In nature, dynamic liquid interfaces play a vital role in regulating gas transport, as exemplified by the adaptive mechanisms of plant stomata and the liquid-lined alveoli, which enable efficient gas exchange through reversible opening and closing. These biological processes provide profound insights into the design of advanced gas control technologies. Inspired by these natural systems, liquid gating membranes have been developed utilizing capillary-stabilized liquids to achieve precise fluid regulation. These membranes offer unique advantages of rapid responses, stain resistance, and high energy efficiency. Particularly, they break through the limitations of traditional solid, porous membranes in gas transport. This perspective introduces bioinspired liquid gating gas valve membranes (LGVMs), emphasizing their opening/closing mechanism. It highlights how external stimuli can be exploited to enable advanced, multi-level gas control through active or passive regulation strategies. Diverse applications in gas flow regulation and selective gas transport are discussed. While challenges related to precise controllability, long-term stability, and scalable production persist, these advancements unlock significant opportunities for groundbreaking innovations across diverse fields, including gas purification, microfluidics, medical diagnostics, and energy harvesting technologies. Full article

Solar trackers represent a significant advancement in enhancing the efficiency of solar energy collection. This study describes the development and implementation of a passive solar tracker featuring a single horizontal axis of rotation and an innovative guide slot mechanism. The tracker is designed to be used with solar radiation-capturing devices. The guide slot mechanism is specifically engineered for a designated date, location, and period to follow the solar trajectory accurately. A contact follower moves along the guide slot, which drives a tracker disk to rotate by the solar trajectory. The mechanism is activated by the movement of a liquid container attached to a spring, thereby storing potential energy. The container releases the liquid through a mechanical valve that regulates the container’s movement, while the guide slot mechanism converts this movement into controlled rotational motion, which is transferred to a mobile structure mounting the solar panel. Notably, the majority of materials utilized in this construction are recycled. Furthermore, the solar tracker proposed in this work is designed to be operable by individuals with limited prior knowledge on the topic, emphasizing the primary contribution of this study: its potential to revolutionize energy collection in developing countries and marginalized urban areas. No similar systems are found upon comparison with existing models in the literature. Experiments conducted with a static solar panel and the same panel integrated into the passive solar tracker revealed a 30.87% improvement in energy collection efficiency over static solar panels. Full article

A microfluidic passive valve (MPV) is important for precise flow control, and it determines the reliability of the microfluidic system. In this paper, a novel MPV capable of delivering a constant flow rate independently of inlet pressure changes is proposed. The flow rate of the MPV is adjusted by the difference between the fluid force on the upper surface of the valve core and the spring force. The constant flow rate of the MPV is maintained by automatically changing the size of the gap channel formed by the groove on the valve core and the baffle on the valve body. The nearly constant flow rate of the MPV is 6.26 mL/min, with a variation of 6.5% under the inlet pressure varied from 1.25 kPa to 3.5 kPa. In addition, the flow characteristics of the MPV are analyzed by numerical simulation. With the increase in the inlet pressure, the maximum velocity gradually increases, while the increment of the maximum velocity decreases. In the movement process of the valve core, the region of pressure drop becomes larger. This work has a certain reference value for the design and research of the MPVs with high throughput liquid delivery. Full article

The mechanical deformation of the ear canal induced by the temporomandibular joint movement constitutes a promising source of energy to power in-ear devices (hearing aids, communication earpieces, etc.). The large morphological variability of the human ear canal and its intrinsic dynamic characteristics—with displacement frequencies below 1.5 Hz with an average volume variation of 60 mm³—motivate the development of non-conventional dedicated energy harvesting methods. This paper demonstrates the concept and design of a modular hydraulic–piezoelectric self-actuated frequency up-conversion micromachine for energy harvesting. The mechanical energy is conveyed using a liquid-filled custom fitted earplug, which can be considered as a hydraulic pump. A hydraulic circuit composed of a pressure amplifier, two driven valves and two check valves allows to drive two micro-pistons. These micro-pistons actuate a bistable oscillator associated to a piezoelectric transducer allowing the low frequency mechanical excitation to be efficiently converted into electric energy through frequency-up conversion. The two integrated passively driven valves are based on tube buckling and allow the pistons to act alternatively on the oscillator to generate a backward and forward run for two jaw movements. A complete theoretical multiphysics model of the machine has been established for the design and evaluation of the potential of the proposed approach. Global analytical and refined FEM approaches have been combined to integrate the fluid and mechanical behaviors. Based on simulation and preliminary experimental data, the harvested energy is expected to be 8 µJ for one jaw closing, with a theoretical 40% end-to-end conversion efficiency. Full article

The threshold of microfluidic inertial switch is excessively dependent on the size of the passive valve structure and the gas–liquid surface energy of working liquid. How to achieve high threshold and anti-high overload using liquid with low viscosity and low surface tension is a challenging work. Based on the designed U-type microfluidic inertial switch, the electrical characteristic of salt solution at microscale as well as the threshold and dynamic electrical performance of switch were studied. The VOF and CSD modules in CFD software were employed to analyze the dynamic flow process, and then the air–liquid surface moving displacement curve was compared by the theoretical model. A self-designed acceleration test platform was utilized to measure the static threshold, dynamic threshold, and anti-high overload of the inertial switch. The results show that the U-type microfluidics inertial switch using salt solution as sensitive electrode has better performance in power connection and anti-high overload. In particular, it also has the ability to achieve a range of dynamic threshold by changing the placement of the contact electrode, which can achieve rapid power on and off. Full article

Understanding the mechanisms of snow adhesion to surfaces and its subsequent shedding provides means to search for active and passive methods to mitigate the issues caused by snow accumulation on surfaces. Here, a novel setup is presented to measure the adhesion strength of snow to various surfaces without altering its properties (i.e., liquid water content (LWC) and/or density) during the measurements and to study snow shedding mechanisms. In this setup, a sensor is utilized to ensure constant temperature and liquid water content of snow on test substrates, unlike inclined or centrifugal snow adhesion testing. A snow gun consisting of an internal mixing chamber and ball valves for adjusting air and water flow is designed to form snow with controlled LWC inside a walk-in freezing room with controlled temperatures. We report that snow adheres to surfaces strongly when the LWC is around 20%. We also show that on smooth (i.e., RMS roughness of less than 7.17 μm) and very rough (i.e., RMS roughness of greater than 308.33 μm) surfaces, snow experiences minimal contact with the surface, resulting in low adhesion strength of snow. At the intermediate surface roughness (i.e., RMS of 50 μm with a surface temperature of 0 °C, the contact area between the snow and the surface increases, leading to increased adhesion strength of snow to the substrate. It is also found that an increase in the polar surface energy significantly increases the adhesion strength of wet snow while adhesion strength decreases with an increase in dispersive surface energy. Finally, we show that during shedding, snow experiences complete sliding, compression, or a combination of the two behaviors depending on surface temperature and LWC of the snow. The results of this study suggest pathways for designing surfaces that might reduce snow adhesion strength and facilitate its shedding. Full article

We present a powerful and compact batch-mode mixing and dilution technique for centrifugal microfluidic platforms. Siphon structures are designed to discretize continuous flows into a sequence of droplets of volumes as low as 100 nL. Using a passive, self-regulating 4-step mechanism, discrete volumes of two fluids are alternatingly issued into a common intermediate chamber. At its base, a capillary valve acts as a fluidic shift register; a single droplet is held in place while two or more droplets merge and pass through the capillary stop. These merged droplets are advectively mixed as they pass through the capillary valve and into the receiving chamber. Mixing is demonstrated for various combinations of liquids such as aqueous solutions as well as saline solutions and human plasma. The mixing quality is assessed on a quantitative scale by using a colorimetric method based on the mixing of potassium thiocyanate and iron(III) chloride, and in the case of human plasma using a spectroscopic method. For instance, volumes of 5 µL have been mixed in less than 20 s. Single-step dilutions up to 1:5 of plasma in a standard phosphate buffer solution are also demonstrated. This work describes the preliminary development of the mixing method which has since been integrated into a commercially available microfluidic cartridge. Full article

The microvalve for accurate flow control under low fluidic pressure is vital in cost-effective and miniaturized microfluidic devices. This paper proposes a novel microfluidic passive valve comprising of a liquid chamber, an elastic membrane, and an ellipsoidal control chamber, which actualizes a high flow rate control under an ultra-low threshold pressure. A prototype of the microvalve was fabricated by 3D printing and UV laser-cutting technologies and was tested under static and time-dependent pressure conditions. The prototype microvalve showed a nearly constant flow rate of 4.03 mL/min, with a variation of ~4.22% under the inlet liquid pressures varied from 6 kPa to 12 kPa. In addition, the microvalve could stabilize the flow rate of liquid under the time-varying sinusoidal pressures or the square wave pressures. To validate the functionality of the microvalve, the prototype microvalve was applied in a gas-driven flow system which employed an air blower or human mouth blowing as the low-cost gas source. The microvalve was demonstrated to successfully regulate the steady flow delivery in the system under the low driving pressures produced by the above gas sources. We believe that this new microfluidic passive valve will be suitable for controlling fluid flow in portable microfluidic devices or systems of wider applications. Full article

A passive microvalve has appealing advantages in cost-effective and miniaturized microfluidic applications. In this work, we present a passive flow regulatory device for enhanced flow control in a microfluidic environment. The device was integrated with two functional elements, including a flow regulating valve and a flow check valve. Importantly, the flow regulating valve could maintain a stable flow rate over a threshold liquid pressure, and the flow check valve enabled effective liquid on/off control, thus accurate forward flow without any backward leakage was achieved. The flow performance of the flow regulating valve was analyzed through 3D FSI (Fluid-Structure Interaction) simulation, and several key parameters (i.e., fluidic channel height and width, control channel length, and Young’s modulus) were found to influence valve flow rate directly. To examine the flow characteristics of the device, we fabricated a prototype using 3D printing and UV laser cutting technologies, and the flow rates of the prototype under varied test pressures were measured in forward and reverse modes, respectively. Experimental results showed that nearly a constant flow rate of 0.42 ± 0.02 mL s⁻¹ was achieved in the forward mode at an inlet pressure range of 70 kPa to 130 kPa, and liquid flow was totally stopped in the reverse mode at a maximum pressure of 200 kPa. The proposed microfluidic flow regulatory device could be employed for accurate flow control in low-cost and portable Lab-on-a-Chip (LoC) applications. Full article

In this paper, we propose an easy-to-implement passive liquid valve (PLV) for the microfluidic compact-disc (CD). This valve can be implemented by introducing venting chambers to control the air flow of the source and destination chambers. The PLV mechanism is based on equalizing the main forces acting on the microfluidic CD (i.e., the centrifugal and capillary forces) to control the burst frequency of the source chamber liquid. For a better understanding of the physics behind the proposed PLV, an analytical model is described. Moreover, three parameters that control the effectiveness of the proposed valve, i.e., the liquid height, liquid density, and venting chamber position with respect to the CD center, are tested experimentally. To demonstrate the ability of the proposed PLV valve, microfluidic liquid switching and liquid metering are performed. In addition, a Bradford assay is performed to measure the protein concentration and evaluated in comparison to the benchtop procedure. The result shows that the proposed valve can be implemented in any microfluidic process that requires simplicity and accuracy. Moreover, the developed valve increases the flexibility of the centrifugal CD platform for passive control of the liquid flow without the need for an external force or trigger. Full article
