The investigation of wave propagation in the geological environment is warranted, and will ultimately help to provide a better understanding of the response of subsoil to excitation. Frequently utilized physical modeling represents a simplification of the global natural system for the needs of the investigation of static and dynamic phenomena with regard to the time domain. The determination of appropriate model materials is probably the most important task for physical model creation. Considering that subsoil represents a crucial medium for wave propagation, an evaluation of suitable model materials was carried out. A plate load test with a circular plate is a non-destructive method for determining the static bearing capacities of soils and aggregates, which are usually expressed by the deformation modulus E_def,2 (MPa) and the static modulus of elasticity E (MPa). A lightweight deflectometer test was used to characterize the impact modulus of deformation E_vd (MPa), which is determined based on the pressure under the load plate due to the impact load. A representative propagation of the load–settlement curve for the PLT and the acceleration–time curve for the hammer drop test were investigated. The calculated E values were found to be in the interval between 2.6 and 5.7 kPa, and depending on the load cycle, the values of E ranged from 2.6 to 3.1 kPa. The modulus E from the hammer drop test was significantly larger than the interval between 10.6 and 40.4 kPa. The values of the dynamic multiplier, as a ratio of the hammer drop value to the PLT value, of the modulus E ranged from 4.1 to 13.0. The output of the plate load testing was utilized for the calibration of the finite element method (FEM) numerical model. Both the physical and numerical models showed practically ideal linear behavior of the mass. However, the testing of gelatin-like materials is a complex process because of their viscoelastic nonlinear behavior. Full article

Dynamic compaction is a method of ground reinforcement that uses the huge impact energy of a free-falling hammer to compact the soil. This study presents a DC method for strengthening coral reef foundations in the reclamation area of remote sea islands. Pilot tests were performed to obtain the design parameters before official DC operation. The standard penetration test (SPT), shallow plate-load test (PLT), and deformation investigation were conducted in two improvement regions (A₁ and A₂) with varying tamping energies. During the deformation test, the depth of the tamping crater for the first two points’ tamping and the third full tamping was observed at two distinct sites. The allowable ground bearing capacity at two disparate field sites was at least 360 kPa. The reinforcement depths were 3.5 and 3.2 m in the A₁ and A₂ zones, respectively. The DC process was numerically analyzed by the two-dimensional particle flow code, PFC2D. It indicated that the reinforcement effect and effective reinforcement depth were consistent with the field data. The coral sand particles at the bottom of the crater were primarily broken down in the initial stage, and the particle-crushing zone gradually developed toward both sides of the crater. The force chain developed similarly at the three tamping energies (800, 1500, and 2000 kJ), and the impact stress wave propagated along the sand particles primarily in the vertical direction. Full article

During road construction, the accuracy of compaction work is critical for the structural stability and maintenance of the road. Although the plate load test (PLT) is commonly used for quality inspections, it is impractical to test every section due to time and cost constraints. Therefore, simpler testing methods are being extensively developed. This study compared quality inspection results using the commonly used PLT, the relatively simple dynamic cone penetrometer test (DCPT), the lightweight deflectometer (LWD) test, and an intelligent quality control system equipped with accelerometer and global positioning system (GPS) sensors in intelligent compaction (IC) rollers. The results showed a strong correlation between the conventional tests (PLT, DCPT, and LWD) and the values obtained from the intelligent quality control system. The correlation analysis between the intelligent quality control system and PLT, LWDT, and DCPT yielded R-square values of 0.69, 0.91, and 0.95, respectively, indicating significantly high correlations. The implementation of intelligent quality management systems in earthwork construction projects will facilitate a thorough verification of the compaction quality throughout all construction segments, ensuring consistent compaction across the project. By enabling real-time data acquisition and analysis, these systems differ markedly from traditional methods, reducing the frequency and necessity of manual inspections. This approach not only streamlines construction processes, but also enhances operational efficiency. As a result, integrating these intelligent systems is anticipated to significantly increase productivity by optimizing the workflow and resource utilization in earthwork construction. Full article

This paper provides a five-year performance evaluation of an application of geogrid reinforcement in low-volume unpaved roads using dynamic cone penetrometer (DCP), plate load tests (PLT), and roadway sensing method. A Forest Service unpaved road located in northern Arizona, USA, exhibited severe deterioration on the surface, creating an unsafe traffic environment for vehicles. A total of four structural sections (1–4; 4.3 m wide) were installed in the 40 m long test area. One additional section of existing subgrade/roadbed with native soil adjacent to the test sections was used for comparison purposes. The project was originally completed in November 2015, followed by five annual field visits to observe surface conditions of the five test sections. Based on DCP and PLT results (both conducted in 2015), and roadway sensing tests conducted in 2020, the section made of 30 cm thick aggregate with one geogrid layer appeared to have a better capacity for resisting traffic loading as compared with the other four sections. This paper concludes that, from a long-term point of view, the geogrid reinforcement improves the capacity of the unpaved roads, with significantly reduced rutting and damage from both roadway traffic loads and weathering effects. Full article

The plate load test (PLT) is the most reliable in situ testing for studying the load–settlement behaviour of footings on unsaturated collapsible soils. In these soils, the suction profile is not constant along the depth, and the scale effect between the prototype and footing leads to different suction averages and, consequently, different data. One method to eliminate the effect of soil suction on the test data is to fully saturate the soil prior to the test, which is also recommended at the design process for footing on collapsible soils. However, the inundation process on PLTs is expensive and time-consuming, which makes this procedure difficult to incorporate into engineering practice. This study presents a device that can be attached to flat dilatometer (DMT) to allow local inundation of the soil as part of the in situ test campaign and obtain the DMT-constrained modulus (M_DMT) for both natural and inundated conditions. The M_DMT presented an average reduction of 56% from natural to inundated condition. This parameter can be used in a model to predict load–settlement curves by DMT data considering the suction influence on this behaviour. The curves obtained from the prediction model were compared to curves determined by PLT conducted under the same in situ conditions. Good agreement was found between the curves predicted by DMT and those measured by PLT for both conditions. The proposed procedure, which uses a device attached to the DMT blade, provides an investigation method to obtain the load–settlement curve under different suction conditions, which can help in the selection and performance prediction of shallow foundations, taking into account suction and collapse phenomenon-related problems. Full article

Bearing capacity and compaction are among the most important and frequently used geotechnical parameters in road construction. The aim of this study was to determine the possibility of predicting the value of the primary deformation modulus E₁ (obtained from measurements using a static plate load test—PLT) based on measurements with a Zorn light falling weight deflectometer (LFWD), type ZFG 3000 GPS, with a drop weight of 10 kg. A regression analysis was performed on 245 bearing capacity measurements that were taken on 46 forest road sections with various road surfaces. Different regression models were tested, from linear to logarithmic, polynomial, exponential and power models, but excluding polynomials of fourth and higher degree. The results showed that the prediction of E₁ values (PLT) from the dynamic deformation modulus values E_vd (LFWD) was possible. However, the reported unsatisfactory strength of the relationship between the two parameters was associated with a high risk of error (r = 0.64, R² = 0.41, S_e = 49.78). Neither the use of more complex non-linear regression models, nor the use of multiple regression by introducing an additional estimator in the form of the s/v ratio, significantly improved estimation results. The quality of the prediction of the E₁ value was not constant. It varied, depending on the type of forest road, the use of geosynthetic reinforcement and the type of road subgrade. During the study, it was also found that the quality of the prediction of the E₁ value could be improved by limiting the range of E_vd values tested from above. It is advisable to continue this type of research, as the obtained results could form the basis for future development of national standards for the use of LFWDs to control the bearing capacity and compaction of forest road pavements. Full article

This article is dedicated to investigating the properties of soil after its reinforcement with fiberglass elements through large-scale laboratory plate-load tests of various samples that varied in the numbers and lengths of the reinforcing elements. The investigation of the vertical elements considered the diameter increase at the bottom toe by using widening washers. The results were compared relative to each other and to the theoretical calculation results. The theoretical calculations for the settlements were undertaken based on the authors’ proposed method. The method considers the number, shape, area and material of the strengthening elements using a pre-proposed reinforcement area factor µ. This pre-established factor was calculated with reference to the elements’ geometry—the diameter of the vertical elements and the bottom’s washer diameter—which determined the reinforcement area. A comparison between the reinforced and reference soft sandy soil samples indicated a 25% increase in the deformation modulus after the reinforcement process at a pressure of 25 kPa. Samples with µ ranging from 1.20 to 1.43 were 55–65% stiffer than samples with µ equal to 0.69 at a pressure of 100 kPa. The comparative analysis of the calculated results and the actual laboratory PLT test results was adequate for use for further development. Full article

Accurate determination of rock mass deformation modulus is very important in rock engineering projects. The plate loading test (PLT) is a method that is generally used in dam construction projects to determine rock mass modulus. Numerical simulation was used to investigate the mechanisms involved in this test. The first objective of the paper was to employ 3D modeling in the interpretation of plate load tests conducted at the Bazoft dam site in Iran. Additionally, a parametric study of the effects of key parameters such as displacement measuring depth and loading plate diameter on the test results was another objective of the study. The moduli values determined numerically were compared against actual filed testing data determined from in-situ test data conducted at the Bazoft dam site, and the values determined from the ISRM suggested formula. The analysis showed that the optimum measurement depth for rock mass modulus calculation is approximately equal to the loading plate diameter and the data determined from measurement depths beyond one plate diameter can be unrealistic. Moreover, the plate diameter can have a significant effect on test results. As the measurement depth increases, the determined modulus values increase at a much more rapid pace when employing smaller size loading plates. Full article

The impermeable cover in urban area has been growing due to rapid urbanization, which prevents stormwater from being naturally infiltrated into the ground. There is a higher chance of flooding in urban area covered with conventional concretes and asphalts. The permeable pavement is one of Low-Impact Development (LID) technologies that can reduce surface runoff and water pollution by allowing stormwater into pavement systems. Unlike traditional pavements, permeable pavement bases employ open-graded aggregates (OGAs) with highly uniform particle sizes. There is very little information on the engineering properties of compacted OGAs. In this study, the moduli of open-graded aggregates under various compaction energies are investigated based on the Plate Load Test (PLT) and Light-Weight Deflectometer (LWD). Artificial Neural Network (ANN) and Linear Regression (LR) models are employed for estimation of the moduli of the aggregates based on the material type and level of compaction. Overall, the moduli from PLT and LWD steeply increase until the number of roller passes reaches 4, and they gradually increase until the number of roller passes becomes 8. A set of simple linear equations are proposed to evaluate the moduli of open-graded aggregates from PLT and LWD based on the material type and the number of roller passes. Full article
