Search Results (29)

This paper presents a circularly polarized (CP) antenna based on crossed dipoles with bandpass-type filtering radiation response. The antenna employs a pair of crossed dipole arms as radiators, which are printed on the upper and lower planes of the substrate. To achieve bandpass filtering effects, radiation nulls are introduced on both sides of the passband. By vertically extending the ends of the four dipole arms, a ring-shaped current is formed between adjacent dipoles, generating the upper-band radiation null. Additionally, four parasitic patches are introduced parallel to the ends of the crossed dipole arms, creating another upper-band radiation null, further enhancing the frequency selectivity at the band edges and broadening the axial ratio (AR) bandwidth. Moreover, a square-ring slot is etched on the ground plane to introduce a lower-band radiation null, ultimately achieving a good bandpass filtering response. The proposed wideband CP filtering dipole antenna is implemented and tested. The antenna has a compact size of 0.49${\lambda }_0\times$ 0.49${\lambda }_0\times$ 0.16${\lambda }_0$ (where ${\lambda }_0$ denotes the wavelength corresponding to the lowest operating frequency). The measured results show that the proposed antenna has an impedance bandwidth of 75% (1.65–3.66 GHz) and an overlapping AR bandwidth of 46.9% (2.25–3.63 GHz). Without additional filtering circuits, the antenna exhibits a stable gain of approximately 7 dB and three radiation nulls, with suppression levels of 20 dB in both the lower and upper stopbands, achieving good bandpass filtering performance. Full article

A millimeter-wave multi-layer and miniaturized multibeam antenna fed by an E-plane Butler matrix (BM) in substrate integrated waveguide (SIW) technology is proposed. For the beam-forming network (BFN), a folded E-plane 4 × 4 BM is proposed, whose basic components are stacked up along the vertical direction aiming to reduce the horizontal size by more than 75% compared with a single-layer BM. For the radiation portion, an unconventional slot antenna array arranged in a ladder type is adopted. The slot antenna elements are distributed in separate layers, making them more compatible with the presented BM and are arranged in the longitudinal direction to suppress the mutual coupling effect. Furthermore, the BM has been adjusted to accommodate the slot antenna array and obtain further miniaturization. The overall dimension of the designed multibeam antenna, taking the BFN into account, is 12 mm × 45 mm × 2 mm (1.2 λ × 4.5 λ × 0.2 λ), which is preferable for future 6G smartphone applications. The impacts of the air gap in fabrication are also taken into consideration to alleviate the error between simulated model and fabricated prototype. Full article

With the rapid development of Wi-Fi 6/6E and dual-band wireless systems, there is an increasing demand for compact antennas with balanced high-gain performance across both 2.4 GHz and 5 GHz bands. However, most existing dual-band metasurface antennas face challenges in uneven gain distribution between lower/higher-frequency bands and structural miniaturization. This paper proposes a high-gain dual-band metasurface antenna based on an artificial magnetic conductor (AMC) array, which has a significant advantage in miniaturization and improving antenna performance. Two types of dual-band AMC structures are applied to design the metasurface antenna. The optimal antenna with dual-slot AMC array operates in the 2.42–2.48 GHz and 5.16–5.53 GHz frequency bands, with a 25% size reduction compared to the reference dual-band U-slot antenna. Meanwhile, high gains of 7.65 dBi and 8 dBi are achieved at 2.4 GHz and 5 GHz frequency bands, respectively. Experimental results verify stable radiation gains across the operation bands, where the total efficiency remains above 90%, agreeing well with the simulation results. This research provides an effective strategy for high-gain and dual-band metasurface antennas, offering a promising solution for integrated modern wireless systems such as Wi-Fi 6, Bluetooth, and MIMO technology. Full article

Millimeter-wave antennas have become more important recently due to the diversity of applications in 5G and upcoming 6G technologies, of which automotive systems constitute a significant part. Two crucial indices, detection range and angular resolution, are used to distinguish the performance of the automotive antenna. Strong gains and narrow beamwidths of highly directive radiation beams afford longer detection range and finer spatial selectivity. Although conventionally used, patch antennas suffer from intrinsic path losses that are much higher when compared to the waveguide antenna. Designed at 77 GHz, presented in this article is an 8-element slot array on the narrow side wall of a rectangular waveguide, thus being readily extendable to planar arrays by adding others alongside while maintaining the element spacing requirement for grating lobe avoidance. Comprising tilted Z-shaped slots for higher gain while keeping constrained within the narrow wall, adjacent ones separated by half the guided wavelength are inclined with reversed tilt angles for cross-polar cancelation. An open-ended external waveguide is placed over each slot for polarization purification. Equivalent circuit models of slotted waveguides aid the design. An approach for sidelobe suppression using the Chebyshev distribution is adopted. Four types of arrays are proposed, all of which show potential for different demands and applications in automotive radar. Prototypes based on designs by simulations were fabricated and measured. Full article

To achieve multi-band coverage within limited space, reduce antenna types, and enhance communication capabilities, an eight-unit dual-band 5G MIMO antenna array is proposed based on a monopole structure. The antenna operates in two frequency bands (3.23–4.14 GHz and 4.31–5.3 GHz), covering the n78 and n79 bands for 5G applications. The dual-band and miniaturized design of the antenna elements is achieved through the slotting and branch-loading techniques. The orthogonal placement of corner antenna elements is implemented to reduce coupling and optimize spatial utilization, achieving isolation of over 16 dB between elements. The introduction of a metasurface structure further improved isolation by 2 dB and increased the peak gain of the antenna array to 11.95 dBi. A prototype is fabricated and tested, demonstrating the following performance metrics: isolation exceeding 18 dB, gain ranging from 6 to 12 dBi, envelope correlation coefficient below 0.05, channel capacity greater than 41 bps/Hz, diversity gain of approximately 10 dB, total active reflection coefficient below −24 dB, and radiation efficiency exceeding 72%. These results confirm the superior performance of the proposed antenna design. Full article

As metasurfaces are in the spotlight, research is being conducted to incorporate them into transmitarray (TA) antennas. Among these, as an attempt to create a low-profile design, a patch antenna classified as low-gain can be utilized as an appropriate source antenna. However, for high efficiency of the TA, the gain of the source antenna must be fundamentally improved. For this, a simple side metal structure was applied to a metallic cross-type slot transmitarray. This acts as a resonant element and reflector by utilizing the electromagnetic wave radiated from the source antenna. The changes in the center frequency and gain due to the application of the side metal structure to the source antenna were analyzed. The gain of the source antenna was improved by a total of 4.63 dB. This is expected to be applied to create various source waves and to conduct future research on improving the gain in transmitarray antennas. Full article

In this study, a millimeter-wave (mmWave) dielectric resonator antenna (DRA) with an omnidirectional pattern is presented for the first time. A key feature of the proposed design is the utilization of a planar feed network to achieve omnidirectional radiation from a rectangular DRA, which has not been reported previously in the open literature. In addition, the proposed antenna offers multiband operation with different types of radiation patterns. The degenerate TE₁₂₁/TE₂₁₁ modes were excited at 28.5 GHz with an overall internal electromagnetic field distribution that was similar to that of the HEM_21δ mode of a cylindrical DRA. The achieved omnidirectional bandwidth and gain were 1.9% and 4.3 dBi, respectively. Moreover, broadside radiation was achieved by exciting the TE₁₁₁ fundamental mode at 17.5 GHz together with the resonance of the feeding ring-slot at 23 GHz. The triple-band operation offers a highly versatile antenna that can be utilized in on-body and off-body communications. Furthermore, the proposed design was validated through measurements, demonstrating good agreement with simulations. Full article

Ultra-wideband (UWB) antennas cover a frequency range of 3.1 to 10.6 GHz and have sparked a lot of research interest as an essential part of wireless communication systems as they provide high data transmission speeds, are less expensive, and consume less power. UWB antennas are widely used in radar imaging, radio frequency identification, public security, and other high-accuracy positioning devices such as altimetry. Some smart applications of UWB antennas are vehicular radar systems, surveillance systems, software-defined radios, spectrum analysis, proximity fuses, etc. Multiple-input-multiple-output (MIMO) is a multiplexing technology that adopts multiple antennas both at the transmitter and receiver, which can enhance the channel capacity. MIMO technology is extensively used in several applications, such as in portable devices, wireless body area networks (WBANs), vehicular communication, and satellite–terrestrial networks. Generally, the MIMO antennas are used to obtain high reliability, high capacity, high throughput, and high security. The UWB MIMO antennas (UMAs) are considered the best choice for wireless communication systems as they offer reliability and wide transmission capacity, in contrast to unit antenna elements (AEs), without increasing system bandwidth or transmission power. The present-day and future communications systems need higher throughput to meet the demands of users. The signal transfer rate can be improved by improving channel bandwidth or increasing the number of receiving antennas. However, the main issue in designing UMAs is to provide high isolation between AEs because mutual coupling interactions between them affect the generated radiation patterns, leading to worse performance and failing to meet the operative constraints and requirements. When introducing decoupling techniques (DTs), researchers experience numerous challenges, including an increase in antenna size, design complexity, and cross-polarization. This article offers an organized review and simulated study of the various DTs in UMAs. The simulated study has been carried out through the implementation of various types of DTs on the same two-port UMA, which consists of two microstrip-fed circular-shaped AEs with open-end slotted partial ground. In contrast with previously reported review articles, this article provides a detailed study of various types of DTs reported so far and a better understanding for selecting appropriate DTs, which help in designing UMAs with better performance. Full article

The microwave field is used for drying and disinfecting grains during the pre-sowing seed treatment. The use of a microwave field in these installations leads to an increase in their productivity and a decrease in the energy consumed by them. In grain dryers, where the grain moves in a dense layer without being loosened, one of the challenges in using microwave fields is ensuring sufficient uniformity of the field distribution. In this article, waveguide design options that introduce microwave radiation into the grain layer are discussed. The objective of this study was to use application software to find the optimum type of transmitter from the three options presented. A mathematical simulation of the electromagnetic field distribution was performed with the use of CST Microwave Studio software 2019 in order to evaluate and compare horn-type, rectangular, and semicircular waveguides. The data on the standing wave ratio and radiation efficiency of these types of waveguides have been reported. The specific features of the microwave electromagnetic field distribution and radiation power in the output of these waveguides have been described. The results of mathematical simulations revealed that semicircular waveguides with slot-type radiators are preferable for processing dense grain layers. Full article

To meet the real demand for broadband full-band high-gain antenna sensors in the process of partial discharge (PD) Ultra-High frequency (UHF) detection test and online monitoring of power equipment, this paper builds a resonant cavity monopole UHF antenna sensor based on Fabry–Perot resonant cavity antenna technology, conducts the sensor Voltage Standing Wave Ratio (VSWR) optimization study using curved flow technology, conducts the sensor gain optimization study using slot dual resonant structure, and, finally, tests the sensor performance using the built PD detection test platform. The resonant cavity monopole antenna exhibits outstanding VSWR performance in the frequency range of 0.37 GHz–3 GHz, according to simulation and test data: the average gain in the frequency range of 0.3 GHz–3 GHz is 4.92 dBi, and the highest gain at the primary resonant frequency of 1.0 GHz is 7.16 dBi, with good radiation performance over the whole frequency spectrum. The electromagnetic pulse signal sensed by the UHF sensor developed in this paper can demonstrate the energy spectrum distribution characteristics of PD radiation electromagnetic wave signal more comprehensively, laying a firm technical foundation for thoroughly understanding the electromagnetic wave radiation characteristics of various types of PD insulation defects of various power equipment and the selection of a specific direction for its supporting optimization. Full article

A low-profile high-efficiency transmitarray antenna (TA) for beamforming applications is proposed and investigated in this paper. The partial H-plane waveguide slot array antenna is employed as the compact low-profile feeding structure of the beamforming TA. The designed TA can achieve a high taper efficiency due to the multi-array sources and the compactness of the partial H-plane waveguide. Moreover, the proposed TA can inherently have a high spillover efficiency because the frequency selective surface (FSS) for beamforming is located just above the radiating slot. The FSS with a transmission phase variation of 2π is designed by a square patch array and used to manipulate the wave-front of the transmitted electromagnetic wave instead of a complicated feed network and phase shifters. To verify its beamforming characteristic, three types of FSSs to operate a forming angle of −40°, −20°, 0°, +20°, and +40° are designed at 12 GHz. The distance between the FSS and the slot array antenna is 0.1λ₀, and the aperture efficiency is measured to be about 69%. The measured results, such as the reflection coefficient and the far-field radiation pattern, are in good agreement with the simulated results. From the measured results, the proposed TA is confirmed to have good beamforming characteristics and high aperture efficiency. Full article

Microwave continuous-flow liquid food sterilisation, in which the liquid is mainly heated by microwaves, has the advantages of fast sterilisation speed, energy saving, comprehensive elimination, and less nutrient loss. Circular pipes are commonly used in microwave continuous-flow liquid heating processing. However, with circular pipes, which are widely used in the industry, the heating is uneven owing to the phenomenon of tube focusing when adopting external radiation. In this study, a novel microwave continuous-flow milk sterilisation system based on a coaxial slot radiator is proposed. First, the coaxial slot radiator was designed to realise efficient radiation through the establishment of multi-physics model. The structure of the system was then optimised by comparing the heating efficiency and uniformity of simulation results. The effect of microwave coaxial slot radiator rotation on heating uniformity was simulated and the results show that the heating uniformity is improved obviously. Experimental equipment was set up to verify the results of the simulation. The experimental results are consistent with the simulation results. Finally, the sensitivity analysis of the system is performed to confirm that, when the dielectric properties and types of liquid food change, the heating of the proposed microwave continuous-flow system remains efficient and uniform. Full article

In this paper, 1 × 2 MIMO of Palm Tree Coplanar Vivaldi Antenna is presented that simulated at 0.5–4.5 GHz. Some GPR applications require wideband antennas starting from a frequency below 1 GHz to overcome high material loss and achieve deeper penetration. However, to boost the gain, antennas are set up in MIMO and this is costly due to the large size of the antenna. When configuring MIMO antenna in the E-plane, there is occasionally uncertainty over which antenna model may provide the optimum performance in terms of return loss, mutual coupling, directivity, beam squint, beam width, and surface current using a given substrate size. However, the configuration of E-plane antenna in MIMO has an issue of mutual coupling if the distance between elements is less than 0.5λ. Furthermore, it produces grating lobes at high frequencies.We implement several types of patch structures by incorporating the truncated, tilt shape, Hlbert and Koch Fractal, Exponential slot, Wave slot, the lens with elips, and metamaterial slot to the radiator by keeping the width of the substrate and the shape of the feeder. The return loss, mutual coupling, directivity, beam squint, beamwidth, and surface current of the antenna are compared for 1 × 2 MIMO CVA. A continuous patch MIMO has a spacing of 0.458λ at 0.5 GHz, which is equivalent to its element width. From the simulation, we found that Back Cut Palm Tree (BCPT) and Horizontale Wave Structure Palm Tree (HWSPT) got the best performance of return loss and mutual scattering at low-end frequency respectively. The improvement of directivity got for Metamaterial Lens Palm Tree (MLPT) of 4.453 dBi if compared with Regular Palm Tree-Coplanar Vivaldi Antena (RPT) at 4 GHz. Elips Lens Palm Tree (ELPT) has the best beam squint performance across all frequencies of 0°. It also gots the best beamwidth at 4.5 GHz of 3.320. In addition, we incorporate the MLPT into the radar application. Full article

Resonant Bessel-beam launchers are low-cost, planar, miniaturized devices capable of focusing electromagnetic radiation in a very efficient way in various frequency ranges, with recent increasing interest for microwave and millimeter-wave applications (i.e., 3–300 GHz). In recent years, various kinds of launchers have appeared, with different feeding mechanisms (e.g., coaxial probes, resonant slots, or loop antennas), field polarization (radial, azimuthal, and longitudinal), and manufacturing technology (axicon lenses, radial waveguides, or diffraction gratings). In this paper, we review the various features of these launchers both from a general electromagnetic background and a more specific leaky-wave interpretation. The latter allows for deriving a useful set of design rules that we here show to be applicable to any type of launcher, regardless its specific realization. Practical examples are discussed, showing a typical application of the proposed design workflow, along with a possible use of the launchers in a modern context, such as that of wireless power transfer at 90 GHz. Full article

This paper proposes a microwave sensor based on a high-sensitivity slot-loaded rectangular microstrip patch antenna (MPA) for measuring microliter-volume liquid chemicals with high relative permittivity and high loss tangent. A rectangular single-ring complementary split ring resonator (SR-CSRR) slot with a bottom-edge center split (BCS) was inserted along the upper radiating edge of the patch to enhance the relative permittivity sensitivity of the MPA. The first resonant frequency of the proposed SR-CSRR-BCS slot-loaded MPA showed the highest sensitivity compared to the resonant frequencies of the MPAs with other commonly used slots for varying the relative permittivity of the planar substrate type material under test from 1 to 10 when placed above the patch. After designing the scaled SR-CSRR-BCS slot-loaded MPA with the unloaded first resonant frequency at 2.5 GHz, a hollow acrylic cylindrical liquid container with an inner volume of approximately 18.6 μL was placed at the top-edge center of the SR-CSRR-BCS slot to achieve maximum sensitivity. A quarter-wavelength transformer was applied between the patch and the feed line of the MPA to improve the impedance mismatch that occurs when liquid chemicals with a high loss tangent are placed in the container. Water, methanol, and ethanol were carefully selected for test liquids to cover a broad range of relative permittivity and high loss tangents. The proposed SR-CSRR-BCS slot-loaded MPA was designed and fabricated on a 0.76 mm-thick RF-35 substrate, and a reference RS-loaded MPA was designed and fabricated for comparison. The shift in the first resonant frequency of the input reflection coefficient characteristic was used for the sensitivity comparison, and the container was filled with 15 μL of the liquids at 25 °C. The measured sensitivity (%) of the proposed SR-CSRR-BCS slot-loaded MPA for water was 0.45%, which was higher than other antenna-based microwave sensors in the literature. Full article
