Search Results (23)

The aim of this paper was to investigate the corrosion behaviour of zinc in simulated concrete solutions using resistometric sensors and to describe the kinetics of zinc corrosion. The sensors provide corrosion data information in real time; thus, it is a useful technique for observing zinc corrosion behaviour in concrete environments. The replacement of carbon steel rebar by galvanized steel in concrete is a discussable topic with contradictory results in the literature presented in the introduction. In our case, zinc resistometric sensors were used, and they showed results in good agreement with other techniques, such as corrosion potential monitoring and EIS measurements. According to our results, zinc is able to passivate in a simulated concrete solution and even in a simulated carbonated solution. The corrosion rate was reduced by almost 40 times, during the active to passive transition. The zinc remains passive even in simulated concrete solutions contaminated with low levels of chloride ions up to 0.9 wt.%. Full article

To evaluate the long term corrosion potential stability of stainless steel (SS) in environmental water, the corrosion potential of SUS304, SUS316, SUS316L, and SUS430 was measured for 1 week in a solution of 0.9 mM NaHCO₃ and 0.5 mM CaCl₂, referred to as “sub-tap water.” The potential of the SSs upon initial immersion in sub-tap water was approximately 10 times less stable than the potentials of Fe and Cu. However, as immersion continued, the stability of the corrosion potential of the SS improved and became equivalent to those of Fe and Cu. The stability could be manipulated by pretreatment (pre-immersion) before samples were immersed in sub-tap water. The stability was increased by pre-immersion in an acidic solution but was reduced by a passivation treatment. The formation of iron oxides on the SS surface stabilized the potential, whereas surface enrichment with Cr led to instability. This behavior can also be inferred from a comparison of the polarization curves, where the passive current after the passivation treatment was the largest. This result is also speculatively attributed to the corrosion potential in sub-tap water decreasing over time after the passivation treatment. The charge transfer resistance likely contributes significantly to the potential stability, as indicated by an equivalent circuit analysis based on electrochemical impedance spectroscopy. The results showed that, when stabilizing the corrosion potential of SS, there is no need to reduce the charge transfer resistance as with existing reference electrodes. Stability is achieved when the surface thickness is such that the pseudo-capacitance in a dilute solution is less than 10 µF s^α−1cm⁻² and potential stability does not influence a few changes in the CPE₁ value after potential stability is achieved. The results of this study show that SS can be used as a quasi-reference electrode material. We expect the findings presented herein to strongly affect the development of electrochemical sensors that can be easily used in long term continuous measurements and in situ applications. Full article

This work focuses on the fabrication and evaluation of a passive wireless sensor for the monitoring of the temperature and corrosion of a metal material at high temperatures. An inductor–capacitor (LC) resonator sensor was fabricated through the screen printing of Ag-based inks on dense polycrystalline Al₂O₃ substrates. The LC design was modeled using the ANSYS HFSS modeling package, with the LC passive wireless sensors operating at frequencies from 70 to 100 MHz. The wireless response of the LC was interrogated and received by a radio frequency signal generator and spectrum analyzer at temperatures from 50 to 800 °C in real time. The corrosion kinetics of the Cu 110 was characterized through thermogravimetric (TGA) analysis and microscopy images, and the oxide thickness growth was then correlated to the wireless sensor signal under isothermal conditions at 800 °C. The results showed that the wireless signal was consistent with the corrosion kinetics and temperature, indicating that these two characteristics can be further deconvoluted in the future. In addition, the sensor also showed a magnitude- and frequency-dependent response to crack/spallation events in the oxide corrosion layer, permitting the in situ wireless identification of these catastrophic events on the metal surface at high temperatures. Full article

This comprehensive review examines the phenomena of stress corrosion cracking (SCC) and chloride-induced stress corrosion cracking (Cl-SCC) in materials commonly used in the oil and gas industry, with a focus on austenitic stainless steels. The study reveals that SCC initiation can occur at temperatures as low as 20 °C, while Cl-SCC propagation rates significantly increase above 60 °C, reaching up to 0.1 mm/day in environments with high chloride concentrations. Experimental methods such as Slow Strain Rate Tests (SSRTs), Small Punch Tests (SPTs), and Constant-Load Tests (CLTs) were employed to quantify the impacts of temperature, chloride concentration, and pH on SCC susceptibility. The results highlight the critical role of these factors in determining the susceptibility of materials to SCC. The review emphasizes the importance of implementing various mitigation strategies to prevent SCC, including the use of corrosion-resistant alloys, protective coatings, cathodic protection, and corrosion inhibitors. Additionally, regular monitoring using advanced sensor technologies capable of detecting early signs of SCC is crucial for preventing the onset of SCC. The study concludes with practical recommendations for enhancing infrastructure resilience through meticulous material selection, comprehensive environmental monitoring, and proactive maintenance strategies, aimed at safeguarding operational integrity and ensuring environmental compliance. The review underscores the significance of considering the interplay between mechanical stresses and corrosive environments in the selection and application of materials in the oil and gas industry. Low pH levels and high temperatures facilitate the rapid progression of SCC, with experimental results indicating that stainless steel forms passive films with more defects under these conditions, reducing corrosion resistance. This interplay highlights the need for a comprehensive understanding of the complex interactions between materials, environments, and mechanical stresses to ensure the long-term integrity of critical infrastructure. Full article

Recycled carbon fibre (rCF) composites are increasingly being explored for applications such as strain sensing, manufacturing of automobile parts, assistive technologies, and structural health monitoring due to their properties and economic and environmental benefits. The high conductivity of carbon and its wide application for sensing makes rCF very attractive for integrating sensing into passive structures. In this paper, capacitive sensors have been fabricated using rCF composites of varying compositions. First, we investigated the suitability of recycled carbon fibre polymer composites for different sensing applications. As a proof of concept, we fabricated five touch/proximity sensors and three soil moisture sensors, using recycled carbon fibre composites and their performances compared. The soil moisture sensors were realised using rCF as electrodes. This makes them corrosion-resistant and more environmental-friendly, compared to conventional soil moisture sensors realised using metallic electrodes. The results of the touch/proximity sensing show an average change in capacitance (ΔC/C~34) for 20 mm and (ΔC/C~5) for 100 mm, distances of a hand from the active sensing region. The results of the soil moisture sensors show a stable and repeatable response, with a high sensitivity of ~116 pF/mL of water in the linear region. These results demonstrate their respective potential for touch/proximity sensing, as well as smart and sustainable agriculture. Full article

Coastal concrete structures, such as cross-sea bridges and tunnels, are susceptible to the penetration of chloride ions, which can lead to the deterioration of the passive film on the rebar surface, consequently accelerating the corrosion process. Conventional methods for monitoring chloride ions typically require in situ drilling for sample collection, thereby compromising efficiency and accuracy. Additionally, real-time monitoring and early warning cannot be achieved. To address these challenges, this work introduces a fluorescent-probe-based fiber optic sensor for monitoring chloride levels in concrete structures. Quinine sulfate was chosen as the fluorescent material due to its exceptional sensitivity to chloride ions and its stability in concrete environments. The proposed sensor was manufactured using sol–gel and 3D-printing techniques. Tests were conducted using concrete simulation fluid and cement mortar specimens. The results demonstrate that the sensitivity of the proposed sensor is greater than 0.01 M, and its accuracy in penetration depth measurement is better than 3 mm. The findings confirm that the designed fiber optic sensor based on quinine sulfate enables real-time monitoring of chloride ions in concrete structures, offering high sensitivity (0.1% in concentration and 2.7 mm in terms of penetration depth), unique selectivity (as it is immune to other ions whose concentrations are 10 times higher than those of Cl⁻), and a compact size (10 × 20 mm). These attributes render it promising for practical engineering applications. Full article

The crevice corrosion of the 7075-T651 aluminium alloy was investigated using in situ electrochemical impedance spectroscopy (EIS), potentiodynamic polarization curves (PC), and H⁺ sensors in acidic NaCl solution with different contents of NaNO₃. In the solution without NaNO₃, the pH in the crevice increased rapidly and gradually reached a relatively stable status. The corrosion of the aluminium alloy in the crevice was inhibited and crevice corrosion could not be initiated. In the solution with NaNO₃, the pH increased rapidly at the initial immersion period and then decreased gradually. The corrosion of the aluminium alloy inside the crevice could be enhanced and the corrosion of the aluminium alloy outside crevice could be inhibited. This triggered crevice corrosion in the solution with NaNO₃. The inhibited corrosion outside the crevice can be attributed to the improved passive film of the specimen outside the crevice by nitrate. The accumulated secondary products of ammonia inside the crevice led to selective dissolution of copper, which triggered the nucleation of pitting corrosion and promoted the corrosion of the specimen inside the crevice. Full article

Using distributed MEMS pressure sensors to measure small flow rates in high resistance fluidic channels is fraught with challenges far beyond the performance of the pressure sensing element. In a typical core-flood experiment, which may last several months, flow-induced pressure gradients are generated in porous rock core samples wrapped in a polymer sheath. Measuring these pressure gradients along the flow path requires high resolution pressure measurement while contending with difficult test conditions such as large bias pressures (up to 20 bar) and temperatures (up to 125 °C), as well as the presence of corrosive fluids. This work is directed at a system for using passive wireless inductive-capacitive (LC) pressure sensors that are distributed along the flow path to measure the pressure gradient. The sensors are wirelessly interrogated with readout electronics placed exterior to the polymer sheath for continuous monitoring of experiments. Using microfabricated pressure sensors that are smaller than ø15 × 3.0 mm³, an LC sensor design model for minimizing pressure resolution, accounting for sensor packaging and environmental artifacts is investigated and experimentally validated. A test setup, built to provide fluid-flow pressure differentials to LC sensors with conditions that mimic placement of the sensors within the wall of the sheath, is used to test the system. Experimental results show the microsystem operating over full-scale pressure range of 20,700 mbar and temperatures up to 125 °C, while achieving pressure resolution of <1 mbar, and resolving gradients of 10–30 mL/min, which are typical in core-flood experiments. Full article

With the development of fiber optical technologies, fiber Bragg grating (FBG) sensors are frequently utilized in structural health monitoring due to their considerable advantages, including fast response, electrical passivity, corrosion resistance, multi-point sensing capability and low-cost production, as well as high accuracy and resolution over a long period. These characteristics allow FBG to be a proper alternative sensing element for displacement measurements. In this article, the recent sensing advances and principles of detection of FBG-based displacement sensors are illustrated. Specifically, the latest FBG-based displacement technologies are examined from three principles of detection, i.e., wavelength, intensity and phase signal demodulation. Regarding wavelength detection methods, the problem related to the cross-sensitivity can significantly be reduced depending on the new type of cantilever–FBG-based sensing developed. Vice versa, only the packaging method of FBG prestressed between two fixed ends can still avoid the chirp phenomenon in the reflection spectrum. Moreover, to attenuate the influence of temperature variations on the accuracy of FBG displacement sensors, specific temperature self-compensation structures were successfully designed according to the concepts of phase signal demodulation. In future investigations, different elastic structures and gratings manufactured through special fibers and new methodologies for temperature compensation will still highly refine the efficiency of FBG-based displacement sensors. Full article

Improved corrosion barrier coatings (CBCs) to protect metals will allow future metal structures to operate for extended periods, ensuring improved safety by reducing environmental pollution and maintenance costs. Many production methods and design of corrosion barrier coatings (CBCs) have been developed. This review focuses only on CBCs made with chemistry techniques. These CBCs can be passive and active with remarkable performance. Today, most of the work focuses on the discovery and application of “smart nanomaterials,” which, if incorporated into “passive CBCs,” will turn them into “active CBCs,” giving them the phenomenon of “self-healing” that extends their service life. Today, many efforts are focused on developing sensors to diagnose corrosion at an early stage and CBCs that self-diagnose the environment and respond on demand. In addition, recent technological developments are reviewed, and a comprehensive strategy is proposed for the faster development of new CBC materials. Full article

Monolithic integration of permanent micromagnets into MEMS structures offers many advantages in magnetic MEMS applications. A novel technique called PowderMEMS, based on the agglomeration of micron-sized powders by atomic layer deposition (ALD), has been used to fabricate permanent micromagnets on 8-inch wafers. In this paper, we report the fabrication and magnetic characterization of PowderMEMS micromagnets prepared from two different NdFeB powder particle sizes. A remanence of 423 mT and intrinsic coercivity of 924 mT is achieved at the low ALD process temperature of 75 °C, making this process compatible with MEMS technology. The magnetic reversible mechanism in the micromagnets is discussed with the help of the Wohlfarth equation. To ensure the operability of such integrated micromagnets in different application environments, we conducted a set of experiments to systematically investigate the thermal and corrosive stability. NdFeB micromagnets with larger powder particle size (d50 = 25 µm) exhibit high thermal stability in air. Furthermore, the corrosion stability of the micromagnets is significantly improved by an additional silicon oxide passivation layer deposited by plasma-enhanced chemical vapor deposition (PECVD). The presented results demonstrate the durability of PowderMEMS micromagnets, enabling their application in various fields, e.g., microfluidics, sensors, actuators, and microelectronics. Full article

The publication describes the design, production, and practical verification of an alternative pressure sensor suitable for measuring the pressure of gas, based on a combination of fiber-optic technology and 3D printing methods. The created sensor uses FBG (Fiber Bragg Grating) suitably implemented on a movable membrane. The sensor is equipped with a reference FBG to compensate for the effect of ambient temperature on the pressure measurement. The sensor is characterized by its immunity to EM interference, electrical passivity at the measuring point, small size, and resistance to moisture and corrosion. The FBG pressure sensor has a pressure sensitivity of 9.086 pm/mbar in the range from 0 to 9 mbar with a correlation coefficient of 0.9982. The pressure measurement in the specified range shows an average measurement error of 0.049 mbar and a reproducibility parameter of 0.0269 ± 0.0135 mbar. Full article

Integrated instrumentation packages are an attractive option for environmental and ecological monitoring at marine energy sites, as they can support a range of sensors in a form factor compact enough for the operational constraints posed by energetic waves and currents. Here we present details of the architecture and performance for one such system—the Adaptable Monitoring Package—which supports active acoustic, passive acoustic, and optical sensing to quantify the physical environment and animal presence at marine energy sites. we describe cabled and autonomous deployments and contrast the relatively limited system capabilities in an autonomous operating mode with more expansive capabilities, including real-time data processing, afforded by shore power or in situ power harvesting from waves. Across these deployments, we describe sensor performance, outcomes for biological target classification algorithms using data from multibeam sonars and optical cameras, and the effectiveness of measures to limit biofouling and corrosion. On the basis of these experiences, we discuss the demonstrated requirements for integrated instrumentation, possible operational concepts for monitoring the environmental and ecological effects of marine energy converters using such systems, and the engineering trade-offs inherent in their development. Overall, we find that integrated instrumentation can provide powerful capabilities for observing rare events, managing the volume of data collected, and mitigating potential bias to marine animal behavior. These capabilities may be as relevant to the broader oceanographic community as they are to the emerging marine energy sector. Full article

In civil engineering, many structures are made of reinforced concrete. Most degradation processes relevant to this material, e.g., corrosion, are related to an increased level of material moisture. Therefore, moisture monitoring in reinforced concrete is regarded as a crucial method for structural health monitoring. In this study, passive radio frequency identification (RFID)-based sensors are embedded into the concrete. They are well suited for long-term operation over decades and are well protected against harsh environmental conditions. The energy supply and the data transfer of the humidity sensors are provided by RFID. The sensor casing materials are optimised to withstand the high alkaline environment in concrete, having pH values of more than 12. Membrane materials are also investigated to identify materials capable of enabling water vapour transport from the porous cement matrix to the embedded humidity sensor. By measuring the corresponding relative humidity with embedded passive RFID-based sensors, the cement hydration is monitored for 170 days. Moreover, long-term moisture monitoring is performed for more than 1000 days. The experiments show that embedded passive RFID-based sensors are highly suitable for long-term structural health monitoring in civil engineering. Full article
