Search Results (11)

Liquefaction and earthquake damage to coral sand sites can cause engineering structure failure. Both testing and analyzing the seismic response characteristics of pile groups on coral sand sites are highly important for the seismic design of engineering structures. To address the lack of research on the seismic dynamic response of group pile foundations in coral sand sites, this study analyzes the characteristics of the seismic dynamic response of vertical and batter pile foundations for bridges in coral sand liquefaction foundations via the shaking table model test and investigates the variation patterns of acceleration, excess pore water pressure (EPWP), and the bending moment and displacement of foundations, soil, and superstructures under different vibration intensities. Results show that the excitation wave type significantly affects liquefaction: at 0.1 g of peak acceleration, only high-frequency sine wave tests liquefied, with small EPWP ratios, while at 0.2 g, all tests liquefied. Vertical pile foundations had lower soil acceleration than batter piles due to differences in bearing mechanisms. Before liquefaction, batter piles had smaller EPWP ratios but experienced greater bending moments under the same horizontal force. Overall, batter piles showed higher dynamic stability and anti-tilt capabilities but endured larger bending moments compared to vertical piles in coral sand foundations. In conclusion, batter pile foundations demonstrate superior seismic performance in coral sand sites, offering enhanced stability and resistance to liquefaction-induced failures. Full article

Post-earthquake investigations have shown that piles in liquefiable soils are highly susceptible to damage, especially in sloping sites. This study examines the seismic performance of pile groups with lateral spreading through advanced numerical modeling. A three-dimensional finite element model, validated against large-scale shaking table test results, is implemented to capture the key mechanisms driving the dynamic response of pile groups under both inertial and kinematic loading conditions. Parametric seismic response analyses are conducted to compare the behavior of batter and vertical piles under varying ground motion intensities. The results indicate that batter piles experience increased axial compressive and tensile forces compared to vertical piles, up to 70% and 20%, respectively. However, batter piles provide enhanced lateral stiffness and shear resistance compared to vertical piles, reducing horizontal displacements by up to 20% and tilting the cap by 85% under strong ground motion. The results demonstrate that batter piles not only enhance the overall seismic stability of the structure but also mitigate the risk of liquefaction-induced lateral spreading in the near-field through pile-pinning effects. While vertical piles are more commonly used in practice, the distinct advantages of batter piles for seismic stability highlighted in this study may encourage using more advanced numerical modeling in engineering projects. Full article

During devastating earthquakes, soil liquefaction has disastrous outcomes on bridge foundations, as mentioned in books and published research. To avoid foundation failure when the surrounding soil is fully liquefied, a bridge’s pile foundation design could be such that the bridge pier is directly resting on the top of a large-diameter monopile instead of the traditional multiple small-diameter piles. This paper discusses the gap of insufficient studies on large-diameter monopiles to support railway bridges subjected to buckling instability and the lack of simplified tools to quickly assess structural reliability. A framework could quickly assess the structural reliability by formulating a simplified reliability analysis. This study focused on pure buckling with shear deformation and reliability assessment to calculate a monopile’s failure probability in fully liquefied soils. In reliability assessment, with the critical pile length (L_crit) and the unsupported pile length (L_uns), the limit state function g(x) = [L_crit − L_uns] thus forms the basis for assessing the safety and reliability of a structure, indicating the state of success or failure. The L_crit formulation is accomplished with a differential equation. Here, L_uns assumes various depths of liquefied soil. The reliability index’s (β) formulation is achieved through the Hasofer–Lind concept and then double-checked through a normal or Gaussian distribution. A case study was conducted using a high-speed railway bridge model from a published research to demonstrate the application of the proposed methodology. To validate the minimum pile diameter for buckling instability when a fully liquefied soil’s thickness reaches the condition that L_crit = L_uns, this study applies the published research of Bhattacharya and Tokimatsu. The validation results show good agreement for 0.85–0.90 m monopile diameters. With a monopile diameter smaller than 0.85 m, the L_crit = L_uns limit was at lesser depths, while with a monopile diameter larger than 0.90 m, the L_crit = L_uns limit was at deeper depths. A load increase notably affected the large-diameter monopiles because the L_crit movement required a longer range. In fully liquefied soil, buckling will likely happen in piles with a diameter between 0.50 m and 1.60 m because the calculated probability of failure (Pf) value is nearly one. Conversely, buckling instability will likely not happen in monopiles with a diameter of 1.80–2.20 m because the Pf value is zero. Hence, the outcome of this case study suggests that the reliable monopile minimum diameter is 1.80 m for supporting a high-speed railway bridge. Lastly, this paper analyzed the shear deformation effect on large-diameter monopiles, the result of which was 0.30% of L_crit. Shear deformation makes minimal contributions to large-diameter monopile buckling. Full article

The provision of drains to geotechnical elements subjected to strong ground motion can reduce the magnitude of shaking-induced excess pore pressure and the corresponding loss of soil stiffness and strength. A series of shaking table tests were conducted within layered soil models to investigate the effectiveness of drained piles to reduce the liquefaction hazard in and near pile-improved ground. The effect of the number of drains per pile and the orientation of the drains relative to the direction of shaking were evaluated in consideration of the volume of porewater discharged, the magnitude of excess pore pressure generated, and the amount of de-amplification in the ground’s motion. The following main conclusions can be drawn from this study. Single, isolated piles and a group of drained piles were tested in three series of shake table tests. Relative to conventional piles, the drained piles exhibited improved performance with regard to the generation and dissipation of excess pore pressure and stiffness of the surrounding soil, with increases in performance correlated with increases in the discharge capacity of the drained pile. The acceleration time histories observed within the pile-improved soil indicated a coupling of the rate and magnitude of porewater discharge, excess pore pressure generated, and de-amplification of strong ground motion. The amount of de-amplification reduced with increases in the number of drains per pile and corresponding reductions in excess pore pressure. The improved performance should prove helpful in the presence of sloping ground characterized with low-permeability soil layers that inhibit the dissipation of pore pressure and have demonstrated the significant potential for post-shaking slope deformation. Full article

The dynamic responses of pile–liquefied composite soils are complex, and the bearing capacities of single piles or pile groups in liquefiable soils remain unclear. For friction piles, the friction resistance determines the vertical bearing capacity of the pile. In a pile–soil system, it is very important to study the friction resistance changes in the pile during vibration. Based on a shaking table test, this study investigated the vertical bearing capacity of a pile foundation–liquefied soil system under simulated horizontal seismic forces, using the MIDAS GTS software. The load borne by the top of the pile was studied under a horizontal earthquake with a certain vertical load, different pile spacings, and different vibration times, along with the cumulative coefficient CCPF of the pile side friction. The distributions of the CCPF along the pile body of a single pile and pile groups with different pile spacings were analyzed at different vibration times. It was found that the CCPF intuitively reflected the distribution law of the pile side friction during vibration. When the CCPF at the bottom of the pile was equal to 1, the load on the top of the pile was equal to the average value of the total load. When the CCPF at the bottom of the pile was less than 1, the load on the top of the pile was less than the average value of the total load. When the CCPF at the bottom of the pile was greater than 1, the load on the top of the pile was greater than the average of the total load. Full article

The liquefaction of soil surrounding a pile significantly affects the dynamic interaction between the soil and the pile. In particular, liquefaction of the sloping ground can induce permanent deformation and a bending moment on the pile due to the lateral displacement of the liquefied soil in the downslope direction. However, numerical analysis studies on piles installed in a liquefiable slope have been very limited and have not properly simulated the behavior of the pile. Therefore, a modified soil–pile interface model was proposed, which linearly decreases the interface friction angle with the increase in the excess pore pressure ratio. The proposed model was validated by comparing it with the centrifuge test results of Yoo et al. (2023). Simulation results on the slope crest settlement and the pile-bending moment showed good agreement with the centrifuge test results. A parametric study was conducted by applying the validated model to analyze the effect of slope inclinations and the amplitude of input motions on the slope displacement and the pile moment. The simulation results showed that the slope inclinations affected the area of the sliding mass, causing a larger pile-bending moment with a larger inclination. When the amplitude of the input motion was sufficiently large to trigger the failure of the liquefied slope, the slope displacement and the pile-bending moment did not increase any further. Full article

One of the challenges to the analysis of interactions between soil and piles in lateral spreading is the modeling of the progress generated by excess pore pressure and soil strength and stiffness degradation. In this paper, a pile–soil interaction analysis method that introduces the thixotropic-induced excess pore pressure model (TEPP) to describe the progressive development of the stress–strain rate connection of liquefying soil is proposed. The reliability of the method was verified by comparing the calculated results with that of the shake table test. Then, the parametric analyses of soil–pile interactions were carried out. The results show that the bending moment and horizontal displacement of pile foundations increase with the increase in superficial viscosity and inclination angle of the site. The horizontal dislocation and bending moment of the pile foundation increase with the decrease in loading frequency as a result of the property of amplifying low-frequency loads and filtering high-frequency loads of liquefied soil. Full article

The saturated soil site-pile foundation-superstructure system, with large degrees of freedom or strong nonlinear problems, often involves a large amount of calculation and low computational efficiency. In this paper, a fully explicit finite difference method is proposed for a saturated soil site-pile foundation-superstructure system. Since the proposed method has the advantages of decoupling in both time and space, it does not need to solve the equations simultaneously, which grants it high computational efficiency. At the same time, the method is implemented on the open-source software OpenSees and is used to compare and analyze the dynamic responses of the shaking table of a liquefiable soil site-pile foundation-superstructure system. After the calculation and analysis, the numerical solutions were found to be in good agreement with the experimental solutions, which verifies the proposed method and illustrates that the proposed method can reasonably simulate the seismic responses of the whole system. In addition, the proposed calculation platform in OpenSees can be used for the analysis of the liquefaction process and the possible large deformation of soil after liquefaction, as well as for analyzing the failure mode of the complex and nonlinear saturated soil sites and structures under the effects of an earthquake. Full article

Piles, which are always exposed to dynamic loads, are widely used in offshore structures. The dynamic response of the pile-soil-superstructure system in liquefiable soils is complicated, and the interaction between the pile and soil and the pile volume effect are the key influencing factors. In this study, a water-soil fully coupled dynamic finite element-finite difference (FE-FD) method was used to numerically simulate the centrifuge shaking table (CST) test of a four-pile group in saturated sand soil. An interface contact model was proposed to simulate the pile-soil interaction, and a solid element was used to consider the volume effect of the pile. The acceleration responses of the soil and pile, settlement deformation, excess pore water pressure, and bending moment were examined. The results show that the bending moment response of the two piles parallel to the shaking direction show minor differences, while the two piles perpendicular to the shaking direction show almost the same distribution. The values of excess pore water pressure at the same depth but different azimuth angles around the pile are also different. The numerical simulation can accurately reproduce soil deformation and pile internal force during and after dynamic loading. Full article

To avoid large deformation, resulting from liquefaction, in inclined and deeply deposited liquefiable soil, it is necessary to design economical and reasonable reinforcement schemes. A reinforcement scheme employing subarea long-short gravel piles was proposed, and it was successfully applied in the embankment construction of the Aksu-kashgar highway. To reveal its underlying mechanism and effect on the seismic performance of the highway, the dynamic responses of natural foundation and two kinds of reinforced foundations were analyzed and compared under this scheme, using the program FEMEPDYN. Results showed that both the seismic subsidence and the excess pore pressure ratios were far less in the foundation reinforced with isometric gravel piles and in the foundation reinforced with subarea long-short gravel piles, compared with that in natural foundation. Therefore, the potential hazards of liquefaction were overcome in these two kinds of reinforced foundations. Furthermore, it was obvious that the shielding region only formed within the foundation reinforced with subarea long-short gravel piles. With the shielding effect, the proposed reinforcement scheme employing subarea long-short gravel piles not only eliminated liquefaction in deeply deposited liquefiable soil, but it also demonstrated an outstanding advantage in that the total length of gravel piles used was greatly reduced compared to the total length in the isometric gravel piles scheme and the interphase long-short gravel piles. Full article

The dynamic behavior of structures in liquefiable sand exhibits more complicated characteristics, due to the development of excess pore pressure caused by cyclic loading, than that in dry sand. Therefore, it is crucial to accurately predict the soil–pile structure behavior during liquefaction to prevent damage to the structures. In this study, three-dimensional numerical modeling was performed to predict the dynamic soil–pile behavior during liquefaction. To directly simulate pore pressure generation due to soil shear deformation, the Finn liquefaction model was applied and coupled with the Mohr-Coulomb elasto-plastic model. Soil nonlinearity was considered by applying hysteretic damping, and the interface model was applied to simulate various dynamic phenomena between the soil and pile. Simplified continuum modeling was introduced to prevent reflection wave generation and increase analysis efficiency. The applicability of the proposed numerical model was validated using the experimental results. Thereafter, a parametric study was conducted to provide a better understanding of the dynamic behavior of pile foundation during liquefaction. From a series of parametric studies, several important factors that can affect the dynamic pile responses in liquefiable sand were identified. Also, the characteristics of the dynamic soil–pile structure interactive behavior, which are significantly different from each other in liquefied and dry sand, were analyzed qualitatively and quantitatively. Full article
