Search Results (15)

The gob-side entry driving in deep mines with soft rock exhibits a complex deformation and instability mechanism. This complexity leads to challenges in roadway stability control which greatly affects the coal mine production succession and safe and efficient mining. This paper takes the gob-side entry in Liuzhuang Coal Mine as the background. By adopting the method of theoretical analysis, a dynamic model of the roof subsidence in the goaf is established. The calculation indicates that achieving the stable subsidence of the basic roof and the equilibrium of the lateral abutment stress within the goaf requires a minimum of 108.9 days, offering a theoretical foundation for selecting an optimal driving time for the gob-side entry. The control technologies and methods of gob-side entry through grouting modification and high-strength support are proposed. Enhancing the length of anchor ropes and the density of bolt (cable) support to improve the role of the roadway support components can be better utilized, so the role of the support components of the roadway can be better exerted. The method of grouting and the reinforcement of coal pillars can effectively improve the carrying capacity of coal pillars. The numerical simulation is used to analyze the deformation law of gob-side entry. The study reveals significant deformation in the coal pillar and substantial roof subsidence, highlighting that maintaining the stability of the coal pillar is crucial for ensuring roadway safety. Following the grouting process, the deformation of the coal pillar and roof subsidence decreased by 16.7% and 7.1%, respectively. This demonstrates that coal pillar grouting not only mitigates pillar deformation but also provides effective control over roof subsidence. This study offers a quantitative calculation method to ascertain the excavation time of gob-side entry, and suggests that the application of high-strength support and the practice of coal pillar grouting can effectively maintain the steadiness of gob-side entry in deep mines with soft rock. Full article

Body weight support (BWS) systems are crucial in gait rehabilitation for individuals incapacitated due to injuries or medical conditions. Traditional BWS systems typically employ either static mass–rope or dynamic mass–spring–damper configurations, which can result in inadequate support stiffness, thereby leading to compromised gait training. Additionally, these systems often lack the flexibility for easy customization of stiffness, which is vital for personalized rehabilitation treatments. A novel BWS system with online variable stiffness is introduced in this study. This system incorporates a drive mechanism governed by admittance control that dynamically adjusts the stiffness by modulating the tension of a rope wrapped around a drum. An automated control algorithm is integrated to manage a smart anti-gravity dynamic suspension system, which ensures consistent and precise weight unloading adjustments throughout rehabilitation sessions. Walking experiments were performed to evaluate the displacement and load variations within the suspension ropes, thereby validating the variable-stiffness capability of the system. The findings suggest that the online variable-stiffness BWS system can reliably alter the stiffness levels and that it exhibits robust performance, significantly enhancing the effectiveness of gait rehabilitation. The newly developed BWS system represents a significant advancement in personalized gait rehabilitation, offering real-time stiffness adjustments and ongoing weight support customization. It ensures dependable control and robust operation, marking a significant step forward in tailored therapeutic interventions for gait rehabilitation. Full article

A knotter is a core component for the automatic bundling of agricultural materials, and a knotter with double-fluted discs is one type. Currently, the research on knotters with double-fluted discs has gradually transitioned from structural design to reliability optimization. To address rope-clamping failures in the rope-clamping drive mechanisms in knotters, the specific failure position of the rope-clamping mechanism and the failure causes were analyzed first. The redesign of the rope-clamping drive mechanism in knotters with double synclastic fluted discs was proposed, including structure optimization and 3D modeling using the GearTrax/KISSsoft and SolidWorks software. A virtual prototype model of a knotter with a flexible rope was established by combining ANSYS with the ADAMS software. A rigid–flexible coupling dynamic simulation of the knotter was carried out using ADAMS, and the simulation results were used as the data input for the ANSYS nCode DesignLife module for the fatigue life simulation of the weak parts (the worm shaft) of the knotter. The operation test results for the rope-clamping drive mechanism indicate that the redesigned rope-clamping drive mechanism is reliable in transmission, with a rope-clamping success rate of 100%. The actual operation times for the worm shaft exceed the minimum fatigue life obtained through joint simulation. The applied joint simulation method has high simulation accuracy. Full article

Cable-driven parallel robots (CDPRs) offer significant advantages, such as the lightweight design, large workspace, and easy reconfiguration, making them essential for various spatial applications and extreme environments. However, despite their benefits, CDPRs face challenges, notably the uncertainty in terms of the post-reconstruction parameters, complicating cable coordination and impeding mechanism parameter identification. This is especially notable in CDPRs with redundant constraints, leading to cable relaxation or breakage. To tackle this challenge, this paper introduces a novel approach using reinforcement learning to drive redundant constrained cable-driven robots with uncertain parameters. Kinematic and dynamic models are established and applied in simulations and practical experiments, creating a conducive training environment for reinforcement learning. With trained agents, the mechanism is driven across 100 randomly selected parameters, resulting in a distinct directional distribution of the trajectories. Notably, the rope tension corresponding to 98% of the trajectory points is within the specified tension range. Experiments are carried out on a physical cable-driven device utilizing trained intelligent agents. The results indicate that the rope tension remained within the specified range throughout the driving process, with the end platform successfully maneuvered in close proximity to the designated target point. The consistency between the simulation and experimental results validates the efficacy of reinforcement learning in driving unknown parameters in redundant constraint-driven robots. Furthermore, the method’s applicability extends to mechanisms with diverse configurations of redundant constraints, broadening its scope. Therefore, reinforcement learning emerges as a potent tool for acquiring motion data in cable-driven mechanisms with unknown parameters and redundant constraints, effectively aiding in the reconstruction process of such mechanisms. Full article

This paper presents a minimally invasive surgical robot system for endoluminal gastrointestinal endoscopy through natural orifices. In minimally invasive gastrointestinal endoscopic surgery (MIGES), surgical instruments need to pass through narrow endoscopic channels to perform highly flexible tasks, imposing strict constraints on the size of the surgical robot while requiring it to possess a certain gripping force and flexibility. Therefore, we propose a novel minimally invasive robot system with advantages such as compact size and high precision. The system consists of an endoscope, two compact flexible continuum mechanical arms with diameters of 3.4 mm and 2.4 mm, respectively, and their driving systems, totaling nine degrees of freedom. The robot’s driving system employs bidirectional ball-screw-driven motion of two ropes simultaneously, converting the choice of opening and closing of the instrument’s end into linear motion, facilitating easier and more precise control of displacement when in position closed-loop control. By means of coordinated operation of the terminal surgical tools, tasks such as grasping and peeling can be accomplished. This paper provides a detailed analysis and introduction of the system. Experimental results validate the robot’s ability to grasp objects of 3 N and test the system’s accuracy and payload by completing basic operations, such as grasping and peeling, thereby preliminarily verifying the flexibility and coordination of the robot’s operation in a master–slave configuration. Full article

The load-adaptive behavior of the muscles in the human musculoskeletal system offers great potential for minimizing resource and energy requirements in many technical systems, especially in drive technology and robotics. However, the lack of knowledge about suitable technical linear actuators that can reproduce the load-adaptive behavior of biological muscles in technology is a major reason for the lack of successful implementation of this biological principle. In this paper, therefore, the different types of linear actuators are investigated. The focus is particularly on artificial muscles and rope pulls. The study is based on literature, on the one hand, and on two physical demonstrators in the form of articulated robots, on the other hand. The studies show that ropes are currently the best way to imitate the load-adaptive behavior of the biological model in technology. This is especially illustrated in the context of this paper by the discussion of different advantages and disadvantages of the technical linear actuators, where ropes, among other things, have a good mechanical and control behavior, which is very advantageous for use in an adaptive system. Finally, the next steps for future research are outlined to conclude how ropes can be used as linear actuators to transfer load-adaptive lightweight design into technical applications. Full article

Three-dimensional weaving structures have high strength and resistance to interlayer shear due to their integrated manufacturing features. The traditional weaving equipment is generally huge and is not effective for weaving small-sized products. Therefore, this paper proposes a new composite forming technology and weaving mechanism based on grid-enhanced structures to braid small-sized preforms, combining the continuous fiber printing technology, the rope drive technology and the 3D weaving technology. This paper adopted the screw theory for forward and inverse kinematic analysis of the weaving mechanism and applied software Adams2020 for trajectory simulation analysis. The theoretical calculation results were basically consistent with the simulation results, which verified the rationality and feasibility of the designed weaving mechanism in small, enhanced grids. Full article

Current autonomous driving systems predominantly focus on 3D object perception from the vehicle’s perspective. However, the single-camera 3D object detection algorithm in the roadside monitoring scenario provides stereo perception of traffic objects, offering more accurate collection and analysis of traffic information to ensure reliable support for urban traffic safety. In this paper, we propose the YOLOv7-3D algorithm specifically designed for single-camera 3D object detection from a roadside viewpoint. Our approach utilizes various information, including 2D bounding boxes, projected corner keypoints, and offset vectors relative to the center of the 2D bounding boxes, to enhance the accuracy of 3D object bounding box detection. Additionally, we introduce a 5-layer feature pyramid network (FPN) structure and a multi-scale spatial attention mechanism to improve feature saliency for objects of different scales, thereby enhancing the detection accuracy of the network. Experimental results demonstrate that our YOLOv7-3D network achieved significantly higher detection accuracy on the Rope3D dataset while reducing computational complexity by 60%. Full article

Both the biomimetic design based on marine life and the origami-based design are recommended as valuable paths for solving conceptual and design problems. The insights into the combination of the two manners inspired this research: an origami polyhedra-inspired soft robotic jellyfish. The core idea of the story is to leverage the deformation mechanism of the origami metamaterial to approximate the jet-propelled swimming behavior of the prolate medusae. First, four possible variants of origami polyhedra were compared by the hydrodynamic simulation method to determine a suitable model for the soft body of robotic jellyfish. Second, the mathematical model for the jet propulsion performance of the soft origami body was built, and the diameter of the jet nozzle was determined through the simulation method. Third, the overall configuration and the rope-motor-driven driving method of the soft robotic jellyfish were presented, and the prototype was developed. The experimental work of jet swimming, thrust forces measurement, and cost of transport further demonstrated the presented soft robotic jellyfish. In addition, the prospective directions were also discussed to improve maneuverability, sensory perception, and morphological improvement. Due to the advantages, including but not limited to, the concise structure, low cost, and ease of manufacture, we anticipate the soft robotic jellyfish can serve for the ecological aquatic phenomena monitoring and data collection in the future. Full article

Regular maintenance of wire rope is considered the key to ensuring the safe operation of a sluice gate. Along these lines, in this work, a six-wheeled wire rope climbing robot was proposed, which can carry cleaning and maintenance tools for online cleaning and safety inspection of the sluice wire rope, without its disassembly. The developed climbing robot is composed of separable driving and driven trolleys. It adopts the spring clamping mechanism and the wheeled movement method. Thus, it can easily adapt to the narrow working environment and different diameter ranges of the sluice wire rope. In addition, the designed six-wheeled wire rope climbing robot not only possesses a simple structure, simple control, and stable climbing speed, which are typical characteristics of wheeled climbing robots, but also a large contact area with objects and small wheel deformation, which are typical characteristics of crawler climbing robots. Structural design and mechanical analysis were also carried out, with the fabrication of a prototype robot system called WRR-II. From the acquired experimental results of the prototype’s climbing speed test, load capacity test, climbing adaptability test, and obstacle-negotiation ability test, the rationality and feasibility of the designed climbing robot scheme were verified. Full article

In recent years, intelligent driving technology based on vehicle–road cooperation has gradually become a research hotspot in the field of intelligent transportation. There are many studies regarding vehicle perception, but fewer studies regarding roadside perception. As sensors are installed at different heights, the roadside object scale varies violently, which burdens the optimization of networks. Moreover, there is a large amount of overlapping and occlusion in complex road environments, which leads to a great challenge of object distinction. To solve the two problems raised above, we propose RD-YOLO. Based on YOLOv5s, we reconstructed the feature fusion layer to increase effective feature extraction and improve the detection capability of small targets. Then, we replaced the original pyramid network with a generalized feature pyramid network (GFPN) to improve the adaptability of the network to different scale features. We also integrated a coordinate attention (CA) mechanism to find attention regions in scenarios with dense objects. Finally, we replaced the original Loss with Focal-EIOU Loss to improve the speed of the bounding box regression and the positioning accuracy of the anchor box. Compared to the YOLOv5s, the RD-YOLO improves the mean average precision (mAP) by 5.5% on the Rope3D dataset and 2.9% on the UA-DETRAC dataset. Meanwhile, by modifying the feature fusion layer, the weight of RD-YOLO is decreased by 55.9% while the detection speed is almost unchanged. Nevertheless, the proposed algorithm is capable of real-time detection at faster than 71.9 frames/s (FPS) and achieves higher accuracy than the previous approaches with a similar FPS. Full article

The cable-spring folding wing is a novel type of rigid-flexible coupling structure for missiles, which is composed of several sets of deployable mechanisms, with each composed of a wheel-rope transmission system and a parallel spring driving mechanism. The movement of the cable is initiated by the driving force produced by parallel springs, which directly changes the magnitude and the distribution of the driving force. Therefore, the cable-spring folding wing system has the typical characteristics of strong nonlinearity and motion coupling. In addition, each deployable mechanism shares an identical structure, but the distribution of motion parameters is discrepant due to external loads. Asynchronous movement of the cable-spring folding wing will occur and become a significant issue, which is detrimental to the working performance and could even lead to failure. Focusing on these problems, the multi-body dynamics theoretical model and simulation model of deployable mechanism are established, the kinematic and dynamic characteristics of critical components are studied, and the key factors affecting the deployment performance are investigated. A new reliability method with an angular precision control for deployable mechanism is proposed based on the theoretical model. The effectiveness of the proposed model and method is verified by comparing it with the Monte Carlo method. On this basis, the reliability evaluation for cable-spring folding wing, comprehensively considering deployment performance and synchronization, is carried out. Full article

In this work, a mechanical model of a rope-driven piezoelectric vibration energy harvester (PVEH) for low-frequency and wideband energy harvesting was presented. The rope-driven PVEH consisting of one low-frequency driving beam (LFDB) and one high-frequency generating beam (HFGB) connected with a rope was modeled as two mass-spring-damper suspension systems and a massless spring, which can be used to predict the dynamic motion of the LFDB and HFGB. Using this model, the effects of multiple parameters including excitation acceleration, rope margin and rope stiffness in the performance of the PVEH have been investigated systematically by numerical simulation and experiments. The results show a reasonable agreement between the simulation and experimental study, which demonstrates the validity of the proposed model of rope-driven PVEH. It was also found that the performance of the PVEH can be adjusted conveniently by only changing rope margin or stiffness. The dynamic mechanical model of the rope-driven PVEH built in this paper can be used to the further device design or optimization. Full article

Nowadays, patients with mild and moderate upper limb paralysis caused by cerebral apoplexy are uncomfortable with autonomous rehabilitation. In this paper, according to the “rope + toothed belt” generalized rope drive design scheme, we design a utility model for a wearable upper limb rehabilitation robot with a tension mechanism. Owing to study of the human upper extremity anatomy, movement mechanisms, and the ranges of motion, it can determine the range of motion angles of the human arm joints, and design the shoulder joint, elbow joint, and wrist joint separately under the principle of ensuring the minimum driving torque. Then, the kinematics, workspace and dynamics analysis of each structure are performed. Finally, the control system of the rehabilitation robot is designed. The experimental results show that the structure is convenient to wear on the human body, and the robot’s freedom of movement matches well with the freedom of movement of the human body. It can effectively support and traction the front and rear arms of the affected limb, and accurately transmit the applied traction force to the upper limb of the joints. The rationality of the wearable upper limb rehabilitation robot design is verified, which can help patients achieve rehabilitation training and provide an effective rehabilitation equipment for patients with hemiplegia caused by stroke. Full article

This paper presents a novel piezoelectric vibration energy harvester (PVEH) in which a high-frequency generating beam (HFGB) is driven by an array of low-frequency driving beams (LFDBs) using ropes. Two mechanisms based on frequency upconversion and multimodal harvesting work together to broaden the frequency bandwidth of the proposed vibration energy harvester (VEH). The experimental results show that the output power of generating beam (GB) remains unchanged with the increasing number of driving beams (DBs), compared with the traditional arrays of beams vibration energy harvester (AB-VEH), and the output power and bandwidth behavior can be adjusted by parameters such as acceleration, rope margin, and stiffness of LFDBs, which shows the potential to achieve unlimited wideband vibration energy-harvesting for a variable environment. Full article
