Intravascular ultrasound (IVUS) imaging has become an essential method for diagnosing coronary artery disease. However, traditional mechanically rotational IVUS catheters encounter issues such as mechanical wear and imaging distortions in curved vessels. The ring-annular IVUS array has gained attention because it offers superior imaging performance without the need for mechanical rotational parts, thereby avoiding rotational imaging distortion. An optimized mechanical micromachining process employing precision dicing technology is proposed in this study, with the objective of achieving higher operating frequencies and minimized outer diameters for a 64-element ring-annular array. This method broadens the range of fabrication options and improves the imaging sensitivity of ring-annular IVUS arrays, as well as eliminating imaging distortion in rotational IVUS catheters, particularly in curved vessels. The probe has a 7.5 Fr (2.5 mm) outer diameter, with key fabrication steps including precision dicing, flexible circuit integration, and Parylene C encapsulation. The ring-annular array has a center frequency of 21.51 MHz with 67.87% bandwidth, with a 56 µm axial resolution and a 276 µm lateral resolution. The imaging performance is further validated by in vitro phantom imaging and ex vivo imaging. Full article

Hyperthermia therapy (HT) is used to treat diseases through heating of high temperature usually in conjunction with some other medical therapeutics such as chemotherapy and radiotherapy. In this study, we propose a promising temperature-controlled hyperthermia method that uses high-intensity focused ultrasound (HIFU) for clinical tumor treatment combined with diagnostic ultrasound image guidance and non-invasive temperature monitoring through speed of sound (SOS) imaging. HIFU heating is realized by a ring ultrasound transducer array with 256 elements. In this study, tumors in the human thigh were set as heating targets. The inner structure information of thigh tissue is obtained by B-mode ultrasound imaging. Since the relationship between temperature and SOS in different human tissue is available, the temperature detection is converted to the SOS detection obtained by the full-wave inversion (FWI) method. Simulation results show that our model can achieve expected hyperthermia of constant temperature on tumor target with 0.2 °C maximum temperature fluctuation for 5 h. Through simulation, our proposed thermal therapy model achieves accurate temperature control of ±0.2 °C in human thigh tumors, which verifies the feasibility of the proposed temperature-controlled hyperthermia model. Furthermore, the temperature measurement can share the same ring ultrasound transducer array for HIFU heating and B-mode ultrasound imaging, which provides a guiding significance for clinical application. Full article

The purpose of this study is to quantitatively evaluate the differences in corneal biomechanics after SMILE and FLEx surgery using an acoustic radiation force optical coherence elastography system (ARF-OCE) and to analyze the effect of the corneal cap on the integrity of corneal biomechanical properties. A custom ring array ultrasound transducer is used to excite corneal tissue to produce Lamb waves. Depth-resolved elastic modulus images of the in vivo cornea after refractive surgery were obtained based on the phase velocity of the Lamb wave. After refractive surgery, the average elastic modulus of the corneal flap decreased (71.7 ± 24.6 kPa), while the elastic modulus of the corneal cap increased (219.5 ± 54.9 kPa). The average elastic modulus of residual stromal bed (RSB) was increased after surgery, and the value after FLEx (305.8 ± 48.5 kPa) was significantly higher than that of SMILE (221.3 ± 43.2 kPa). Compared with FLEx, SMILE preserved most of the anterior stroma with less change in corneal biomechanics, which indicated that SMILE has an advantage in preserving the integrity of the corneal biomechanical properties. Therefore, the biomechanical properties of the cornea obtained by the ARF-OCE system may be one of the essential indicators for evaluating the safety of refractive surgery. Full article

Argus II retinal prosthesis is the US Food and Drug Administration (FDA) approved medical device intended to restore sight to a patient’s blind secondary to retinal degeneration (i.e., retinitis pigmentosa). However, Argus II and most reported retinal prostheses require invasive surgery to implant electrodes in the eye. Recent studies have shown that focused ultrasound can be developed into a non-invasive retinal prosthesis technology. Ultrasound energy focused on retinal neurons can trigger the activities of retinal neurons with high spatial-temporal resolution. This paper introduces a novel design and simulation of a ring array transducer that could be used as non-invasive ultrasonic retinal stimulation. The array transducer is designed in the shape of a racing ring with a hemisphere surface that mimics a contact lens to acoustically couple with the eye via the tear film and directs the ultrasound to avoid the high acoustic absorption from the crystalline lens. We will describe the design methods and simulation of the two-dimensional pattern stimulation. Finally, compared with other existing retinal prostheses, we show that the ultrasound ring array is practical and safe and could be potentially used as a non-invasive retinal prosthesis. Full article

A stacked three-phase piezoelectric composites ring array underwater ultrasound transducer was developed in this paper. The circular structure of three-phase piezoelectric composite with a large open angle was improved based on the 1-3 piezoelectric composites. The structure size of the transducer’s sensitive component was designed by using ANSYS simulation software, and the single-ring samples of three-phase piezoelectric composites with different thicknesses were fabricated. Based on the bandwidth broadening theory of multimode coupled vibration, the piezoelectric composite ring-shaped sensitive component was fabricated by the piezoelectric composite curved-surface-forming process. According to the design structure of the transducer, the stacked three-phase piezoelectric composites ring array underwater ultrasound transducer was processed. The experimental results show that the maximum transmission voltage response is 154 dB, the open angle of the horizontal beam reaches 360°, and the bandwidth of −3 dB is 86 kHz. The developed transducers achieved a high frequency, broadband, and large open angle to radiate sound waves. Full article

Ultrasound computed tomography (USCT) systems based on capacitive micromachined ultrasonic transducer (CMUT) arrays have a wide range of application prospects. For this paper, a high-precision image reconstruction method based on the propagation path of ultrasound in breast tissue are designed for the CMUT ring array; that is, time-reversal algorithms and FBP algorithms are respectively used to reconstruct sound speed distribution and acoustic attenuation distribution. The feasibility of this reconstruction method is verified by numerical simulation and breast model experiments. According to reconstruction results, sound speed distribution reconstruction deviation can be reduced by 53.15% through a time-reversal algorithm based on wave propagation theory. The attenuation coefficient distribution reconstruction deviation can be reduced by 61.53% through FBP based on ray propagation theory. The research results in this paper will provide key technological support for a new generation of ultrasound computed tomography systems. Full article

This paper presents a multielement annular ring ultrasound transducer formed by individual high-frequency PMUTs (17.5 MHz in air and 8.7 MHz in liquid) intended for high-precision axial focalization and high-performance ultrasound imaging. The prototype has five independent multielement rings fabricated by a monolithic process over CMOS, allowing for a very compact and robust design. Crosstalk between rings is under 56 dB, which guarantees an efficient beam focusing on a range between 1.4 mm and 67 µm. The presented PMUT-on-CMOS annular array with an overall diameter down to 669 µm achieves an output pressure in liquid of 4.84 kPa/V/mm² at 1.5 mm away from the array when the five channels are excited together, which is the largest reported for PMUTs. Pulse-echo experiments towards high-resolution imaging are demonstrated using the central ring as a receiver. With an equivalent diameter of 149 µm, this central ring provides high receiving sensitivity, 441.6 nV/Pa, higher than that of commercial hydrophones with equivalent size. A 1D ultrasound image using two channels is demonstrated, with maximum received signals of 7 mVpp when a nonintegrated amplifier is used, demonstrating the ultrasound imaging capabilities. Full article

Nonlinear ultrasound has been proven to be a useful nondestructive testing tool for micro-damage inspection of materials and structures operating in harsh environment. When measuring the nonlinear second harmonic wave in a solid specimen in the pulse–echo (PE) testing mode, the stress-free boundary characteristics brings the received second harmonic component close to zero. Therefore, the PE method has never been employed to measure the so-called “nonlinear parameter (β)”, which is used to quantify the degree of micro-damage. When there are stress-free boundaries, a focused beam is known to improve the PE reception of the second harmonic wave, so phased-array (PA) transducers can be used to generate the focused beam. For the practical application of PE nonlinear ultrasonic testing, however, it is necessary to develop a new type of PA transducer that is completely different from conventional ones. In this paper, we propose a new annular PA transducer capable of measuring β with improved second harmonic reception in the PE mode. Basically, the annular PA transducer (APAT) consists of four external ring transmitters and an internal disk receiver at the center. The focused beam properties of the transducers are analyzed using a nonlinear sound beam model which incorporates the effects of beam diffraction, material attenuation, and boundary reflection. The optimal design of the APAT is performed in terms of the maximum second harmonic reception and the total correction close to one, and the results are presented in detail. Full article

Photoacoustic imaging (PAI) is an emerging imaging technique that bridges the gap between pure optical and acoustic techniques to provide images with optical contrast at the acoustic penetration depth. The two key components that have allowed PAI to attain high-resolution images at deeper penetration depths are the photoacoustic signal generator, which is typically implemented as a pulsed laser and the detector to receive the generated acoustic signals. Many types of acoustic sensors have been explored as a detector for the PAI including Fabry–Perot interferometers (FPIs), micro ring resonators (MRRs), piezoelectric transducers, and capacitive micromachined ultrasound transducers (CMUTs). The fabrication technique of CMUTs has given it an edge over the other detectors. First, CMUTs can be easily fabricated into given shapes and sizes to fit the design specifications. Moreover, they can be made into an array to increase the imaging speed and reduce motion artifacts. With a fabrication technique that is similar to complementary metal-oxide-semiconductor (CMOS), CMUTs can be integrated with electronics to reduce the parasitic capacitance and improve the signal to noise ratio. The numerous benefits of CMUTs have enticed researchers to develop it for various PAI purposes such as photoacoustic computed tomography (PACT) and photoacoustic endoscopy applications. For PACT applications, the main areas of research are in designing two-dimensional array, transparent, and multi-frequency CMUTs. Moving from the table top approach to endoscopes, some of the different configurations that are being investigated are phased and ring arrays. In this paper, an overview of the development of CMUTs for PAI is presented. Full article

Currently, breast cancer is one of the most common cancers in women all over the world. A novel 3D breast ultrasound imaging ring system using the linear array transducer is proposed to decrease costs, reduce processing difficulties, and improve patient comfort as compared to modern day breast screening systems. The 1 × 128 Piezoelectric Micromachined Ultrasonic Transducer (PMUT) linear array is placed 90 degrees cross-vertically. The transducer surrounds the mammary gland, which allows for non-contact detection. Once the experimental platform is built, the breast model is placed through the electric rotary table opening and into a water tank that is at a constant temperature of 32 °C. The electric rotary table performs a 360° scan either automatically or mechanically. Pulse echo signals are captured through a circular scanning method at discrete angles. Subsequently, an ultrasonic tomography algorithm is designed, and a horizontal slice imaging is realized. The experimental results indicate that the preliminary detection of mass is realized by using this ring system. Circular scanning imaging is obtained by using a rotatable linear array instead of a cylindrical array, which allows the size and location of the mass to be recognized. The resolution of breast imaging is improved through the adjustment of the angle interval (>0.05°) and multiple slices are gained through different transducer array elements (1 × 128). These results validate the feasibility of the system design as well as the algorithm, and encourage us to implement our concept with a clinical study in the future. Full article
