With the growing cost of electrical energy, the necessity of energy-saving implementation in industries based on energy audits has become a major focus area. Energy audit results indicate energy-saving potential in an application and require the physical presence of the auditor’s team for monitoring and analyzing the energy consumption data. The use of Industrial Internet of Things (IIoT) for remote data monitoring and analysis is growing and new industrial applications based on IIoT are being developed and used by various industrial sectors. Possibilities of a mixed method of physical and remote energy audit using IIoT in industrial applications and its advantages as proposed in this research work needs to be explored. Existing hydraulic press machines running with direct online starter (DOL) can be run with variable speed drive (VSD) for energy saving but this requires an extensive energy audit. Key electrical and operational parameters of the hydraulic pump motor were monitored and analyzed remotely using IIoT in this research work by operating the hydraulic press with DOL and VSD motor control methods one by one. The input power factor of the hydraulic pump motor showed an improvement from 0.79 in DOL control to 0.9 in VSD control at different motor loads. The hydraulic pump motor starting current showed a reduction of 84% with VSD control. The hydraulic pump motor’s continuous current was reduced by 40% and 65% during the loading and unloading cycle, respectively, with VSD control. Electrical consumption was reduced by 24% as a result of operating the hydraulic pump motor at 35 Hz with VSD control without impacting the performance of the hydraulic press. These results indicated more efficient control by changing to VSD control in comparison with DOL control. A combination of physical and remote energy audits as performed in this research work using the proposed IIoT framework can be utilized for implementing energy saving in hydraulic presses thus motivating industries to adopt available more energy-efficient technologies at a faster pace. Full article

This paper takes the position control performance of pump-controlled hydraulic presses as the research object. The control methods are designed respectively for the two motion stages of rapid descent and slow descent of hydraulic presses in order to improve the control performance of the system. First of all, the accuracy model of the pump-controlled hydraulic presses position servo system (the pump-controlled hydraulic presses position servo system, which is called PCHPS) and its MATLAB/Simulink simulation platform are established. Based on the theoretical analysis and experimental data, the interference factors affecting the tracking accuracy and positioning accuracy of the PCHPS are analyzed. Then, an adaptive integral robust control (the adaptive integral robust control, which is called AIRC) for PCHPS is designed to reduce the influence of nonlinear factors on the system, and the effectiveness of the controller is verified by simulation. Finally, the position control experiment of PCHPS is designed, and the experimental results show that the AIRC can effectively reduce nonlinear factors such as unknown interference in the slow-down stage of the system. The positioning accuracy is raised to within 0.008 mm, which improves the process level of the hydraulic presses. Full article

Primary control of linear motion by variable speed electric motors driving a hydraulic cylinder via a constant displacement pump is an established and successful concept with a frequent use in industry. One problem arises when low or zero motion speed has to be realized under high pump pressure conditions. Such load scenarios occur frequently in certain pressing processes, e.g., for sintering or veneering. Most pumps have a lower speed limit, below which critical tribological conditions occur which impair lifespan and efficiency. In addition, pump speed control and pump fluctuation suffer from the mixed lubrication conditions in such an operation range. For a circumvention of such low speed pump operation, a digital valve control concept is presented and studied in this paper. Valve control is used in load holding phases with low speed. Pressure is provided by an accumulator which is charged by the pump in short charging cycles at reasonable pump speeds. It is shown that the mean control error during load holding phase lies within the desired band and the fluctuations of the control force are lower than those of the pump control. In addition, the unfavorable pump operation conditions can be avoided via digital control. Full article

This paper proposes an energy-saving system based on a prefill system and a buffer system to improve the energy efficiency and the processing performance of hydraulic presses. Saving energy by integrating such systems into the cooling system of a hydraulic press has not been previously reported. A prefill system, powered by the power unit of the cooling system, is used to supply power simultaneously with the traditional power unit during the pressurization stage, thus reducing the usage of pumps and installed power of the hydraulic press. In contrast to the traditional prefill system, the proposed energy-saving system is controlled by a servo valve to adjust flow according to the load profile. In addition, a buffer system is employed to the cooling system to absorb the hydraulic shock generated at the unloading stage, store those shares of hydraulic energy as a recovery accumulator, and then release this energy to power the prefill system and the hydraulic actuator in the subsequent productive process. Finally, through a series of comparative experiments, it was preliminarily validated that the proposed system could reduce the installed power and pressure shock by up to 22.85% and 41%, respectively, increase energy efficiency by up to 26.71%, and provide the same processing characteristics and properties as the traditional hydraulic press. Full article

The study deals with the energy-saving process of hot open die elongation forging of heavy steel forgings on an 80 MN industrial hydraulic forging press. Three innovative energy-saving power supply solutions useful for industrial hydraulic forging presses were analyzsed. The energy-saving power supply of hydraulic forging presses consists in reducing electricity consumption by the electric motor driving the pumps, reducing the noise emitted by pumps and reducing leaks in hydraulic piston cylinders. The predicted forging force as a function of heavy steel forging heights for various deformation temperatures and strain rates was determined. A simulation model of the 80 MN hydraulic forging press is presented, which is useful for determining the time-varying parameters during the forging process. An energy-saving control for the hydraulic forging press based on the forging process parameters’ prediction has been developed. Real-time model predictive control (MPC) was developed based on multiple inputs multiple outputs (MIMO), and global predictive control (GPC). The GPC has been implemented in the control system of an 80 MN industrial hydraulic forging press. The main advantage of this control system is the repeatability of the forging process and minimization of the size deviation of heavy large steel forgings Full article

Taking the open circuit hydraulic pump-controlled forging press system as the research object, according to the problems of pressure-relief impact of this system, the pressure-relief rules, mathematic models of the energy release rules, and the flow release rules were established, and the pressure-relief performance in different stages of each pressure-relief curve was analyzed. Based on the different requirements of the pressure gradient decrease, the combined pressure-relief curve (CPRC) was proposed to realize variable-pump eccentric magnitude planning. An experimental study on the pressure-relief process with CPRC was carried out. The results show that the pressure fluctuation of the pressure-relief pipe was reduced and the suppression effect of pressure-relief impact was better than that of the single regular pressure-relief curve. When the initial pressures were 10 MPa and 15 MPa, the pressure impact of the pressure-relief tube decreased by 45.45% and 37.5%, respectively, which realized the smooth pressure relief of the main cylinder. Full article
