As a technological advantage of ultrasonic non-destructive testing, fully focused imaging can accurately feedback the defective characteristics of the inspected object, greatly improving the detection efficiency. This article aims to address the challenges of outdated and low detection rates in the detection technology of branch pipe fillet welds. The full matrix acquisition (FMC) and total focus method (TFM) ultrasonic detection technology are used for detection and defect image feature analysis. Firstly, a multi-mode, fully focused real-time imaging software system was developed to address the specificity of the detection object; secondly, a phased array detection system based on 64 elements was constructed; finally, a region wavelet denoising method based on TFM images was proposed to solve the problem of artifacts caused by poor coupling; and based on the feature extraction method for a minimum rectangle, we analyzed the size, position, angle, and other information regarding defects. Through experiments, it has been found that this technology can effectively improve the detection efficiency of branch pipe weld defects, with a detection rate of 100%. Based on the partition fusion denoising method, the defect imaging quality can be further improved; at the same time, based on the feature extraction method, the error is 0.1 mm, the length range of various defects is 2.3 mm–6.3 mm, the width range is 0.6 mm–0.8 mm, and the angle range is 52°–75°, which can provide an application basis for the localization, classification, and risk assessment of corner weld defects in branch pipes. Full article

In addressing the design challenges for constant-stress accelerated life testing in non-rectangular experimental domains, we aim to optimize the precision in estimating parameters for the product reliability statistical model. Following the principles of regression orthogonal design theory to determine the combinations of stress levels, we constrain the maximum stress levels of each experimental stress along the boundary curve of the non-rectangular experimental domain. The remaining stress levels and the allocation ratios of specimens for each test serve as design variables in the optimization process. We establish a mathematical model for the optimal design of constant-stress accelerated life testing in non-rectangular experimental domains. The results of the optimized design for comprehensive stress accelerated life testing in non-rectangular experimental regions of aerospace electrical connectors indicate that, with the same sample size, the optimized testing scheme not only enhances the precision of model parameter estimation but also reduces the number of required tests. At an equivalent number of tests and testing duration, the optimization scheme proposed in this study demonstrates an improvement of over 63% in the precision of model parameter estimation compared to the EM-optimized testing scheme in non-rectangular experimental regions. Using the mean, standard deviation, and coefficient of variation of the determinant values of the information matrix as criteria for evaluating the precision and robustness of experimental designs, a simulated evaluation was conducted for the optimized experimental design, a conventional experimental design, and an EM experimental design. The results indicate that the optimal experimental design outperforms both the conventional experimental design and the EM experimental design in terms of precision and robustness. Full article

The freeform surface is treated as a single machining region for most traditional toolpath generation algorithms. However, due to the complexity of a freeform surface, it is impossible to produce a high-quality surface using one unique machining process. Hence, region-based methods are widely investigated for freeform surface machining to achieve an optimized toolpath. The Non-Uniform Rational B-spline Surface (NURBS) represented freeform surface is not suitable for region-based toolpath generation because of the surface gaps caused by NURBS trimming and merging operations. To solve the limitation of the NURBS, T-spline is proposed with the advantages of being gap-free, having less control points, and local refinement, which is an ideal tool for region-based toolpath generation. Thus, T-spline is introduced to represent a freeform surface for its toolpath generation in the paper. A region-based toolpath generation method for the T-spline surface is proposed based on watershed technology. Firstly, watershed-based feature recognition is presented to divide the T-spline surface into a set of sub-regions. Secondly, the concept of a PolyBoundingBox that consists of a set of minimum bounding boxes is proposed to describe the sub-regions, and Manufacturing-Suitable Regions are constructed with the help of T-spline local refinement and the PolyBoundingBox. In the end, an optimized multi-rectangles toolpath generation algorithm is applied for sub-regions. The proposed method is tested using three synthetic T-spline surfaces, and the comparison results show the advantage in toolpath length and toolpath reversing number. Full article
