This study aims to overcome the technical bottleneck of non-invasive differentiation between the rammed earth layer and pebble layer in complex shallow subsurface environments, particularly focusing on the challenge of detecting highly heterogeneous pebble layers with complex wavefield characteristics. Using the western city wall of the Baodun site (Xinjin, Sichuan, China) as a case study, we introduce a high-resolution seismic detection technique combined with controllable high-frequency seismic source excitation to investigate the response characteristics of high-frequency components and energy variations of seismic waves in different strata, thereby revealing differences in physical properties between the rammed earth layer and pebble layer. Through high-frequency data acquisition, specialized processing, and interpretative analysis of seismic data, we successfully distinguish the two strata and delineate pebble-related anomalous zones. The results also indicate that, due to complex geological conditions, the reflection and refraction patterns of seismic waves in the pebble layer are exceptionally intricate. Moreover, the interplay of abrupt seismic velocity variations, interference waves, and other contributing factors leads to pronounced heterogeneity and strong scattering characteristics in the seismic data across the time, frequency, and phase domains. This research overcomes the limitations of conventional geophysical methods and confirms the applicability of high-frequency seismic techniques to complex near-surface archaeological contexts. It provides robust scientific support for the archaeological study of the Baodun site and offers a methodological reference for subsurface mapping of pebble layer in prehistoric urban landscapes. Full article

Effective vertical seismic profiling (VSP) of upgoing and downgoing wave separation is essential for high-quality imaging. However, VSP wavefield separation is particularly challenging under complex geological conditions. Existing solutions encompass one derived from the mathematical characteristics of upgoing and downgoing waves, employing signal decomposition methodologies, and another that utilizes data-driven machine learning techniques, achieving wavefield separation by training sample data to identify the distinct characteristics of upgoing and downgoing waves. This study introduces a VSP wave-separation method using signal knowledge representation, primarily by constructing knowledge representations of upgoing and downgoing waves. Physics-informed recurrent neural network FWI and Poynting vector physical knowledge representation yielded accurate velocity models. Axial gradient information was utilized to construct morphological knowledge representations of upgoing and downgoing waves. Directional differentiation knowledge representations were established based on kinematic characteristic disparities between upgoing and downgoing waves in the time-depth domain. These wave knowledge representations (KRs) built a dual convolutional autoencoder. Its distinct branches extracted up/down wave information, while the KRs, transformed into loss functions, enabled knowledge-driven unsupervised VSP wave separation. The proposed methodology was validated using a homogeneous layer and Marmousi models, demonstrating the effective separation of upgoing and downgoing waves from the VSP seismic records. Full article

Seismic wave propagation in complex terrains, especially in the presence of air layers, plays a crucial role in accurate subsurface imaging. However, the influence of different boundary conditions on seismic wave propagation characteristics has not been fully explored. This study employs the finite element method (FEM) to simulate and analyze seismic wavefields under different boundary conditions, including perfectly matched layer (PML), Neumann free boundary conditions, and air layer conditions. First, the finite element solution for the 2D frequency-domain acoustic wave equation is introduced, and the correctness of the algorithm is validated using a homogeneous model. Then, both horizontal and undulating terrain interfaces are designed to investigate the kinematic and dynamic characteristics of the wavefields under different boundary conditions. The results show that PML boundaries effectively absorb seismic waves, prevent reflections, and ensure stable wave propagation, making them an ideal choice for simulating open boundaries. In contrast, Neumann boundaries generate significant reflected waves, particularly in undulating terrains, complicating the wavefield characteristics. Introducing an air layer alters the dynamics of the wavefield, leading to energy leakage and multi-path effects, which are more consistent with real-world seismic-geophysical models. Finally, the computational results using the Overthrust model under different boundary conditions further demonstrate that different boundary conditions significantly affect wavefield morphology. It is essential to select appropriate boundary conditions based on the specific simulation requirements, and boundary conditions with an air layer are most consistent with real seismic geological models. This study provides new insights into the role of boundary conditions in seismic numerical simulations and offers theoretical guidance for improving the accuracy of wavefield simulations in realistic geological scenarios. Full article

We observed high-quality waves from a repeatable airgun seismic source recorded by a linear ultra-dense seismic array across the Xiliushui fault zone, one of the inactive faults in the Qilian Mountain, on the northeastern margin of the Tibetan Plateau, China. We used Snell’s law of seismic ray propagation to determine a simplified ambient velocity model. Based on the flexible and precise spectral element method, we computed broadband synthetic seismograms for a shallow low-velocity fault zone (FZ) to model the direct P-wave travel time delay and incident angle of the wavefield near the FZ. The FZ extent range and boundaries were inverted by apparent travel time delays and amplification patterns across the fault. According to prior information on the properties of the direct P-waves, we could constrain the inverse modeling and conduct a grid search for the fault parameters. The velocity reduction between the FZ and host rock, along with the dip angle of the FZ, were also constrained by the P-wave travel time delay systematic analysis and incoming angle of the P-waves. We found that the Xiliushui fault has a 70~80 m-wide low-velocity fault damage zone in which the P-wave velocity is reduced to ~40% with respect to the host rock. The fault damage zone dips ~35°southwest and extends to ~165 m in depth. The repeatability and environment protection characteristics of the airgun seismic survey and the economic benefits of a limited number of instruments setting are prominent. Full article

Vector decomposition of P- and S-wave modes from elastic seismic wavefields is a key step in elastic reverse-time migration (ERTM) to effectively improve the multi-wave imaging accuracy. Most previously developed methods based on the apparent velocities or the polarization characteristics of different wave modes are unable to accurately achieve the vector decomposition of P- and S-wave modes. To effectively overcome the shortcomings of conventional methods, we develop a vector decomposition method of P- and S-wave modes using self-attention deep convolutional generative adversarial networks (SADCGANs) to effectively separate the horizontal and vertical components of P- and S-wave modes from elastic seismic wavefields and accurately preserve their amplitude and phase characteristics for isotropic elastic media. For an elastic model, we use many time slices for a given source position to train the neural network, and use other time slices not in this training dataset to test the neural network. Numerical examples of different models demonstrate the effectiveness and feasibility of our developed method and indicate that it provides an effective intelligent data-driven vector decomposition method of P- and S-wave modes. Full article

Local full-waveform inversion (FWI) methods use redatumed seismic responses of virtual receivers within the subsurface to build the local objective function based on the convolution-type representation theorem. The Marchenko method is widely used to obtain the redatumed data. The method only requires a smoothed velocity model with correct kinematic characteristics of seismic responses for redatuming of the single-sided reflection data. However, the standard Marchenko method is insensitive to lateral propagation of the wavefield. By injecting the standard Marchenko redatumed wavefield along the boundary of the target, the local wavefield propagation modeling produces errors, which affects the accuracy of the local FWI. In this paper, a method to obtain more accurate Green’s functions is proposed by incorporating vertical seismic profile data (VSP) into the calculation process of the Marchenko source-receiver redatuming. This method allows one to obtain the accurate laterally propagating waveform, resulting in a significant improvement of lateral resolution. The proposed method is applied to a benchmark model dataset and compared with the local FWI based on standard Marchenko redatuming. Full article

Earth–rock dams are typical soil–rock mixtures with high heterogeneity. Mastering the effect of dam heterogeneity on seismic wavefields is the premise of accurately detecting hidden risks in dams. In this paper, based on the soil–rock mixture characteristics of actual dams, a soil–rock mixture model that can reflect the heterogeneity of dams is established through local segmentation and reassignment of random disturbances. The influence of local area size on model heterogeneity is described. The seismic wavefield in a soil–rock mixture dam is numerically simulated through a staggered-grid finite-difference algorithm with second-order accuracy in time and sixth-order accuracy in space. Then, the effect of dam heterogeneity on effective wavefields is analyzed. The results show that the heterogeneity of the earth–rock dam can lead to scattered waves in the seismic wavefield, and the scattered waves are mainly generated by Rayleigh surface waves. In the seismic record, scattered waves with strong energy appear in the region below the surface waves. The scattered wave energy is weak and close to that in the homogeneous media in the region above the surface waves. As the rock content in the dam increases, the scattering of seismic wavefields and the energy of scattered waves weaken gradually. The scattered waves generated by the heterogeneity of the dam significantly impact the reflected longitudinal wave and converted wave but, affect the reflected shear wave less. The numerical simulation results are consistent with the acquired seismic wavefield from the field test, proving the effectiveness of the numerical simulation for the seismic wavefield propagation characteristics of the earth–rock dam. Full article

Water injection in geothermal areas is the preferential strategy to sustain the natural production of geothermal resources. In this context, monitoring microearthquakes is a fundamental tool to track changes in the reservoirs in terms of soil composition, response to injections, and resource exploitation with space and time. Therefore, refined source characterization is crucial to better estimate the size, source mechanism, and rupture process of microearthquakes, as they are possibly related to industrial activities, and to identify any potential variation in the background seismicity. Standard approaches for source parameter estimation are ordinarily based on the modelling of Fourier displacement spectra and its characteristic parameters: the low-frequency spectral level and corner frequency. Here, we apply an innovative time domain technique that uses the curves of P-wave amplitude vs. time along the seismogram. This methodology allows estimation of seismic moment, source radius, and stress release from the plateau level and the corner time of the average logarithm of P-wave displacement versus time with the assumption of a triangular moment rate function, uniform rupture speed, and a constant/frequency-independent Q-factor. In the current paper, this time domain methodology is implemented on a selected catalog of microearthquakes consisting of 83 events with a moment magnitude ranging between 1.0 and 1.5 that occurred during a 7-year period (2007–2014) of fluid extraction/injection around Prati-9 and Prati-29 wells at The Geysers geothermal field. The results show that the time domain technique provides accurate seismic moment (moment magnitude) and rupture duration/radius estimates of microearthquakes down to the explored limit (M 1) while accounting for the anelastic attenuation effect in the radiated high-frequency wavefield. The retrieved source radius vs. moment scaling is consistent with a self-similar, constant stress drop scaling model, which proves an appropriate attenuation correction and the validity of the assumed, triangular moment rate function for microearthquake ruptures. Two alternative mechanical models are proposed to explain the observed difference (about two orders of magnitude) in the retrieved average stress release estimates between the time and frequency domain methods. We argue that the two quantities may not refer to the same physical quantity representing the stress release of earthquake ruptures. Either the smaller stress release values from the time domain method may indicate a larger fracture area (by a factor of 20) radiating the observed P-waveforms than the one estimated from the corner frequencies, or the frequency domain estimate is a proxy for dynamic stress release while the time domain is more representative of the static release. The latter is associated with a much lower dynamic friction value than static friction value at the fault during the rupture process. Full article

Distributed acoustic sensing (DAS) is an emerging technology for recording vibration signals via the optical fibers buried in subsurface conduits. Its relatively easy-to-deploy and high spatial and temporal sampling characteristics make DAS an appealing tool to record seismic wavefields at higher quantity and quality than traditional geophones. Considering that the usage of optical fibers in the urban environment has drawn relatively less attention aside from its functionality as a telecommunication cable, we examine its ability to record seismic signals and investigate its preliminary application in city traffic monitoring. To solve the problems that DAS signals are prone to a variety of environmental noise and are generally of weak amplitude compared to noise, we propose a fast workflow for real-time DAS data processing, which can enhance the detection of regular car signals and suppress the other components. We conduct a DAS experiment in Hangzhou, China, a typical metropolitan area that can provide us with a rich data library to validate our DAS data-processing workflow. The well-processed data enable us to extract their slope and coherency attributes that can provide an estimate of real traffic situations. The one-minute (with video validations) and 24 h statistics of these attributes show that the speed and volume of car flow are well correlated demonstrates the robustness of the proposed data processing workflow and great potential of DAS for city traffic monitoring with high precision and convenience. However, challenges also exist in view that all the attributes are statistically analyzed based on the behaviors of a large number of cars, which is meaningful but lacking in precision. Therefore, we suggest developing more quantitative processing and analyzing methods to provide precise information on individual cars in future works. Full article

We present two case studies of the application of seismic surveys to estimate the elastic properties of soil and rock in the shallow subsurface. The two sites present very different geological characteristics. The first test site is a town on the Croatian coast, not far from the city of Split, built on hard rock, where we acquired three seismic lines. The second site is located in the outskirts of the city of Ferrara, in Italy, in an alluvial plain, where two lines were acquired. In both sites, for detailed characterization, we acquired surface-, compressional- and shear-waves, further distinguishing the latter between horizontally (SH) and vertically (SV) polarized wavefields. We processed the data by performing a Multichannel Analysis of Surface Waves to compute a preliminary one-dimensional shear wave velocity profile. Then, we performed first-break tomography to compute P-, SH- and SV-velocity profiles. Such unusual acquisition allowed us to compute not only basic engineering parameters such as the equivalent shear-wave velocity of the first 30 m of subsurface (V_S30) from the SH profiles but also other useful parameters such as the V_P/V_S and estimate the anisotropy of the medium thanks to the V_SV/V_SH. Given the level of detail of the results and their engineering value, we conclude that the method of investigation we applied in the two test sites is a valuable tool for characterizing the shallow subsurface. Full article

Ultra-deep (7500–9000 m) Ordovician tight limestone heterogeneous fractured-vuggy reservoir is an important target of FuMan Oilfield in Tarim Basin. The strike-slip fault controlled reservoir is related to formation fracture and dissolution caused by geological stress. The seismic wave-field anomaly characteristics with different energy and irregular waveform are displayed in the seismic profile. Accurate identification of fractured-vuggy reservoirs wrapped in tight limestone is the direct scheme to improve production efficiency. Therefore, a new combination method flow of seismic wave-field anomaly recognition is proposed. In this process, the seismic data must be preprocessed initially, and on this basis, robust formation dip scanning is carried out. Secondly, the dip data is applied to the transverse smoothing filter to obtain the formation background data. Eventually, the seismic wave-field anomaly data is the residual between background data and original seismic data. This method has been applied in blocks with different structural characteristics and can effectively improve the resolution of strike-slip fault controlled reservoirs. Based on the results, the drilling success rate is increased to more than 95%, and the high-yield rate of oil tests is increased to 75% in 2021. Multiple applications indicate that the method is robust and can be popularized. Full article

The accurate prediction of the geological conditions ahead of a tunnel plays an important role in tunnel construction. Among all forward geological prospecting methods, the seismic detection method is widely applied. However, due to the characteristics of the tunnel and the complexity of the geological conditions, the seismic wavefield is complicated. Carrying out a more realistic forward modeling method is vital for fully understanding the law of seismic wave propagation and the characteristics of seismic wavefield in the tunnel. In this paper, the 3D staggered-grid finite-difference scheme in the cylindrical coordinate system based on the decoupled nonconversion elastic wave equation is used to carry out the numerical simulation. This method can avoid the diffraction interferences produced at the edges of the tunnel face in the Cartesian coordinate system. Based on this forward modeling method, the characteristics of wavefield and propagation laws of seismic waves under three kinds of common typical unfavorable geological models were explored, which can provide theoretical guidance to seismic data interpretation of tunnel seismic forward prospecting in practice. Full article

Microseismic (MS) source location is a fundamental and critical task in mine MS monitoring. The traditional ray tracing-based location method can be easily affected by many factors, such as multi-ray path effects, waveform focusing and defocusing of wavefield propagation, and low picking precision of seismic phase arrival. By contrast, the Gaussian beam reverse-time migration (GBRTM) location method can effectively and correctly model the influences of multi-path effects and wavefield focusing and defocusing in complex 3D media, and it takes advantages of the maximum energy focusing point as the source location with the autocorrelation imaging condition, which drastically reduces the requirements of signal-to-noise ratio (SNR) and picking accuracy of P-wave arrival. The Gaussian beam technique has been successfully applied in locating natural earthquake events and hydraulic fracturing-induced MS events in one-dimensional (1D) or simple two-dimensional (2D) velocity models. The novelty of this study is that we attempted to introduce the GBRTM technique into a mine MS event location application and considered utilizing a high-resolution tomographic 3D velocity model for wavefield back propagation. Firstly, in the synthetic test, the GBRTM location results using the correct 2D velocity model and different homogeneous velocity models are compared to show the importance of velocity model accuracy. Then, it was applied and verified by eight location premeasured blasting events. The synthetic results show that the spectrum characteristics of the recorded blasting waveforms are more complicated than those generated by the ideal Ricker wavelet, which provides a pragmatic way to evaluate the effectiveness and robustness of the MS event location method. The GBRTM location method does not need a highly accurate picking of phase arrival, just a simple detection criterion that the first arrival waveform can meet the windowing requirements of wavefield back propagation, which is beneficial for highly accurate and automatic MS event location. The GBRTM location accuracy using an appropriate 3D velocity model is much higher than that of using a homogeneous or 1D velocity model, emphasizing that a high-resolution velocity model is very critical to the GBRTM location method. The average location error of the GBRTM location method for the eight blasting events is just 17.0 m, which is better than that of the ray tracing method using the same 3D velocity model (26.2 m). Full article
