Search Results (23)

With the large-scale application and high-quality development demands of optical fiber cables, higher requirements have been placed on the corresponding measurement technologies. In recent years, optical fiber testing has played a crucial role in evaluating cable performance, as well as in the deployment, operation, maintenance, fault repair, and upgrade of optical networks. The Optical Time-Domain Reflectometer (OTDR) is a fiber fault diagnostic tool recommended by standards such as the International Telecommunication Union and the International Electrotechnical Commission. It is used to certify the performance of new fiber links and monitor the status of existing ones, detecting and locating fault events with advantages including simple operation, rapid response, and cost-effectiveness. First, this paper introduces the working principle and system architecture of OTDR, along with a brief discussion of its performance evaluation metrics. Next, a comprehensive review of improved OTDR technologies and systems is provided, categorizing different performance enhancement methods, including the enhanced measurement distance with simple structure and low cost in 2024, and the high spatial resolution measurement of optical fiber reflection events and non-reflection events in 2025. Finally, the development trends and future research directions of OTDR are outlined, aiming to achieve the development of low-cost, high-performance OTDR systems. Full article

Distributed Acoustic Sensing (DAS) has emerged as a groundbreaking technology in seismology, transforming fiber-optic cables into dense, cost-effective seismic monitoring arrays. DAS makes use of Rayleigh backscattering to detect and measure dynamic strain and vibrations over extended distances. It can operate using both pre-existing telecommunication networks and specially designed fibers. This review explores the principles of DAS, including Coherent Optical Time Domain Reflectometry (COTDR) and Phase-Sensitive OTDR (ϕ-OTDR), and discusses the role of optoelectronic interrogators in data acquisition. It examines recent advancements in fiber design, such as helically wound and engineered fibers, which improve DAS sensitivity, spatial resolution, and the signal-to-noise ratio (SNR). Additionally, innovations in deployment techniques include cemented borehole cables, flexible liners, and weighted surface coupling to further enhance mechanical coupling and data accuracy. This review also demonstrated the applications of DAS across earthquake detection, microseismic monitoring, reservoir characterization and monitoring, carbon storage sites, geothermal reservoirs, marine environments, and urban infrastructure surveillance. The study highlighted several challenges of DAS, including directional sensitivity limitations, vast data volumes, and calibration inconsistencies. It also addressed solutions to these problems, such as advances in signal processing, noise suppression techniques, and machine learning integration, which have improved real-time analysis and data interpretability, enabling DAS to compete with traditional seismic networks. Additionally, modeling approaches such as full waveform inversion and forward simulations provide valuable insights into subsurface dynamics and fracture monitoring. This review highlights DAS’s potential to revolutionize seismic monitoring through its scalability, cost-efficiency, and adaptability to diverse applications while identifying future research directions to address its limitations and expand its capabilities. Full article

Using fiber optics as a tool for different kinds of geotechnical monitoring can be highly attractive and cost-effective when compared to conventional instruments, such as piezometers and inclinometers, among others. A single fiber optic cable may cover a larger monitoring area compared to conventional instrumentation and allows for monitoring more than one physical quantity with the same fiber optic cable. The literature provides several different examples of distributed fiber optic systems usage. For using any sensor, a calibration curve and parameters are required. In the case of strain sensors, calibration is required to derive strain values from the frequency measurement quantity. However, fiber optic sensor cable manufacturers do not often provide cable calibration parameters, and researchers should consult the specialized literature. This article thus presents a bench adjusted for tests with single-mode fiber optic cables, as well as results of tensile tests for defining the function of strain variations in two different optical fiber cables manufactured by different companies using two different distributed interrogators. This paper also proposes a methodology for calibrating fiber optic cable deformation. A few manufacturers of fiber optic cables aim at civil engineering applications. Therefore, we propose a calibration methodology to show the possibility of obtaining calibration parameters of any fiber optic cable, even those manufactured for telecommunications purposes and not only for cables manufactured for civil engineering use. Thus, researchers will not be restricted to the acquisition of special cables for their applications. The results allowed us to conclude that the application of calibrated fiber optic sensors to experimental pile foundations permits the evaluation of the load–displacement behavior of these elements under different loading conditions. Full article

Passive Optical Networks (PONs) are telecommunication technologies that use fiber-optic cables to deliver high-speed internet and other communication services to end users. PONs split optical signals from a single fiber into multiple fibers, serving multiple homes or businesses without requiring active electronic components. PONs planning involves designing and optimizing the infrastructure for delivering fiber-optic communications to end users. The main contribution of this paper is the introduction of tailored operators within a genetic algorithm (GA) optimization approach for PONs planning. A three vector and an aggregator vector are devised to account, respectively, for physical and logical connections of the network, facilitating the execution of GA operators. This codification and these operators are versatile and can be applied to any population-based algorithm, not limited to GAs alone. Furthermore, the proposed operators are specifically designed to exploit the unique characteristics of PONs, thereby minimizing the occurrence of unfeasible solutions and accelerating convergence towards an optimal network design. By incorporating these specialized operators, this research aims to enhance the efficiency of PONs planning, ultimately leading to reduced costs and improved network performance. Full article

Underground telecommunication cables are highly susceptible to damage from excavation activities. Preventing accidental damage to underground telecommunication cables is critical and necessary. In this study, we present field trial results of monitoring excavation activities near underground fiber cables using an intensity-based phase-sensitive optical time-domain reflectometer (φ-OTDR). The reasons for choosing intensity-based φ-OTDR for excavation monitoring are presented and analyzed. The vibration signals generated by four typical individual excavation events, i.e., cutting, hammering, digging, and tamping at five different field trial sites, as well as five different mixed events in the fifth field trial site were investigated. The findings indicate that various types of events can generate vibration signals with different features. Typically, fundamental peak frequencies of cutting, hammering and tamping events ranged from 30 to 40 Hz, 11 to 15 Hz, and 30 to 40 Hz, respectively. Digging events, on the other hand, presented a broadband frequency spectrum without a distinct peak frequency. Moreover, due to differences in environmental conditions, even identical excavation events conducted with the same machine may also generate vibration signals with different characteristics. The diverse field trial results presented offer valuable insights for both research and the practical implementation of excavation monitoring techniques for underground cables. Full article

This article discusses the use of distributed acoustic sensing (DAS) for monitoring gas–liquid two-phase slug flow in horizontal pipes, using standard telecommunication fiber optics connected to a DAS integrator for data acquisition. The experiments were performed in a 14 m long, 5 cm diameter transparent PVC pipe with a fiber cable helically wrapped around the pipe. Using mineral oil and compressed air, the system captured various flow rates and gas–oil ratios. New algorithms were developed to characterize slug flow using DAS data, including slug frequency, translational velocity, and the lengths of slug body, slug unit, and the liquid film region that had never been discussed previously. This study employed a high-speed camera next to the fiber cable sensing section for validation purposes and achieved a good correlation among the measurements under all conditions tested. Compared to traditional multiphase flow sensors, this technology is non-intrusive and offers continuous, real-time measurement across long distances and in harsh environments, such as subsurface or downhole conditions. It is cost-effective, particularly where multiple measurement points are required. Characterizing slug flow in real time is crucial to many industries that suffer slug-flow-related issues. This research demonstrated the DAS’s potential to characterize slug flow quantitively. It will offer the industry a more optimal solution for facility design and operation and ensure safer operational practices. Full article

For the maintenance of railways on soft soils, accurate knowledge of the subsoil conditions is essential. Soft soils at shallow depths have high variability; thus, high spatial resolution is required. Spare telecommunication fiber-optic cables, known as dark fiber, can be used as an array of sensors to measure waves generated by running trains, which offers a unique opportunity to characterize shallow soils at high spatial resolution. We used dark fiber to measure seismic waves generated by running trains and implemented a seismic interferometry technique to retrieve surface waves. We evaluated the reliability of selected parts of the recorded signals split as bow waves (the train approaching the fiber), train waves (the train passing alongside the fiber), and tail waves (the train leaving the fiber) to retrieve broad-band surface waves. The analysis was performed in two distinctive zones. Zone I consists of a thick–soft (2.0–6.0 m thickness) layer, and Zone II consists of a thin–soft (less than 2.0 m thickness) layer, both overlaying a “stiffer” sand layer. At Zone I, train waves yielded the best results in revealing the thick–soft layer. At Zone II, the bow waves yielded clear high-frequency energy, revealing the overall soil structure but without identifying the shallow thin–soft layer. Full article

In the rapidly evolving landscape of modern technology, particularly in telecommunications and pervasive computerization across diverse sectors, the value of information has soared, becoming the linchpin of success in politics and business alike. With the majority of information now flowing through various computing devices, safeguarding them from unauthorized interception has assumed paramount importance. A critical threat in this context emanates from unintentional electromagnetic emissions generated by these devices. Under favorable conditions, these emissions can be exploited by unauthorized entities to reconstruct processed information, a phenomenon known as electromagnetic infiltration. Such emissions, correlated with useful information and conducive to its reconstruction, are termed revealing emissions, with the enabling process labelled as electromagnetic information leakage. This article presents the design and construction of a remote control system for managing antenna amplifier blocks within the AM 524 antenna system, dedicated to investigating information leakage from multimedia devices. The system facilitates remote switching of the five inputs on antenna amplifiers GX 525, GX 526, and GX 527 from a PC, utilizing specialized software. The authors provide an overview of the AM 524 antenna system, elucidate the design concept behind the remote control system, and highlight the central component—the ADAM 6052 module. Additionally, the article introduces the controlling software. It encompasses the device’s construction, including component details, connection schematics, and images of the assembled system, along with a verification process confirming its operational accuracy. Furthermore, the article outlines the application of the proposed solution in assessing the effectiveness of shielding within SAC chambers, employing the measurement methodology specified in accordance with the EN 50147-1:1996 standard. This additional information underscores the practical utility and relevance of the presented remote control system in the context of electromagnetic shielding evaluation for secure environments. Additionally, to assess the effectiveness of the proposed commutator solution, measurements were conducted to evaluate the shielding efficiency of the SAC chamber using a modified coaxial cable. The results of the shielding efficiency of the SAC chamber measurements for the proposed and classical solutions are also presented. Full article

Precast reinforced concrete (RC) girders with dapped ends are used in order to reduce the overall depths of concrete floors and bridge decking and meet architectural requirements. The structural requirements by reducing the depths of these girders result in stress concentrations within the recessed zones. Thus, girders with dapped ends require special details for the strengthening systems. The use of open transverse holes in RC sections is for the passage of various service lines such as telecommunication cables, gas lines, water pipes, electricity cables, etc. The behaviours of RC girders with dapped ends and openings strengthened by bolts subjected to two vertical concentrated loads were numerically simulated by utilising commercial finite element software ANSYS. The numerical results from the simulated models were identical and compatible with those experimental results stated in literature. The validation of the numerical results with those experimental ones was based on the statistical analysis by including the calculations of the correlation coefficients, arithmetic means, and standard deviations for all the simulated girder models in terms of loads and deflections. The obtained numerical results showed that an increase in the compressive strength of concrete by 20% would cause an increase in the loading resistance of the models by 13% and a decrease in the deflection by 21%, respectively. Also, it was indicated that the type of section, i.e., the change of the section from solid to open (with transverse openings), would decrease the resistance of the section by 8–16% and increase the deflections by 15–20%. Similarly, an increase in the number of holes would result in the decreases in the load resistance by up to 6% and the increases in the deflections by up to 24% under the same applied loads. Strengthening openings using vertical bolts has an important role in enhancing the resistance of the models by 8–20% and decreasing the deflections by 20–30%. The failure patterns were hybrid, e.g., flexure and shear, and identical with the experimental ones. Finally, the effect of using the cylindrical compressive strength of concrete as a mechanical parameter on the structural behaviours of the simulated models was investigated, which could improve the resistance loading and decrease the deflections of the models. Full article

Distributed Dynamic Strain Sensing (DDSS), also known as Distributed Acoustic Sensing (DAS), is becoming a popular tool in array seismology. A new generation of engineered fibers is being developed to improve sensitivity and reduce the noise floor in comparison to standard fibers, which are conventionally used in telecommunication networks. Nevertheless, standard fibers already have extensive coverage around the Earth’s surface, so it motivates the use of the existing infrastructure in DDSS surveys to avoid costs and logistics. In this study, we compare DDSS data from stack instances of standard multi-fiber cable with DDSS data from a co-located single-fiber engineered cable. Both cables were buried in an area located 2.5 km NE from the craters of Mt. Etna. We analyze how stacking can improve signal quality. Our findings indicate that the stack of DDSS records from five standard fiber instances, each 1.5 km long, can reduce optical noise of up to 20%. We also present an algorithm to correct artifacts in the time series that stem from dynamic range saturation. Although stacking is able to reduce optical noise, it is not sufficient for restoring the strain-rate amplitude from saturated signals in standard fiber DDSS. Nevertheless, the algorithm can restore the strain-rate amplitude from saturated DDSS signals of the engineered fiber, allowing us to exceed the dynamic range of the record. We present measurement strategies to increase the dynamic range and avoid saturation. Full article

We introduce a novel long-range traffic monitoring system for vehicle detection, tracking, and classification based on fiber-optic distributed acoustic sensing (DAS). High resolution and long range are provided by the use of an optimized setup incorporating pulse compression, which, to our knowledge, is the first time that is applied to a traffic-monitoring DAS system. The raw data acquired with this sensor feeds an automatic vehicle detection and tracking algorithm based on a novel transformed domain that can be regarded as an evolution of the Hough Transform operating with non-binary valued signals. The detection of vehicles is performed by calculating the local maxima in the transformed domain for a given time-distance processing block of the detected signal. Then, an automatic tracking algorithm, which relies on a moving window paradigm, identifies the trajectory of the vehicle. Hence, the output of the tracking stage is a set of trajectories, each of which can be regarded as a vehicle passing event from which a vehicle signature can be extracted. This signature is unique for each vehicle, allowing us to implement a machine-learning algorithm for vehicle classification purposes. The system has been experimentally tested by performing measurements using dark fiber in a telecommunication fiber cable running in a buried conduit along 40 km of a road open to traffic. Excellent results were obtained, with a general classification rate of 97.7% for detecting vehicle passing events and 99.6% and 85.7% for specific car and truck passing events, respectively. Full article

Submarine lifelines (pipelines and cables) often cross areas characterized by earthquake-related geohazards (tectonic faulting, landslides and seabed liquefaction). Avoiding geologically hazardous areas increases the length (i.e., cost), whereas a potential crossing may detrimentally affect the structural performance of the infrastructure, requiring more sophisticated design approaches and/or more costly and probably impractical deep sea condition-mitigation measures. Under such adverse conditions, a cost-effective and resilient lifeline route is deemed necessary. The current paper presents a smart decision-support tool for the optimal route selection of submarine cables, assessing whether the proposed routing could effectively cross a (seismically) geologically hazardous area. The GIS-based tool is based on an efficient methodology that combines a least-cost path analysis with a multi-criteria decision method. Accordingly, several routes can be derived for user-defined scenarios, by assigning different weight factors in the adopted design criteria and hazards. When crossing fault zones, the problem of fault-cable intersection is quantitatively assessed in a realistic manner via advanced numerical models. The optimal route can be selected by considering the potential cable distress (i.e., exceedance of allowable cable strains). This tool can be efficiently implemented for deriving the optimal route of energy and telecommunication offshore cables, as it is described in the examined real case studies. Full article

Distributed acoustic sensing (DAS) is an emerging technology for recording vibration signals via the optical fibers buried in subsurface conduits. Its relatively easy-to-deploy and high spatial and temporal sampling characteristics make DAS an appealing tool to record seismic wavefields at higher quantity and quality than traditional geophones. Considering that the usage of optical fibers in the urban environment has drawn relatively less attention aside from its functionality as a telecommunication cable, we examine its ability to record seismic signals and investigate its preliminary application in city traffic monitoring. To solve the problems that DAS signals are prone to a variety of environmental noise and are generally of weak amplitude compared to noise, we propose a fast workflow for real-time DAS data processing, which can enhance the detection of regular car signals and suppress the other components. We conduct a DAS experiment in Hangzhou, China, a typical metropolitan area that can provide us with a rich data library to validate our DAS data-processing workflow. The well-processed data enable us to extract their slope and coherency attributes that can provide an estimate of real traffic situations. The one-minute (with video validations) and 24 h statistics of these attributes show that the speed and volume of car flow are well correlated demonstrates the robustness of the proposed data processing workflow and great potential of DAS for city traffic monitoring with high precision and convenience. However, challenges also exist in view that all the attributes are statistically analyzed based on the behaviors of a large number of cars, which is meaningful but lacking in precision. Therefore, we suggest developing more quantitative processing and analyzing methods to provide precise information on individual cars in future works. Full article

Among the fire reports caused by seasonal devices registered with the Korea Fire Information Center in 2021, fires caused by heating cables accounted for the largest portion with 350 cases. As a result of analyzing the heating cable fires from 2015 to 2021, we have classified the heating cable fires into four types according to the method of winding the heating wire. First, we hypothesized that the temperature is high when the density is high due to the overlap of the hot wires or when there is a thermal insulating material. We predicted that the temperature would rise through a random game and established a reproducibility test plan. In order to check how heat generation changes depending on the winding method of antifreeze heating cables, we selected 10 manufacturers and checked the temperature characteristics according to the test conditions (Paragraph 11, Paragraph 19.101) of the Technical Regulations for Electrical and Telecommunication Products and Components of Korea (K 10013), tested the four methods mentioned in this thesis and compared and analyzed the results. The experiment results indicate that the temperature of the heater part in antifreeze heating cables was mostly higher than the conditions required by the existing standards in cases 1 to 4. In particular, in the case of No. 5 manufacturer’s sample, the temperature of the heating cable of Case 1 was measured to be the highest at 119.0 °C. In addition, as a result of applying the data engineering reproducibility test results in the framework of the random game λ proposed in this thesis, we have derived the same results as the predicted hypothesis. Case 1 refers to the case where a fire occurs due to the heating cable being wrapped around the water pipe and insulation or taped outside; It is one of the methods that users actually use a lot in the field. Based on experiment, we have concluded that the fire risk is high under the Case 1 condition. Thus, the test conditions in the existing K 10013 Standard need to be strengthened according to the Case 1 condition. Full article

Aramid, chemically known as para phenylene terephthalamide or PPD-T, has been widely used in the reinforcement of telecommunication cables, rubber materials (transmission belts, pneumatic belts), ballistic clothing, and frictional materials primarily due to their high tensile resistance, high elastic modulus, and excellent thermal stability (−80–200 °C). These unique properties of aramid originate from its chemical structure, which consists of relatively rigid polymer chains linked by benzene rings and amide bonds (-CO-NH-). Here, in this work inspired by these properties, a heat spreader called Thermal Interface Material (TIM) is developed by synthesizing a resin from scrap aramid fibers. When hexagonal boron nitride (h-BN) as filler is introduced into the as-synthesized aramid resin to form a thin film of thermal sheet (50 μm), an in-plane thermal conductivity as high as 32.973 W/mK is achieved due to the firmly stacked and symmetric arrangement of the h-BN in the resin matrix. Moreover, the influence of h-BN platelet size is studied by fabricating thermal sheets with three different sizes of h-BN (6–7.5 μm, 15–21 μm, and 30–35 μm) in the aramid resin. The results of the study show that as platelet size increases, thermal conductivity increases significantly. Since the resin reported herein is developed out of scrap aramid fibers, the cost involved in the manufacture of the thermal sheet will be greatly lower. As the thermal sheet is designed with h-BN rather than graphene or carbonaceous materials, this high heat spreading sheet can be employed for 5G antenna modules where properties like a low dielectric constant and high electrical insulation are mandated. Full article
