The production of cost-effective novel materials for PV solar cells with long-term stability, high energy conversion efficiency, enhanced photon absorption, and easy electron transport has stimulated great interest in the research community over the last decades. In the presented work, Cu/Cu₂S-MWCNTs nanocomposites were produced and analyzed in the framework of potential applications for PV solar cells. Firstly, the surface of the produced one-dimensional Cu was covered by Cu₂S nanoflake. XRD data prove the formation of both Cu and Cu₂S structures. The length and diameter of the one-dimensional Cu wire were 5–15 µm and 80–200 nm, respectively. The thickness of the Cu₂S nanoflake layer on the surface of the Cu was up to 100 nm. In addition, the Cu/Cu₂S system was enriched with MWCNTs. MWCNs with a diameter of 50 nm interact by forming a conductive network around the Cu/Cu₂S system and facilitate quick electron transport. Raman spectra also prove good interfacial coupling between the Cu/Cu₂S system and MWCNTs, which is crucial for charge separation and electron transfer in PV solar cells. Furthermore, UV studies show that Cu/Cu₂S-MWCNTs nanocomposites have a wide absorption band. Thus, MWCNTs, Cu, and Cu₂S exhibit an intense absorption spectrum at 260 nm, 590 nm, and 972 nm, respectively. With a broad absorption band spanning the visible–infrared spectrum, the Cu/Cu₂S-MWCNTs combination can significantly boost PV solar cells’ power conversion efficiency. Furthermore, UV research demonstrates that the plasmonic character of the material is altered fundamentally when CuS covers the Cu surface. Additionally, MWCN-Cu/Cu2S nanocomposite exhibits hybrid plasmonic phenomena. The bandgap of Cu/Cu₂S NWs was found to be approximately 1.3 eV. Regarding electron transfer and electromagnetic radiation absorption, the collective oscillations in plasmonic metal-p-type semiconductor–conductor MWCNT contacts can thus greatly increase energy conversion efficiency. The Cu/Cu₂S-MWCNTs nanocomposite is therefore a promising new material for PV solar cell application. Full article

Polymer-stabilized cholesteric liquid crystals (PSCLCs) have emerged as promising candidates for one-dimensional photonic lattices that enable precise tuning of the photonic band gap (PBG). This work systematically investigates the effect of polymer concentrations on the AC electric field-induced tuning of the PBG in PSCLCs, in so doing it explores a range of concentrations and provides new insights into how polymer concentration affects both the stabilization of cholesteric textures and the electro-optic response. We demonstrate that low polymer concentrations (≈3 wt. %) cause a blue shift in the short wavelength band edge, while high concentrations (≈10 wt. %) lead to a contraction and deterioration of the reflection band. Polarization optical microscopy was conducted to confirm the phase transition induced by the application of an electric field. The observations confirm that increased polymer concentration stabilizes the cholesteric texture. Particularly, the highly desired fingerprint texture was stabilized in a sample with 10 wt. % of the polymer, whereas it was unstable for lower polymer concentrations. Additionally, higher polymer concentrations also improved the dissymmetry factor and stability of the lasing emission, with the dissymmetry factor reaching the value of around 2 for samples with 10 wt. % of polymer additive. Our results provide valuable comprehension into the design of advanced PSCLC structures with tunable optical properties, enhancing device performance and paving the way for innovative photonic applications. Full article

We study the nested topological band-gap structure of one-dimensional (1D) photonic super-lattices. One cell of the super-lattice is composed of two kinds of photonic crystals (PhCs) with different topologies so that there is a domain wall (DW) state at the interface between the two PhCs. We find that the coupling of periodic DWs could form a new band-gap structure inside the original gap. The new band-gap structure could be topologically nontrivial, and a topological phase transition can occur if the structural or material parameters of the PhCs are tuned. Theoretically, we prove that the Hamiltonian of such coupled DWs can be reduced to the simple Su–Schrieffer–Heeger (SSH) model. Then, if two super-lattices carrying different topological phases are attached, a new topological interface state can occur at the interface between the two super-lattices. Finally, we find the nested topological band-gap structure in two-dimensional (2D) photonic super-lattices. Consequently, such nested topological structures can widely exist in complex super-lattices. Our work improves the topological study of photonic super-lattices and provides a new way to realize topological interface states and topological phase transitions in 1D and 2D photonic super-lattices. Topological interface states in super-lattices are sensitive to frequency and have high accuracy, which is desired for high-performance filters and high-finesse cavities. Full article

A new approach to determining the sensitivity of refractive index sensors is proposed. It has been shown that relative and absolute sensitivity show different results, and also, for the first time, it is demonstrated that relative sensitivity has advantages over absolute sensitivity. In addition, the influence of the relative width of the photonic band gap and the difference in the refractive indices of the layers on the sensitivity are examined and the corresponding dependences of these parameters are obtained. We propose these parameters as a convenient tool for optimizing the sensitivity of sensors based on defective photonic crystals. Finally, results are obtained regarding the behavior of the defect mode at the center of the photonic band gap of one-dimensional photonic crystals. Full article

The transfer matrix approach is used to study the optical characteristics of thermal radiation in a one-dimensional photonic crystal (1DPC) with metamaterial. In this method, every layer within the multilayer structure is associated with its specific transfer matrix. Subsequently, it links the incident beam to the next layer from the previous layer. The proposed structure is composed of three types of materials, namely InSb, ZrO₂, and Teflon, and one type of epsilon-negative (ENG) metamaterial and is organized in accordance with the laws of sequencing. The semiconductor InSb has the capability to adjust bandgaps by utilizing its thermally responsive permittivity, allowing for tunability with temperature changes, while the metamaterial modifies the bandgaps according to its negative permittivity. Using quasi-periodic shows that, in contrast to employing absolute periodic arrangements, it produces more diverse results in modifying the structure’s band-gaps. Using a new sequence arrangement mixed-quasi-periodic (MQP) structure, which is a combination of two quasi periodic structures, provides more freedom of action for modifying the properties of the medium than periodic arrangements do. The ability to control thermal radiation is crucial in a range of optical applications since it is frequently unpolarized and incoherent in both space and time. These configurations allow for the suppression and emission of thermal radiation in a certain frequency range due to their fundamental nature as photonic band-gaps (PBGs). So, we are able to control the thermal radiation by changing the structure arrangement. Here, the We use an indirect method based on the second Kirchoff law for thermal radiation to investigate the emittance of black bodies based on a well-known transfer matrix technique. We can measure the transmission and reflection coefficients with associated transmittance and reflectance, T and R, respectively. Here, the effects of several parameters, including the input beam’s angle, polarization, and period on tailoring the thermal radiation spectrum of the proposed structure, are studied. The results show that in some frequency bands, thermal radiation exceeded the black body limit. There were also good results in terms of complete stop bands for both TE and TM polarization at different incident angles and frequencies. This study produces encouraging results for the creation of Terahertz (THz) filters and selective thermal emitters. The tunability of our media is a crucial factor that influences the efficiency and function of our desired photonic outcome. Therefore, exploiting MQP sequences or arrangements is a promising strategy, as it allows us to rearrange our media more flexibly than quasi-periodic sequences and thus achieve our optimal result. Full article

The physical mechanisms supporting the existence of topological interface modes in photonic structures, formed with the concatenation of two finite, N-period, one-dimensional photonic crystals, are investigated. It is shown that these mechanisms originate from a specific configuration of bands and bandgaps of topological origin in the band structure of the concatenated structure. Our analysis reveals that the characteristics of such a configuration depend on the structural parameters, including the number, N, of unit cells, and determine the properties of the corresponding resonant transmission peak. It was shown that the width and maximum value of the transmission peaks decrease with N. These results not only provide new physical insight into the origin and nature of such modes, but also can be used to control and manipulate the transmission peak properties, such as peak values, full width at half maximum (FWHM), and Q-factor, which are of special interest in the fields of optical sensing, filters, etc. Full article

One-dimensional photonic crystals have been used in sensing applications for decades, due to their ability to induce highly reflective photonic bandgaps. In this study, one-dimensional photonic crystals with alternating low- and high-density layers were fabricated from a single photosensitive polymer (IP-Dip) by two-photon polymerization. The photonic crystals were modified to include a central defect layer with different elastic properties compared to the surrounding layers, for the first time. It was observed that the defect mode resonance can be controlled by compressive force. Very good agreement was found between the experimentally measured spectra and the model data. The mechanical properties of the flexure design used in the defect layer were calculated. The calculated spring constant is of similar magnitude to those reported for microsprings fabricated on this scale using two-photon polymerization. The results of this study demonstrate the successful control of a defect resonance in one-dimensional photonic crystals fabricated by two-photon polymerization by mechanical stimuli, for the first time. Such a structure could have applications in fields, such as micro-robotics, and in micro-opto–electro–mechanical systems (MOEMSs), where optical sensing of mechanical fluctuations is desired. Full article

Based on the transfer-matrix method, we theoretically explore the transmission and reflection properties of light waves in a one-dimensional defective photonic crystal composed of superconductor (HgBa₂Ca₂Cu₃O_8+δ) and semiconductor (GaAs) layers. The whole system is centrosymmetric and can generate a defect transmission peak in the photonic band gap. We study the effect of the temperature on the defect mode. Results obtained show that the defect mode shifts to the lower frequency regions as the value of the environmental temperature increases, and the resonance of the defect mode can be strengthened further as the number of periods increases. In addition, our findings reveal that the central wavelength of the defect mode increases with the increase in the environmental temperature and it presents a nearly linear relationship between the central wavelength of the defect mode and the temperature in cryogenic environments. Therefore, we can use the temperature response of the defect mode to detect the temperature. It is hoped that this study has potential applications for the development of cryogenic sensors with high sensitivity. Full article

A one-dimensional photonic crystal (1DPhC) with a defect layer is utilized as an optical filter in a simple realization of narrow linewidth LED-based sources. The 1DPhC comprising TiO${}_2$ and SiO${}_2$ layers is characterized by two narrow defect mode resonances within the 1DPhC band gap, or equivalently, by two peaks in the normal incidence transmittance spectrum at wavelengths of 625.4 nm and 697.7 nm, respectively. By combining the optical filter with LEDs, the optical sources are employed in interferometry experiments, and the defect mode resonances of a Lorentzian profile with linewidths of 1.72 nm and 1.29 nm, respectively, are resolved. In addition, a simple way to tune the resonances by changing the angle of incidence of light on the optical filter is demonstrated. All-dielectric optical filters based on 1DPhCs with a defect layer and combined with LEDs thus represent an effective alternative to standard coherent sources, with advantages including narrow spectral linewidths and variable output power, with an extension to tunable sources. Full article

Over the last several years, two-photon polymerization has been a popular fabrication approach for photonic crystals due to its high spatial resolution. One-dimensional photonic crystals with photonic bandgap reflectivities over 90% have been demonstrated for the infrared spectral range. With the success of these structures, methods which can provide tunability of the photonic bandgap are being explored. In this study, we demonstrate the use of mechanical flexures in the design of one-dimensional photonic crystals fabricated by two-photon polymerization for the first time. Experimental results show that these photonic crystals provide active mechanically induced spectral control of the photonic bandgap. An analysis of the mechanical behavior of the photonic crystal is presented and elastic behavior is observed. These results suggest that one-dimensional photonic crystals with mechanical flexures can successfully function as opto-mechanical structures. Full article

The anodizing of aluminium under oscillating conditions is a versatile and reproducible method for the preparation of one-dimensional photonic crystals (PhCs). Many anodizing parameters have been optimised to improve the optical properties of anodic aluminium oxide (AAO) PhCs. However, the influence of the crystallographic orientation of an Al substrate on the characteristics of AAO PhCs has not been considered yet. Here, the effect of Al substrate crystallography on the properties of AAO PhCs is investigated. It is experimentally demonstrated that the cyclic anodizing of coarse-grained aluminium foils produces a mosaic of photonic crystals. The crystallographic orientation of Al grains affects the electrochemical oxidation rate of Al, the growth rate of AAO, and the wavelength position of the photonic band gap. Full article

In this paper, we studied the transmission properties, including photonic band gap (PBG) and defect mode properties, of one-dimensional photonic crystals (1D PCs) consisting of gradient materials. When keeping the average refractive index of the gradient materials in the 1D gradient-material PCs (1D GPCs) the same as the index of the corresponding normal materials in the 1D normal-material PCs (1D NPCs), by transfer matrix method, we found that the complete 1D GPCs with high-index gradient materials benefit to achieve larger omni-PBG than that in 1D NPCs. In our high-index gradient material case, for TE(TM) wave, the optimal omni-PBGs in 1D GPCs with first- and second-order gradient materials are 38.6% (50.2%) and 15.9% (22.3%) larger than that in 1D NPCs; while for the optimal relative bandwidths of omni-PBG, the corresponding promotions are 41.1% (52.3%) and 16.1% (22.6%), respectively. In addition, when defective 1D GPCs have gradient-material defect, the position of defect modes can be adjusted by selecting proper parameters of the gradient materials. These types of research are useful for designing wide PBG devices and tunable narrow-band filters which have potential application in optical communication. Full article

In the current study, we aim to limit the power dissipation in amorphous silicon solar cells by enhancing the cell absorbance at different incident angles. The current improvement is justified by adding the single-period of ternary 1D photonic crystal with texturing on the top surface, which acts as an anti-reflecting coating. The texturing shape gives the photons at least two chances to localize inside the active area of the cell. Therefore, it increases the absorbance of the cell. Moreover, we add binary one-dimensional photonic crystals with the features of a photonic band gap, which acts as a back mirror to return the photons that were transmitted inside the cell’s active region. The considered structure is demonstrated by the well-defined finite element method (FEM) by using COMSOL multiphysics. Full article

It has been shown that the photonic bandgap of one-dimensional (1D) dielectric periodic thin films can vanish at the first Bragg condition for TM modes. Here, we address the case of 1D photonic crystal slabs formed by a chain of high-index dielectric particles with transversal confinement and show that the Bragg bandgap can vanish for both TE- and TM-like modes. Calculations using plane-wave expansion and finite-difference time-domain methods confirm that the PBG vanishes. PBG closure is explained as being a result of the interplay between the electric and magnetic dipole resonances of the isolated nanoparticle with Bragg resonance, as confirmed by calculating the electric and magnetic dipoles of the isolated nanobricks. This can be considered as a manifestation of the metamaterial behavior of the 1D system when using silicon as an underlying material. Our finding may have important consequences for the fields of photonic crystals and all-dielectric metamaterials. Full article

A novel lattice Boltzmann method (LBM) with a pseudo-equilibrium potential is proposed for electromagnetic wave propagation in one-dimensional (1D) plasma photonic crystals. The final form of the LBM incorporates the dispersive effect of plasma media with a pseudo-equilibrium potential in the equilibrium distribution functions. The consistency between the proposed lattice Boltzmann scheme and Maxwell’s equations was rigorously proven based on the Chapman–Enskog expansion technique. Based on the proposed LBM scheme, we investigated the effects of the thickness and relative dielectric constant of a defect layer on the EM wave propagation and defect modes of 1D plasma photonic crystals. We have illustrated that several defect modes can be tuned to appear within the photonic bandgaps. Both the frequency and number of the defect modes could be tuned by changing the relative dielectric constant and thickness of the defect modes. These strategies would assist in the design of narrowband filters. Full article
