High-density polyethylene (HDPE) pipes are widely used in urban natural gas pipeline systems due to their excellent mechanical and chemical properties. However, welding joints are critical weak points in these pipelines, and defects, such as cold welding—caused by reduced temperature or/and insufficient pressure—pose significant safety risks. Traditional non-destructive testing (NDT) methods face challenges in detecting cold welding defects due to the polymer’s complex structure and characteristics. This study presents a microwave-based NDT system for detecting cold welding defects in thermal fusion welds of HDPE pipes. The system uses a focusing antenna with a resonant cavity, connected to a vector network analyzer (VNA), to measure changes in microwave parameters caused by cold welding defects in thermal fusion welds. Experiments conducted on HDPE pipes welded at different temperatures demonstrated the system’s effectiveness in identifying areas with a lack of fusion. Mechanical and microstructural analyses, including tensile tests and scanning electron microscopy (SEM), confirmed that cold welding defects lead to reduced mechanical properties and lower material density. The proposed microwave NDT method offers a sensitive, efficient approach for detecting cold welds in HDPE pipelines, enhancing pipeline integrity and safety. Full article

The performance of high-density polyethylene (PE) pipes joints directly affects the total pipeline’s operation, and so studying the residual stress of butt fusion joints is crucial for enhancing the safety of gas pipelines. Based on a layer-by-layer ring cutting test method, we measured the distribution of residual stresses in the fusion zone and heat-affected zone of butt fusion joints for PE gas pipes. Firstly, the ring samples were cut, their diameter changes were measured, and the results were compared with those predicted by the theoretical calculations. This showed that the circumferential residual stresses of the butt fusion joint for the PE gas pipes are exponentially distributed in the base material (BM) zone, the weld zone (WZ) and the heat-affected zone (HAZ). Furthermore, the residual stresses in the HAZ are lower than those in the BM zone, and the smallest residual stresses were seen in the WZ. Finally, using X-ray diffraction (XRD) technology, the crystallinities in the BM zone, the WZ, and the HAZ of the butt joints were measured. The crystallinity gradually decreased from the WZ to the HAZ and the BM zone, and the crystallinity in each zone was also related to the magnitude of the residual stresses. Full article

The paper analyzes the process of indentation of polymeric materials with a spherical indenter. The loading diagrams P(h) obtained experimentally and by means of finite element method (FEM) are analyzed. The material under study was high-density polyethylene (HDPE) of PE100 grade, taken from a pipeline for gas distribution systems. The aim of the work was to determine the parameters of the computer model, taking into account hardening and creep processes when verifying P(h) diagrams with experimental studies. The influence of variation of the parameters of the calculation formulas on the reliability of the simulation results was analyzed. The results of the calculation of mechanical properties of material on the basis of P(h) diagrams by the Oliver–Pharr method for model and experimental diagrams were compared. The possibility of using computer modeling for the analysis of instrumented indentation processes is demonstrated, since the results revealed the convergence of the elastic modulus of 1078 GPa for FEM and 1083 GPa for the experiment. The conformity of the Oliver–Pharr method for determining the contact depth is also shown, which differed from the model geometry by only 2.3%. Simulation of the indentation process using the Norton model via FEM, as well as determining the parameters of the material deformation function while taking creep into account, makes it possible to describe the process of contact interaction and shows good agreement with experimental data. Full article

Gas polyethylene (PE) pipes have an become essential component of the urban gas pipeline network due to their long service life and corrosion resistance. To prevent safety incidents, regular monitoring of gas pipelines is crucial. Traditional inspection methods face significant challenges, including low efficiency, high costs, and limited applicability. Machine vision-based inspection methods have emerged as a key solution to these issues. Despite this, the method also encounters the problem of scarcity of defect samples and uneven data distribution in gas pipeline defect detection. For this reason, an improved Deep Convolutional Generative Adversarial Network (DCGAN) is proposed. By integrating the Minibatch Discrimination (MD), Spectral Normalization (SN), Self-Attention Mechanism (SAM) and Two-Timescale Update Rule (TTUR), the proposed approach overcomes the original DCGAN’s limitations, including mode collapse, low resolution of generated images, and unstable training, the data augmentation of defective images inside the pipeline is realized. Experimental results demonstrate the superiority of the improved algorithm in terms of image generation quality and diversity, while the ablation study validates the positive impact of the improvement in each part. Additionally, the relationship between the number of augmented images and classification accuracy, showing that classifier performance improved across all scenarios when generated defect images were included. The findings indicate that the images produced by the improved model significantly enhance defect detection accuracy and hold considerable potential for practical application. Full article

A parallel four-legged pipeline robot is designed to mitigate the issue of uneven motor loading on the single-leg linkage responsible for movement along the pipe diameter. This issue occurs because the drive motor located closer to the robot body requires higher torque when the serial robot operates along the inner wall of a circular polyethylene gas pipe in an urban environment. The forward and inverse kinematic equations for a single-leg linkage are derived to establish the relationship between joint angles and foot trajectories. Building on this analysis, the forward and inverse kinematic solutions for all four legs are also derived. An optimized diagonal trotting gait is selected as the robot’s walking pattern to ensure a balance between stability and movement efficiency, considering the robot’s structural configuration. Motion simulations for both the serial and parallel robots are performed using simulation software, with a detailed analysis of the displacement of the robot’s center of mass and the leg centers during movement. The driving torque of the leg motors in both configurations is controlled and examined. Simulation results indicate that the designed parallel four-legged pipeline robot achieves lower motion error and smoother leg movements within the pipe. Compared to the serial robot, the maximum torque required to drive the leg motors is reduced by approximately 33%, demonstrating the effectiveness and validity of the overall structural design. Full article

This study proposes a buried PE gas pipeline positioning method based on the elliptical method of an acoustic signal analysis. The cross-correlation time delay positioning technology is combined with the elliptical equation, forming an effective mechanism for pipeline depth positioning. First, a dual-tree complex wavelet transform is employed to denoise the collected signals, enhancing the quality and accuracy of the data. Subsequently, the cross-correlation function is utilized to extract the delay times between the signals. The obtained delay times are then substituted into the elliptical equation to calculate the depth of the buried PE pipeline. Based on this theoretical framework, a simulation model is established in COMSOL, and positioning simulation analyses are conducted under three different conditions: pipeline depth, relative sensor positions, and distances between sensors and excitation points. The simulation results indicate that a clear correlation exists between the signal delay time and the pipeline position, with simulation errors controlled within 5%, thus validating the theoretical feasibility of the method. To further assess the effectiveness of this approach, an experimental testing system is constructed. The experimental study was carried out under four different conditions: pipeline burial depth, relative sensor positions, distances between sensors and excitation points, and excitation frequencies. The experimental results demonstrate that these factors significantly affect the pipeline depth positioning. The comparison results show that the method has a high accuracy in depth positioning, with experimental errors controlled within 10%. This study proves that accurate positioning of pipeline depth could be achieved by substituting signal delay times into the elliptical equation, thereby validating the method’s feasibility in practical applications. The proposed method effectively addressed the shortcomings of existing pipeline depth positioning technologies, providing important theoretical support and a practical reference for future pipeline positioning research. Full article

Polyethylene (PE) pipes are widely used in urban gas transportation due to their good toughness and corrosion resistance. Currently, the designed service life of a PE pipeline is 50 years, and some urban gas PE pipelines are approaching their service life. However, research on the aging assessment of PE pipelines is not complete, and it is impossible to effectively predict their aging status in service. Once urban gas PE pipelines are damaged, serious accidents may be caused. PE80 and PE100 pipelines are commonly used for urban gas, and improved accelerated aging tests were conducted considering different conditions of pressure, pipe diameter, and temperature. According to the experimental results, an aging life prediction method for PE pipes was constructed based on the Arrhenius formula considering multiple effect factors. Full article

High-density polyethylene (HDPE) has emerged as a promising alternative to fiber-reinforced plastic (FRP) for small vessel manufacturing due to its durability, chemical resistance, lightweight properties, and recyclability. However, while thermoplastic polymers like HDPE have been extensively used in gas and water pipelines, their application in large, complex marine structures remains underexplored, particularly in terms of joining methods. Existing techniques, such as ultrasonic welding, laser welding, and friction stir welding, are unsuitable for large-scale HDPE components, where extrusion welding is more viable. This study focuses on evaluating the impact of key process parameters, such as the preheating temperature, hot air movement speed, and nozzle distance, on the welding performance of HDPE. By analyzing the influence of these variables on heat distribution during the extrusion welding process, we aim to conduct basic research to derive optimal conditions for achieving strong and reliable joints. The results highlight the critical importance of a uniform temperature distribution in preventing defects such as excessive melting or thermal degradation, which could compromise weld integrity. This research provides valuable insights into improving HDPE joining techniques, contributing to its broader adoption in the marine and manufacturing industries. Full article

Traditionally, subsea pipelines designed for the transportation of oil, gas, and water are constructed using carbon steel due to its strength, toughness, and ability to operate at temperatures up to 427 °C. However, polyethylene (PE), especially its high-density variant (HDPE), presents advantages such as reduced installation costs, diminished water leakage, and superior corrosion resistance. As research endeavours to enhance PE properties, its adoption for subsea applications is anticipated to rise. This study first delineates the mechanical behaviour of HDPE pipelines for offshore installation, identifying pulling tension, dimension ratio, water depth, and air fill ratio as the paramount lay parameters. Subsequently, a theoretical bend radius equation was derived from pipelaying mechanics using a purely geometric approach. Within this equation, two determinants, parameter X and parameter Y, dictate the sagbend bend radius. Regression analysis elucidated the relationships of lay parameters with both X and Y, yielding a general equation for X in terms of pull tension, water depth, and air fill ratio and another for Y as a function of water depth. Together, these geometric determinants underpin the sagbend bend radius estimation model. For overbend bend radius prediction, a lay index (I_L) was fashioned from the aforementioned three parameters. Correlation assessments between the lay index and overbend bend radius revealed R² values of 0.940, 0.836, and 0.712 for pipes with diameters of 2.0, 2.5, and 3.0 metres, respectively. This underscores the model’s proficiency in predicting the bend radius, albeit with decreasing precision for larger-diameter pipelines. Full article

The use of guided wave-based Ultrasonic Testing (UT) for monitoring Polyethylene (PE) pipes is mostly restricted to detecting defects in welded zones, despite its diversified success in monitoring metallic pipes. PE’s viscoelastic behavior and semi-crystalline structure make it prone to crack formation under extreme loads and environmental factors, which is a leading cause of pipeline failure. This state-of-the-art study aims to demonstrate the potential of UT for detecting cracks in non-welded regions of natural gas PE pipes. Laboratory experiments were conducted using a UT system consisting of low-cost piezoceramic transducers assembled in a pitch-catch configuration. The amplitude of the transmitted wave was analyzed to study wave interaction with cracks of different geometries. The frequency of the inspecting signal was optimized through wave dispersion and attenuation analysis, guiding the selection of third- and fourth- order longitudinal modes for the study. The findings revealed that cracks with lengths equal to or greater than the wavelength of the interacting mode were more easily detectable, while smaller crack lengths required greater crack depths for detection. However, there were potential limitations in the proposed technique related to crack orientation. These insights were validated using a finite element-based numerical model, confirming the potential of UT for detecting cracks in PE pipes. Full article

Liquefied natural gas (LNG) is one of the most promising fuels for energy supply because it has a favorable combination of environmental and economic properties in connection with new trends aimed at the development of ecological and sustainable consumption of natural resources, which ensure a constant growth in LNG consumption. The article presents an analytical review of the main technical solutions for the construction of cryogenic pipelines and insulating coating structures. The ANSYS Fluent software was used for simulation of the LNG flow in a pipeline section 10 m long with an outer diameter of 108 mm for three types of insulating coating (polyurethane (PU) foam, aerogel, and vacuum-insulated pipe (VIP)). In addition, an assessment was made of the insulating effect on the LNG temperature distribution along the length of the pipeline. The largest increase in temperature from 113 K to 113.61 K occurs in PU foam-insulated pipes; the smallest was observed in VIP. Further, as an alternative to steel, the use of ultra-high molecular weight polyethylene (UHMWPE) for pipeline material was considered. The optimal result in terms of temperature distributions was obtained while simulating the flow of an LNG pipeline with PU foam by increasing the thickness of the insulating coating to 0.05 m. Full article

This article is devoted to the study of means and methods for non-destructive testing mechanical properties of polyethylene gas pipelines that have been in operation for 25–55 years. In order to assess mechanical properties, stress at yield was chosen as a key parameter. Stress at yield is determined from the results of tensile tests and is associated with the limiting circumferential (hoop) stress, determined from the results of tests for short-term pressure. Tensile tests require sample cutting and the shutdown of pipelines’ service. To solve this problem of nondestructive testing of pipelines, tests were carried out using the methods of Shore, Leeb and dynamic instrumental indentation. According to the test results, it was revealed that the correlation coefficient between the values of stress at yield and hardness, obtained by the method of dynamic instrumental indentation, is 0.98 which confirms the possibility of the evaluation of the mechanical properties of pipelines by the method of dynamic instrumental indentation. Full article

For the problem of classification and identification of defects in polyethylene (PE) gas pipelines, this paper firstly performs preliminary screening of the acquired images and acquisition efficiency of defective image acquisition was improved. Images of defective PE gas pipelines were pre-processed. Then, edge detection of the defective images was performed using the improved Sobel algorithm and an adaptive threshold segmentation method was applied to segment the defects in the pipeline images. Finally, the defect images were morphologically processed to obtain binary images. The obtained binary images were applied with VGG16 to complete the training of the defect classifier. The experimental findings show that in the TensorFlow API environment, the test set’s highest accuracy reached 97%, which can achieve the identification of defect types of underground PE gas transmission pipelines. Full article

The classification of hidden dangers in urban gas pipelines plays a vital role in the smooth operation of urban gas pipelines and in solving the problem of hidden safety dangers in urban gas pipelines. In recent years, the number and proportion of polyethylene (PE) pipelines in urban gas pipelines are increasing day by day, but the current classification of hidden dangers in urban gas pipelines is still based on steel pipelines, and the classification method is highly subjective. Therefore, this paper proposes an improved PLC method that integrates the use of a risk matrix and compensation coefficient to solve the problem of grading the hidden dangers of PE pipelines of urban gas. The improved PLC method is based on the failure database of urban gas PE pipelines to obtain the vulnerability and severity of consequences when determining the initial level of hidden dangers, and the compensation coefficient is modified according to regional vulnerability, ease of rectification, condition around the pipeline, positioning technology, leak detection technology, and emergency ability, which can effectively reduce the subjectivity of hidden danger classification. Using the improved PLC method to classify urban gas pipelines for hidden dangers can provide pipeline operating companies with a basis for decision making in the process of hidden danger disposal and effectively reduce pipeline safety risks. Full article

With continued urbanization in China, the construction of urban gas pipelines is increasing, and the safety of gas pipelines are also increasingly affected by urban development and the increased scope of buildings and roads. Pipes with defects are more likely to fail under the surface loads. In this study, uniaxial tensile tests of high-density polyethylene (HDPE) pipes were carried out to obtain the real material parameters of pipe. A pipeline-soil interaction finite element model of HDPE pipeline with defects under surface load was established. The failure mechanism of the urban gas pipeline was studied and the influence of parameters such as internal pressure, defect position, defect depth on the mechanical behavior, and failure of pipelines were analyzed. A failure criterion for HDPE pipes with defects under surface load was proposed based on the limit-state curves obtained under different working conditions. Furthermore, an accurate and efficient fitness-for-service assessment procedure of pipes with defects under surface load was proposed. The results showed that maximum Mises stress of the pipeline gradually increased with increasing surface load and the position of maximum stress changed from the top and bottom of the pipe to the defect position and both sides of the pipe. Finally, when Mises stress of the HDPE pipe exceeds the yield limit, failure will occur. Internal pressure, defect location, and defect depth were found to influence the failure process and critical surface load of the pipeline. Safety evaluation curves of the gas pipeline with defects under surface load were obtained by calculating the critical failure load of the pipeline under various working conditions. Finally, a nonlinear fitting method was used to derive a formula for calculating the critical surface load under different defect parameters. The proposed method provides a useful reference for urban gas pipeline safety management. Full article
