Search Results (36)

The development of efficient and sustainable water recycling systems is essential for long-term human missions and the establishment of space habitats on the Moon, Mars, and beyond. Humidity condensate (HC) is a low-strength wastewater that is currently recycled on the International Space Station (ISS). The main contaminants in HC are primarily low-molecular-weight organics and ammonia. This has caused operational issues due to microbial growth in the Water Process Assembly (WPA) storage tank as well as failure of downstream systems. In addition, treatment of this wastewater primarily uses adsorptive and exchange media, which must be continually resupplied and represent a significant life-cycle cost. This study demonstrates the integration of a membrane-aerated biological reactor (MABR) for pretreatment and storage of HC, followed by brackish water reverse osmosis (BWRO). Two system configurations were tested: (1) periodic MABR fluid was sent to batch RO operating at 90% water recovery with the RO concentrate sent to a separate waste tank; and (2) periodic MABR fluid was sent to batch RO operating at 90% recovery with the RO concentrate returned to the MABR (accumulating salinity in the MABR). With an external recycle tank (configuration 2), the system produced 2160 L (i.e., 1080 crew-days) of near potable water (dissolved organic carbon (DOC) < 10 mg/L, total nitrogen (TN) < 12 mg/L, total dissolved solids (TDS) < 30 mg/L) with a single membrane (weight of 260 g). When the MABR was used as the RO recycle tank (configuration 1), 1100 L of permeate could be produced on a single membrane; RO permeate quality was slightly better but generally similar to the first configuration even though no brine was wasted during the run. The results suggest that this hybrid system has the potential to significantly enhance the self-sufficiency of space habitats, supporting sustainable extraterrestrial human habitation, as well as reducing current operational problems on the ISS. These systems may also apply to extreme locations such as remote/isolated terrestrial locations, especially in arid and semi-arid regions. Full article

With the increasing number of cislunar space missions, real-time and reliable navigation and communication services have become critical. It is necessary to develop the navigation constellations dedicated to cislunar space services. However, there are plenty of orbits in cislunar space providing alternative orbits, which makes constellation design a challenging task. To address this, this paper proposes a method for a cislunar navigation constellations configuration design via orbits with resonant periods. First, a periodic orbit catalog for the Earth–Moon system is constructed. Baseline orbits are selected from different orbital families, and all resonant orbits with periods proportional to the baseline orbits are compiled into a resonant orbit set. Second, a Dilution of Precision (DOP) model for navigation performance and a spatial zoning model are established. Then, resonant orbital combinations are screened based on orbital type composition, followed by resonance constellation generation according to predetermined constellation scales. All constellation configurations are categorized by orbital type to obtain a full resonant constellation set. Finally, the proposed method is applied to design optimal configurations providing navigation services for near-Earth and lunar regions. The simulation results shows that constellations combining L2 southern/northern Near-Rectilinear Halo Orbits (NRHOs) with vertical orbits at L4/L5 points deliver the optimal navigation performance in cislunar regions. The relationships between orbital radius and DOP values in target areas, as well as the DOP evolution patterns over constellation periods, are analyzed. The mean DOP values of the optimal constellation in both the near-Earth region and the lunar region increase as the spatial radius expands. Full article

Accurate localization is a key requirement for deep-space exploration, enabling spacecraft operations with limited ground support. Upcoming commercial and scientific missions to the Moon are designed to extensively use optical measurements during low-altitude orbital phases, descent and landing, and high-risk operations, due to the versatility and suitability of these data for onboard processing. Navigation frameworks based on optical data analysis have been developed to support semi- or fully-autonomous onboard systems, enabling precise relative localization. To achieve high-accuracy navigation, optical data have been combined with complementary measurements using sensor fusion techniques. Absolute localization is further supported by integrating onboard maps of cataloged surface features, enabling position estimation in an inertial reference frame. This study presents a navigation framework for optical image processing aimed at supporting the autonomous operations of lunar orbiters. The primary objective is a comprehensive characterization of the navigation camera’s properties and performance to ensure orbit determination uncertainties remain below 1% of the spacecraft altitude. In addition to an analysis of measurement noise, which accounts for both hardware and software contributions and is evaluated across multiple levels consistent with prior literature, this study emphasizes the impact of process noise on orbit determination accuracy. The mismodeling of orbital dynamics significantly degrades orbit estimation performance, even in scenarios involving high-performing navigation cameras. To evaluate the trade-off between measurement and process noise, representing the relative accuracy of the navigation camera and the onboard orbit propagator, numerical simulations were carried out in a synthetic lunar environment using a near-polar, low-altitude orbital configuration. Under nominal conditions, the optical measurement noise was set to 2.5 px, corresponding to a ground resolution of approximately 160 m based on the focal length, pixel pitch, and altitude of the modeled camera. With a conservative process noise model, position errors of about 200 m are observed in both transverse and normal directions. The results demonstrate the estimation framework’s robustness to modeling uncertainties, adaptability to varying measurement conditions, and potential to support increased onboard autonomy for small spacecraft in deep-space missions. Full article

The lunar south pole has gained significant attention due to its unique scientific value and potential for supporting future human exploration. Its potential water ice reservoirs and favourable conditions for long-term habitation make it a strategic target for upcoming space missions. This has led to a continuous increase in missions towards the Moon thanks mainly to the boost provided by NASA’s Artemis programme. This study focuses on designing a satellite constellation to provide communication coverage for the lunar south pole. Among the various cislunar orbits analysed, the halo orbit families near Earth–Moon Lagrangian points L1 and L2 emerged as the most suitable ones for ensuring continuous communication while minimising the number of satellites required. These orbits, first described by Farquhar in 1966, allow spacecraft to maintain constant communication with Earth due to their unique geometric properties. The candidate orbits were initially implemented in MATLAB using the Circular Restricted Three-Body Problem (CR3BP) to analyse their main features such as stability, periodicity, and coverage time percentage. In order to develop a more detailed and realistic scenario, the obtained initial conditions were refined using a full ephemeris model, incorporating a ground station located near the Connecting Ridge Extension to evaluate communication performance depending on the minimum elevation angle of the antenna. Different multi-body constellations were propagated; however, the constellation consisting of three satellites around L2 and a single satellite around L1 turned out to be the one that best matches the coverage requirements. Full article

We detail the use of the University of Tasmania’s (UTAS) optical and radio telescopes to conduct observations of near-Earth asteroids from 2021 to 2024. The Canberra Deep Space Communication Complex transmitted a radio signal at 7159.45 MHz, with the radar echo detected by the UTAS radio telescopes. The method of accounting for the Doppler shift between the stations and the near-Earth object is described so that others can implement a similar program. We present our results, with confirmed detections of 1994 PC1 and 2003 UC20 asteroids using the Hobart and Katherine 12-m antennas, demonstrating the feasibility of using small radio telescopes for these observations. Additionally, the recently upgraded Ceduna 30 m antenna was used to detect 2024 MK. Data collected from other observatories, such as Tidbinbilla, as well as the UTAS radar tracking of the moon are also presented in the context of demonstrating the means of applying these Doppler corrections and the accuracy of each method. Optical observations conducted in this period are also detailed as they complement radar observations and aid in refining the orbit parameters. Full article

Nanophase iron (np-Fe) is widely distributed on the surface of lunar soil particles, forming as a result of space weathering. These np-Fe particles contribute to the reddening and darkening of the visible to near-infrared spectra of weathered lunar material and serve as critical indicators for assessing the maturity of lunar soil. (1) This article reviews the proposed formation mechanisms of np-Fe particles from studies of Apollo and Luna soils, including the thermal reduction of iron melts, vapor deposition caused by micrometeorite impacts, and hydrogen reduction due to solar wind exposure. (2) Additionally, recent findings from the analysis of Chang’E-5 lunar soil are highlighted, revealing new mechanisms such as sub-solidus decomposition of olivine, impact-driven disproportionation, and FeO eutectic reactions. (3) Experimental studies simulating space weathering through laser and ion irradiation are also discussed and compared. Despite extensive research, a definitive understanding of np-Fe particle formation remains elusive. Previous lunar soil samples have been collected from the near side of the Moon. This year, the Chang’E-6 mission has successfully returned the first-ever lunar soil samples from the far side. These samples are expected to exhibit unique space weathering characteristics, providing new insights into the formation mechanisms of np-Fe in lunar soil. Full article

In this paper, the finite element method (FEM) is integrated with orthogonal polynomial approximation in high-dimensional spaces to innovatively model the Moon’s surface gravity anomaly. The aim is to approximate solutions to Laplace’s classical differential equations of gravity, employing classical Chebyshev polynomials as basis functions. Using classical Chebyshev polynomials as basis functions, the least-squares approximation was used to approximate discrete samples of the approximation function. These test functions provide an understanding of errors in approximation and corresponding errors due to differentiation and integration. These test functions provide an understanding of errors in approximation and corresponding errors due to differentiation and integration. The first application of this project is to substitute the globally valid classical spherical harmonic series of approximations with locally valid series of orthogonal polynomial approximations (i.e., using the FEM approach). With an error tolerance set at ${10}^{-9}$$\mathrm{m}{\mathrm{s}}^{-2}$, this method is used to adapt the gravity model radially upwards from the lunar surface. The results showcase a need for a higher degree of approximation on and near the lunar surface, with the necessity decreasing as the radius increases. Notably, this method achieves a computational speedup of five orders of magnitude when applying the method to radial adaptation. More intrinsically, the second application involves using the methodology as an effective tool in solving boundary value problems. Specifically, this approach is implemented to solve classical differential equations involved with high-precision, long-term orbit propagation. This application provides a four-order-of-magnitude speedup in computational time while maintaining an error within the ${10}^{-10}$$\mathrm{m}{\mathrm{s}}^{-2}$ error range for various orbit propagation tests. Alongside the advancements in orthogonal approximation theory, the FEM enables revolutionary speedups in orbit propagation without compromising accuracy. Full article

Space-based observations of the total lunar eclipse on 21 January 2019 were conducted using the geostationary Earth-orbiting satellite Gaofen-4 (GF-4). This study represents a pioneering effort to address the observational gap in full-disk lunar eclipse photometry from space. With its high resolution and ability to capture the entire lunar disk, GF-4 enabled both quantitative and qualitative analyses of the variations in lunar brightness, as well as spectra and color changes, across two spatial dimensions, from the whole lunar disk to resolved regions. Our results indicate that before the totality phase of the lunar eclipse, the irradiance of the Moon diminishes to below approximately 0.19% of that of the uneclipsed Moon. Additionally, we observed an increase in lunar brightness at the initial entry into the penumbra. This phenomenon is attributed to the opposition effect, providing scientific evidence for this unexpected behavior. To investigate detailed spectral variations, specific calibration sites, including the Chang’E-3 landing site, MS-2 in Mare Serenitatis, and the Apollo 16 highlands, were analyzed. Notably, the red-to-blue ratio dropped below 1 near the umbra, contradicting the common perception that the Moon appears red during lunar eclipses. The red/blue ratio images reveal that as the Moon enters Earth’s umbra, it does not simply turn red; instead, a blue-banded ring appears at the boundary due to ozone absorption and the lunar surface composition. These findings significantly enhance our understanding of atmospheric effects on lunar eclipses and provide crucial reference information for the future modeling of lunar eclipse radiation, promoting the integration of remote sensing science with astronomy. Full article

Communication transmission in the near-Moon space is a critical enabler of scientific exploration in this region. However, the communication network in near-Moon space shows trends of diversification, heterogeneity, and collaboration, posing significant challenges to the management of an integrated communication network. This paper proposes a networking routing method for near-Moon-space cross-domain network transmission. Considering the constraints of heterogeneous networks including Moon–Earth, Moon–surface, and relay transmission, the method enhances transmission routing efficiency at the network layer of near-Moon-space systems, thereby improving the overall efficiency of heterogeneous network interactions. This research focuses on the networking routing of cross-domain networks. To simplify the research problem, a mixed link resource and scheduling model of heterogeneous networks is proposed. Based on this model, a time-varying and fixed topology network sub-network clustering method was designed to reduce the complexity of the routing algorithm. A routing scheduling algorithm is provided in combination with hierarchical routing search, and related experiments and comparisons were carried out. Finally, considering the practical issues of communication relay channels and rate limitations in relay satellites, time windows and communication rate constraints were used to enhance the reliability of the simulation validation. Simulation results show that this method effectively addresses the issue of low transmission interaction efficiency in heterogeneous networks within cislunar space. Compared with previous designs, it improves link load rate by 31%, reduces average service delay by 8%, and significantly enhances link stability and load rate. Full article

In the realm of precision space applications, improving the accuracy of orbit determination (OD) is a crucial and demanding task, primarily because of the presence of measurement noise. To address this issue, a novel machine learning method based on bidirectional long short-term memory (BiLSTM) is proposed in this research. In particular, the proposed method aims to improve the OD accuracy of Earth–Moon Libration orbits with angle-only measurements. The proposed BiLSTM network is designed to detect inaccurate measurements during an OD process, which is achieved by incorporating the least square method (LSM) as a basic estimation approach. The structure, inputs, and outputs of the modified BiLSTM network are meticulously crafted for the detection of inaccurate measurements. Following the detection of inaccurate measurements, a compensating strategy is devised to modify these detection results and thereby reduce their negative impact on OD accuracy. The modified measurements are then used to obtain a more accurate OD solution. The proposed method is applied to solve the OD problem of a 4:1 synodic resonant near-rectilinear halo orbit around the Earth–Moon L2 point. The training results reveal that the bidirectional network structure outperforms the regular unidirectional structures in terms of detection accuracy. Numerical simulations show that the proposed method can reduce the estimated error by approximately 10%. The proposed method holds significant potential for future missions in cislunar space. Full article

The NASA’s Artemis project intends to bring humans back to the Moon in the next decade. A key element of the project will be the Lunar Gateway, a space station placed in a peculiar, near rectilinear Halo orbit in the vicinity of a collinear libration point in the Earth–Moon system. This study focuses on the high-fidelity description of the relative orbit dynamics of a chaser spacecraft with respect to the Gateway, as well as on the design of a proper orbit control strategy for rendezvous maneuvers. A novel formulation of the Battin–Giorgi approach is introduced, in which the reference orbit is that traveled by the Gateway, i.e., it is a highly non-Keplerian, perturbed orbit. The modified Battin–Giorgi approach allows for the description of a relative orbit motion with no restrictive assumption, while including all the relevant orbit perturbations on both the chaser and the Gateway. Moreover, nonlinear hybrid predictive control is introduced as a feedback guidance strategy. This new technique is shown to outperform the classical, well-established feedback linearization in terms of success rate and accuracy on the final conditions. Moreover, a Monte Carlo analysis confirms that hybrid predictive control is also effective in the presence of the temporary unavailability of propulsion or thrust misalignment. Full article

In the near future, international space agencies have planned to achieve significant milestones in investigating the utilization of Global Navigation Satellite Systems (GNSS) within and beyond the current space service volume up to their application to lunar missions. These initiatives aim to demonstrate the feasibility of GNSS navigation at lunar altitudes. Based on the outcomes of such demonstrations, dozens of lunar missions will likely be equipped with a GNSS receiver to support autonomous navigation in the lunar proximity. Relying on non-invasive, consolidated differential techniques, GNSS will enable baseline estimation, thus supporting a number of potential applications to lunar orbiters such as collaborative navigation, formation flight, orbital manoeuvers, remote sensing, augmentation systems and beyond. Unfortunately, the large dynamics and the geometry of such differential GNSS scenarios set them apart from current terrestrial and low-earth orbit use cases. These characteristics result in an increased sensitivity to measurements time misalignment among orbiters. Hence, this paper offers a review of baseline estimation methods and characterizes the divergences and limitations w.r.t. to terrestrial applications. The study showcases the estimation of the baseline length between a lunar CubeSat mission, VMMO, and the communication relay Lunar Pathfinder mission. Notably, real GNSS measurements generated by an Engineering Model of the NaviMoon receiver in the European Space Agency (ESA/ESTEC) Radio Navigation Laboratory are utilized. A radio-frequency constellation simulator is used to generate the GNSS signals in these hardware-in-the-loop tests. The performed analyses showed the invalidity of common terrestrial differential GNSS ranging techniques for space scenarios due to the introduction of significant biases. Improved ranging algorithms were proposed and their potential to cancel ranging errors common to both receivers involved was confirmed. Full article

Lithium, a critical natural resource integral to modern technology, has influenced diverse industries since its discovery in the 1950s. Of particular interest is lithium-7, the most prevalent lithium isotope on Earth, playing a vital role in applications such as batteries, metal alloys, medicine, and nuclear research. However, its extraction presents significant environmental and logistical challenges. This article explores the potential for lithium exploration on the Moon, driven by its value as a resource and the prospect of cost reduction due to the Moon’s lower gravity, which holds promise for future space exploration endeavors. Additionally, the presence of lithium in the solar wind and its implications for material transport across celestial bodies are subjects of intrigue. Drawing from a limited dataset collected during the Apollo missions (Apollo 12, 15, 16, and 17) and leveraging artificial intelligence techniques and sample expansion through bootstrapping, this study develops predictive models for lithium-7 concentration based on spectral patterns. The study areas encompass the Aitken crater, Hadley Rima, and the Taurus–Littrow Valley, where higher lithium concentrations are observed in basaltic lunar regions. This research bridges lunar geology and the formation of the solar system, providing valuable insights into celestial resources and enhancing our understanding of space. The data used in this study were obtained from the imaging sensors (infrared, visible, and ultraviolet) of the Clementine satellite, which significantly contributed to the success of our research. Furthermore, the study addresses various aspects related to statistical analysis, sample quality validation, resampling, and bootstrapping. Supervised machine learning model training and validation, as well as data import and export, were explored. The analysis of data generated by the Clementine probe in the near-infrared (NIR) and ultraviolet-visible (UVVIS) spectra revealed evidence of the presence of lithium-7 (Li-7) on the lunar surface. The distribution of Li-7 on the lunar surface is non-uniform, with varying concentrations in different regions of the Moon identified, supporting the initial hypothesis associating surface Li-7 concentration with exposure to solar wind. While a direct numerical relationship between lunar topography and Li-7 concentration has not been established due to morphological diversity and methodological limitations, preliminary results suggest significant economic and technological potential in lunar lithium exploration and extraction. Full article

The launch azimuth of the Naro Space Center is limited toward the south of the Korean peninsula, at 170 ± 10 degrees, suitable for the polar orbit, sun-synchronous orbit, and safety range issues. In this circumstance, one option to send a satellite into GEO is to perform a dog-leg maneuver during ascent, thus forming a medium-inclination orbit under such a restrictive condition. However, this option requires an immense amount of energy for the dog-leg maneuver, as well as a plane change maneuver. The only remaining option is to raise the apogee to the Moon, utilizing lunar gravity to lower the inclination to near zero and then returning to the vicinity of the Earth at an altitude of 35,786 km without maneuver. In order to design lunar-assisted GEO transfer, all feasible paths are defined, but questions remain about how seasonal variations affect all these potential paths. Therefore, this study aims to design and analyze all available trajectories for the year 2031 using a high-fidelity dynamic model, root-finding algorithm, and well-arranged initial conditions, focusing on the impact of seasonal trends. The simulation results indicate that cislunar free-return trajectories generally require less $\mathit{\Delta }V$ compared to circumlunar free-return trajectories, and circumlunar trajectories are minimally affected by lunisolar effects due to their relatively short return time of flight. Conversely, cislunar trajectories show seasonal variations, so spring and fall seasons require up to 20 m/s less $\mathit{\Delta }V$ than summer and winter seasons due to the relatively long time of return duration. Full article

This paper investigates the trajectory design problem in the scenario of a multiple Sun-synchronous Orbit (SSO) space debris flyby mission from a DRO space station. At first, the characteristics of non-planar transfer from DRO to SSO in the Earth–Moon system are analyzed. The methods of large-scale ergodicity and pruning are utilized to investigate single-impulse and two-impulse DRO–Earth transfers. Using a powered lunar flyby, the two-impulse DRO–Earth transfer is able to fly by SSO debris while satisfying the requirements of the mission. After the local optimization, the optimal result of two-impulse DRO–Earth transfer and flyby is obtained. A multi-objective evolutionary algorithm is used to design the Pareto-optimal trajectories of multiple flybys. The semi-analytical optimization method is developed to provide the estimations of the transfer parameters in order to reduce the computations caused by the evolutionary algorithm. Simulations show that transferring from the 3:2 resonant DRO to a near-coplanar flyby of a SSO target debris using a powered lunar gravity assist needs a 0.47 km/s velocity increment. The mission’s total velocity increment is 1.39 km/s, and the total transfer time is 2.23 years. Full article
