtrusive and seamless sensing for WTS applications. Specifically, the knitted sensor has a unique intermeshing loop structure which is currently used to monitor repetitive body movements such as breathing (microscale motion) and walking (macroscale motion). However, the practical sensing application of knit structure demands a comprehensive study of knit structures as a sensor. In this work, we present a detailed performance evaluation of six knitted sensors and sensing variation caused by design, sensor size, stretching percentages % (10, 15, 20, 25), cyclic stretching (1000), and external factors such as sweat (salt-fog test). We also present regulated respiration (inhale–exhale) testing data from 15 healthy human participants; the testing protocol includes three respiration rates; slow (10 breaths/min), normal (15 breaths/min), and fast (30 breaths/min). The test carried out with statistical analysis includes the breathing time and breathing rate variability. These testing results offer an empirically derived guideline for future WTS research, present aggregated information to understand the sensor behavior when it experiences a different range of motion, and highlight the constraints of the silver-based conductive yarn when exposed to the real environment. Full article

Breathing is essential for human life. Issues related to respiration can be an indicator of problems related to the cardiorespiratory system; thus, accurate breathing monitoring is fundamental for establishing the patient’s condition. This paper presents a ready-to-use and discreet chest band for monitoring the respiratory parameters based on the piezoresistive transduction mechanism. In detail, it relies on a strain sensor realized with a pressure-sensitive fabric (EeonTex LTT-SLPA-20K) for monitoring the chest movements induced by respiration. In addition, the band includes an Inertial Measurement Unit (IMU), which is used to remove the motion artefacts from the acquired signal, thereby improving the measurement reliability. Moreover, the band comprises a low-power conditioning and acquisition section that processes the signal from sensors, providing a reliable measurement of the respiration rate (RR), in addition to other breathing parameters, such as inhalation (TI) and exhalation (TE) times, inhalation-to-exhalation ratio (IER), and flow rate (V). The device wirelessly transmits the extracted parameters to a host device, where a custom mobile application displays them. Different test campaigns were carried out to evaluate the performance of the designed chest band in measuring the RR, by comparing the measurements provided by the chest band with those obtained by breath count. In detail, six users, of different genders, ages, and physical constitutions, were involved in the tests. The obtained results demonstrated the effectiveness of the proposed approach in detecting the RR. The achieved performance was in line with that of other RR monitoring systems based on piezoresistive textiles, but which use more powerful acquisition systems or have low wearability. In particular, the inertia-assisted piezoresistive chest band obtained a Pearson correlation coefficient with respect to the measurements based on breath count of 0.96 when the user was seated. Finally, Bland–Altman analysis demonstrated that the developed system obtained 0.68 Breaths Per Minute (BrPM) mean difference (MD), and Limits of Agreement (LoAs) of +3.20 and −1.75 BrPM when the user was seated. Full article

Respiration monitoring is a very important indicator of health status. It can be used as a marker in the recognition of a variety of diseases, such as sleep apnea, asthma or cardiac arrest. The purpose of the present study is to overcome limitations of the current state of the art in the field of respiration monitoring systems. Our goal was the development of a lightweight handheld device with portable operation and low power consumption. The proposed approach includes a textile capacitive sensor with interdigitated electrodes embroidered into the facemask, integrated with readout electronics. Readout electronics is based on the direct interface of the capacitive sensor and a microcontroller through just one analog and one digital pin. The microcontroller board and sensor are powered by a smartphone or PC through a USB cable. The developed mobile application for the Android™ operating system offers reliable data acquisition and acts as a bridge for data transfer to the remote server. The embroidered sensor was initially tested in a humidity-controlled chamber connected to a commercial impedance analyzer. Finally, in situ testing with 10 volunteering subjects confirmed stable operation with reliable respiration monitoring. Full article

E-textile sensor networks enable a variety of applications including pervasive monitoring for distributed healthcare. While commercial wearables can now measure various quantities such as heart rate and activities in a real-time, robust, and pervasive manner, breathing sensors remain an ongoing research challenge. In this paper, the use of wearable antennas for respiration monitoring is investigated based on a low-profile broadband fully textile antenna. It is demonstrated that the antenna, suitable for operation on different substrates and body parts, exhibits over 2 dB wireless gain sensitivity to normal breathing. Unlike recent wearable breathing sensors, the proposed antenna has a very simple structure and does not rely on active mechanical sensing elements or specific materials. A simple peak-detection algorithm is investigated showing a nearly 100% breath detection accuracy in line-of-sight. Based on the experimental results, it can be concluded that e-textile antennas can be utilized as highly accurate sensors for respiration monitoring, without the need for specific sensing elements or materials. Full article

The demand for wearable devices to measure respiratory activity is constantly growing, finding applications in a wide range of scenarios (e.g., clinical environments and workplaces, outdoors for monitoring sports activities, etc.). Particularly, the respiration rate (RR) is a vital parameter since it indicates serious illness (e.g., pneumonia, emphysema, pulmonary embolism, etc.). Therefore, several solutions have been presented in the scientific literature and on the market to make RR monitoring simple, accurate, reliable and noninvasive. Among the different transduction methods, the piezoresistive and inertial ones satisfactorily meet the requirements for smart wearable devices since unobtrusive, lightweight and easy to integrate. Hence, this review paper focuses on innovative wearable devices, detection strategies and algorithms that exploit piezoresistive or inertial sensors to monitor the breathing parameters. At first, this paper presents a comprehensive overview of innovative piezoresistive wearable devices for measuring user’s respiratory variables. Later, a survey of novel piezoresistive textiles to develop wearable devices for detecting breathing movements is reported. Afterwards, the state-of-art about wearable devices to monitor the respiratory parameters, based on inertial sensors (i.e., accelerometers and gyroscopes), is presented for detecting dysfunctions or pathologies in a non-invasive and accurate way. In this field, several processing tools are employed to extract the respiratory parameters from inertial data; therefore, an overview of algorithms and methods to determine the respiratory rate from acceleration data is provided. Finally, comparative analysis for all the covered topics are reported, providing useful insights to develop the next generation of wearable sensors for monitoring respiratory parameters. Full article

Wearable light textiles are gaining widespread interest in application for measurement and monitoring of biophysical parameters. Fiber optic sensors, in particular Bragg Grating (FBG) sensors, can be a competitive method for monitoring of respiratory behavior for chest and abdomen regions since the sensors are able to convert physical movement into wavelength shift. This study aims to show the performance of elastic belts with integrated optical fibers during the breathing activities done by two volunteers. Additionally, the work aims to determine how the positions of the volunteers affect the breathing pattern detected by optical fibers. As a reference, commercial mobile application for sensing vibration is used. The obtained results show that the FBGs are able to detect chest and abdomen movements during breathing and consequently reconstruct the breathing pattern. The accuracy of the results varies for two volunteers but remains consistent. Full article

The stretchable sensor has been considered as the most important component in a wearable device. However, it is still a great challenge to develop a highly sensitive textile-based strain sensor with good flexibility, excellent skin affinity, and large dynamic range. Herein, polypyrrole (PPy) was immobilized on a stretchable textile knitted by polyester and spandex via low-temperature interfacial polymerization to prepare a conductive strain sensor for human motion and respiration measurements. Scanning electron microscopy, Fourier transform infrared spectrometry, and thermal gravimetric data verify that a thin layer of PPy has been successfully coated on the textile with a high density and very uniform distribution. The resistance of the as-prepared textile is 21.25 Ω/cm² and the PPy-coated textile could be used as an electric conductor to light up a LED lamp. Moreover, the textile could tolerate folding at an angle of 180° and 500 times of bending-twisting cycles without significant changes on its resistance. A negative correlation between the resistance change and the applied strain is observed for the textile-based sensor in the strain ranging from 0 to 71% with the gauge factor of −0.46. After more than 200 cycles of stretching-releasing under the strain of 26%, there is no obvious alteration on the sensing responses. The sensors were attached on volunteers’ body or clothes for the real-time measurement of human motions and respiration, demonstrating that the textile-based sensor could sensitively detect finger, elbow, and knee bending and differentiate deep, normal, and fast breath. This work may provide an approach to uniform and dense coating conductive polymers on textiles for highly sensitive and stretchable sensors, which possess great potentials in practical applications for real-time monitoring human motions and physiological signs. Full article

Functional textiles with unique functions, including free cutting, embroidery and changeable shape, will be attractive for smart wear of human beings. Herein, we fabricated a sandwich-like humidity sensor made from silver coated one-dimensional magnetite nanowire (Fe₃O₄ NW) arrays which were in situ grown on the surface of modified polypropylene nonwoven fabric via simultaneous radiation induced graft polymerization and co-precipitation. The humidity sensor exhibits an obvious response to the relative humidity (RH) ranging from RH 11% to RH 95% and its response value reaches a maximum of 6600% (ΔI/I₀) at 95% relative humidity (RH). The humidity sensor can be tailored into various shapes and embroidered on its surface without affecting its functionalities. More interesting, the intensity of its response is proportional to the size of the material. These features permit the sensor to be integrated into commercial textiles or a gas mask to accurately monitor a variety of important human activities including respiration, blowing, speaking and perspiration. Moreover, it also can distinguish different human physical conditions by recognizing respiration response patterns. The sandwich-like sensor can be readily integrated with textiles to fabricate promising smart electronics for human healthcare. Full article

This paper presents a system dedicated to monitoring the heart activity parameters using Electrocardiography (ECG) mobile devices and a Wearable Heart Monitoring Inductive Sensor (WHMIS) that represents a new method and device, developed by us as an experimental model, used to assess the mechanical activity of the hearth using inductive sensors that are inserted in the fabric of the clothes. Only one inductive sensor is incorporated in the clothes in front of the apex area and it is able to assess the cardiorespiratory activity while in the prior of the art are presented methods that predict sensors arrays which are distributed in more places of the body. The parameters that are assessed are heart data-rate and respiration. The results are considered preliminary in order to prove the feasibility of this method. The main goal of the study is to extract the respiration and the data-rate parameters from the same output signal generated by the inductance-to-number convertor using a proper algorithm. The conceived device is meant to be part of the “wear and forget” equipment dedicated to monitoring the vital signs continuously. Full article
