Search Results (72)

This article presents a Synthetic-Aperture Distributed Phased Array (SADPA) framework to address emitter localization challenges in dynamic environments. Building on Distributed Synthetic-Aperture Radar (DSAR) principles, SADPA integrates distributed phased arrays with motion-induced phase compensation, enabling coherent aperture synthesis beyond physical array limits. By analytically modeling and compensating nonlinear phase variations caused by platform motion, we resolve critical barriers to signal integration while extending synthetic apertures. An improved MUSIC algorithm jointly estimates emitter positions and phase distortions, overcoming parameter coupling inherent in moving systems. To quantify fundamental performance limits, the Cramer–Rao bound (CRB) is derived as a theoretical benchmark. Numerical simulations demonstrate the SADPA framework’s superior performance in multi-source resolution and positioning accuracy; it achieves 0.012 m resolution at 10 GHz for emitters spaced 0.01 m apart. The system maintains consistent coherent gain exceeding 30 dB across both the 1.5 GHz communication and 10 GHz radar bands. Monte Carlo simulations further reveal that the MUSIC-DPD algorithm within the SADPA framework attains minimum positioning error (RMSE), with experimental results closely approaching the theoretical CRB. Full article

Emitter localization offers significant advantages such as high concealment, long detection range, and low cost, making it indispensable in target positioning. The utilization of low earth orbit satellite formation with AOA (Angle of Arrival) and TDOA (Time Difference of Arrival) measurements is a key technology for achieving emitter localization. To address the issues of requiring numerous cooperative platforms and the poor accuracy of single-epoch solutions with single-parameter closed-form algorithms, this paper proposes a multi-parameter multi-epoch positioning method based on a three-satellite formation. Simulation data are used to analyze the positioning accuracy under various epochs and different TDOA and AOA noise conditions. The experimental results demonstrate that, compared to the traditional single-parameter single-epoch localization method, utilizing a three-satellite formation with combined AOA and TDOA parameters, along with a multi-epoch solution approach, significantly improves localization accuracy to within an order of ten meters. This method enhances robustness and provides a viable strategy for addressing localization challenges caused by underdetermined systems of equations. Additionally, the results verify that an accumulated almanac element duration of 20 s ensures high positioning accuracy while maintaining a low computational cost. The combined multi-parameter multi-epoch method shows substantial advantages in improving both accuracy and robustness, providing valuable insights for future satellite-based emitter localization technologies. Full article

Radar emitter signal deinterleaving based on pulse description words (PDWs) is a challenging task in the field of electronic warfare because of the parameter sparsity and uncertainty of PDWs. In this paper, a modulation-hypothesis-augmented Transformer model is proposed to identify emitters from a single PDW with an end-to-end manner. Firstly, the pulse features are enriched by the modulation hypothesis mechanism to generate I/Q complex signals from PDWs. Secondly, a multiple-parameter embedding method is proposed to expand the signal discriminative features and to enhance the identification capability of emitters. Moreover, a novel Transformer deep learning model, named PulseFormer and composed of spectral convolution, multi-layer perceptron, and self-attention based basic blocks, is proposed for discriminative feature extraction, emitter identification, and signal deinterleaving. Experimental results on synthesized PDW dataset show that the proposed method performs better on emitter signal deinterleaving in complex environments without relying on the pulse repetition interval (PRI). Compared with other deep learning methods, the PulseFormer performs better in noisy environments. Full article

Radar radiation source recognition is critical for the reliable operation of radar communication systems. However, in increasingly complex electromagnetic environments, traditional identification methods face significant limitations. These methods often struggle with high noise levels and diverse modulation types, making it difficult to maintain accuracy, especially when the Signal-to-Noise Ratio (SNR) is low or the available training data are limited. These difficulties are further intensified by the necessity to generalize in environments characterized by a substantial quantity of noisy, low-quality signal samples while being constrained by a limited number of desirable high-quality training samples. To more effectively address these issues, this paper proposes a novel approach utilizing Model-Agnostic Meta-Learning (MAML) to enhance model adaptability in few-shot learning scenarios, allowing the model to quickly learn with limited data and optimize parameters effectively. Furthermore, a multimodal fusion neural network, DCFANet, is designed, incorporating residual blocks, squeeze and excitation blocks, and a multi-scale CNN, to fuse I/Q waveform data and time–frequency image data for more comprehensive feature extraction. Our model enables more robust signal recognition, even when the signal quality is severely degraded by noise or when only a few examples of a signal type are available. Testing on 13 intra-pulse modulated signals in an Additive White Gaussian Noise (AWGN) environment across SNRs ranging from −20 to 10 dB demonstrated the approach’s effectiveness. Particularly, under a $5-way5-shot$ setting, the model achieves high classification accuracy even at −10dB SNR. Our research underscores the model’s ability to address the key challenges of radar emitter signal recognition in low-SNR and data-scarce conditions, demonstrating its strong adaptability and effectiveness in complex, real-world electromagnetic environments. Full article

Specific emitter identification is a challenge in the field of radar signal processing. Its aims to extract individual fingerprint features of the signal. However, early works are all designed using either signal or time–frequency image and heavily rely on the calculation of hand-crafted features or complex interactions in high-dimensional feature space. This paper introduces the time–frequency multimodal feature fusion network, a novel architecture based on multimodal feature interaction. Specifically, we designed a time–frequency signal feature encoding module, a wvd image feature encoding module, and a multimodal feature fusion module. Additionally, we propose a feature point filtering mechanism named FMM for signal embedding. Our algorithm demonstrates high performance in comparison with the state-of-the-art mainstream identification methods. The results indicate that our algorithm outperforms others, achieving the highest accuracy, precision, recall, and F1-score, surpassing the second-best by 9.3%, 8.2%, 9.2%, and 9%. Notably, the visual results show that the proposed method aligns with the signal generation mechanism, effectively capturing the distinctive fingerprint features of radar data. This paper establishes a foundational architecture for the subsequent multimodal research in SEI tasks. Full article

Accurately classifying the intra-pulse modulations of radar emitter signals is important for radar systems and can provide necessary information for relevant military command strategy and decision making. As strong additional white Gaussian noise (AWGN) leads to a lower signal-to-noise ratio (SNR) of received signals, which results in a poor classification accuracy on the classification models based on deep neural networks (DNNs), in this paper, we propose an effective denoising method based on a denoising diffusion probabilistic model (DDPM) for increasing the quality of signals. Trained with denoised signals, classification models can classify samples denoised by our method with better accuracy. The experiments based on three DNN classification models using different modal input, with undenoised data, data denoised by the convolutional denoising auto-encoder (CDAE), and our method’s denoised data, are conducted with three different conditions. The extensive experimental results indicate that our proposed method could denoise samples with lower values of the SNR, and that it is more effective for increasing the accuracy of DNN classification models for radar emitter signal intra-pulse modulations, where the average accuracy is increased from around 3 to 22 percentage points based on three different conditions. Full article

Falling within the safe bands for human eyes, 1550 nm semiconductor lasers have a wide range of applications in the fields of LIDAR, fast-ranging long-distance optical communication, and gas sensing. The 1550 nm human eye-safe high-power tunnel junction quantum well laser developed in this paper uses three quantum well structures connected by two tunnel junctions as the active region; photolithography and etching were performed to form two trenches perpendicular to the direction of the epitaxial layer growth with a depth exceeding the tunnel junction, and the trenches were finally filled with oxides to reduce the extension current. Finally, a 1550 nm InGaAlAs quantum well laser with a pulsed peak power of 31 W at 30 A (10 KHz, 100 ns) was realized for a single-emitter laser device with an injection strip width of 190 μm, a ridge width of 300 μm, and a cavity length of 2 mm, with a final slope efficiency of 1.03 W/A, and with a horizontal divergence angle of about 13° and a vertical divergence angle of no more than 30°. The device has good slope efficiency, and this 100 ns pulse width can be effectively applied in the fields of fog-transparent imaging sensors and fast headroom ranging radar areas. Full article

Deep learning has brought great development to radar emitter identification technology. In addition, specific emitter identification (SEI), as a branch of radar emitter identification, has also benefited from it. However, the complexity of most deep learning algorithms makes it difficult to adapt to the requirements of the low power consumption and high-performance processing of SEI on embedded devices, so this article proposes solutions from the aspects of software and hardware. From the software side, we design a Transformer variant network, lightweight convolutional Transformer (LW-CT) that supports parameter sharing. Then, we cascade convolutional neural networks (CNNs) and the LW-CT to construct a one-dimensional-CNN-Transformer(1D-CNN-Transformer) lightweight neural network model that can capture the long-range dependencies of radar emitter signals and extract signal spatial domain features meanwhile. In terms of hardware, we design a low-power neural network accelerator based on an FPGA to complete the real-time recognition of radar emitter signals. The accelerator not only designs high-efficiency computing engines for the network, but also devises a reconfigurable buffer called “Ping-pong CBUF” and two-level pipeline architecture for the convolution layer for alleviating the bottleneck caused by the off-chip storage access bandwidth. Experimental results show that the algorithm can achieve a high recognition performance of SEI with a low calculation overhead. In addition, the hardware acceleration platform not only perfectly meets the requirements of the radar emitter recognition system for low power consumption and high-performance processing, but also outperforms the accelerators in other papers in terms of the energy efficiency ratio of Transformer layer processing. Full article

Efficient and effective radar emitter recognition is critical for electronic support measurement (ESM) systems. However, in complex electromagnetic environments, intercepted pulse trains generally contain substantial data noise, including spurious and missing pulses. Currently, radar emitter recognition methods utilizing traditional artificial neural networks (ANNs) like CNNs and RNNs are susceptible to data noise and require intensive computations, posing challenges to meeting the performance demands of modern ESM systems. Spiking neural networks (SNNs) exhibit stronger representational capabilities compared to traditional ANNs due to the temporal dynamics of spiking neurons and richer information encoded in precise spike timing. Furthermore, SNNs achieve higher computational efficiency by performing event-driven sparse addition calculations. In this paper, a lightweight spiking neural network is proposed by combining direct coding, leaky integrate-and-fire (LIF) neurons, and surrogate gradients to recognize radar emitters. Additionally, an improved SNN for radar emitter recognition is proposed, leveraging the local timing structure of pulses to enhance adaptability to data noise. Simulation results demonstrate the superior performance of the proposed method over existing methods. Full article

To address the issue associated with poor accuracy rates for specific emitter identification (SEI) under low signal-to-noise ratio (SNR) conditions, where the single-dimension radar signal characteristics are severely affected by noise, we propose an attention-enhanced dual-branch residual network structure based on the adaptive large-margin Softmax (ALS). Initially, we designed a dual-branch network structure to extract features from one-dimensional intermediate frequency data and two-dimensional time–frequency images, respectively. By assigning different attention weights according to their importance, these features are fused into an enhanced joint feature for further training. This approach enables the model to extract distinctive features across multiple dimensions and achieve good recognition performance even when the signal is affected by noise. In addition, we have introduced L-Softmax to replace the original Softmax and propose the ALS. This approach adaptively calculates the classification margin decision parameter based on the angle between samples and the classification boundary and adjusts the margin values of the sample classification boundaries; it reduces the intra-class distance for the same class while increasing the inter-class distance between different classes without the need for cumbersome experiments to determine the optimal value of decision parameters. Our experimental findings revealed that, in comparison to alternative methods, our proposed approach markedly enhances the model’s capability to extract features from signals and classify them in low-SNR environments, thereby effectively diminishing the influence of noise. Notably, it achieves the highest recognition rate across a range of low-SNR conditions, registering an average increase in recognition rate of 4.8%. Full article

Radar emitter signal sorting (RESS) is a crucial process in contemporary electronic battlefield situation awareness. Separating pulses belonging to the same radar emitter from interleaved radar pulse sequences with a lack of prior information, high density, strong overlap, and wide parameter distribution has attracted increasing attention. In order to improve the accuracy of RESS under scenarios with limited labeled samples, this paper proposes an RESS model called TR-RAGCN-AFF-RESS. This model transforms the RESS problem into a pulse-by-pulse classification task. Firstly, a novel weighted adjacency matrix construction method was proposed to characterize the structural relationships between pulse attribute parameters more accurately. Building upon this foundation, two networks were developed: a Transformer(TR)-based interleaved pulse sequence temporal feature extraction network and a residual attention graph convolutional network (RAGCN) for extracting the structural relationship features of attribute parameters. Finally, the attention feature fusion (AFF) algorithm was introduced to fully integrate the temporal features and attribute parameter structure relationship features, enhancing the richness of feature representation for the original pulses and achieving more accurate sorting results. Compared to existing deep learning-based RESS algorithms, this method does not require many labeled samples for training, making it better suited for scenarios with limited labeled sample availability. Experimental results and analysis confirm that even with only 10% of the training samples, this method achieves a sorting accuracy exceeding 93.91%, demonstrating high robustness against measurement errors, lost pulses, and spurious pulses in non-ideal conditions. Full article

Radar specific emitter identification (SEI) involves extracting distinct fingerprints from radar signals to precisely attribute them to corresponding radar transmitters. In view of the limited characterization of fingerprint information by single-domain features, this paper proposes the utilization of multi-domain mixed kernel canonical correlation analysis for radar SEI. Initially, leveraging the complementarity across diverse feature domains, fingerprint features are extracted from four distinct domains including: envelope feature, spectrum feature, short-time Fourier transform and ambiguity function. Subsequently, kernel canonical correlation analysis is employed to amalgamate the correlation characteristics inherent in multi-domain data. Considering the insufficient of a single kernel function with only interpolation or extrapolation ability, we adopt mixed kernel to improve the projection ability of the kernel function. Experimental results substantiate that the proposed feature fusion approach maximizes the complementarity of multiple features while reducing feature dimensionality. The method achieves an accuracy of up to 95% in experiments, thereby enhancing the efficacy of radar SEI. Full article

Specific emitter identification (SEI) refers to the task of distinguishing similar emitters, especially those of the same type and transmission parameters, which is one of the most critical tasks of electronic warfare. However, SEI is still a challenging task when a feature has low physical representation. Feature representation largely determines the recognition results. Therefore, this article expects to move toward robust feature representation for SEI. Efficient multimodal strategies have great potential for applications using multimodal data and can further improve the performance of SEI. In this research, we introduce a multimodal emitter identification method that explores the application of multimodal data, time-series radar signals, and feature vector data to an enhanced transformer, which employs a conformer block to embed the raw data and integrates an efficient multimodal feature representation module. Moreover, we employ self-knowledge distillation to mitigate overconfident predictions and reduce intra-class variations. Our study reveals that multimodal data provide sufficient information for specific emitter identification. Simultaneously, we propose the CV-CutMixOut method to augment the time-domain signal. Extensive experiments on real radar datasets indicate that the proposed method achieves more accurate identification results and higher feature discriminability. Full article

In recent years, radar emitter signal recognition has enjoyed a wide range of applications in electronic support measure systems and communication security. More and more deep learning algorithms have been used to improve the recognition accuracy of radar emitter signals. However, complex deep learning algorithms and data preprocessing operations have a huge demand for computing power, which cannot meet the requirements of low power consumption and high real-time processing scenarios. Therefore, many research works have remained in the experimental stage and cannot be actually implemented. To tackle this problem, this paper proposes a resource reuse computing acceleration platform based on field programmable gate arrays (FPGA), and implements a one-dimensional (1D) convolutional neural network (CNN) and long short-term memory (LSTM) neural network (NN) model for radar emitter signal recognition, directly targeting the intermediate frequency (IF) data of radar emitter signal for classification and recognition. The implementation of the 1D-CNN-LSTM neural network on FPGA is realized by multiplexing the same systolic array to accomplish the parallel acceleration of 1D convolution and matrix vector multiplication operations. We implemented our network on Xilinx XCKU040 to evaluate the effectiveness of our proposed solution. Our experiments show that the system can achieve 7.34 giga operations per second (GOPS) data throughput with only 5.022 W power consumption when the radar emitter signal recognition rate is 96.53%, which greatly improves the energy efficiency ratio and real-time performance of the radar emitter recognition system. Full article

Radar emitter signal intra-pulse modulation recognition is important for modern electronic reconnaissance systems to analyze target radar systems. In the actual environment, the intra-pulse modulations of the sampled radar emitter signals contain not only the known types in the library but also the unknown types. Therefore, the existing recognition methods, which are based on a closed set, cannot recognize the unknown samples. In order to solve this problem, in this paper, we proposed a method for radar emitter signal intra-pulse modulation open set recognition. The proposed method could classify the known modulations and identify the unknown modulation by using an original deep neural network-based recognition model trained on a closed set, estimating the signal-to-noise ratio, and calculating the reconstruction loss by an encoder–decoder model. For a given sample, the original deep neural network-based recognition model will label it as a certain known class temporarily. By estimating the SNR of the sample and calculating the reconstruction loss by inputting the sample to the corresponding encoder–decoder model related to the temporary predicted known class, whether the sample belongs to the predicted temporary known class or the unknown class will be confirmed. Experiments were conducted with five different openness conditions. The experimental results indicate that the proposed method has good performance on radar emitter signal intra-pulse modulation open set recognition. Full article
