The acquisition of electroencephalography (EEG) concurrently with functional magnetic resonance imaging (fMRI) requires a careful consideration of the health hazards resulting from interactions between the scanner’s electromagnetic fields and EEG recording equipment. The primary safety concern is excessive RF-induced heating of the tissue in the vicinity of electrodes. We have previously demonstrated that concurrent intracranial EEG (icEEG) and fMRI data acquisitions (icEEG-fMRI) can be performed with acceptable risk in specific conditions using a head RF transmit coil. Here, we estimate the potential additional heating associated with the addition of scalp EEG electrodes using a body transmit RF coil. In this study, electrodes were placed in clinically realistic positions on a phantom in two configurations: (1) icEEG electrodes only, and (2) following the addition of subdermal scalp electrodes. Heating was measured during MRI scans using a body transmit coil with a high specific absorption rate (SAR), TSE (turbo spin echo), and low SAR gradient-echo EPI (echo-planar imaging) sequences. During the application of the high-SAR sequence, the maximum temperature change for the intracranial electrodes was +2.8 °C. The addition of the subdural scalp EEG electrodes resulted in a maximum temperature change for the intracranial electrodes of 2.1 °C and +0.6 °C across the scalp electrodes. For the low-SAR sequence, the maximum temperature increase across all intracranial and scalp electrodes was +0.7 °C; in this condition, the temperature increases around the intracranial electrodes were below the detection level. Therefore, in the experimental conditions (MRI scanner, electrode, and wire configurations) used at our centre for icEEG-fMRI, adding six scalp EEG electrodes did not result in significant additional localised RF-induced heating compared to the model using icEEG electrodes only. Full article

Thermal Magnetic Resonance (ThermalMR) integrates Magnetic Resonance Imaging (MRI) diagnostics and targeted radio-frequency (RF) heating in a single theranostic device. The requirements for MRI (magnetic field) and targeted RF heating (electric field) govern the design of ThermalMR applicators. We hypothesize that helmet RF applicators (HPA) improve the efficacy of ThermalMR of brain tumors versus an annular phased RF array (APA). An HPA was designed using eight broadband self-grounded bow-tie (SGBT) antennae plus two SGBTs placed on top of the head. An APA of 10 equally spaced SGBTs was used as a reference. Electromagnetic field (EMF) simulations were performed for a test object (phantom) and a human head model. For a clinical scenario, the head model was modified with a tumor volume obtained from a patient with glioblastoma multiforme. To assess performance, we introduced multi-target evaluation (MTE) to ensure whole-brain slice accessibility. We implemented time multiplexed vector field shaping to optimize RF excitation. Our EMF and temperature simulations demonstrate that the HPA improves performance criteria critical to MRI and enhances targeted RF and temperature focusing versus the APA. Our findings are a foundation for the experimental implementation and application of a HPA en route to ThermalMR of brain tumors. Full article

This paper describes the principles behind the radio-frequency (RF) sensing of bacterial biofilms in pipes and heat exchangers in a dairy processing plant using an electromagnetic simulation. Biofilm formation in dairy processing plants is a common issue where the absence of timely detection and subsequent cleaning can cause serious illness. Biofilms are known for causing health issues and cleaning requires a large volume of water and harsh chemicals. In this work, milk transportation pipes are considered circular waveguides, and pasteurizers/heat exchangers are considered resonant cavities. Simulations were carried out using the CST studio suite high-frequency solver to determine the effectiveness of the real-time RF sensing. The respective dielectric constants and loss tangents were applied to milk and biofilm. In our simulation, it was observed that a 1 µm thick layer of biofilm in a milk-filled pipe shifted the reflection coefficient of a 10.16 cm diameter stainless steel circular waveguide from 0.229 GHz to 0.19 GHz. Further sensitivity analysis revealed a shift in frequency from 0.8 GHz to 1.2 GHz for a film thickness of 5 µm to 10 µm with the highest wave reflection (S11) peak of ≈−120 dB for a 6 µm thick biofilm. A dielectric patch antenna to launch the waves into the waveguide through a dielectric window was also designed and simulated. Simulation using the antenna demonstrated a similar S11 response, where a shift in reflection coefficient from 0.229 GHz to 0.19 GHz was observed for a 1 µm thick biofilm. For the case of the resonant cavity, the same antenna approach was used to excite the modes in a 0.751 m × 0.321 m × 170 m rectangular cavity with heat exchange fins and filled with milk and biofilm. The simulated resonance frequency shifted from 1.52 GHz to 1.54 GHz, for a film thickness varying from 1 µm to 10 µm. This result demonstrated the sensitivity of the microwave detection method. Overall, these results suggest that microwave sensing has promise in the rapid, non-invasive, and real-time detection of biofilm formation in dairy processing plants. Full article

We report a novel, miniaturized gas sensor configuration with ppbv (parts-per-billion by volume) sensitivity, where detection of the gas sample concentration is realized inside a Nd:YVO₄/YVO₄/Air-Gap structure (2 × 2 × 14 mm³) of the double-beam, monolithic diode-pumped solid-state laser (DPSSL) resonator operating at 1064 nm. Both generated probe and reference beams are passed through an ultra-compact sensing volume (4 μL) of the air-gap section filled with gas molecules. Simultaneously, an auxiliary laser beam is targeted on the absorption line of a measured gas sample and focused on a 1064 nm probe beam only. Due to the absorption effect, excited gas molecules are heated locally, resulting in a negligible change in a gas refractive index (RI), which is inherent to the photothermal effect (PT). Hence, the PT-induced variations of the gas RI inside the laser resonator are modulating the optical path-length of the probe beam, which resulted in a significant optical frequency shift of the probe beam against the reference one. The optical frequency changes were measured by applying the heterodyne detection technique, where both 1064 nm beams were coupled onto the near-infrared (near-IR) high-speed photodiode (PD), resulting in a beat note signal readout down-converted into the radio-frequency (RF) domain. The RF mixer was used to shift the beat note in frequency accordingly to the frequency modulation (FM) demodulator range. The demodulator converts the beat note frequency changes into a proportional voltage signal. To provide better gas sensor properties, a typical wavelength modulation spectroscopy (WMS) technique was additionally used. The solid-state laser intra-cavity photothermal sensor (SLIPS) is a unique approach to gas spectroscopy, which provides tens of ppbv sensitivity, more than 5000 signal-to-noise (SNR) ratio, baseline-free measurements, miniature, versatile and non-complex sensor setup based on inexpensive DPSSL technology. The SLIPS has no limitation in terms of the excitation wavelength because only one near-IR detector for signal retrieval is needed. Full article

Glioblastoma multiforme (GBM) is the most lethal and common brain tumor. Combining hyperthermia with chemotherapy and/or radiotherapy improves the survival of GBM patients. Thermal magnetic resonance (ThermalMR) is a hyperthermia variant that exploits radio frequency (RF)-induced heating to examine the role of temperature in biological systems and disease. The RF signals’ power and phase need to be supervised to manage the formation of the energy focal point, accurate thermal dose control, and safety. Patient position during treatment also needs to be monitored to ensure the efficacy of the treatment and avoid damages to healthy tissue. This work reports on a multi-channel RF signal supervision module that is capable of monitoring and regulating RF signals and detecting patient motion. System characterization was performed for a broad range of frequencies. Monte-Carlo simulations were performed to examine the impact of power and phase errors on hyperthermia performance. The supervision module’s utility was demonstrated in characterizing RF power amplifiers and being a key part of a feedback control loop regulating RF signals in heating experiments. Electromagnetic field simulations were conducted to calculate the impact of patient displacement during treatment. The supervision module was experimentally tested for detecting patient motion to a submillimeter level. To conclude, this work presents a cost-effective RF supervision module that is a key component for a hyperthermia hardware system and forms a technological basis for future ThermalMR applications. Full article

As a result of their IC compatibility, high acoustic velocity, and high thermal conductivity, aluminum nitride (AlN) resonators have been studied extensively over the past two decades, and widely implemented for radio frequency (RF) and sensing applications. However, the temperature coefficient of frequency (TCF) of AlN is −25 ppm/°C, which is high and limits its RF and sensing application. In contrast, the TCF of heavily doped silicon is significantly lower than the TCF of AlN. As a result, this study uses an AlN contour mode ring type resonator with heavily doped silicon as its bottom electrode in order to reduce the TCF of an AlN resonator. A simple microfabrication process based on Silicon-on-Insulator (SOI) is presented. A thickness ratio of 20:1 was chosen for the silicon bottom electrode to the AlN layer in order to make the TCF of the resonator mainly dependent upon heavily doped silicon. A cryogenic cooling test down to 77 K and heating test up to 400 K showed that the resonant frequency of the AlN resonator changed linearly with temperature change; the TCF was shown to be −9.1 ppm/°C. The temperature hysteresis characteristic of the resonator was also measured, and the AlN resonator showed excellent temperature stability. The quality factor versus temperature characteristic was also studied between 77 K and 400 K. It was found that lower temperature resulted in a higher quality factor, and the quality factor increased by 56.43%, from 1291.4 at 300 K to 2020.2 at 77 K. Full article

In-stent restenosis concerning the coronary artery refers to the blood clotting-caused re-narrowing of the blocked section of the artery, which is opened using a stent. The failure rate for stents is in the range of 10% to 15%, where they do not remain open, thereby leading to about 40% of the patients with stent implantations requiring repeat procedure within one year, despite increased risk factors and the administration of expensive medicines. Hence, today stent restenosis is a significant cause of deaths globally. Monitoring and treatment matter a lot when it comes to early diagnosis and treatment. A review of the present stent monitoring technology as well as the practical treatment for addressing stent restenosis was conducted. The problems and challenges associated with current stent monitoring technology were illustrated, along with its typical applications. Brief suggestions were given and the progress of stent implants was discussed. It was revealed that prime requisites are needed to achieve good quality implanted stent devices in terms of their size, reliability, etc. This review would positively prompt researchers to augment their efforts towards the expansion of healthcare systems. Lastly, the challenges and concerns associated with nurturing a healthcare system were deliberated with meaningful evaluations. Full article

Thermal Magnetic Resonance (ThermalMR) leverages radio frequency (RF)-induced heating to examine the role of temperature in biological systems and disease. To advance RF heating with multi-channel RF antenna arrays and overcome the shortcomings of current RF signal sources, this work reports on a 32-channel modular signal generator (SG_PLL). The SG_PLL was designed around phase-locked loop (PLL) chips and a field-programmable gate array chip. To examine the system properties, switching/settling times, accuracy of RF power level and phase shifting were characterized. Electric field manipulation was successfully demonstrated in deionized water. RF heating was conducted in a phantom setup using self-grounded bow-tie RF antennae driven by the SG_PLL. Commercial signal generators limited to a lower number of RF channels were used for comparison. RF heating was evaluated with numerical temperature simulations and experimentally validated with MR thermometry. Numerical temperature simulations and heating experiments controlled by the SG_PLL revealed the same RF interference patterns. Upon RF heating similar temperature changes across the phantom were observed for the SG_PLL and for the commercial devices. To conclude, this work presents the first 32-channel modular signal source for RF heating. The large number of coherent RF channels, wide frequency range and accurate phase shift provided by the SG_PLL form a technological basis for ThermalMR controlled hyperthermia anti-cancer treatment. Full article

A reactive high-power impulse magnetron sputtering (r-HiPIMS) and a reactive high-power impulse magnetron sputtering combined with electron cyclotron wave resonance plasma source (r-HiPIMS + ECWR) were used for the deposition of p-type CuFe_xO_y thin films on glass with SnO₂F conductive layer (FTO). The aim of this work was to deposit CuFe_xO_y films with different atomic ratio of Cu and Fe atoms contained in the films by these two reactive sputtering methods and find deposition conditions that lead to growth of films with maximum amount of delafossite phase CuFeO₂. Deposited copper iron oxide films were subjected to photoelectrochemical measurement in cathodic region in order to test the possibility of application of these films as photocathodes in solar hydrogen production. The time stability of the deposited films during photoelectrochemical measurement was evaluated. In the system r-HiPIMS + ECWR, an additional plasma source based on special modification of inductively coupled plasma, which works with an electron cyclotron wave resonance ECWR, was used for further enhancement of plasma density n_e and electron temperature T_e at the substrate during the reactive sputtering deposition process. A radio frequency (RF) planar probe was used for the determination of time evolution of ion flux density i_ionflux at the position of the substrate during the discharge pulses. Special modification of this probe to fast sweep the probe system made it possible to determine the time evolution of the tail electron temperature T_e at energies around floating potential V_fl and the time evolution of ion concentration n_i. This plasma diagnostics was done at particular deposition conditions in pure r-HiPIMS plasma and in r-HiPIMS with additional ECWR plasma. Generally, it was found that the obtained ion flux density i_ionflux and the tail electron temperature T_e were systematically higher in case of r-HiPIMS + ECWR plasma than in pure r-HiPIMS during the active part of discharge pulses. Furthermore, in case of hybrid discharge plasma excitation, r-HiPIMS + ECWR plasma has also constant plasma density all the time between active discharge pulses n_i ≈ 7 × 10¹⁶ m⁻³ and electron temperature T_e ≈ 4 eV, on the contrary in pure r-HiPIMS n_i and T_e were negligible during the “OFF” time between active discharge pulses. CuFe_xO_y thin films with different atomic ration of Cu/Fe were deposited at different conditions and various crystal structures were achieved after annealing in air, in argon and in vacuum. Photocurrents in cathodic region for different achieved crystal structures were observed by chopped light linear voltammetry and material stability by chronoamperometry under simulated solar light and X-ray diffraction (XRD). Optimization of depositions conditions results in the desired Cu/Fe ratio in deposited films. Optimized r-HiPIMS and r-HiPIMS + ECWR plasma deposition at 500 °C together with post deposition heat treatment at 650 °C in vacuum is essential for the formation of stable and photoactive CuFeO₂ phase. Full article

We propose two approaches—hot-embossing and dielectric-heating nanoimprinting methods—for low-cost and rapid fabrication of periodic nanostructures. Each nanofabrication process for the imprinted plastic nanostructures is completed within several seconds without the use of release agents and epoxy. Low-cost, large-area, and highly sensitive aluminum nanostructures on A4 size plastic films are fabricated by evaporating aluminum film on hot-embossing nanostructures. The narrowest bandwidth of the Fano resonance is only 2.7 nm in the visible light region. The periodic aluminum nanostructure achieves a figure of merit of 150, and an intensity sensitivity of 29,345%/RIU (refractive index unit). The rapid fabrication is also achieved by using radio-frequency (RF) sensitive plastic films and a commercial RF welding machine. The dielectric-heating, using RF power, takes advantage of the rapid heating/cooling process and lower electric power consumption. The fabricated capped aluminum nanoslit array has a 5 nm Fano linewidth and 490.46 nm/RIU wavelength sensitivity. The biosensing capabilities of the metallic nanostructures are further verified by measuring antigen–antibody interactions using bovine serum albumin (BSA) and anti-BSA. These rapid and high-throughput fabrication methods can benefit low-cost, highly sensitive biosensors and other sensing applications. Full article
