Helical twist provides an additional degree of freedom for controlling light in optical waveguides, expanding their applications in sensing. In this paper, we propose a helical broken-circular-symmetry core microstructured optical fiber for refractive index sensing. The proposed fiber consists of pure silica and its noncircular helical core is formed by a broken air ring. By using finite element modeling combined with transformation optics, the modal characteristics of the fiber are investigated in detail. The results show that for the core located at the fiber center, the confinement loss of fundamental core modes increases with twist rate, whereas for a sufficiently large core offset the modes can be well confined owing to the twist-induced light guidance mechanism, showing decreases with rising twist rate in the loss spectra. Moreover, we have found that for large twist rates and core offsets, resonant peaks occur at different twist rates due to the couplings between the fundamental core modes and the highly leaky modes created by the helical structure. The refractive index sensing performance is also studied and the obtained results show that the proposed fiber has great potential in fiber sensing. Full article

In this work a plasmonic sensor with a D-Shaped microstructured optical fiber $\left(\mathrm{MOF}\right)$ is proposed to detect a wide range of analyte refractive index $\left(\mathrm{RI} ;{\mathrm{n}}_{\mathrm{a}}\right)$ by doping the pure silica $\left({\mathrm{SiO}}_2\right)$ core with distinct concentrations of Germanium Dioxide $\left({\mathrm{GeO}}_2\right)$, causing the presentation of high spectral sensitivity. In this case, the fiber is shaped by polishing a coating of ${\mathrm{SiO}}_2$, on the region that will be doped with ${\mathrm{GeO}}_2$, in the polished area, a thin gold $\left(\mathrm{Au}\right)$ layer, which constitutes the plasmonic material, is introduced, followed by the analyte, in a way which the gold layer is deposited between the ${\mathrm{SiO}}_2$. and the analyte. The numerical results obtained in the study shows that the sensor can determine efficiently a range of 0.13 refractive index units $\left(\mathrm{RIU}\right)$, with a limit operation where ${\mathrm{n}}_{\mathrm{a}}$ varies from 1.32 to 1.45. Within this application, the sensor has reached an average wavelength sensitivity $\left(\mathrm{WS}\right)$ of up to $11,650.63 \mathrm{nm}/\mathrm{RIU}$. With this level of sensitivity, the D-Shaped format and wide range of ${\mathrm{n}}_{\mathrm{a}}$ detection, the proposed fiber has great potential for sensing applications in several areas. Full article

Signal transmission over optical fibers in the ultraviolet to near-infrared domains remains very challenging due to their high intrinsic losses. In radiation-rich environments, this is made even more difficult due to the radiation-induced attenuation (RIA) phenomenon. We investigated here how the number of hydroxyl groups (OH) present in multi-mode (MM) pure-silica core (PSC) optical fibers influences the RIA levels and kinetics. For this, we tested three different fiber samples: one “wet”, one “dry” and one with an intermediate “medium” OH content. The RIA of the three samples was measured in the 400–900 nm (~3 eV to ~1.4 eV) spectral range during and after an X-ray irradiation at a dose rate of 6 Gy(SiO₂) s⁻¹ up to a total accumulated dose of 300 kGy(SiO₂). Furthermore, we evaluated the H₂-pre-loading efficiency in the medium OH sample to permanently improve both its intrinsic losses and radiation response in the visible domain. Finally, the spectral decomposition of the various RIA responses allows us to better understand the basic mechanisms related to the point defects causing the excess of optical losses. Particularly, it reveals the relationship between the initial OH groups content and the generation of non-bridging oxygen hole centers (NBOHCs). Moreover, the presence of hydroxyl groups also affects the contribution from other intrinsic defects such as the self-trapped holes (STHs) to the RIA in this spectral domain. Full article

The technical process of the synthesis of a fluorophosphosilicate (FPS) glass core was thoroughly investigated for the first time utilizing a modified chemical vapor deposition (MCVD) all-gas-phase fabrication method. It was discovered that the limiting doping level of the silica glass simultaneously co-doped with phosphorus (P) and fluorine (F) was found to be confined by the formation of POF₃ gas. The dopants content was achieved as high as 4.7 at% of P and 1.1 at% of F in a glass core, respectively. A developed “in-house” manufacturing method makes it possible to fabricate a large mode area (LMA) purely single-mode Er–Yb co-doped optical fibers with a core diameter of 20 μm and with a lasing efficiency comparable to commercially available LMA Er–Yb optical fibers. Full article

We report here the response of a commercial ultra-low loss (ULL) single-mode (SM) pure silica core (PSC) fiber, the Vascade EX1000 fiber from Corning, associated with 0.16 dB/km losses at 1.55 µm to 40 keV X-rays at room temperature. Today, among all fiber types, the PSC or F-doped ones have been demonstrated to be the most tolerant to the radiation induced attenuation (RIA) phenomenon and are usually used to design radiation-hardened data links or fiber-based point or distributed sensors. The here investigated ULL-PSC showed, instead, surprisingly high RIA levels of ~3000 dB/km at 1310 nm and ~2000 dB/km at 1550 nm at a limited dose of 2 kGy(SiO₂), exceeding the RIA measured in the P-doped SM fibers used for dosimetry for doses of ~500 Gy. Moreover, its RIA increased as a function of the dose with a saturation tendency at larger doses and quickly recovered after irradiation. Our study on the silica structure suggests that the very specific manufacturing process of the ULL-PSC fibers applied to reduce their intrinsic attenuation makes them highly vulnerable to radiations even at low doses. From the application point of view, this fiber cannot be used for data transfer or sensing in harsh environments, except as a very efficient radiation detector or beam monitor. Full article

A trench-assisted multicore fiber (TA-MCF) with single-supermode transmission and nearly zero flattened dispersion is proposed herein. By adding a simplified microstructure cladding with only one ring of low-index inclusions on the basis of the multicore fiber, the microstructure cladding and mode-coupling mechanism were jointly employed into the TA-MCF to modulate light transmission. This guarantees that the TA-MCFs had sufficient capability for wideband dispersion management when only pure, germanium-doped, and fluorine-doped silica glass with low index differences were chosen to form the TA-MCF. Analyses also revealed that the TA-MCFs have the merits of shorter cut-off wavelength and flatter-top optical intensity distribution compared with traditional multicore fibers. After the investigation of the structural parameters’ influences on the dispersion of the fundamental supermode, two TA-MCFs with single-supermode transmission and nearly zero flattened dispersion were designed. For the seven-core TA-MCF, the dispersion varying from −0.46 to 1.35 ps/(nm·km) in the wavelength range of 1.50 to 2.04 μm, with bending loss as low as 0.085 dB/km and 35-mm bending radius at 1550 nm was achieved with index difference less than 0.015. The TA-MCFs proposed herein have the advantages of being a quasi-single material, with an all solid scheme and simplified structure. Full article

In this work, we report about our recent results concerning the fabrication of Long Period Grating (LPG) sensors in several optical fibers, through the Electric Arc Discharge (EAD) technique. In particular, the following silica fibers with both different dopants and geometrical structures are considered: standard Ge-doped, photosensitive B/Ge codoped, P-doped, pure-silica core with F-doped cladding, Panda type Polarization-maintaining, and Hollow core Photonic crystal fiber. An adaptive platform was developed and the appropriate “recipe” was identified for each fiber, in terms of both arc discharge parameters and setup arrangement, for manufacturing LPGs with strong and narrow attenuation bands, low insertion losses, and short length. As the fabricated devices have appealing features from the application point of view, the sensitivity characteristics towards changes in different external perturbations (i.e., surrounding refractive index, temperature, and strain) are investigated and compared, highlighting the effects of different fiber composition and structure. Full article

In this paper we report on the engineering of repeatable surface enhanced Raman scattering (SERS) optical fiber sensor devices (optrodes), as realized through nanosphere lithography. The Lab-on-Fiber SERS optrode consists of polystyrene nanospheres in a close-packed arrays configuration covered by a thin film of gold on the optical fiber tip. The SERS surfaces were fabricated by using a nanosphere lithography approach that is already demonstrated as able to produce highly repeatable patterns on the fiber tip. In order to engineer and optimize the SERS probes, we first evaluated and compared the SERS performances in terms of Enhancement Factor (EF) pertaining to different patterns with different nanosphere diameters and gold thicknesses. To this aim, the EF of SERS surfaces with a pitch of 500, 750 and 1000 nm, and gold films of 20, 30 and 40 nm have been retrieved, adopting the SERS signal of a monolayer of biphenyl-4-thiol (BPT) as a reliable benchmark. The analysis allowed us to identify of the most promising SERS platform: for the samples with nanospheres diameter of 500 nm and gold thickness of 30 nm, we measured values of EF of 4 × 10⁵, which is comparable with state-of-the-art SERS EF achievable with highly performing colloidal gold nanoparticles. The reproducibility of the SERS enhancement was thoroughly evaluated. In particular, the SERS intensity revealed intra-sample (i.e., between different spatial regions of a selected substrate) and inter-sample (i.e., between regions of different substrates) repeatability, with a relative standard deviation lower than 9 and 15%, respectively. Finally, in order to determine the most suitable optical fiber probe, in terms of excitation/collection efficiency and Raman background, we selected several commercially available optical fibers and tested them with a BPT solution used as benchmark. A fiber probe with a pure silica core of 200 µm diameter and high numerical aperture (i.e., 0.5) was found to be the most promising fiber platform, providing the best trade-off between high excitation/collection efficiency and low background. This work, thus, poses the basis for realizing reproducible and engineered Lab-on-Fiber SERS optrodes for in-situ trace detection directed toward highly advanced in vivo sensing. Full article

During the past few years, we have studied the granulated silica method as a versatile and cost effective way of fiber preform production and the sol-gel method. Until now, we have used the sol-gel technology together with an iterative re-melting and milling step in order to produce rare earth or transition metal doped granular material for the granulated silica method. Here, we present that the iterative re-melting (laser-assisted) and milling step is no longer needed to reach a high homogeneity. The sol-gel method also offers a high degree of compositional flexibility with respect to dopants; it further facilitates achieving high concentrations, even in cases when several dopants are used. We employed optical active doped sol-gel derived granulate for the fiber core, whereas pure or index-raised granulated silica has been employed for the cladding. Based on the powder-in-tube technique, where silica glass tubes are appropriately filled with these granular materials, fibers has been directly drawn (“fiber rapid prototyping”), or eventually after an additional optional quality enhancing vitrification step. The powder-in-tube technique is also ideally suited for the preparation of microstructured optical fibers. Full article

Effects of radiation on sensing and data transmission components are of greatinterest in many applications including homeland security, nuclear power generation, andmilitary. A new type of microstructured optical fiber (MOF) called the random hole opticalfiber (RHOF) has been recently developed. The RHOFs can be made in many differentforms by varying the core size and the size and extent of porosity in the cladding region.The fibers used in this study possessed an outer diameter of 110 μm and a core ofapproximately 20 μm. The fiber structure contains thousands of air holes surrounding thecore with sizes ranging from less than 100 nm to a few μm. We present the first study ofthe behavior of RHOF under gamma irradiation. We also propose, for the first time to ourknowledge, an ionizing radiation sensor system based on scintillation light from ascintillator phosphor embedded within a holey optical fiber structure. The RHOF radiationresponse was compared to normal single mode and multimode commercial fibers(germanium doped core, pure silica cladding) and to those of radiation resistant fibers (puresilica core with fluorine doped cladding fibers). The comparison was done by measuringradiation-induced absorption (RIA) in all fiber samples at the 1550 nm wavelength window(1545 ± 25 nm). The study was carried out under a high-intensity gamma ray field from a ⁶⁰Co source (with an exposure rate of 4x10⁴ rad/hr) at an Oak Ridge National Laboratory gamma ray irradiation facility. Linear behavior, at dose values less than 10⁶ rad, was observed in all fiber samples except in the pure silica core fluorine doped cladding fiber which showed RIA saturation at 0.01 dB. RHOF samples demonstrated low RIA (0.02 and 0.005 dB) compared to standard germanium doped core pure silica cladding (SMF and MMF) fibers. Results also showed the possibility of post-fabrication treatment to improve the radiation resistance of the RHOF fibers. Full article
