Despite the strength and ductility of steel reinforcing bars, their susceptibility to corrosion can limit the long-term durability of reinforced concrete structures. Fiber-reinforced polymer (FRP) reinforcing bars made with a thermosetting matrix offer corrosion resistance but cannot be field-bent, which limits flexibility during construction. FRP reinforcing bars made with fiber-reinforced thermoplastic polymers (FRTP) address this limitation; however, their high processing viscosity presents manufacturing challenges. In this study, the Continuous Forming Machine, a novel pultrusion device that uses pre-consolidated fiber-reinforced thermoplastic tapes as feedstock, is described and used to fabricate 12.7 mm nominal diameter thermoplastic composite rebars. Simple bend tests on FRTP rebar that rely on basic equipment are performed to verify its ability to be field-formed. The manual bending technique demonstrated here is practical and straightforward, although it does result in some fiber misalignment. Subsequently, surface deformations are introduced to the rebar to promote mechanical bonding with concrete, and tensile tests of the bars are conducted to determine their mechanical properties. Finally, flexural tests of simply-supported, 6 m long beams reinforced with FRTP rebar are performed to assess their strength and stiffness as well as the practicality of using FRTP rebar. The beam tests demonstrated the prototype FRTP rebar’s potential for reinforcing concrete beams, and the beam load–deformation response and capacity agree well with predictions developed using conventional structural analysis principles. Overall, the results of the research reported indicate that thermoplastic rebars manufactured via the Continuous Forming Machine are a promising alternative to both steel and conventional thermoset composite rebar. However, both the beam and tension test results indicate that improvements in material properties, especially elastic modulus, are necessary to meet the requirements of current FRP rebar specifications. Full article

The motion of a heavy mass on a bridge span causes vibrations whose magnitude and frequency content depend on the mechanical properties of the structural system, including the magnitude of that mass and its speed of traverse. In order to limit vibrations that could potentially cause damage, a simple passive device configuration, namely the tuned mass damper (TMD), is introduced and its effect on the beam vibrations analyzed. Specifically, a TMD in the form of a single-degree-of-freedom (SDOF) unit comprising a mass and a spring is placed on the span to act as a secondary system for absorbing vibrations from the primary system, i.e., the bridge itself. A Lagrangian energy balance formulation is used to derive the governing equations of motion, followed by an analytical solution using the Laplace transform to investigate the transmission of vibratory energy between primary and secondary systems. Results are given in terms of time histories, Fourier spectra and spectrograms, where the influence of the TMD in reducing vibratory energy is demonstrated. The TMD is placed in the region where the beam’s transverse motion is at a maximum, while its mechanical properties are sub-optimal, in the sense that there is no separate damper present and minimal damping is provided by the spring element itself. In parallel with the analysis, a series of experiments involving a simply supported model steel bridge span traversed by a heavy mass are conducted to first gauge the analytical solution and then to confirm the validity of the proposed passive scheme. Full article

To study the normal section crack resistance of pre-stressed steel-reinforced concrete simply supported composite beams, the specific parameters such as the component steel content, the reinforcement ratio of non-pre-stressed and pre-stressed bars, and the section size of simply supported beams, are designed with different sections and reinforcement. Given the relatively poor bond property between steel and concrete, by introducing the bond property reduction coefficient, the formula for calculating the average crack spacing of pre-stressed steel-concrete simply supported composite beams is modified. Through the analysis of test data, the influence coefficient of concrete self-elongation between cracks on crack width is obtained, and the formula for calculating average crack width reflecting the characteristics of pre-stressed steel-concrete simply supported composite beams is obtained. The value of the expansion coefficient considering the uneven distribution of cracks is obtained by the crack distribution curve and the formula for calculating the crack width of pre-stressed steel concrete composite beams is given. The actual average crack spacing of the 5 pre-stressed steel-concrete simply supported beams in this test is 106.04 mm, which is calculated according to the above formula. The average value of the ratio between the calculated value and the measured value is 0.916, the standard deviation is 0.059, and the coefficient of variation is 0.064. The average value of calculated and measured crack widths of the beams is 0.927, the standard deviation is 0.194, and the coefficient of variation is 0.209. Full article

This article presents woven carbon-fiber-reinforced polymer (CFRP) tubular mesh used as a reinforcement on the inner surface of hollow beams made of high-performance concrete (HPC). The tubular mesh was designed to serve as both the tensile and shear reinforcement of hollow beams intended for the construction of small self-supporting structures that could be assembled without mechanization. The reinforcement was prepared with a tri-axial weaving machine from carbon filament yarn and was homogenized using epoxy resin. The interaction of the composite reinforcement with the cementitious matrix was investigated, and the surface of the reinforcement was modified using silica sand and polyvinyl alcohol (PVA) fibers to improve cohesion. The sand coating enhanced bond strength, resulting in the significantly higher flexural strength of the hollow beam of 128%. The PVA fibers had a lower positive effect of 64% on the flexural strength but improved the ductility of the beam. Individual beams were connected by gluing steel parts directly inside the hollow core of the HPC beam. This procedure provides good interaction between the CFRP reinforcement and the glued steel insert and allows for the fast and simple assembly of structures. The weaving of additional layers of the CFRP reinforcement around HPC beams was also explored. A small structure made of the hollow HPC beams with inner composite reinforcement was constructed to demonstrate the possibilities of the presented technology. Full article

In the field of structural health monitoring (SHM), with the mature development of artificial intelligence, deep learning-based structural damage identification techniques have attracted wide attention. In this paper, the convolutional neural network (CNN) is used to extract the damage feature of simple supported steel beams. Firstly, the transient dynamic analysis of the steel beam is carried out by finite element software, and the acceleration response signals under different damage scenarios are obtained. Then, the acceleration response signal is decomposed by wavelet packet decomposition (WPD) to extract the wavelet packet band energy ratio variation (ERV) index as the training sample of CNN. Subsequently, the vibration experiment of a simple supported steel beam was carried out, and the results were compared with the numerical simulation results. The characteristic indexes were obtained by making corresponding changes to the vibration signal, and then, the experimental data were input into the CNN to predict the effect of damage detection. The results show that the method can successfully detect the intact structure, single damage, and multiple damages with an accuracy of 95.14% under impact load, and the performance is better than that of support vector machine (SVM), with good robustness. Full article

This work presented some selected results of laboratory tests and FEM analysis study of simple supported RC beams strengthened using carbon strips. The beams were examined to establish the effectiveness of this method of strengthening in terms of increasing their load-carrying capacity as well as flexural stiffness at different preloading states. A set of beams was divided into five groups, which differ in the level of the load applied before application of the composite strips on their bottom surfaces. Laboratory tests were supplemented with numerical analyses based on the finite-element method (FEM) using Abaqus software. The created numerical models were validated, and good agreement of the experimental results with the results obtained in the numerical analyses was observed. The deformation state existing in the main reinforcing bars, in concrete as well as in the strengthening composite strip, and its influence on the failure mechanism of the beams were analyzed. In the stiffness analysis, it was assumed that the stiffness of a beam strengthened with composite material after the elastic range (concrete and reinforcement steel) can be represented by the relation between the stiffness of the noncracked section B and beam curvature κ. The curvature–bending moment diagram as well as bending moment–stiffness diagram were prepared on the basis of laboratory and numerical results. Based on the results, it can be stated that the preload on the beam before strengthening affects the levels of deformation and the utilization rates of the composite material as well as reinforcing bars. The curvature and stiffness of the beams depend on the load level at which the CFRP strip strengthening is realized. The results of the analysis of preloaded beams before strengthening indicate that totally relieving them prior to strip application turns out to be the most beneficial solution. Full article

Non-prismatic reinforced concrete (RC) beams are widely used for various practical purposes, including enhancing architectural aesthetics and increasing the overall thickness in the support area above the column, which gives high assurance to services that this will not result in the distortion of construction features and can reduce heights. The hollow sections (recess) can also be used for the maintenance of large structural sections and the safe passage of utility lines of water, gas, telecommunications, electricity, etc. They are generally used in large and complex civil engineering works like bridges. This study conducted a numerical study using the commercial finite element software ANSYS version 15 for analysing RC beams, hollow longitudinally sectioned and retrofitted with carbon fibre reinforced polymers (CFRPs), which were subjected to concentrated vertical loads. The numerical analysis results on the simulated beam models were in excellent agreements with the previous experimental test results. This convergence was confirmed by a statistical analysis, which considered the correlation coefficients, individual arithmetic means and standard deviations for all the calculated deflections of the simulated beam models. A proposed numerical simulation model with the hypotheses can be considered suitable for modelling the behaviours of simple supported non-prismatic RC beams under vertical concentrated loads. The numerical results showed that altering the cross-section from solid to hollow could reduce the load carrying capacities of the beams by up to 53% and increase the corresponding deflections by up to 40%, respectively. Using steel pipes for making recesses could enhance the loading capacity by up to 56%, increase the ductility, and reduce the corresponding deflections by up to 30%, respectively. Finally, it was found that bonding the CFRP sheets in the lower middle tensile areas of the hollow beams could improve the resistance and reduce the deformations by up to 27%. The failure patterns for all the numerical models were shear failure. The cylinder compressive strength could be used as a mechanical parameter for modelling and assessing the structural behaviours of the beam models, as its increase could improve the load carrying capacities and reduce the deflections by 30–50%. Full article

Rehabilitation, strengthening, and retrofitting of existing masonry buildings represent an important challenge for the construction engineering field. Often, slab strengthening/retrofitting is performed by replacing existing timber and steel beams or by adding new beams to improve the slab load-carrying capacity. The computation of the stresses at the beam–masonry interface (i.e., the contact pressure) is crucial to properly design the beam support length, preventing local failure of masonry and beam. This paper presents a simple analytical procedure to compute the contact pressure at the beam–masonry interface. The analytical procedure is validated by comparison between analytical and corresponding numerical results obtained by finite element modeling. Different types of beam (solid and laminated timber beams and steel beams) were considered, as well as different support conditions (simply resting on the wall considering different support lengths or fully embedded). The results obtained show that the method proposed is simple and reliable, which makes it suitable for professional practice. Full article

This study proposes a cost-effective prestress monitoring method for post-tensioned reinforced concrete (RC) beams using a smart strand. Firstly, the concept of a piezoelectric-based smart strand and its implementation for prestress force monitoring are developed. The smart strand is prepared by embedding inexpensive and high-sensitivity electromechanical impedance (EMI) sensors in a steel strand. Next, the feasibility of the proposed method is experimentally verified for prestress force monitoring of a simple supported post-tensioned RC beam. A smart strand prototype is fabricated and embedded into a 6.4 m RC beam which is then prestressed with different levels. For each prestress level, the EMI responses of the smart tendon are measured and the EMI features are extracted for prestress force monitoring. The results showed that the EMI signals of the smart strand showed strong resonant peaks that varied sensitively to the prestress level of the beam. The prestress change in the prestressed RC beam was successfully estimated by using linear regression models of the EMI features. Full article

Bridge designs are becoming slender and lighter, making wind dynamic effects even more important than wind static effects. Some types of bridges show especially vulnerable situations during construction stages, when the structure is lighter or does not have its final stiffness. The aim of this document is to assess the dynamic wind loading on simple girder bridges during their construction phases. The studied section is formed by two steel beams supporting a concrete slab, but the analysis was made when the concrete slab has not been built yet. Several CFD simulations were made to find the aerodynamic parameters depending on the section’s dimensions. Three construction stages were analyzed: when only one beam is placed, when both beams are in their final locations but they are not connected yet, and when both beams are joined by the bracing. The results showed that vortex shedding effects are stronger in the along-wind direction due to the low horizontal bending stiffness of the beams and their large area perpendicular to the flow. Increasing beams’ distance is a good solution to reduce wind effects. However, closing the section with light plates was more effective, decreasing the frequency of vortex shedding and its effects. Full article

Stiffness is the main parameter of the beam’s resistance to deformation. Based on advanced research, the stiffness of bamboo-reinforced concrete beams (BRC) tends to be lower than the stiffness of steel-reinforced concrete beams (SRC). However, the advantage of bamboo-reinforced concrete beams has enough good ductility according to the fundamental properties of bamboo, which have high tensile strength and high elastic properties. This study aims to predict and validate the stiffness of bamboo-reinforced concrete beams from the experimental results data using artificial neural networks (ANNs). The number of beam test specimens were 25 pieces with a size of 75 mm × 150 mm × 1100 mm. The testing method uses the four-point method with simple support. The results of the analysis showed the similarity between the stiffness of the beam’s experimental results with the artificial neural network (ANN) analysis results. The similarity rate of the two analyses is around 99% and the percentage of errors is not more than 1%, both for bamboo-reinforced concrete beams (BRC) and steel-reinforced concrete beams (SRC). Full article

Contemporary stabilized rammed earth (SRE) draws upon traditional rammed earth (RE) methods and materials, often incorporating reinforcing steel and rigid insulation, enhancing the structural and energy performance of the walls while satisfying building codes. SRE structures are typically engineered by licensed Structural Engineers using the Concrete Building Code or the Masonry Building Code. The construction process of SRE creates structural walls of relatively high compressive strength appropriate for a broad range of heating and cooling climates. The incorporation of rigid insulation creates a high mass interior wythe that is thermally separated from the exterior, resulting in improved thermal performance. Modular aluminum reinforced formwork allows walls to be built without the use of through ties, common in concrete construction. The North American Rammed Earth Builders Association (NAREBA) collaborated with Unisol Engineering Ltd. and the British Columbia Institute of Technology (BCIT) on a battery of tests to obtain preliminary data to be used in support of engineering design. The tests included compressive strength comparisons, pull out rebar testing of both horizontally and vertically placed steel, simple beam tests, and the deflection of two composite wall columns with an insulation core and two types of reinforcing steel connections between the RE wythes. Full article
