In the dynamic analysis of dam–reservoir interactions, the computational efficiency of coupling system is relatively low. When numerical methods such as the scaled boundary finite element method (SBFEM) or the finite element method (FEM) are used to deal with hydrodynamic pressure, the additional mass matrix for the hydrodynamic pressure of incompressible reservoir water obtained is the full matrix. In this study, an efficient three dimensional (3D) dynamic fluid–solid coupling analysis method for dam–reservoir systems based on the FEM-SBFEM is proposed and applied to the dynamic calculation and analysis of an arch dam under seismic conditions, which adopts the SBFEM to solve the hydrodynamic pressure of the reservoir and employs the FEM to discretize the dam. In the proposed method, the hydrodynamic pressure additional mass matrix is simplified according to the physical meaning and distribution characteristics of the additional matrix with only a reduction coefficient α (0 < α ≤ 1.0), which is simple and easy to implement. The suggested value of the reduction coefficient α for the added mass matrix of the hydrodynamic pressure is selected to be 0.6 so as to ensure that the error of the maximum value of the dynamic response of the dam is limited within 5%, which is acceptable, and the elapsed time of calculation can be reduced to one twentieth of the accurate solution, which is a great jump in calculation efficiency. The proposed method provides a practical and effective process for the analysis of dam–reservoir dynamic interaction systems with a large computational scale and a fine grid scale. Full article

In quasi-brittle materials such as concrete, numerical methods are frequently used to simulate the crack propagation for monotonic loading. However, further research and action are required to better understand the fracture properties under cyclic loading. For this purpose, in this study, we present numerical simulations of mixed-mode crack propagation in concrete using the scaled boundary finite element method (SBFEM). The crack propagation is developed based on a cohesive crack approach combined with the thermodynamic framework of a constitutive concrete model. For validation, two benchmark crack-mode examples are modelled under monotonic and cyclic loading conditions. The numerical results are compared against the results from available publications. Our approach revealed good consistency compared to the test measurements from the literature. The damage accumulation parameter was the most influential variable on the load-displacement results. The proposed method can provide a further investigation of crack growth propagation and damage accumulation for cyclic loading within the SBFEM framework. Full article

Lamb wave dispersion curves are useful for optimizing the inspection scanning distance that can be covered with good sensitivity in many current applications. However, one of the main problems concerning this calculation lies in selecting a numerical method that is computationally accurate and efficient. In this paper, Lamb waves dispersion curves are generated by the Scaled Boundary Finite Element Method, and by the Rayleigh–Lamb equation. For the semi-analytical case, waveguide cross-section discretization was performed using isoparametric elements and high-order spectral elements. The semi-analytical formulations lead to an eigenvalue problem that can be solved efficiently by calculating the couples of wavenumbers and frequencies that guarantee the wave mode propagation, the basis for generating the dispersion curves. These are compared with those obtained from the analytical solution for the symmetric and antisymmetric modes; in both cases, homogeneous plates of constant thickness are considered. The numerical results show good agreement when using a low number of isoparametric elements, or a single spectral element with shape functions of the order of six for computing the dispersion curves and wave structure. The calculation is given with low computational effort, and the relative variation with respect to the analytical reference values is less than 2%. Full article

Many concrete structures, such as bridges and wind turbine towers, fail mostly due to the fatigue rapture and bending, where the cracks are initiated and propagate under cyclic loading. Modeling the fracture process zone (FPZ) is essential to understanding the cracking behavior of heterogeneous, quasi-brittle materials such as concrete under monotonic and cyclic actions. The paper aims to present a numerical modeling approach for simulating crack growth using a scaled boundary finite element model (SBFEM). The cohesive traction law is explored to model the stress field under monotonic and cyclic loading conditions. In doing so, a new constitutive law is applied within the cohesive response. The cyclic damage accumulation during loading and unloading is formulated within the thermodynamic framework of the constitutive concrete model. We consider two common problems of three-point bending of a single-edge-notched concrete beam subjected to different loading conditions to validate the developed method. The simulation results show good agreement with experimental test measurements from the literature. The presented analysis can provide a further understanding of crack growth and damage accumulation within the cohesive response, and the SBFEM makes it possible to identify the fracture behavior of cyclic crack propagation in concrete members. Full article

Hydrodynamic pressure is an important factor that cannot be ignored in the seismic safety evaluation of dams. However, when the polyhedron-scaled boundary finite element method is used to simulate dams in a cross-scale dynamic analysis, polygonal surfaces often appear on the upstream face of dams, which is difficult to deal with for conventional methods of hydrodynamic pressure. In this paper, a three-dimensional calculation method of hydrodynamic pressure based on the polyhedron-scaled boundary finite element method is proposed, in which polygon (triangle, quadrilateral, pentagon, hexagon, heptagon, octagon, etc.) semi-infinite prismatic fluid elements are constructed using the mean-value shape function. The proposed method, with a high efficiency, overcomes the limitation of conventional methods in which only quadrangle or triangle boundary faces of elements are permitted. The accuracy of the proposed method is proved to be high when considering various factors. Furthermore, combined with the polyhedron-scaled boundary finite element method for a solid dam, the proposed method for reservoir water is used to develop a nonlinear dynamic coupling method for cross-scale concrete-faced rockfill dam-reservoir systems based on the polyhedron SBFEM. The results of the numerical analysis show that when the hydrodynamic pressure is not considered, the error of rockfill dynamic acceleration and displacement could reach 15.4% and 12.7%, respectively, and the error of dynamic face slabs’ stresses could be 24.9%, which is not conducive to a reasonable seismic safety evaluation of dams. Full article

The existence of pores is a very common feature of nature and of human life, but the existence of pores will alter the mechanical properties of the material. Therefore, it is very important to study the impact of different influencing factors on the mechanical properties of porous materials and to use the law of change in mechanical properties of porous materials for our daily lives. The SBFEM (scaled boundary finite element method) method is used in this paper to calculate a large number of random models of porous materials derived from Matlab code. Multiple influencing factors can be present in these random models. Based on the Monte Carlo simulation, after a large number of model calculations were carried out, the results of the calculations were analyzed statistically in order to determine the variation law of the mechanical properties of porous materials. Moreover, this paper gives fitting formulas for the mechanical properties of different materials. This is very useful for researchers estimating the mechanical properties of porous materials in advance. Full article

This paper presents direct computations of 3-D fracture parameters including stress intensity factors (SIFs) and T-stress for straight and curved planar cracks with the p-version finite element method (P-FEM) and contour integral method (CIM). No excessive singular element or enrichment function is required for the computation. To demonstrate the accuracy and efficiency of the proposed approaches, several benchmark numerical models of 3-D planar straight and curved cracks with single and mixed-mode fractures are considered and analyzed: a through thickness edge straight crack in a homogeneous material, a through thickness inclined straight crack, a penny-shaped crack embedded in a cube and a central ellipse shaped crack in a homogeneous cube. Numerical results are analyzed and compared with analytical solutions and those reported by the extended finite element method (XFEM) and the scaled boundary finite element method (SBFEM) in the available literature. Numerical experiments show the accuracy, robustness and effectiveness of the present method. Full article

Generating random aggregate models (RAMs) plays a key role in the mesoscopic modelling of concrete-like composite materials. The arbitrary geometry, wide gradation, and high volume ratio of aggregates pose a great challenge for fast and efficient numerical construction of concrete meso-structures. This paper presents a simple strategy for generating RAMs of concrete based on Laguerre tessellation, which mainly consists of three steps: tessellation, geometric smoothing, and scaling. The computer-assisted design (CAD) file of RAMs obtained by the proposed approach can be directly adopted for the construction of random numerical concrete samples. Combined with the image-based octree meshing algorithm, the scaled boundary finite element method (SBFEM) was adopted for an automatic stress analysis of mass concrete samples, and a parametric study was conducted to investigate the meso-structural effects on concrete elasticity properties. The modelling results successfully reproduced the increasing trend of concrete elastic modulus with the grading of coarse aggregates in literature test data and demonstrate the effectiveness of the proposed strategy. Full article

Guided waves (GW) are of great interest for non-destructive testing (NDT) and structural health monitoring (SHM) of engineering structures such as for oil and gas pipelines, rails, aircraft components, adhesive bonds and possibly much more. Development of a technique based on GWs requires careful understanding obtained through modelling and analysis of wave propagation and mode-damage interaction due to the dispersion and multimodal character of GWs. The Scaled Boundary Finite Element Method (SBFEM) is a suitable numerical approach for this purpose allowing calculation of dispersion curves, mode shapes and GW propagation analysis. In this article, the SBFEM is used to analyse wave propagation in a plate consisting of an isotropic aluminium layer bonded as a hybrid to an anisotropic carbon fibre reinforced plastics layer. This hybrid composite corresponds to one of those considered in a Type III composite pressure vessel used for storing gases, e.g., hydrogen in automotive and aerospace applications. The results show that most of the wave energy can be concentrated in a certain layer depending on the mode used, and by that damage present in this layer can be detected. The results obtained help to understand the wave propagation in multi-layered structures and are important for further development of NDT and SHM for engineering structures consisting of multiple layers. Full article

Three alternative approaches, namely the extended/generalized finite element method (XFEM/GFEM), the scaled boundary finite element method (SBFEM) and phase field methods, are surveyed and compared in the context of linear elastic fracture mechanics (LEFM). The purpose of the study is to provide a critical literature review, emphasizing on the mathematical, conceptual and implementation particularities that lead to the specific advantages and disadvantages of each method, as well as to offer numerical examples that help illustrate these features. Full article

Fracture mechanics is one of the most important approaches to structural safety analysis. Modeling the fracture process zone (FPZ) is critical to understand the nonlinear cracking behavior of heterogeneous quasi-brittle materials such as concrete. In this work, a nonlinear extended scaled boundary finite element method (X-SBFEM) was developed incorporating the cohesive fracture behavior of concrete. This newly developed model consists of an iterative procedure to accurately model the traction distribution within the FPZ accounting for the cohesive interactions between crack surfaces. Numerical validations were conducted on both of the concrete beam and dam structures with various loading conditions. The results show that the proposed nonlinear X-SBFEM is capable of modeling the nonlinear fracture propagation process considering the effect of cohesive interactions, thereby yielding higher precisions than the linear X-SBFEM approach. Full article
