Search Results (33)

This study focuses on how rocks respond mechanically and how to keep them stable when soft rock roadways are under deep tectonic stress. It does this through a combination of theoretical analysis, numerical simulations, and field applications. We created a mechanical model of roof strata to calculate how much they would bend under both horizontal tectonic stress and their weight. This modeling helped us determine the critical yield limits. A systematic study of the angle θ between the direction of tectonic stress and the axis of the roadway showed that the concentration of horizontal stress on the roof gets stronger as θ increases, while the vertical stress on the sidewalls slowly gets weaker. The main sign of surrounding rock failure is shear damage that is most severe at the roof, floor, and shoulder angles. The maximum plastic zone depth occurs at θ = 90°. Studies that looked at both gob-side and along-roadway stages found that the two types of failure were very different, characterized by severe roof damage during roadway advancement and pronounced coal pillar instability in gob-side conditions. Based on these results, targeted support strategies were successfully used in field engineering to control deformations and provide both theoretical foundations and practical solutions for stabilizing deep soft rock roadways under tectonic stress. Full article

The instability of mine roadways is significantly influenced by the coupled effects of groundwater seepage and non-uniform loading. These interactions often induce localized plastic deformation and progressive failure, particularly in the roof and sidewall regions. Seepage elevates pore water pressure and deteriorates the mechanical properties of the rock mass, while non-uniform loading leads to stress concentration. The combined effect facilitates the propagation of microcracks and the formation of shear zones, ultimately resulting in localized instability. This initial damage disrupts the mechanical equilibrium and can evolve into severe geohazards, including roof collapse, water inrush, and rockburst. Therefore, understanding the damage and failure mechanisms of mine roadways at the mesoscale, under the combined influence of stress heterogeneity and hydraulic weakening, is of critical importance based on laboratory experiments and numerical simulations. However, the large scale of in situ roadway structures imposes significant constraints on full-scale physical modeling due to limitations in laboratory space and loading capacity. To address these challenges, a straight-wall circular arch roadway was adopted as the geometric prototype, with a total height of 4 m (2 m for the straight wall and 2 m for the arch), a base width of 4 m, and an arch radius of 2 m. Scaled physical models were fabricated based on geometric similarity principles, using defect-bearing sandstone specimens with dimensions of 100 mm × 30 mm × 100 mm (length × width × height) and pore-type defects measuring 40 mm × 20 mm × 20 mm (base × wall height × arch radius), to replicate the stress distribution and deformation behavior of the prototype. Uniaxial compression tests on water-saturated sandstone specimens were performed using a TAW-2000 electro-hydraulic servo testing system. The failure process was continuously monitored through acoustic emission (AE) techniques and static strain acquisition systems. Concurrently, FLAC^3D 6.0 numerical simulations were employed to analyze the evolution of internal stress fields and the spatial distribution of plastic zones in saturated sandstone containing pore defects. Experimental results indicate that under non-uniform loading, the stress–strain curves of saturated sandstone with pore-type defects typically exhibit four distinct deformation stages. The extent of crack initiation, propagation, and coalescence is strongly correlated with the magnitude and heterogeneity of localized stress concentrations. AE parameters, including ringing counts and peak frequencies, reveal pronounced spatial partitioning. The internal stress field exhibits an overall banded pattern, with localized variations induced by stress anisotropy. Numerical simulation results further show that shear failure zones tend to cluster regionally, while tensile failure zones are more evenly distributed. Additionally, the stress field configuration at the specimen crown significantly influences the dispersion characteristics of the stress–strain response. These findings offer valuable theoretical insights and practical guidance for surrounding rock control, early warning systems, and reinforcement strategies in water-infiltrated mine roadways subjected to non-uniform loading conditions. Full article

The dip angle and thickness of coal seams are key geological determinants in mine system engineering. Roadways excavated in steeply inclined or thick coal seams typically exhibit significant deformation, with the combined geological configuration of steeply inclined thick seams thus presenting heightened support demands. Therefore, taking the 1502 level roadway in the Dayuan Coal Industry—situated in a steeply inclined thick coal seam—as an engineering case, mechanical models of roadways with different cross-sectional shapes are established, and the deformation and failure mechanisms of surrounding rock under different coal seam dip angles are analyzed. Based on this analysis, an asymmetric support technology scheme is proposed, followed by surrounding rock deformation monitoring and a support effectiveness evaluation. Key findings include the following: (1) in steeply inclined thick coal seam roadways with different cross-sectional shapes, the stress distribution and plastic zone development of surrounding rock follow a descending sequence, inclined roof trapezoidal section > rectangular section > arched section. Among these, the arched section is identified as the optimal roadway cross-sectional shape for this engineering context. (2) The stress-concentration area in the arch roadway aligns with the inclined direction of the coal seam, forming asymmetric stress concentration patterns. Specifically, as the coal seam dip angle increases, stress increases at the arch shoulder of the upper sidewall and the wall foundation of the lower sidewall. Concurrently, such stress concentration induces shear failure in the surrounding rock, which serves as the primary mechanism causing asymmetric deformation and failure in steeply inclined thick coal seam roadways. (3) In the 1502 level roadway, the asymmetric support technology with dip-oriented reinforcement was implemented. Compared to the original support scheme, roof deformation and sidewall convergence decreased by 46.17% and 46.8%, respectively. The revealed failure mechanisms of steeply inclined thick coal seam roadways and the proposed asymmetric support technology provide technical and engineering references for roadway support in similar mining conditions. Full article

The non-uniform deformation and failure phenomena encountered in steeply inclined coal seams during roof-cutting and gob-side entry retaining operations demand urgent resolution. Taking the haulage roadway of the 3131 working face in Longmenxia South Coal Mine as the research background, the theoretical analysis method is adopted to explore the mechanical state of the main roof in inclined coal seams and the design of roadside support resistance. According to the structural evolution characteristics of the main roof, it is divided into four periods. Based on the elastic theory, corresponding mechanical models are established, and the mechanical expressions of the main roof stress and deflection are derived. The distribution characteristics of the main roof’s mechanical state in each zone and the influence law of the coal seam dip angle on the main roof’s mechanical state are studied. This study reveals a critical transition from symmetric to asymmetric mechanical behavior in the main roof structure due to the coal seam dip angle and roof structure evolution. The results show that, in the absence of roadside support, during the roadway retaining period, the upper surface of the main roof is in tension, and the lower surface is under compression. The stress value increases slowly from the high-sidewall side to the middle, while it increases sharply from the middle to the short-sidewall side. Under the inclined coal seam, as the dip angle of the coal and rock strata increases, the component load perpendicular to the roof direction decreases, and the roof deflection also decreases accordingly. On this basis, the design formula for the roadside support resistance of gob-side entry retaining with roof cutting in inclined coal seams is presented, and the roadside support resistance of the No. 3131 haulage roadway is designed. Building upon this foundation, a design formula for roadside support resistance in steeply inclined coal seams with roof-cutting and gob-side entry retaining has been developed. This formula was applied to the No. 3131 haulage roadway support design. Field engineering tests demonstrated that the maximum roof-to-floor deformation at the high sidewall decreased from 600 mm (unsupported condition) to 165 mm during the entry retaining period. During the advanced influence phase of secondary mining operations, the maximum deformation at the high sidewall was maintained at approximately 193 mm. Full article

Components made of composite materials are being increasingly used in the construction of rolling stock. Currently, the use of components made of composite materials as train structural elements is increasingly being considered. Non-structural components made of composites are most often found inside rail vehicles (e.g., the interior lining), while structural components made of sandwich composite materials can be used for the roof, sidewalls, and underframe constructions. This article provides a description of an innovative sandwich composite developed for a metro’s underframe, as well as the production process and preparation of the composite specimens. The main parts of the work are flammability and mechanical (static and fatigue) tests of the innovative sandwich composite. The scope of the flammability tests included the testing of the fire properties using the radial plate method, the optical density of smoke, and the content of toxic gases. The mechanical strength of the sandwich composite was examined during a flexural (three-point bending) test and a fatigue strength under a given dynamic load. The results presented in the article are very significant, both in terms of flammability and the mechanical strength tests. In order to produce large-size train components, appropriately large patches of component layers of the composite are required; this may pose production problems. Full article

To provide a comprehensive analysis of how an intricate landscape environment comprising various landscape elements influences driving safety and comfort. Beginning with the individual design of the tunnel body section, which includes the roof, sidewalls, road surface, and sidewalk facade markings, this paper references the driver’s biomass index to identify design alterations that satisfy basic safety requirements through simulated driving experiments. Subsequently, employing orthogonal experimental design and semi-supervised clustering algorithms, we ascertain the optimal combination of the four main landscape elements of the tunnel body section that align with both safety and comfort objectives. The experimental findings demonstrate that a safe and comfortable landscape design for urban tunnel sections does not entail a single optimal design; rather, any landscape design conforming to the criterion of “patterned landscapes are set on the side walls and roofs of the tunnel instead of the surface of the road” is the optimal design. Full article

In deep rock engineering, caverns are often disturbed by engineering loads from different directions. To investigate the dynamic response of deep U-shaped caverns under different incident orientations, a theoretical solution of the dynamic stress concentration factor along the cavern boundary was derived based on the wave function expansion and conformal mapping method, and the failure characteristics around the cavern were further investigated by PFC2D (Particle Flow Code in two dimensions). As the incident orientation increases from 0° to 90°, the dynamic compressive stress concentration area transforms from both the roof and the floor to the sidewalls, and the peak dynamic stress concentration factor of the roof decreases from 2.98 to −0.20. The failure of the floor converts from dynamic compression shear failure to dynamic tensile failure. Compared to a stress wave incident from the curved boundary, a stress wave incident from the flat boundary causes severer damage. When the stress wave is incident from the sidewall, the cavern with a larger height-to-width (h/w) ratio exhibits severer damage. Conversely, the cavern with a smaller h/w ratio tends to fail as the stress wave is incident from the floor. This paper provides a basic understanding of dynamic responses of the deep U-shaped cavern. Full article

An abandoned gypsum mine has been discovered beneath the route of a highway construction in Hunan province, south China. Due to the highway construction and operations safety, there is an urgent need for a comprehensive stability analysis of the abandoned mining area. The 3D laser scanning detection technique has been adopted, and over 400 drillholes were strategically placed near the highway to capture the spatial information of the abandoned gypsum mine. The ore body has an average mining thickness of about 3 m, and the depth of the mining roof ranges from 40 to 60 m, with an average span of 16 m. Based on the research achievements in the engineering geological investigation, rock mass quality assessment, and geometry information, a simplified numerical model has been established for stability analysis. The numerical model employed the IMASS rock mass constitutive model to conduct a stability analysis of the abandoned gypsum mine during the excavation process and in the medium to long term. The IMASS constitutive model can effectively reflect the entire process of rock mass from microscopic damage to macroscopic instability, and the numerical simulation of current and long-term stages provides a much greater understanding of the mining room stability and the effect of various geo-mechanical parameters not considered in traditional empirical methods. The abandoned gypsum mine stability is guaranteed in the mining and current stages. However, the numerical results showed that a 0.4 m spalling thickness of the sidewalls can cause an overall instability and failure of the abandoned mine, and reinforcement measures must be taken for long-term safety. The stability of the abandoned gypsum mine with filling solutions was also evaluated numerically. Full article

The random distribution of a complex joint network within a coal–rock mass has a significant weakening effect on its bearing capacity, making the surrounding rock of the roadway highly susceptible to instability and failure under the influence of in situ stress and mining-induced stress. This poses challenges in controlling the surrounding rock and seriously affects the normal production of mines. Consequently, it is imperative to conduct stability analysis on complex jointed roadway surrounding rock. Therefore, taking the transport roadway of Panel 11030 in the Zhaogu No. 2 Coal Mine as a case study, the microscopic contact parameters of particles and joint surfaces in each rock layer were calibrated through uniaxial compression and shear simulation tests using the particle flow simulation software PFC2D 5.0. Based on the calibrated microscopic contact parameters, a multilayered roadway surrounding rock model containing complex joints was established, and the joint density was quantified to analyze its effects on the displacement field, stress field, force chain field, and energy field of the roadway surrounding rock. The research findings indicate that as the distance to the sidewall decreases, the impact of joint density on the deformation of the surrounding rock of the roadway increases. The displacement of the roadway roof, floor, and sidewalls is affected differently by the joint density, predominantly contingent upon the properties of the rock mass. During the process of stress redistribution in the surrounding rock, the vertical stress of the roof and floor is released more intensively compared to the horizontal stress, while the horizontal stress of the sidewalls is released more intensively compared to the vertical stress. The increase in joint density leads to an increasing release rate of the surrounding rock stress, causing the load-bearing rock mass to transfer towards the deeper part. As the joint density increases, the force chain network gradually transitions from dense to sparse, resulting in a decrease in strong force chains and a decline in the bearing capacity of the surrounding rock, accompanied by an expansion in the range of force chain failure and deformation. With the continuous increase in joint density, the values of maximum released kinetic energy and residual released kinetic energy become larger. Once the joint density reaches a certain threshold, the kinetic energy stability zone consistently maintains a high energy level, indicating extreme instability in the roadway and sustained deformation. The results provide a valuable insight for analyzing the failure mechanism of complex jointed roadway surrounding rock and implementing corresponding support measures. Full article

Creep is a fundamental property that naturally exists in some types of rock, which is significant for the long-term stability of roadways during the mining process. In this paper, the long-term strength of coal and rock were determined via laboratory experiments, and a Cvisc elasto-viscoplastic model was adopted and introduced in FLAC3D, based on the 31101 transport roadway in the Hongqinghe Coal Mine, to investigate the influence of creep on the stability of a deep high-stress roadway. The test results show that the long-term strength of 3-1 coal and sandy mudstone was 18.65 MPa and 39.95 MPa, respectively. The plastic zone, the deformation, and the damage of the roadway’s surrounding rock displayed an obvious increase after being excavated for 720 d as the creep model was chosen. The plastic zone failure was modeled with shear-p (1090.7 m³), shear-n (381.7 m³), tension-n (98.4 m³), and tension-p (30.8 m³). The damage value had an obvious increment of 21.2% (0.053), and the deformation increased in the order of the two sidewalls (1978 mm), the roof (907 mm), and the floor (101 mm). The creep of the roadway can be divided into three stages: the accelerating stage, the decaying stage, and the stable stage. The creep speed of each stage is greatly affected by the presence or absence of anchor spray support: the creep speed of the bare roadway roof, sidewalls, and floor stability was 1.01, 1.02, and 0.12 mm/d, respectively. After anchor spray support, the creep velocity, correspondingly, decreased to 0.69, 0.37, and 0.12 mm/d, and the amount of surrounding rock damage decreased from 0.302 to 0.243. This indicates that the anchor spray support can significantly reduce the creep effect of the roadway. The Cvisc creep model was verified to be reliable and can provide guidance for deep high-stress coal roadway support. Full article

Artificial construction of a weakening zone over the roadway is an essential method for preventing coal bursts and rock bursts caused by strong mining tremors. However, concerning the seismic absorption and load reduction capabilities of an artificial structural weakening zone, the degree of rock mass damage to the roadway under weakening zone protection remains unclear. This study employed principles of elasticity and UDEC (Universal Distinct Element Code) to explore the seismic attenuation and load reduction capabilities of the weakening zone. The results indicate that the absorbing ability of the weakening zone increases exponentially with its weakening coefficient. Under the same dynamic load disturbance, when the weakening coefficient rises from 0.00 to 0.99, the sidewall displacement from the elastic wave source side changes from 0.400 m to 0.228 m. The total number of cracks in the roadway-surrounding rock, and the ranges of overstressed zones decreased linearly. The critical threshold of the roadway resisting the mining tremor disturbance increased. In particular, when the mining tremor is located directly above the roadway, the initial deformation of the roof is the largest, and the cumulative deformation of the rib is greater than the roof. By creating a weakening zone with a coefficient exceeding 0.95, the roadway remains unaffected by the 20 MPa dynamic loading. The study provides a theoretical basis for controlling coal burst that is triggered by mining tremors. Full article

The coal walls in a caving face with a tall mining height are prone to rib spalling, which leads to the phased cessation of the mining of the working face, causes heavy losses, and endangers the safety of underground workers. In order to prevent serious rib spalling accidents of coal walls in fully mechanized caving faces with a large mining height and to improve the prediction of and ability to control rib spalling, a load-bearing mechanical model of the roof–coal wall–support system was established based on the moment-balance relationship. The expressions for the deformation and stress distribution in a coal wall were calculated. Then, the influences of key factors on the horizontal displacement of the coal wall were investigated. A numerical simulation model of the working face was established, and an orthogonal test design was introduced. On this basis, the influences of four factors: cutting height, breaking position of the main roof, support strength, and sidewall protecting force of the support on the horizontal displacement and volume of a plastic zone of coal wall, were analyzed. Moreover, their order of importance was ranked on the basis of sensitivity. Based on the engineering conditions and production practices in the Cuncaota II Coal Mine, key parameters for controlling and measures for preventing the rib spalling of the coal wall are proposed to guide practical actions. Full article

After coal mining enters the deep, the mining environment changes dramatically, and engineering disasters become increasingly prominent, which are mostly related to rock instability and failure. As traditional support is difficult to meet production needs, it is necessary to improve the support system. Based on the engineering background of the Pinggang mining roadway, this work studies the migration law of overlying strata in deep goaf by theoretical analysis and numerical simulation. The results show that the vertical stress and plastic failure range of the surrounding rock in front of the working face increase with the advance distance and when the working face advances to the first square, reaching the maximum. A stope spatial model considering the influence of horizontal stress is established. Combined with the theory of key strata, the stress transfer characteristics of overlying strata are analyzed. It can be seen that 0~30 m in front of the coal wall of the working face is the influence range of advanced abutment pressure, and the dynamic mining pressure in this range has a great influence. The inclined direction of the working face, 0~20 m away from the coal wall of the roadway, is the influence range of the solid coal abutment pressure. On this basis, the “migration- transfer- control” technical system of surrounding rock in deep stope face is put forward, i.e., the stress transfer of surrounding rock is caused by overlying rock migration, and the large deformation of surrounding rock is controlled by supporting means. Based on the original support scheme of the roadway, three reinforcement schemes are designed for the roof, the sidewalls, and both the roof and sides. The deformation control effect of the reinforcement scheme is far greater than that of the single factor, and the field monitoring effect is good. The research results aim to provide theoretical and technical support for the deformation control of mining roadways in the deep mining process. Full article

Surrounding rock of roadway with a coal–rock interface is a common form in coal mines. In order to determine deformation characteristics and obtain the control principle of roadways with a coal–rock interface, the interface between the roof and coal seam was added to simulate the weak cohesion between the stratum. In this model, the interface shear stiffness was considered to be one of the key factors affecting horizontal inward movement of the roadway sidewalls. The deformation of the roadway with or without coal–rock interface under different burial depths was analyzed. Then, the shear stiffness of the interface element was changed to study the influence of shear stiffness on roadway deformation. At the same time, the characteristics of discontinuous deformation caused by the coal–rock interface at different positions in the roadway were studied. The results show that the roadway sidewall appeared to bulge in the middle and there is no dislocation and a small deformation in the contact position of the roadway sidewall with the roof and the floor when there is no interface between the stratum of the roadway. When there is an interface, the sidewall of the roadway is extruded as a whole, the slip and dislocation between the coal sidewall and the roof were obvious, and the maximum deformation of the sidewall is 1.68 times that of the roadway without an interface. When the shear stiffness of the interface is low, the deformation and the range of the plastic zone of roadway are large, with a large deformation at the upper part of the roadway sidewall, and a small deformation at the lower part of the roadway sidewall. The deformation of sidewall at the interface position decreases gradually with the increase of the interface shear stiffness, approaching the shape without the interface. When the coal–rock interface is at the sidewall of the roadway, the deformation of the rock and coal body at the interface is discontinuous, with slip and dislocation. The greater the proportion of rock height in the roadway sidewall, the greater the rock deformation. On the contrary, the coal deformation increases. It is more reasonable to simulate the deformation of roadways by adding a coal–rock interface, and the results are closer to the actual situation. Full article

The control difficulty of whole coal cavern groups is greatly increased due to the characteristics of soft rock with low strength, large sections, and the mutual influence of crossed cavern groups. The large section gas storage cavern group is taken as the research background. In this paper, the equivalent circle method is used to solve the loose circle of a rectangular roadway, and numerical calculation is used to obtain the deformation and stress distribution laws of the surrounding rock under the excavation conditions of large section whole coal cavern groups (WCCG). The deformation and failure mechanisms of the surrounding rock are revealed under the linkage impact between large section whole coal cavern groups. The stratified reinforcement ring concept of “long cable-bolt-grouting” (LBG) was proposed for the stability control of surrounding rock in the WCCG. On the roof of whole coal cavern groups, the supporting configuration of a high-strength bolt with a high pre-tightening force and the high-strength anchor with a high pre-tightening force were determined. On the two sides and floor of the WCCG, the grouting scheme was determined. These two supporting configurations in both the roof and sidewalls were applied to the large section gas storage cavern group. The results show that the surrounding rock presents asymmetric deformation and failure characteristics due to the large excavation area and complex structure. Tensile failure and mixed tensile-shear failure mainly occur in the shallow part of the surrounding rock, while shear failure mainly occurs in the deep part of the surrounding rock. The roof displacement curves show a symmetric distribution and saddle distribution in the low- and high-negative pressure caverns, respectively. The maximum displacements are on the left and right sides of the cavern roof. The range of the loose rings is 3.34 m and 2.54 m, respectively, on the roof and the two ribs. The stratified reinforcement ring support technology of LBG can effectively reduce the failure depth of surrounding rock, and the surrounding rock is in a stable state. The study can provide a theoretical basis for the layout of large section cavern groups and the stability control of surrounding rock. Full article
