Search Results (108)

Precise identification of active jamming in complex electromagnetic environments remains critically challenging for cognitive radar systems. Current methods often exhibit limitations in insufficient feature extraction and underutilization of jamming signals, leading to substantial performance degradation, particularly in low jamming-to-noise ratio (JNR) scenarios. To address these challenges, we propose a novel framework based on a multi-domain fusion network, MDFNet, to recognize 12 types of active jamming signals. MDFNet improves the recognition robustness under varying JNR conditions through a two-stage fusion of complementary features from pulse compression time–frequency (PC-TF) and range-Doppler (RD) domain images. Specifically, a novel dual-modal feature fusion (DMFF) module integrates PC-TF and RD features, while a decision fusion strategy leverages their distinctive characteristics. Experiments on typical jamming dataset demonstrate that MDFNet achieves an overall recognition accuracy of 96.05%. Notably, at a JNR of −20 dB, MDFNet outperforms the existing fusion methods by 12.86–18.19%. In summary, our proposed method significantly enhances the jamming recognition capability of cognitive radar systems in complex environments. Full article

Micro-Doppler signatures play a crucial role in capturing target features for the radar classification task, and the time–frequency distribution method is widely used to represent micro-Doppler signatures in many applications including human activities, ground moving target identification, and different types of drones distinguishing. However, most existing studies that utilize radar micro-Doppler spectrograms often require extended observation times to effectively represent the cyclostationarity and periodic modulation of radar signals to achieve promising classification results. In addition, the presence of noise in real-world environments poses challenges by generating weak micro-Doppler features and a low signal-to-noise ratio (SNR), leading to a significant decline in classification accuracy. In this paper, we present a novel one-dimensional (1D) denoising and classification cascaded framework designed for low-resolution radar targets using a micro-Doppler spectrum. This framework provides an effective signal-based solution for feature extraction and recognition from the single-frame micro-Doppler spectrum in a conventional pulsed radar system, which boasts high real-time efficiency and low computation requirements under conditions of low resolution and a short dwell time. Specifically, the proposed framework is implemented using two cascaded subnetworks: Firstly, for radar micro-Doppler spectrum denoising, we propose an improved 1D DnCNN subnetwork to enhance noisy or weak micro-Doppler signatures. Secondly, an AlexNet subnetwork is cascaded for the classification task, and the joint loss is calculated to update the denoising subnetwork and assist with optimal classification performance. We have conducted a comprehensive set of experiments using six types of targets with a ground surveillance radar system to demonstrate the denoising and classification performance of the proposed cascaded framework, which shows significant improvement over separate training of denoising and classification models. Full article

The wind field, a critical atmospheric parameter, significantly influences climate, weather forecasting, aviation safety, and wind energy applications. The precise observation of wind fields is essential for improving weather predictions, studying climate change, ensuring aviation safety, and optimizing wind energy systems. Among the various wind field detection methods, coherent wind lidar technology stands out due to its superior detection range, accuracy, and robustness. However, the high-range resolution required for applications such as aircraft takeoff and landing or wind turbine region monitoring presents unique challenges in wind detection. To address the aforementioned challenges, this study established a modular coherent Doppler wind lidar simulation system. Unlike traditional single-module simulation approaches, this system achieves multi-parameter coupling analysis of laser emission under pulse modulation, atmospheric transmission, and wind speed inversion through integrated hardware-transmission-processing collaborative modeling. Subsequently, by adjusting key parameters of the system model, an in-depth analysis of wind speed inversion within a 1.2 km detection range was conducted, investigating the dual impacts of reducing pulse duration on both range resolution and wind speed measurement accuracy. Furthermore, a Mach–Zehnder modulator module was implemented in the radar hardware section to generate odd–even pulse pairs, while a differential correlation algorithm was introduced in the data processing module to enhance range resolution. Ultimately, wind speed measurements with a 4.5 m range resolution along the laser emission direction were achieved in simulations. Comparative analysis shows that pulse modulation techniques effectively reduce wind speed measurement errors caused by short-pulse methods, offering a reliable framework for practical wind field measurements. Full article

Compared to conventional pulse-limited altimeters (i.e., low-resolution mode, LRM), the synthetic aperture radar (SAR, i.e., high-resolution mode, HRM) altimeter offers superior precision and along-track resolution abilities. However, because the SAR altimeter relies on Doppler shifts caused by the relative movement between radar scattering points and the altimeter antenna, the geophysical parameters obtained by the SAR altimeter are sensitive to the direction of ocean wave movements driven by the wind and waves. Both practice and theory have shown that the wind and wave effects have a greater impact on HRM data than LRM. LRM values of range and significant wave height (SWH) from modern retracking are the best representations there are of these quantities, and this study aims to bring HRM data into line with them. In this study, wind and wave effects in SAR altimeter measurements were analyzed and corrected. The radar altimeter onboard the Sentinel-6 satellite is the first SAR altimeter to operate in an interleaved open burst mode. It has the capability of simultaneous generation of both LRM and HRM data. This study utilizes Sentinel-6 altimetry data and ERA5 re-analysis data to identify the influence of ocean waves. The analysis is based on the altimeter range and SWH differences between the HRM and LRM measurements with respect to different geophysical parameters derived from model data. Results show that both HRM range and SWH measurements are impacted by SWH and wind speed, and the HRM SWH measurements are also significantly impacted by vertical velocity. An upwave/downwave bias between HRM and LRM range is observed. To reduce wave impact on the SAR altimeter measurements, a back-propagation neural network (BPNN) method is proposed to correct the HRM range and SWH measurements. Based on Sentinel-6 measurements and ERA5 re-analysis data, our corrections significantly reduce biases between LRM and HRM range and SWH values. Finally, the accuracies of the sea surface height (SSH) and SWH measurements after correction are assessed using crossover analysis and compared against NDBC buoy data. The standard deviation (STD) of the HRM SSH differences at crossovers has no significant changes before (3.97 cm) and after (3.94 cm) correction. In comparison to the NDBC data, the root mean square error (RMSE) of the corrected HRM SWH data is 0.187 m, which is significantly better than that with no correction (0.265 m). Full article

In this work, we investigate the gridless parameter estimation of pulse–Doppler radar targets using a reduced number of samples under a limited bit budget. We propose a hybrid analog and digital (HAD) acquisition system integrating a tunable analog component, low-resolution quantizers, and a digital filter. Under the framework of task-based quantization, the HAD architecture is designed to optimize target parameter estimation within the constraints of the bit budget. Specifically, a small subset of the received signal samples is observed and the low-rank parameter matrix is recovered using matrix completion techniques. The atomic norm minimization method is applied to reconstruct the complete parameter matrix, enabling gridless estimation of the parameters. Numerical experiments are conducted to validate the effectiveness of the proposed receiver in gridless parameter estimation. Full article

(1) The aliasing of radial velocities from weather radars is a known challenge in meteorology. It may also occur during bird migration if the unambiguous velocity threshold is below the birds’ ground speed. High variability in birds’ radial velocities and high flight speeds lead to multiple aliasing (folding) and challenge meteorological dealiasing approaches. Unfolded radial velocities are essential for calculating flight directions and speed and derived migration traffic rates for aeroecological applications. (2) We study the occurrence of aliasing in measurements of different pulse repetition frequencies (PRF) in C-band weather radars in bird and insect cases and test the efficiency of a dealiasing algorithm widely used in biological weather radar software. We use dual-PRF measurements as a reference to avoid the folding of radial velocities in quantitative and qualitative bird migration outputs. (3) The dealiasing algorithm performed poorly in single-PRF measurements during bird migration, though not in insect and precipitation cases. In contrast, dual-PRF velocities yielded proper flight speeds, flight directions and migration traffic rates. (4) The study unveils severe biases in aeroecological analyses of C-band weather radars from imperfectly dealiased single-PRF radial velocities. Dual-PRF measurements with appropriate dealiasing postprocessing offer a valid alternative to single PRF and should be preferred whenever available. Full article

An intelligent approach is proposed and investigated in this paper for the detection of ultra-low-altitude sea-skimming moving targets for airborne pulse Doppler radar. Without suppressing interferences, the proposed method uses both target and multipath information for detection based on their distinguishable image features and deep learning (DL) techniques. First, the image features of the target, multipath, and sea clutter in the real-measured range-Doppler (RD) map are analyzed, based on which the target and multipath are defined together as the generalized target. Then, based on the composite electromagnetic scattering mechanism of the target and the ocean surface, a scattering-based echo generation model is established and validated to generate sufficient data for DL network training. Finally, the RD features of the generalized target are learned by training the DL-based target detector, such as you-only-look-once version 7 (YOLOv7) and Faster R-CNN. The detection results show the high performance of the proposed method on both simulated and real-measured data without suppressing interferences (e.g., clutter, jamming, and noise). In particular, even if the target is submerged in clutter, the target can still be detected by the proposed method based on the multipath feature. Full article

Different from the standard probability hypothesis density (PHD) and cardinality probability hypothesis density (CPHD) filters, the trajectory PHD (TPHD) and trajectory CPHD (TCPHD) filters employ the sets of trajectories rather than the sets of the targets as the variables for multi-target filtering. The TPHD and TCPHD filters exploit the inherent potential of the standard PHD and CPHD filters to generate the target trajectory estimates from first principles. In this paper, we develop the TPHD and TCPHD filters for pulse Doppler radars (PD-TPHD and PD-TCPHD filters) to improve the multi-target tracking performance in the scenario with clutter. The Doppler radar can obtain the Doppler measurements of targets in addition to the position measurements of targets, and both measurements are integrated into the recursive filtering of PD-TPHD and PD-TCPHD. PD-TPHD and PD-TCPHD can propagate the best augmented Poisson and independent identically distributed multi-trajectory density approximation, respectively, through the Kullback–Leibler divergence minimization operation. Considering the low computational complexity of sequential filtering, Doppler measurements are sequentially applied to the Gaussian mixture implementation. Moreover, we perform the $L$-scan implementations of PD-TPHD and PD-TCPHD. Simulation results demonstrate the effectiveness and robustness of the proposed algorithms in the scenario with clutter. Full article

The velocity/distance trade-off poses a fundamental challenge in pulsed Doppler weather radar systems and is known as the velocity/distance dilemma. Techniques such as multiple-pulse repetition frequency, staggered pulse repetition time (PRT), and pulse phase coding are commonly used to mitigate this issue. The current study evaluates the adaptability/capability of a specific type of low-capture signal called the non-uniform PRT (NPRT) through analyzing the weather target characteristics of typical velocity distributions. The spectral moments estimation (SME) signal-processing algorithm of the NPRT weather echo is designed to calculate the average power, velocity, and spectrum width of the target. A comprehensive error analysis is conducted to ascertain the efficacy of the NPRT processing algorithm under influencing factors. The results demonstrate that the spectral parameters of weather target echo with a velocity of $[-50,50]$ m/s through random-jitter NPRT signals align with radar functionality requirements (RFRs). Notably, the NPRT waveform resolves the inherent conflicts between the maximum unambiguous distance and velocity and elevates the upper limit of the maximal observation velocity. The evaluation results confirm that nonlinear radar signal processing technology can improve a radar’s detection performance and provide a new method for realizing the multifunctional observation of radar in different applications. Full article

Synthetic aperture radar (SAR) inter-pulse parameter agility technology involves dynamically adjusting parameters such as the pulse width, chirp rate, carrier frequency, and pulse repetition interval within a certain range; this effectively increases the complexity and uncertainty of radar waveforms, thereby countering active deceptive interference signals from multiple dimensions. With the development of active deceptive interference technology, single-parameter agility can no longer meet the requirements, making multi-parameter joint agility one of the main research directions. However, inter-pulse carrier frequency agility can cause azimuth Doppler chirp rate variation, making azimuth compression difficult and compensation computationally intensive, thus hindering imaging. Additionally, pulse repetition interval (PRI) agility leads to non-uniform azimuth sampling, severely deteriorating image quality. To address these issues, this paper proposes a multi-parameter agile SAR imaging scheme based on traditional frequency domain imaging algorithms. This scheme can handle joint agility of pulse width, chirp rate polarity, carrier frequency, and PRI, with relatively low computational complexity, making it feasible for engineering implementation. By inverting SAR images, the echoes with multi-parameter joint agility are obtained, and active deceptive interference signals are added for processing. The interference-suppressed imaging results verify the effectiveness of the proposed method. Furthermore, simulation results of point targets with multiple parameters under the proposed processing algorithm show that the peak sidelobe ratio (PSLR) and integrated sidelobe ratio (ISLR) are improved by 12 dB and 10 dB, respectively, compared to the traditional fixed waveform scheme. Full article

Airborne Frequency Diversity Array (FDA) radar operating at a high pulse repetition frequency encounters severe range-ambiguous clutter. The slight frequency increments introduced by the FDA result in angle and range coupling. Under these conditions, conventional space-time adaptive processing (STAP) often exhibits diminished performance or fails, complicating target detection. This paper proposes a method combining elevation oblique subspace projection with azimuth-Doppler STAP to suppress range-ambiguous clutter. The method compensates for the quadratic range dependence by analyzing the relationship between elevation frequency and range. It uses an elevation oblique subspace projection technique to construct an elevation adaptive filter, which separates clutter from ambiguous regions. Finally, residual clutter suppression is achieved through azimuth-Doppler STAP, enhancing target detection performance. Simulation results demonstrate that the proposed method effectively addresses range dependence and ambiguity issues, improving target detection performance in complex airborne FDA radar environments. Full article

In autonomous driving, Frequency-Modulated Continuous-Wave (FMCW) radar has gained widespread acceptance for target detection due to its resilience and dependability under diverse weather and illumination circumstances. Although deep learning radar target identification models have seen fast improvement, there is a lack of research on their susceptibility to adversarial attacks. Various spoofing attack techniques have been suggested to target radar sensors by deliberately sending certain signals through specialized devices. In this paper, we proposed a new adversarial deep learning network for spoofing attacks in radar target detection (RTD). Multi-level adversarial attack prevention using deep learning is designed for the coherence pulse deep feature map from DAALnet and Range-Doppler (RD) map from TDDLnet. After the discrimination of the attack, optimization of hybrid deep learning (OHDL) integrated with enhanced PSO is used to predict the range and velocity of the target. Simulations are performed to evaluate the sensitivity of AOHDL for different radar environment configurations. RMSE of AOHDL is almost the same as OHDL without attack conditions and it outperforms the earlier RTD implementations. Full article

Multichannel Synthetic Aperture Radar (MC-SAR) systems, such as Azimuth Multi-Phase Centre (AMPC) SAR, provide an effective solution for achieving high-resolution wide-swath (HRWS) imaging by reducing the pulse repetition frequency (PRF) to increase the swath width. However, in an Electronic Countermeasures (ECM) environment, the image quality of multichannel SAR systems can be significantly degraded by electromagnetic interference. Previous research into interference and counter-interference techniques has predominantly focused on single-channel SAR systems, with relatively few studies addressing the specific challenges faced by MC-SAR systems. This paper uses the classical spatial filtering technique of adaptive digital beamforming (DBF). Considering the Doppler ambiguity present in the echoes, two schemes—Interference Reconstruction And Cancellation (IRC) and Channel Grouping Nulling (CGN)—are designed to effectively eliminate suppressive interference. The IRC method eliminates the effects of interference without losing spatial degrees of freedom, ensuring effective suppression of Doppler ambiguity in subsequent processing. This method shows significant advantages under conditions of strong Doppler ambiguity and low jammer-to-signal ratio. Conversely, the CGN method mitigates the effect of interference on multichannel imaging at the expense of degrees of freedom redundant to Doppler ambiguity suppression. It shows remarkable interference suppression performance under weak-Doppler-ambiguity conditions, allowing for better image recovery. Simulations performed on point and distributed targets have validated that the proposed methods can effectively remove interfering signals and achieve high-resolution wide-swath (HRWS) SAR images. Full article

In detecting hypersonic vehicles, the radar echo signal is coupled with an intra-pulse Doppler frequency (I-D frequency) component caused by relative motion of a plasma sheath (PSh) and the vehicle, which can induce the phenomenon of a ghost target in a one-dimensional range profile. In order to investigate the I-D frequency generated by the relative motion of a PSh, this study transforms a linear frequency modulated (LFM) signal into a single carrier frequency signal based on echo signal equivalent time delay-dechirp processing and realizes high resolution and fast extraction of the I-D frequency coupled with the frequency-domain echo signal. Furthermore, by relying on the computation of the surface flow field of the RAMC-II Blunt Cone Reentry Vehicle, the coupled I-D frequency in the radar echo signal of a PSh-enveloped target under circumstances of typical altitudes and carrier frequencies is extracted and further investigated, revealing the variation law of I-D frequency. The key findings of this study provide a novel approach for suppressing anomalies in radar detection of PSh-enveloped targets as well as effective detecting and as robust target tracking. Full article

This paper presents a novel, cost-effective technique for estimating the Doppler effect in the time domain using a single pulse and subsequently leveraging the precise Doppler value to recover the radar waveform. The proposed system offers several key advantages over existing techniques, including the ability to calculate the target speed without any frequency ambiguity and the ability to detect a wide range of target speeds. These two features are not available in any existing techniques, including the conventional moving target detection (MTD) processor. To ensure improved accuracy and robust estimation, the system employs ensemble and iterative techniques by recursively and efficiently reducing the Doppler residues from the signal. Furthermore, the proposed system demonstrates effective signal recovery of a well-known bi-phase code shape at low signal-to-noise ratios in just a few iterations. The performance evaluation of the new algorithm demonstrates its practicability and its superiority over traditional radar systems. Implementation on software-defined radio (SDR) reveals that the proposed system excels in Doppler estimation and signal recovery at low SNRs, demonstrating promising results. Full article
