The dynamic injection characteristics of high-pressure common rail fuel injection systems are determined by the speed response performance of the solenoid valve. A simulation model has been established for investigating the influence mechanism and change law of characteristic parameters on speed response characteristics of the solenoid valve. The speed response characteristics of the solenoid valve, including the average opening speed, the average closing speed, the maximum opening speed, and the maximum closing speed, caused by the changes of characteristic parameters such as pre-tightening force of the solenoid valve spring, mass of the solenoid valve moving parts, diameter of the outflow orifice, diameter of the inflow orifice, diameter of the control piston, and pressure in the common rail, have been studied. The correlation analysis of the influence factors is carried out by using the experimental design method based on the response surface model, and the correlation coefficients between each factor and the speed response characteristics of the solenoid valve are obtained. The results show that both single factors and interaction factors of the parameters are correlated with the speed response characteristics of the solenoid valve. The results of this paper can provide a theoretical reference for the design and optimization of the high-pressure common rail injector. Full article

The present research analyses the injection rate of a direct rail injection diesel engine, focusing specifically on the influence of the nozzles and various operating conditions from real road tests on the rate of injection. A diesel injector test bench was used for feedback with real data from the test vehicle under real road conditions. An analysis of the behaviour of the injection rate was carried out using the zero-dimensional model. This model generated a predictive model that incorporated the five variables identified through a developed multivariate analysis of variance, showing a high correlation of dependence between variations in injection pressure, the diameter of the holes, and the number of holes with greater representativeness. The results obtained showed that the nozzle geometry and the physical properties of the fuel had a direct effect on the injection rate. This analysis enriches the understanding of fuel injection and its effects on diesel engine performance by providing an analysis of the system components that influence the injection rate and generating a simple tool to feed thermodynamic diagnostic models. The proposal model may be used as an input in thermodynamics predictive models and reduce the simulation load in computational fluid dynamics predictive models. Full article

A variety of needle-motion profiles are used in diesel injectors. However, it is unclear what the underlying mechanism is to determine the needle-motion profiles and how they affect the spray dynamics. It has been of significant interest to examine how the spray dynamics will change if only altering the needle valve opening speed or closing speed while all other parameters are kept the same. The different needle-motion profiles were obtained using a piezo nozzle (Nozzle #P) and a solenoid nozzle (Nozzle #S), which have identical nozzle geometry. By utilizing the X-ray imaging technique, it was observed that the average needle valve speed of Nozzle #P was 51% higher at the opening stage but 17% lower at the closing stage than Nozzle #S. When the needle valve lift is low (approximately 200 $\mathsf{\mu }\mathrm{m}$), the needle valve opening speed has a crucial effect on spray dynamics. The faster needle valve opening of Nozzle #P results in a 42% larger spray spreading angle and 34% lower spray velocity at the downstream field. The spray dynamics may be controllable by properly designing the needle-motion profiles in the scenarios of the low needle lifts. However, when the needle valve is sufficiently open (approximately over 200 $\mathsf{\mu }\mathrm{m}$), almost identical spray characteristics were observed regardless of the needle-motion profiles. Full article

This paper presents a flow analysis of the original pressure sensor used to determine times until full opening and closing of the pulse-operated low-pressure gas-phase solenoid valve. The sensor in question, due to the fast variation of the process lasting several milliseconds, has high requirements in terms of response time and ability to identify characteristic parameters. A CFD code has been employed to successfully model the flow behavior of the original pressure sensor used to determine times until full opening and closing of the pulse-operated low-pressure gas-phase solenoid valve at different inlet flow conditions, using the Eulerian multiphase model, established on the Euler–Euler approach, implemented in the commercial CFD package ANSYS Fluent. The results of the modelling were validated against the experimental data and also give more comprehensive information on the flow, such as the plunger displacement waveform. The flow calculations were dynamic in nature; therefore, the experimental plunger displacement waveforms were entered as input in the software for dynamic mash implementation. In identifying the times until full opening and closing, the characteristic points of the pressure waveform on the pressure sensor plate were adopted. CFD flow calculations confirmed the accuracy of identifying the times until full opening and closing by relating them to the results from the plunger displacement sensor. The validation of the results of calculations with the analyzed sensor and the original stand also confirmed the correctness of the use of this type of method for the assessment of gas injector operating times. In the case of time until full opening, the CFD calculations were shown to be consistent with experimental tests, with only a few cases where the relative difference with respect to the displacement sensor reached 3%. The situation was slightly worse in the case of time until full closing, where the results of CFD calculations were in agreement with the displacement sensor, while the experimental test stands had a relative difference of up to 21%. It should be remembered that the sensor evaluates times below 5 × 10⁻³ s, and its construction and response time determine the use depending on the adopted level of accuracy. Full article

An experimental study was performed to explore the influence of dwell time on the hydraulic interactions between injection events using pilot injection strategy, split injection strategy, post injection strategy and a solenoid diesel injector. To do so, a sweep of dwell time from 0.55 up to 2 ms using all multiple injection strategies and levels of rail pressure, of 80, 100 and 120 MPa, and single level of back pressure, of 5 MPa, was performed. The hydraulic interactions between injection events were characterized through the second injection hydraulic delay and second injection mass in an injection discharge curve indicator equipped with all the components required for its operation and control. In order to define the operating conditions of the multiple injection strategies, to ensure the same injected fuel mass in all cases, the characteristic curves of injection rate for the solenoid diesel injector studied were obtained. The second injection hydraulic delay increases with dwell time values in the range of 0.55–0.9 ms for all multiple injection strategies and levels of rail pressure tested. Conversely, the second injection hydraulic delay decreases with dwell time values higher than 0.9 ms. Moreover, the second hydraulic delay depends mainly on the dwell time and not on the injected fuel mass during the first injection event. The second injection mass increases with dwell values less than 0.6 ms. By contrast, the second injection mass is not significantly affected by that of the first injection at a dwell time higher than 0.6 ms. Full article

The tire pyrolysis oil is a waste-derived fuel with a lower cetane number and higher den-sity than diesel fuel, but this is a promising waste-based fuel for compression ignition en-gines. In the European Union, it is necessary to increase the bio-share of fuels, and the second-generation waste-derived blend components are essential for achieving the 2030 goals. The injection characteristics of tire pyrolysis oil and diesel oil were investigated on a Bosch solenoid type common rail (CR) injector. Six different premixed ratios were investi-gated, including in a low volume percentage 250 ppm and higher 10%, 20%, and 100% pyrolysis oil and 100% diesel oil. The simulation investigation was done in the AVL Fire software, the experimental investigations were done on a LDX CR injection test bench, and the videos were taken on an Olympus Ispeed 3 camera. The scope of the research was to record the flow pattern of the fuel mixture, flowing out of the high-pressure injector, from which the mixing with air and the quality of the resulting combustion can be deduced, which has a significant effect on the emissions. Full article

The presented paper aims to study the influence of mineral diesel fuel and synthetic Gas-To-Liquid fuel (GTL) on the injection process, fuel flow conditions, and cavitation formation in a modern common-rail injector. First, the influence on injection characteristics was studied experimentally using an injection system test bench, and numerically using the one-dimensional computational program. Afterward, the influence of fuel properties on internal fuel flow was studied numerically using a computational program. The flow inside the injector was considered as multiphase flow and was calculated through unsteady Computational Fluid Dynamics simulations using a Eulerian–Eulerian two-fluid approach. Finally, the influence of in-cylinder back pressure on the internal nozzle flow was studied at three distinctive back pressures. The obtained numerical results for injection characteristics show good agreement with the experimental ones. The results of 3D simulations indicate that differences in fuel properties influence internal fuel flow and cavitation inception. The location of cavitation formation is the same for both fuels. The cavitation formation is triggered regardless of fuel properties. The size of the cavitation area is influenced by fuel properties and also from in-cylinder back pressure. Higher values of back pressure induce smaller areas of cavitation and vice versa. Comparing the conditions at injection hole exit, diesel fuel proved slightly higher average mass flow rate and velocities, which can be attributed to differences in fluid densities and viscosities. Overall, the obtained results indicate that when considering the injection process and internal nozzle flow, GTL fuel can be used in common-rail injection systems with solenoid injectors. Full article

The article presents a model-based evaluation of the impact of the plunger stroke on functional parameters of the low-pressure pulse gas solenoid injector. A reduced-order physics-based mathematical model was used to achieve this goal. The model was built on the basis of specified simplifications of the process, considering the forces that cause the plunger to move and the forces constituting resistance to its displacement. The implementation of a mathematical description in to the Matlab-Simulink environment allowed one to determine the characteristic values of operation of the Valtek Rail Type-30 injector, including plunger displacement courses. Calculations made with the assumption of the factory plunger stroke confirmed the validity of the model. The differences in opening and closing times were below 3% in comparison to the values given in the objects technical information. By assuming a specific plunger stroke, the functional relationships of opening and closing times were determined. The results showed a distortion of the force–response dependence for different plunger strokes. Results presented in the article can be used to support control-oriented modeling of systems incorporating pulsed gas dosing devices, such as combustion engines or gas turbines. More specifically, the proposed method can be used to pre-calibrate the delay time of the injector operation. Full article

The present investigation uses a blend of Nigella sativa biodiesel, diesel, n-butanol, and graphene oxide nanoparticles to enhance the performance, combustion and symmetric characteristics and to reduce the emissions from the diesel engine of a modified common rail direct injection (CRDI). A symmetric toroidal-type combustion chamber and a six-hole solenoid fuel injector were used in the current investigation. The research aimed to study the effect of two fuel additives, n-butanol and synthesized asymmetric graphene oxide nanoparticles, in improving the fuel properties of Nigella sativa biodiesel (NSME25). The concentration of n-butanol (10%) was kept constant, and asymmetric graphene oxide nano-additive and sodium dodecyl benzene sulphonate (SDBS) surfactant were added to n-butanol and NSME25 in the form of nanofluid in varying proportions. The nanofluids were prepared using a probe sonication process to prevent nanoparticles from agglomerating in the base fluid. The process was repeated for biodiesel, n-butanol and nanofluid, and four different stable and symmetric nanofuel mixtures were prepared by varying the graphene oxide (30, 60, 90 and 120 ppm). The nanofuel blend NSME25B10GO90 displayed an enhancement in the brake thermal efficiency (BTE) and a reduction in brake-specific fuel consumption (BSFC) at maximum load due to high catalytic activity and the enhanced microexplosion phenomenon developed by graphene oxide nanoparticles. The heat release rate (HRR), in-cylinder temperature increased, while exhaust gas temperature (EGT) decreased. Smoke, hydrocarbon (HC), carbon monoxide (CO₂) and carbon monoxide (CO) emissions also fell, in a trade-off with marginally increased NO_x, for all nanofuel blends, compared with Nigella sativa biodiesel. The results obtained indicates that 90 ppm of graphene oxide nanoparticles and 10% n-butanol in Nigella sativa biodiesel are comparable with diesel fuel. Full article

An experimental investigation has been carried out to compare the performance and emissions of a low-compression-ratio Euro 5 diesel engine featuring high EGR rates, equipped with different injector technologies, i.e., solenoid, indirect-acting, and direct-acting piezoelectric. The comparisons, performed with reference to a state-of-the-art double fuel injection calibration, i.e., pilot-Main (pM), are presented in terms of engine-out exhaust emissions, combustion noise (CN), and fuel consumption, at low–medium engine speeds and loads. The differences in engine performance and emissions of the solenoidal, indirect-acting, and direct-acting piezoelectric injector setups have been found on the basis of experimental results to mainly depend on the specific features of their hydraulic circuits rather than on the considered injector driving system. Full article

This paper provides a new common rail injector drive circuitry for practical use. The new drive circuitry with variable freewheeling circuit was developed based on the requirements for the rate of current drop in the peak-and-hold solenoid model. The variable freewheeling circuit exhibited superior performance in the control accuracy compared to the conventional circuit with a resistor in series with diode (RD) freewheeling circuit. Furthermore, the current cutting process was 30 $\mathsf{\mu }$ s shorter, and the control accuracy of the cycle fuel injection mass was improved by at least 0.36% or exactly 2.86% when a small fuel injection mass was used. In addition, the variable freewheeling circuit consumed less power because the drive power charging was done through the feedback from electromagnetic energy to electrical energy. When the fuel injection mass was large, the fall range of the driving power voltage became 1 V smaller, its recovery time was 1ms shorter, and the highest temperature of the drive circuitry was only 37 ${}^{\circ }$ C, which was 127 ${}^{\circ }$ C lower than that of the RD freewheeling due to the decrease in energy consumption. Finally, experimental tests with a multi-cylinder engine showed that the variable freewheeling circuit reduced the cycle-by-cycle combustion variations by 0.5%, and lessened the NOx and soot emissions significantly by 3.5% and 4%, respectively, in comparison to the RD freewheeling circuit. Full article

The high-pressure (HP) injector is a highly dynamic component requiring careful voltage and pressure input modulation to achieve the required fuel injection quantities of gasoline direct injection (GDI) engines. Accurate fuel injection curves are a key influence for this technology, and therefore, will require an accurate estimation of fuel flow rate to be realized. In order to be driven to rapid response with respect to solenoid valve coils, HP injectors typically require to be designed to be capable of rapid response in GDI engines. In this paper, the design and analysis of the proposed injector drive circuit are presented. Next, the effects of total pulse width, injector supply voltage, fuel system pressure, and pulse width modulation (PWM) operation on fuel injection quantities of an HP injector are measured for achieving robust performance and stability in the presence of bounded errors of the GDI injectors due to total pulse width, injector’s supply voltage, fuel pressure and PWM operation. Additionally, the fuel injection quantities of the HP injector are measured by tuning the parameters of the injector drive circuit with the PWM operation. These are defined as the fuel injection curves. Finally, experimental results are provided for verification of the proposed injector drive circuit. Full article

Optimising the combustion process in compression ignition (CI) engines is of interest in current research as a potential means to reduce fuel consumption and emission levels. Combustion optimisation can be achieved as a result of understanding the relationship between spraying technique and combustion characteristics. Understanding macroscopic characteristics of spray is an important step in predicting combustion behaviour. This study investigates the impact of injector hole diameter on macroscopic spray characteristics (spray penetration, spray cone angle, and spray volume) of butanol-diesel blends. In the current study, a Bosch (0.18 mm diameter) and a Delphi (0.198 mm) injector were used. Spray tests were carried out in a constant volume vessel (CVV) under different injection conditions. The test blends were injected using a solenoid injector with a common rail injection system and images captured using a high-speed camera. The experimental results showed that the spray penetration (S) was increased with larger hole diameter. Spray penetration of a 20% butanol-80% diesel blend was slightly further than that of neat diesel. Spray penetration of all test fuels was increased as a result of increased injection pressure (IP), while spray cone angle (θ) was slightly widened due to the increase in either hole diameter or injection pressure. Spray volume of all test fuels was increased as a result of increased hole diameter or injection pressure. Thus, an efficient diesel engine performance can be achieved as a result of controlling injection characteristics, especially when using a promising additive like butanol blended with diesel. Full article

Diversification of energy sources is a key task for decreasing environmental impacts and global emission of gases. JP-8, a fuel derived from natural gas, coal, biomass, and waste plastics, is a bright prospect. JP-8 is considered a multi-source multi-purpose fuel, with several applications. A preliminary characterization of the JP-8 injection rate and injection quantity behavior was investigated based on the high-pressure common rail injection system used in a heavy-duty engine. According to the spill injection and injection pressure, a trade-off trend between injection rate and injection quantity was observed. As expected, pilot injection of JP-8 aviation fuel and diesel fuel affects the spray quantity and injection evolution of the subsequent operation without pilot injection. The difference in spilling between diesel and JP-8 aviation fuel is greater than the difference in injection amount per time; in the process of controlling the injector solenoid through ECU (Electric Control Units), the oil pressure valve and the needle valve operate to a higher extent in order to maintain the diesel fuel’s injection quantity volume. It was found that the total injection quantity was decreased by adding 20% pilot injection duration. Because the pilot injection quantity causes solenoid response, loss and needle lift stroke friction loss. Full article
