Grease lubrication is cost-effective and low-maintenance for motorized spindles, but standard steel bearings can fail at high speeds. This study focuses on high-speed full ceramic ball bearings lubricated with grease. The coefficient of friction torque in the empirical formula is corrected by establishing the heat generation model of full ceramic ball bearing and combining it with experiments. A simulation model of grease flow is established to study the influence of grease filling amount on grease distribution. The simulation model of the temperature field of a full ceramic ball bearing is established to analyze the influence of rotating speed on bearing heat generation, and experiments verify the calculation results of the theoretical model. The results show that an optimal grease filling amount of 15~25% ensures even distribution without accumulation. Additionally, when the amount of grease is constant, the outer ring temperature increases with higher rotating speeds. The test results show that when the grease filling is 0.9~1.2 g, it accounts for about 9~12% of the volume of the bearing cavity, and the temperature of the outer ring is the lowest. At a rotation speed of 24,000 rpm, the outer ring temperature of the grease-lubricated bearing is 50.1 °C, indicating a reasonable range for use in motorized spindles. It provides a theoretical basis for the optimization design of macro-structural parameters of full ceramic ball bearings in the future, which can minimize heat generation and maximize bearing capacity. Full article

In this work, a chemical modification method was used to prepare silicone grease with high thermal conductivity. We report two preparation methods for thermal conductive fillers, which are hydroxylated boron nitride-grafted carboxylic silicone oil (h-BN-OH@CS) and amino boron nitride-grafted carboxylic silicone oil (h-BN-NH₂@CS). When h-BN-OH@CS and h-BN-NH₂@CS were filled with 30 wt% in the base grease, the thermal conductivity was 1.324 W m⁻¹ K⁻¹ and 0.982 W m⁻¹ K⁻¹, which is 6.04 and 4.48 times that of the base grease (0.219 W m⁻¹ K⁻¹), respectively. The interfacial thermal resistance is reduced from 11.699 °C W⁻¹ to 1.889 °C W⁻¹ and 2.514 °C W⁻¹, respectively. Inorganic filler h-BN and organic filler carboxylic silicone oil were chemically grafted to improve the compatibility between h-BN and the base grease. The covalent bond between functionalized h-BN and carboxylic silicone oil is stronger than the van der Waals force, which can reduce the viscosity of the silicone grease. Full article

In order to ensure the safety and extend the lifecycle of lithium-ion power batteries in electric vehicles, a battery thermal management system based on minichannel liquid cooling is proposed to cool rectangular lithium-ion batteries, and a three-dimensional cooling system model is established. The effects of the number of channels, the thickness of heat conducting silicone grease and the thermal conductivity of the battery itself on the temperature rise and voltage drop changes during the discharge process of the battery are studied. The results show that the maximum temperature of the battery decreases with the increase of the number of channels, and the voltage drop inside the channel increases with the increase of the number of channels. The maximum temperature of the battery increases with the increase of the thickness of the thermal grease, but the increase is only 1.26 K. The maximum temperature and local temperature difference of the battery change significantly with the change of the thickness of the battery and its own thermal conductivity. The simulation results will be beneficial to the design of a battery thermal management system based on minichannel liquid cooling. Full article

Wireless electric vehicle charging technology is developing in the direction of high power levels. However, more generated heat brought by higher power will accelerate the system’s aging and can even lead to damage. An excellent thermal design for the magnetic coupler can reduce each part’s maximum temperature, ensuring long-term operation reliability. Therefore, in this article, the magnetic coupler’s thermal estimation and design are studied based on a 6.6 kW wireless electric vehicle charging system. First, the calculation method of internal resistance of a litz coil, core loss, and eddy current loss of a shielding aluminum plate are studied. Considering the influence of thermal fields on material properties, each part’s power loss calculation formula is further modified to improve the accuracy. After that, heat dissipation research is carried out. The heat dissipation measures, such as filling the surface of the shielding aluminum plate with thermal conductive silicone grease, are proposed. Finally, the effectiveness of the heat dissipation measures is verified by simulation and experiments. The experiment shows that the error between the power loss value of each part calculated by simulation and measured by the experiment is less than 15%, and the maximum temperature of the magnetic coupler is controlled below 80 °C. Full article

In order to investigate the effect of different influencing factors on the application of temperature differential power generation in the ship exhaust gas and to explore the potential of waste heat recovery and the utilization of exhaust gas during ship travel, an experimental system based on the temperature differential power generation of ship exhaust gas in the marine environment was established. The maximum output power and the maximum efficiency of each temperature-difference power generation module were theoretically calculated. The results showed that the insulation material and the salt water (seawater) had little effect on the efficiency of the temperature differential power generation modules. Conversely, the installation pressure, the heat transfer oil, the cooling water temperature (seawater temperature), and the heat source temperature (exhaust gas pipe temperature) had a great influence on the open-circuit voltage and the maximum output power. The thermally conductive silicone grease and the cooling water temperature of 10 °C increased the open-circuit voltage by 31.54% and 18.95%, respectively, and increased the maximum output power by 82.05% and 51.79%, respectively. The maximum output of a single temperature differential power generator reached 63.5% when using an installation pressure of 3 bar, a cooling water temperature of 20 °C, double-layer aluminum insulation, and thermally conductive silicone grease. Finally, this study provides relevant data support for using temperature differential power generation devices for ship exhaust gas. Full article

To improve the problems of large interface thermal resistance and low heat dissipation efficiency in battery thermal management (BTM), this paper uses methyl silicone oil as the matrix, AIN, copper powder (CP), and carbon fiber (CF) as thermally conductive fillers, and acetone and stearic acid as particle surface modification components. A variety of binary thermal silicone greases (TSGs) with different compositions were prepared. Different instruments were used to test the material properties of TSGs, and a better TSG was selected to coat the interface between battery and phase change material (PCM) for battery charging and discharging experiments. Through the analysis of experimental data, it was found that among the TSGs made of three mixed fillers (AIN/CP, AIN/CF, CP/CF), the three TSGs had good thermal stability, and their thermal degradation temperature both exceeded 300 °C. As the ratio of thermally conductive filler was gradually changed from 5:1 to 1:5, the TSG containing CP/CF had higher thermal conductivity and lower volume resistivity, while the TSG containing AIN/CF had the least damage due to interface wear. The acidification treatment of thermally conductive filler can improve the adsorption and compatibility of thermally conductive particles and silicone oil, and reduce the oil separation rate of TSGs. The prepared expanded graphite (EG)/paraffin wax (PW) composite phase change material (CPCM) has a relatively large latent heat of phase change, which can effectively control the temperature of the battery, but coating TSG between the battery and the CPCM can further enhance the heat dissipation effect of the battery. Full article

As electronic devices and mainboards become smaller, the need for thermal conductive materials having excellent internal heat dissipation is increasing. In this study, nano thermal grease was prepared by mixing in copper nanopowder, which is used as a heat transfer medium in thermal grease, which is a kind of thermal conductive material, with silicon oil. In addition, copper powder was mixed with graphene and alumina, respectively, and the thermal conductivity performance was compared. As a result, the thermal conductivity improved by 4.5 W/m·k over the silicon base, and the upward trend of thermal conductivity increased steadily up to 15 vol. %, and the increasing trend decreased after 20 vol. %. In addition, the increased rate of thermal conductivity from 0 to 5 vol. % and 10 to 15 vol. % was the largest. Full article

For reliability and thermal management of power devices, the most frequently used technique is to employ heatsinks. In this work, a new configuration of offset strip fin heatsink based on using the concept of curvy fins and U-turn is proposed with the aim of improving the heat transfer performance. With this aim, a three-dimensional model of heatsink with Silicon Insulated-Gate Bipolar Transistors (IGBTs) and diodes, solder, Direct Bonded Copper (DBC) substrate, baseplate and thermal grease is developed. Richardson’s extrapolation is used for increasing the accuracy of the numerical simulations and to validate the simulations. To study the effectiveness of the new offset design, results are compared with conventional offset strip fin heatsink. Results show that in aspects of design of heatsinks (including heat transfer coefficient, maximum chip temperature and thermal resistance), the new introduced model has advantages compared to the conventional offset strip fin design. These enhancements are caused by the combination of the longer coolant passage in the heatsink associated with generation of disturbance and recirculation areas along the curvy fins, creation of centrifugal forces in the U-turn, and periodic breaking up boundary layers. Also, it is shown that due to narrower passage and back-and-forth route, the new introduced design can handle the hot spots better than conventional design. Full article

The thermally conductive properties of silicone thermal grease enhanced by hexagonal boron nitride (hBN) nanosheets as a filler are relevant to the field of lightweight polymer-based thermal interface materials. However, the enhancements are restricted by the amount of hBN nanosheets added, owing to a dramatic increase in the viscosity of silicone thermal grease. To this end, a rational structural design of the filler is needed to ensure the viable development of the composite material. Using reduced graphene oxide (RGO) as substrate, three-dimensional (3D) heterostructured reduced graphene oxide-hexagonal boron nitride (RGO-hBN)-stacking material was constructed by self-assembly of hBN nanosheets on the surface of RGO with the assistance of binder for silicone thermal grease. Compared with hBN nanosheets, 3D RGO-hBN more effectively improves the thermally conductive properties of silicone thermal grease, which is attributed to the introduction of graphene and its phonon-matching structural characteristics. RGO-hBN/silicone thermal grease with lower viscosity exhibits higher thermal conductivity, lower thermal resistance and better thermal management capability than those of hBN/silicone thermal grease at the same filler content. It is feasible to develop polymer-based thermal interface materials with good thermal transport performance for heat removal of modern electronics utilising graphene-supported hBN as the filler at low loading levels. Full article

The objective of this study was to numerically investigate the heat transfer characteristics of a 36V electronic control unit (ECU) system of an electric bicycle and to validate the experimental data. The temperatures of the ECU heatsink, seven metal-oxide-silicon field effect transistors (MOSFETs) and two capacitors of the 36V ECU system were numerically derived under variable operating conditions including power dissipation, thermal grease, ambient temperature and heatsink material, to analyze the heat transfer characteristics. When the thermal conductivity of the thermal grease increased from 0.01 W/m °C to 3.0 W/m° C, the temperatures of the seven MOSFETs and the two capacitors decreased by 51.245% and 3.58%, respectively. When the total power dissipation increased from 2.57 MW/m³ to 4.26 MW/m³, the temperatures of the ECU heatsink, seven MOSFETs and the two capacitors increased by 20.95%, 30.31% and 21.54%, respectively. Furthermore, increasing the ambient temperatures from 30 °C to 40 °C resulted in an increase in the temperatures of the ECU heatsink, MOSFET and capacitor by 24.75%, 9.93% and 22.04% respectively.. These numerically derived temperatures for the MOSFET and the ECU heatsink were validated with the experimental results within a range of 7.2% and 1.7%, respectively. This confirmed that the applied numerical model was valid. Full article
