To realize the real-time structural health and operational safety monitoring of military and industrial devices, such as hypersonic vehicles, aero-engine blades, and thermal power plant boilers, at operating temperatures up to and beyond 1400 °C, this study presents a miniaturised, integrated, high-thermal-stability wireless sensor device. This study investigated the influence of temperature on the interdigital electrodes (IDEs) of surface acoustic wave (SAW) temperature sensors for three configurations: bare electrode, single-layer protective film, and multilayer composite film. While the exposed electrode exhibited thermal stability at 1000 °C, it underwent structural failure at 1250 °C. To achieve health monitoring at temperatures exceeding 1400 °C, an Al₂O₃/AlN/Al₂O₃ multilayer protective architecture was developed. The device demonstrated functionality up to 1400 °C with a temperature coefficient of frequency (TCF) of −40.03 ppm/°C, yielding a sensitivity of 12.0 kHz/°C at a center frequency of ~300 MHz. The electrode protection structure elevated the maximum operating temperature. A hybrid heterogeneous integration of high-temperature co-fired ceramic (HTCC) inverted-F antenna and a Langasite (LGS) SAW device with a multilayer composite film was realised. The wireless device maintained functionality from room temperature to 1400 °C and withstood 1400 °C for 2 h, exhibiting a maximum repeatability error of 12.67% (corresponding to a temperature measurement error of ~177.4 °C at 1400 °C). This integrated design enables the miniaturization of high-temperature wireless sensors, making them suitable for harsh environments. Full article

In the fields of cell engineering, bio-fabrication, and targeted therapy, achieving high-precision manipulation of microparticles and cells remains a technical challenge. Although acoustic tweezers based on surface acoustic waves (SAWs) offer a promising solution, the structural complexity of conventional SAW devices has limited their practical applications. This work proposes a symmetric interdigitated transducer (IDT)-based acoustic tweezers device featuring a simple structure and high flexibility for modulating acoustic pressure field patterns and enabling particle manipulation. Theoretical investigations into the particle manipulation mechanism of the proposed device were conducted using the finite element method. A detachable polymethyl methacrylate (PMMA) assembly chamber was also designed. The effectiveness of the device was validated through dynamic and reconfigurable manipulation experiments using fluorescent polystyrene microspheres. Experimental results demonstrate that the proposed device can rapidly and precisely modulate SAW to achieve array-based manipulation of particle clusters, forming corresponding array patterns. Compared with conventional sorting methods, this device offers advantages including low cost, high precision, ease of operation, and good biocompatibility, making it suitable for large-scale manipulation of microparticles and biological cells. This technology has the potential to expand the application landscape of SAW and may emerge as a cutting-edge approach for directed cell assembly and culture. Full article

High-frequency surface acoustic wave (SAW) devices require piezoelectric thin films combining strong electromechanical coupling, high acoustic velocity, and compatibility with scalable fabrication. Lithium niobate (LiNbO₃) is a promising material, but the growth of high-quality thin films remains challenging because of lithium volatility and process-control issues. In this work, chemical beam epitaxy (CBE) was investigated as an alternative route for the deposition of c-axis-oriented LiNbO₃ thin films on C-plane sapphire at a relatively low growth temperature of 400 °C. Structural characterization confirmed high crystalline quality, with clear (006) and (0012) XRD reflections and a rocking-curve full width at half maximum of 0.04°. To evaluate acoustic performance, a SAW delay line and a one-port resonator were fabricated on 350 nm thick films using e-beam lithography. The devices operated in the 1–3 GHz range and exhibited electromechanical coupling factors of about 0.3% for the Rayleigh mode at 1.7 GHz and 3% for the Sezawa mode at 2.75 GHz. Propagation velocities ranged from 5094 to 8250 m/s, and the Rayleigh-mode resonator quality factor reached about 500. These results demonstrate the feasibility of CBE-grown LiNbO₃ films for SAW device applications. Full article

Controlling spin dynamics conventionally requires external magnetic fields, strong electric bias, or material-specific spin–orbit interactions, while the temporal reference frame remains fixed. Here we introduce curved-time spintronics, a framework in which a synthetic lapse field, implemented through GHz surface-acoustic-wave (SAW) modulation, reshapes the effective flow of time experienced by spinor, magnonic, and photon–spin degrees of freedom. Using a curved-time Schrödinger–Pauli model, we show that it renormalizes the Larmor frequency, modifies SOC-driven splittings, and produces helicity-dependent spin precession under circularly polarized excitation. Strikingly, a spatial lapse gradient induces a Hall-like transverse drift even when in the absence of any external electric field or intrinsic Berry curvature, demonstrating that time geometry alone can generate transverse transport. Time-domain simulations confirm curvature-driven Hall response across graphene, carbon nanotubes, and generic Dirac platforms, establishing a material-agnostic, field-free mechanism for transverse spin manipulation. We further predict curvature-dependent spin diffusion, temporal magnon focusing, and helicity-selective entanglement generation, and propose pump–probe detection via ultrafast Kerr rotation synchronized to SAW-driven lapse modulation. These results position engineered time geometry as a new spintronic control axis, enabling Hall-like effects, spin transport, and chiral phase manipulation without relying on intrinsic material properties, magnetic fields, or electric gating. Full article

The rapid and precise detection of biomarkers and pathogens remains a critical challenge in clinical diagnostics. Traditional methodologies are frequently hindered by protracted workflows, complex sample preparation, and reliance on resource-intensive instrumentation. Acoustofluidics—the synergistic integration of acoustics and microfluidics—has emerged as a transformative solution for point-of-care testing (POCT). Bulk acoustic wave (BAW) and surface acoustic wave (SAW) technologies enable the contactless, label-free, and biocompatible manipulation of bioparticles across micro- and nanometer scales. This review critically examines recent advancements in BAW- and SAW-based acoustofluidic biosensors. We elucidate the fundamental principles governing distinct acoustic modes—including Quartz Crystal Microbalance (QCM), film bulk acoustic resonator (FBAR), and Solidly Mounted Resonator (SMR) for BAW and Rayleigh and Love waves for SAW—and evaluate their specific roles in liquid-phase sensing, particle sorting, and cellular focusing. Results show that integrating on-chip sample preparation accelerates diagnostic workflows, reducing assay times to under 10 min. Coupling acoustic manipulation with optical, mass-based, or electrochemical modalities effectively overcomes fundamental diffusion limits, achieving ultrasensitive, multimodal detection. We address translational challenges—acoustothermal heating, biofouling, and scalable integration. Following a discussion of clinical applications in oncology and infectious diseases, we map emerging trajectories, emphasizing AI-driven intelligent microfluidics, modular architectures, and flexible wearable platforms that will ultimately democratize continuous precision diagnostics. Full article

Capacitive micromechanical ultrasonic transducers (CMUTs), as microelectromechanical systems (MEMS) devices, have broad application prospects in ultrasonic imaging and sensing. This study investigates the influence of surface acoustic waves (SAWs) using periodically arranged CMUTs as the fundamental unit cells. We first utilize finite element analysis (FEA) to calculate and analyze the band structure and bandgap characteristics of phononic crystals under infinite periodic conditions. Subsequently, for finite periodic structures in practical applications, acoustic transmission spectra were further simulated using FEA to verify the bandgap characteristics of the structure for SAWs. Accordingly, this paper leverages a deep learning framework based on a multilayer perceptron (MLP) architecture to achieve the inverse design and optimization of CMUT geometric parameters, tailored to specific target bandgap requirements. The results demonstrate that this approach can efficiently and accurately determine the optimal structural configurations, offering a robust and novel technical paradigm for the precise control of SAWs using CMUT-based periodic arrays. Full article

Surface Acoustic Wave (SAW) magnetic sensors are traditionally fabricated on rigid substrates, which severely limits their application on curved or irregular surfaces. To address this critical limitation, this paper presents a novel flexible SAW magnetic sensor based on a grating-arrayed Terfenol-D thin film deposited on a 50 µm thick flexible lithium niobate (LiNbO₃) substrate. Unlike conventional designs using a continuous magnetostrictive layer, the proposed grating-arrayed structure is designed to aid in hysteresis compensation and minimize measurement errors associated with residual magnetization. As demonstrated experimentally, the sensors achieve a high sensitivity of 85.8 kHz/mT for devices with λ-wide gratings and a maximum frequency shift of 377 kHz at 5 mT. A systematic investigation reveals that sensitivity is critically dependent on the grating width and film thickness, with 500 nm thick gratings yielding optimal performance. Crucially, the sensor’s functionality under mechanical deformation is validated, and a differential measurement method is introduced to effectively compensate for stress-induced frequency shifts, ensuring reliable operation in practical, non-ideal conditions. The results confirm the sensor’s robust performance under the tested stress conditions, positioning this flexible SAW magnetic sensor as a promising solution for advanced, conformable sensing applications. Full article

Surface Acoustic Wave (SAW) technology, long central to analog signal processing and RF filtering, is undergoing a major renewal. Driven by advances that decouple SAWs from traditional piezoelectric materials and fixed-function devices, the field is gaining unprecedented control over acoustic, optical, and electronic interactions at the micro and nanoscale. This review synthesizes these developments across four fronts: new physical mechanisms for SAW manipulation, emerging material platforms, ranging from thin films to 2D systems, along with reconfigurable device architectures and circuits, and the expanding landscape of applications they enable. Optical methods are reshaping how SAWs are generated and controlled, bypassing the limits of conventional electromechanical coupling. Coherent optical excitation of high-Q SAW cavities via Brillouin-like optomechanical interactions now grants access to modes in non-piezoelectric substrates such as diamond and silicon, while on-chip SAW excitation in photonic waveguides through backward stimulated Brillouin scattering opens new integrated sensing routes. In parallel, magneto-acoustic experiments have revealed nonreciprocal SAW diffraction from resonant scattering in magnetoelastic gratings. On the device side, ZnO thin-film transistors integrated on LiNbO₃ exploit acoustoelectric coupling to realize voltage-tunable phase shifters; UHF Z-shaped delay lines achieve high sensitivity in a compact footprint; and parametric synthesis of wideband, multi-stage lattice filters targets 5G-class performance. Atomistic simulations show that SAW propagation in 2D MXene films can be engineered via surface terminations, while aerosol jet printing and SAW-assisted particle patterning provide agile, cleanroom-light fabrication of microfluidic and magnetic components. These advances enable applications ranging from hybrid quantum systems and quantum links to lab-on-a-chip particle control, SBS-based and UHF sensing, reconfigurable RF front-ends, and soft robotic actuators based on patterned magnetic composites. At the same time, optical techniques offer non-contact probes of dissipation, and MXenes and other emerging materials open new regimes of acoustic control. Conclusively, they are transforming SAW technology into a versatile, programmable platform for mediating complex interactions in next-generation electronic, photonic, and quantum systems. Full article

This paper introduces a laser interferometric elastography (LIE) system that uses a narrow linewidth laser and a single photodetector to measure mechanical displacements induced by surface acoustic waves (SAWs) generated by an electrically driven piezoelectric transducer. The method relies on phase delay analysis of the resulting interference signal to determine displacement within the medium, thereby eliminating the need for complex interferometers and broadband light sources. By substantially reducing optical hardware requirements, the system provides a compact and cost-effective platform for elasticity mapping in biological samples. Quantitative assessment of mechanical properties is achieved through controlled mechanical excitation and phase-resolved signal collection, demonstrating the practicality of simplified LIE for real-world applications. Full article

A two-dimensional segmentation model based on the P-matrix array was developed to simulate surface acoustic wave (SAW) delay-line devices under irregular loading. Building on coupling-of-modes (COM) theory and P-matrix model, a channelization approach was introduced to enhance conventional response simulation, enabling the systematic extraction of frequency and phase characteristics under varying spatial load distributions. Experimental verification was conducted using SAW devices fabricated by depositing aluminum interdigital transducers (IDTs) on Y-cut 35° quartz crystals through semiconductor lithography. The results demonstrate that the two-dimensional segmentation method effectively and accurately simulates the response of SAW delay line devices under various non-uniform and irregular mass loading distributions, both the phase shift and frequency shift exhibit linear proportionality to the loaded area (R² > 0.99), while the amplitude-frequency characteristics remain stable with increasing load coverage, showing no observable distortion or aberration. Quantitative mass detection experiments employing polystyrene microspheres further demonstrate that the device response increases linearly with the number of sample injections, and the shift magnitude is directly proportional to the amount injected per loading event. Full article

This paper presents a yarn tension sensor based on Surface Acoustic Waves (SAW). To enhance the detection accuracy of the sensor, an improved beam structure is designed for tension measurement, along with intelligent algorithms for temperature compensation. Firstly, regarding the sensor structure, a simply supported beam with a hyperbolic surface is designed to achieve stress concentration by reducing the section modulus at the beam’s midpoint. Secondly, by incorporating an unbalanced split-electrode Interdigital Transducer (IDT) design, the sensor effectively suppresses signal sidelobe interference and significantly improves the structure’s tension sensitivity. Finally, in terms of signal processing, to eliminate the influence of environmental temperature fluctuations on measurements, a temperature-compensation algorithm based on Bayesian Optimization Least Squares Support Vector Machine (BO-LSSVM) with Gaussian Process regression is proposed. Experimental results show that the tension sensitivity of the improved structure was 8.2% higher than that of the doubly clamped beam and 12.7% higher than that of the cantilever beam. For temperature compensation, the BO-LSSVM model reduced the Mean Relative Error (MRE) by 5.67 percentage points relative to raw data and by 2.04 percentage points relative to the fixed-parameter LSSVM model, lowering the temperature sensitivity coefficient from 4.09 $(\times {10}^{-3}/°\mathrm{C})$ to 0.41 $({10}^{-3}/°\mathrm{C})$. Full article

Acoustofluidics has emerged as a transformative technology for contact-free manipulation of microparticles and fluids in microscale systems. Although bulk acoustic waves (BAWs) are known to displace inhomogeneous fluids through acoustic radiation force acting at fluid interfaces, the capability of surface acoustic waves (SAWs) to produce analogous relocation phenomena remains largely unexplored. This study addresses a critical gap in acoustofluidic theory by presenting the first comprehensive finite element method investigation of SAW-driven motion of inhomogeneous fluid confined within microchannels of widths equal to one full or one-half SAW wavelength. Unlike BAW-based system that generate uniform pressure fields across channel heights, SAW devices exhibit inherently nonuniform vertical pressure distributions and intense near-boundary streaming—features that fundamentally alter fluid relocation dynamics. Our simulations demonstrate that despite high-frequency operation (6.65 MHz) and strong ARF, standing SAW fields fail to achieve stable fluid relocation in both initially stable and unstable configurations due to vertical pressure stratification and rapid floor-level streaming. Nevertheless, these same characteristics generate vigorous transverse folding flows that enable exceptionally rapid homogenization, offering a distinct acoustofluidic mechanism for on-chip mixing. These findings not only elucidate fundamental physical differences between BAW and SAW actuation in multiphase microfluidic systems but also establish design principles for SAW-induced microfluidic mixers. The results provide crucial theoretical guidance for device optimization where rapid homogenization is desired over stable stratification. Full article

Plasma regeneration was investigated as a means of regenerating microstructures on biosensors for repeated use. These microstructures were based on the deposition of suspensions containing polymer microspheres. While this method provides a simple way to structure surfaces, obtaining regular structures in a reproducible way remains a challenge. Therefore, it would be advantageous to be able to reuse regular structures, which requires regeneration. To investigate this concept, surface acoustic wave (SAW) resonators were structured using 5 µm and 20 µm polystyrene microspheres and coated with parylene C to stabilize the particle structures. After use in bioanalytical experiments, the biological residues and the parylene C cover layer were removed with plasma, and a new parylene C layer was added. Both atmospheric and low-pressure plasma were tested for regeneration. As a result, the low-pressure plasma was to be preferred because it did not damage the transducer structures on the SAW resonators, unlike the atmospheric plasma. Water contact angle measurements and transmission spectra recorded with a network analyzer confirmed that freshly prepared and regenerated structured SAW resonators coated with parylene C exhibited similar wetting properties and resonance parameters. Therefore, plasma regeneration is an effective way to enable the reuse of perfectly structured SAW resonators. Full article

This paper presents a cover lens concept for camera modules based on surface acoustic waves (SAW) to mitigate the degradation of physical AI optical sensor field-of-view performance caused by surface contamination. The proposed approach utilizes a single-phase unidirectional transducer (SPUDT) that intentionally breaks left–right symmetry through a geometrically asymmetric electrode array to generate SAW, thereby removing droplet contamination. First, the acoustic streaming induced inside a single sessile droplet by the SAW was visualized, and the dynamic behavior of the droplet upon SAW actuation was observed using a high-speed camera. The internal flow developed into a recirculating vortex structure with directional deflection relative to the SAW propagation direction, indicating a symmetry-broken streaming pattern rather than a purely symmetric circulation. Upon the application of the SAW, the droplet was confirmed to move a total of 7.2 mm along the SAW propagation direction, accompanied by interfacial deformation and oscillation. Next, an analysis of transport trajectories for five sessile droplets dispensed at different y-coordinates ($y_1$–$y_5$) revealed that all droplets were transported along the x-axis regardless of their initial positions. Furthermore, the analysis of transport velocity as a function of droplet viscosity (1 $\mathrm{c}\mathrm{P}$ and 10 $\mathrm{c}\mathrm{P}$) and volume (2$\mathrm{\mu }\mathrm{L}$, 4$\mathrm{\mu }\mathrm{L}$, and 6 $\mathrm{\mu }\mathrm{L}$) demonstrated that the transport velocity gradually increased with driving voltage but decreased as viscosity increased under identical actuation conditions. Finally, the proposed cover lens was applied to an automotive front camera module to verify its effectiveness in improving object recognition performance by removing surface contamination. Based on its simple structure and driving principle, the proposed technology is deemed to be expandable as a surface contamination cleaning technology for various physical AI perception systems, including intelligent security cameras and drone camera lenses. Full article

Langasite (LGS)-based surface acoustic wave (SAW) sensors are promising for high-temperature pressure detection. However, their performance is limited by the low pressure sensitivity of conventional sealed-cavity packaging and temperature-induced measurement drift. To address these issues, this study introduces a novel LGS SAW pressure sensor featuring two key innovations: a Kovar alloy point-force packaging structure to amplify pressure-induced LGS substrate deformation, enhancing sensitivity compared to traditional designs, and SAW resonators fabricated on an LGS (0°, 138.5°, 26.7°) cut, selected based on electromechanical simulations for its superior intrinsic pressure sensitivity and monotonic frequency–temperature response, effectively mitigating temperature interference on pressure measurements. Experimental characterizations show the resonator achieves a high Q-value of ~3000 at ~357 MHz. Tested under conditions of 250 °C and 0–0.4 MPa, the sensor exhibits a pressure sensitivity of 0.1866 MHz/MPa with a relative error of only 4.8% versus the finite element method (FEM)-simulated 0.196 MHz/MPa, demonstrating the proposed design’s effectiveness for accurate, stable pressure monitoring in harsh high-temperature environments such as turbine engines and high-temperature manufacturing lines. Full article
