Considering moment redistribution in the design of ultra-high-performance concrete (UHPC) statically indeterminate structures can fully exploit the load-bearing potential of members, simplify reinforcement details, and save construction costs. Due to the excellent properties of ultra-high-performance concrete (UHPC) that distinguish it from conventional concrete, new characteristics of the moment redistribution manifest in UHPC structures. In this study, a finite element (FE) analytical model was developed to simulate and analyze the bending behavior and moment redistribution of UHPC continuous beams reinforced with high-strength steel bars. The simulation and test results exhibited excellent agreement with the experimental research. Based on the FE model, a fine analysis for nine simulated two-span UHPC continuous beams was conducted with a detailed discussion of the failure modes, load-displacement curves, variations of support reaction forces, tensile strains of steel bars, and the whole process of moment redistribution. Subsequently, the variation rules of moment redistribution in UHPC continuous beams were explored by an extensive parametric study of 108 simulated beams. The studied parameters included a neutral axis depth factor, concrete strength, yielding strength of reinforcement, beam depth, span–depth ratio, reinforcement ratio between the mid-span and intermediate support section, as well as load forms. According to the numerical results, new formulas for estimating the two-stage moment redistribution in UHPC continuous beams with high-strength reinforcement were established. Finally, a comparison of moment redistribution between normal concrete continuous beams and UHPC continuous beams was performed. It can be observed that the elastic moment distribution in UHPC continuous beams was comparatively smaller, while the plastic moment distribution was relatively larger than those of normal concrete continuous beams. Overall, the degree of the total moment distribution in UHPC structures was greater than that of normal concrete structures due to the high ductility of UHPC. The research in this study may provide a technical reference for the practical engineering of UHPC. Full article

Bolted spherical joints, due to their prominent merits in installation, have been widely used in modern spatial structures. Despite significant research, there is a lack of understanding of their flexural fracture behaviour, which is important for the catastrophe prevention of the whole structure. Given the recent development to fill this knowledge gap, it is the objective of this paper to experimentally investigate the flexural bending capacity of the overall fracture section featured by a heightened neutral axis and fracture behaviour related to variable crack depth in screw threads. Accordingly, two full-scale bolted spherical joints with different bolt diameters were evaluated under three-point bending. The fracture behaviour of bolted spherical joints is first revealed with respect to typical stress distribution and fracture mode. A new theoretical flexural bending capacity expression for the fracture section with a heightened neutral axis is proposed and validated. A numerical model is then developed to estimate the stress amplification and stress intensity factors related to the crack opening (mode-I) fracture for the screw threads of these joints. The model is validated against the theoretical solutions of the thread-tooth-root model. The maximum stress of the screw thread is shown to take place at the same location as the test bolted sphere, while its magnitude can be greatly reduced with an increased thread root radius and flank angle. Finally, different design variants related to threads that have influences on the SIFs are compared, and the moderate steepness of the flank thread has been found to be efficient in reducing the joint fracture. The research findings could thus be beneficial for further improving the fracture resistance of bolted spherical joints. Full article

High-strength concrete (HSC) has been broadly applied to various civil structures for its advantages including high compressive strength and excellent durability and creep resistance. However, the brittleness of HSC raises concern about its use in practice. So far study on continuous reinforced HSC beams is limited. This work investigates the structural response of reinforced HSC continuous beams, and the results are compared with those of the counterparts made of normal-strength concrete (NSC). By applying a finite element method verified by experimental data, a comprehensive assessment is performed on two-span reinforced NSC and HSC (compressive strengths of 30, 60 and 90 MPa) continuous beams. A wide range of flexural reinforcement ratios are used to cover both under-reinforced and over-reinforced beams. The results show that reinforced HSC beams exhibit better flexural performance in terms of ultimate load, deformation, flexural ductility and moment redistribution, when compared to reinforced NSC beams. Formulae relating flexural ductility and moment redistribution with either neutral axis depth or tensile steel strain are suggested. Full article

This study presents three-point bending fracture tests on glass fiber-reinforced polymer (GFRP) reinforced concrete notched beams. Few studies have been conducted to date to understand the fracture behavior of this type of specimens. The specimens have nominal depth, width, and length equal to 150 mm, 150 mm, and 550 mm. Plain concrete notched beams with the same dimensions are cast from the same batch of concrete to compare the responses with GFRP reinforced concrete notched beams. The notch of the plain concrete specimens is either saw cut or cast. These two notch fabrication methods are compared based on the load responses. The peak load, crack mouth opening displacement (CMOD), GFRP bar slip at two ends, and load point displacement are used to discuss the results of the fracture tests. In addition, digital image analysis is performed to identify the fracture process zone (FPZ) and the location of the neutral axis, which are used to determine the force in the GFRP bar via cross-sectional analysis. Finally, the GFRP bar force versus slip responses are compared with those from the pull-out tests performed on the same bar to show that the bond of the bar in the pull-out tests represents an upper bound limit compared to the behavior in bending. Full article

A new type of composite voided slab, the TUBEDECK (TD), which utilizes the structural function of profiled steel decks, has recently been proposed. Previous studies have confirmed that the flexural strength of TD slabs can be calculated based on the full composite contribution of the steel deck, but for long-span flexural members, the deflection serviceability requirement is often dominant. Herein, we derived a novel deflection prediction approach using the results of flexural tests on slab specimens, focusing on TD slabs. First, deflection prediction based on modifications of the current code was proposed. Results revealed that TD slabs exhibited smaller long-term deflections and at least 10% longer maximum span lengths than solid slabs, indicating their greater efficiency. Second, a novel rational method was derived for predicting deflections without computing the effective moment of inertia. The ultimate deflections predicted by the proposed method correlated closely with the deflection under maximum bending moments. To calculate immediate deflections, variation functions for the concrete strain at the extreme compression fiber and neutral axis depth were assumed with predictions in good agreement with experiments. The proposed procedure has important implications in highlighting a new perspective on the deflection prediction of reinforced concrete and composite flexural members. Full article

This article presents an experimental study on the evolution of the neutral axis depth at failure in the critical section with the flexural ductility and plastic rotation capacity of reinforced concrete (RC) lightweight-aggregate concrete (LWAC) beams. For this, the results of a previous experimental program involving RC LWAC beams tested in flexure until failure are used. The variable studies were the concrete compressive strength (between 22.0 and 60.4 MPa and dry density between 1651 and 1953 kg/m³) and the longitudinal tensile reinforcement ratio (between 0.13% and 2.69%). The flexural ductility and the plastic rotation capacity of the RC LWAC beams are characterized by a ductility index and a plastic trend parameter, respectively. The influence of the variable studies, as well as the relation of the flexural ductility and plastic rotation capacity with the values for the neutral axis depth at failure are analyzed and discussed. Some conclusions are drawn which can be useful for the design of RC LWAC beams for flexure. In particular, it is shown that the practical rule of limiting the neutral axis depth at failure to ensure ductile behavior, as used in normal-weight aggregate concrete beams, is also valid for RC LWAC beams. Full article

The article analyses the calculation of the deflection of reinforced concrete beams strengthened with fiber reinforced polymer. This paper specifically focuses on estimating deflection when the yielding of reinforcement is reached. The article proposes a simple method for calculating deflection that was compared with the experimentally predicted deflection. The carried out comparison has showed that the proposed method is suitable not only for the strengthened beams but also for the reinforced concrete beams with a varying reinforcement ratio. The suggested calculation method is based on the effective moment of inertia, such as the one introduced in the ACI Committee 318 Building Code Requirement for Structural Concrete (ACI318). The development of deflection was divided into three stages, and equations for the effective moment of inertia were proposed considering separate stages. In addition, the put forward equations were modified attaching additional relative coefficients evaluating a change in the depth of the neutral axis. Full article

It is difficult to detect and evaluate the structural damage in a shield tunnel during operation because many traditional techniques based on the observation of vibrations are limited in daily monitoring in tunnels. Thus, the curvature radius of a static longitudinal settlement curve is used to identify the residual health and safety of an in-service shield tunnel. However, there are still two problems. The curvature radius is suitable for a qualitative judgment rather than a quantitative evaluation for longitudinal damage detection. Moreover, the curvature radius, which is calculated from the measured settlements of three neighboring points, gives an average damage degree in a wide scope only and is difficult to use to identify the damage’s precise location. By means of the analysis of three kinds of longitudinal failure modes in a shield tunnel, this paper proposes: (1) a damage detection method based on the monitored increment of the neutral axis depth; and (2) an index to evaluate longitudinal damage. The index is composed of the residual ratios of the equivalent flexural stiffness (HFM1) and the equivalent shear stiffness (HFM3). The neutral axis position and the proposed damage index can be determined using long-gauge Fiber Bragg Grating sensors. Results from numerical simulations show that the deviation between the HFM1 and the true value residual ratio of the equivalent flexural stiffness is no more than 1.7%. The HFM3 is equal to its true value in the entire damage process. A loading experiment for a scaled-down model of a shield tunnel using long-gauge Fiber Bragg Grating sensors indicated that the errors in the HFM1 were no more than 5.0% in the case of early damage development (HFM1 ≥ 0.5). The maximum error did not exceed 9.0% even under severe damage conditions in the model. Meanwhile, the HFM3 also coincided with its true value in the entire testing process. Full article

The neutral axis position (NAP) is a key parameter of a flexural member for structure design and safety evaluation. The accuracy of NAP measurement based on traditional methods does not satisfy the demands of structural performance assessment especially under live traffic loads. In this paper, a new method to determine NAP is developed by using modal macro-strain (MMS). In the proposed method, macro-strain is first measured with long-gauge Fiber Bragg Grating (FBG) sensors; then the MMS is generated from the measured macro-strain with Fourier transform; and finally the neutral axis position coefficient (NAPC) is determined from the MMS and the neutral axis depth is calculated with NAPC. To verify the effectiveness of the proposed method, some experiments on FE models, steel beam and reinforced concrete (RC) beam were conducted. From the results, the plane section was first verified with MMS of the first bending mode. Then the results confirmed the high accuracy and stability for assessing NAP. The results also proved that the NAPC was a good indicator of local damage. In summary, with the proposed method, accurate assessment of flexural structures can be facilitated. Full article
