Solar air heating devices have been employed in a wide range of industrial and home applications for solar energy conversion and recovery. It is a useful technique for increasing the rate of heat transfer by artificially creating repetitive roughness on the absorbing surface in the form of semicircular ribs. A thermo-hydraulic performance analysis for a fully developed turbulent flow through rib-roughened solar air heater (SAH) is presented in this article by employing computational fluid dynamics. Both 2-dimensional geometrical modeling and numerical solutions were performed in the finite volume package ANSYS FLUENT. The renormalization-group (RNG) k-ε turbulence model was used, as it is suitable for low Reynolds number (Re) turbulent flows. A thermo-hydraulic performance analysis of an SAH was carried out for a ranging Re, 3800–18,000 (6 sets); relative roughness pitch (RRP), 5–25 (12 sets); relative roughness height (RRH), 0.03–0.06 (3 sets); and heat flux, 1000 W/m². The numerical analysis revealed that with an RRP of 5 and an RRH of 0.06, the roughened duct produces the highest augmentation in average Nu_r in the order of 2.76 times that of a plain duct at an Re of 18,000. With an RRP = 10 and RRH = 0.06, the roughened duct was found to provide the most optimum thermo-hydraulic performance parameter (THPP). The THPP was determined to have a maximum value of 1.98 when the Re is equal to 15,000. It was found that semi-circular ribs which have a rib pitch = 20 mm and a rib height = 2 mm can be applied in an SAH to enhance heat transfer. Full article

The scientific literature extensively mentions the use of a solar air heater (SAH) by utilizing solar energy for heating purposes. The poor heat-transfer rate of an SAH with a flat plate is caused by developing a laminar sub-layer near the heated base plate. The plate temperatures improve significantly, resulting in losses and a decrease in performance. The passive approach entails the placement of fins/turbulators/pouring material/ribs to the surface where the boundary layer forms to disrupt it. Artificially roughened SAH for gathering and efficiently using solar radiations for thermal purposes is extensively described in the literature. This paper includes a thorough literature overview of the history, basics, roughness evolution, forms of SAH, and recent breakthroughs in thermal performance improvement techniques for SAH compiled by several researchers. This paper uses a comparative evaluation of several roughness geometries and kinds of SAH to uncover thermohydraulic performance factors that may be considered in future research to pick the optimal configuration. Full article

Artificial roughness applied to a Solar Air Heater (SAH) absorber plate is a popular technique for increasing its total thermal efficiency (${\eta }_{t-th}$). In this paper, the influence of geometrical parameters of V-down ribs attached below the corrugated absorbing plate of a SAH on the ${\eta }_{t-th}$ was examined. The impacts of key roughness parameters, including relative pitch $p/e$ (6–12), relative height $e/D$ (0.019–0.043), angles of attack $\alpha$ (30–75°), and Re (1000–20,000), were examined under real weather conditions. The SAH ${\eta }_{t-th}$ roughened by V-down ribs was predicted using an in-house developed conjugate heat-transfer numerical model. The maximum SAH ${\eta }_{t-th}$ was shown to be 78.8% as predicted under the steady-state conditions of Re = 20,000, solar irradiance G = 1000 W/m², p/e = 8, e/D = 0.043, and α = 60. The result was 15.7% greater efficiency compared to the default smooth surface. Under real weather conditions, the ${\eta }_{t-th}$ of the roughened SAH with single- and double-glass covers were 17.7 and 20.1%, respectively, which were higher than those of the smooth SAH. Full article

In this paper, a numerical investigation was performed of an air jet incident that normally occurs on a horizontal heated plane. Analysis of flow physics and entropy generation due to heat and friction is included using a simple easy-to-manufacture, surface roughening element: a circular rib concentric with the air jet. This study shows how varying the locations and dimensions of the rib can deliver a favorable trade-off between entropy generation and flow parameters, such as vortex generation and heat transfer. The performance of the roughness element was tested at three different radii; R/D = 1, 1.5 and 2, where D was the jet hydraulic diameter and R was the radial distance from the geometric center. At each location, the normalized rib height (e/D) was increased from 0.019 to 0.074 based on an increment of (e/D) = 0.019. The jet-to-target distance was H/D = 6 and the jet Reynolds number (Re) ranged from 10,000 to 50,000 Re, which was obtained from the jet hydraulic diameter (D), and the jet exit velocity (U). All results are presented in the form of entropy generation due to friction and heat exchange, as well as the total entropy generated. A detailed comparison of flow physics is presented for all ribs and compared with the baseline case of a smooth surface. The results show that at higher Reynolds numbers, adding a rib of a suitable height reduced the total entropy ($S_t$) by 31% compared to the no rib case. In addition, with ribs of heights 0.019, 0.037 and 0.054, respectively, the entropy generated by friction ($S_f$) was greater than that due to heat exchange ($S_h$) by about 42%, 26% and 4%, respectively. The rib of height e/D = 0.074 produced the minimum S_t at R/D = 1. As for varying R/D, varying rib location and Re values had a noticeable impact on $S_h$, $S_f$ and ($S_t$). Placing the rib at R/D = 1 gave the highest total entropy generation ($S_t$) followed by R/D = 1.5 for all Re. Finally, the Bejan number increased as both rib height and rib location increased. Full article

In the near future, when designing and using Double Wall Airfoils, which will be manufactured by 3D printers, the positional relationship between the impingement cooling nozzle and the heat transfer enhancement ribs on the target plate naturally becomes more accurate. Taking these circumstances into account, an experimental study was conducted to enhance the heat transfer of the wall jet region of a round impingement jet cooling system. This was done by installing circular ribs or vortex generators (VGs) in the impingement cooling wall jet region. The local heat transfer coefficient was measured using the naphthalene sublimation method, which utilizes the analogy between heat and mass transfer. As a result, it was clarified that, within the ranges of geometries and Reynolds numbers at which the experiments were conducted, it is possible to improve the averaged Nusselt number Nu up to 21% for circular ribs and up to 51% for VGs. Full article

The jet impingement technique is an effective method to achieve a high heat transfer rate and is widely used in industry. Enhancing the heat transfer rate even minimally will improve the performance of many engineering systems and applications. In this numerical study, the convective heat transfer process between orthogonal air jet impingement on a smooth, horizontal surface and a roughened uniformly heated flat plate is studied. The roughness element takes the form of a circular rib of square cross-section positioned at different radii around the stagnation point. At each location, the effect of the roughness element on heat transfer rate was simulated for six different heights and the optimum rib location and rib dimension determined. The average Nusselt number has been evaluated within and beyond the stagnation region to better quantify the heat transfer advantages of ribbed surfaces over smooth surfaces. The results showed both flow and heat transfer features vary significantly with rib dimension and location on the heated surface. This variation in the streamwise direction included both augmentation and decrease in heat transfer rate when compared to the baseline no-rib case. The enhancement in normalized averaged Nusselt number obtained by placing the rib at the most optimum radial location R/D = 2 was 15.6% compared to the baseline case. It was also found that the maximum average Nusselt number for each location was achieved when the rib height was close to the corresponding boundary layer thickness of the smooth surface at the same rib position. Full article
