Search Results (31)

The mean stress effect remains a critical aspect in multiaxial fatigue analysis. This work presents a new criterion that, based on the classical Findley criterion, applies a material-dependent exponent to the mean normal stress term and includes the ultimate tensile stress as a fitting parameter. This way of considering the non-linear effect of the mean stress, with a material-dependent rather than a fixed exponent, is totally innovative among the multiaxial fatigue criteria found in the literature. In order to verify its accuracy, the new criterion has been checked against an extended version of the Papuga database of multiaxial experimental tests with 485 results, and compared with the criteria by Findley, Robert, and Papuga. The new criterion provides outstanding results for pure uniaxial cases, with multiaxial performance similar to the Robert criterion with a smaller range of error and a conservative trend, even surpassing the popular Papuga method in several relevant loading scenarios. These features enhance the applicability and versatility of the criterion for its use in the fatigue design of structural components. Full article

Twin-roll casting is a technology for the production of thin strips directly from liquid metal by combining continuous casting with hot rolling in a single step. The thermo-mechanical cyclic interaction with the solidifying strip causes fatigue crack formation at the outer surface of the rolls. A 2D FEM model with Eulerian boundary conditions and the interference fit load on the rolls was defined. The influence of the roll–strip thermal contact, the inlet temperature of the liquid aluminum, the efficiency of the water cooling and the production rate on the fatigue damage of the rolls was analyzed with a parametric study. The maximum temperature of the rolls, the maximum contact pressure, the accumulated plastic strain and the equivalent strain computed (considering a multiaxial out-of-phase fatigue criterion) were considered to investigate the thermo-mechanical fatigue load on the rolls. The results showed that, in the considered range, the most influential parameters on the fatigue mechanism are the heat contact conductance coefficient, which dominates the thermo-mechanical load, and the tangential velocity of the rolls, which contributes to the thermal field and determines the roll–strip mechanical contact interaction. Full article

The fatigue performance of steel–concrete composite beams is crucial for ensuring structural safety. To account for the member’s multiaxial stress state, this study employed the critical surface method, using fatigue damage parameters as an evaluation index for assessing fatigue performance. Static and fatigue performance tests on steel–concrete beams were conducted to identify failure characteristics, which informed the development of a finite element model that incorporates concrete damage. Using the SWT model, the most unfavorable loading parameters were determined by analyzing critical paths on the test beams, providing a basis for predicting how initial defects impact fatigue performance. The impact of initial defects on the fatigue performance of the composite beam is assessed using this criterion. The results indicate that the discrepancy between the actual and predicted load capacities of the test beam is within 5%, and cyclic loading significantly affects the test beam’s mechanical properties, resulting in a 27% reduction in load capacity and a 48% increase in deflection after 2 million cycles. Finite element modeling reveals that components experience multiaxial stress, with test beam mechanical property changes aligning with predicted fatigue damage parameters, confirming the reliability of using these parameters as a criterion. As the strength of the composite beams diminished due to pore defects, the fatigue damage parameter escalated, increasing the likelihood of crack formation. However, once the concrete’s strength fell to a level where the pegs were insufficiently constrained, the structural damage pattern shifted, and the fatigue damage parameter subsequently decreased. Full article

Based on the dynamic characteristics of the axle box front cover of high-speed trains in the subharmonic resonance state, the nonlinear single-degree-of-freedom (SDOF) model was proved to be reasonable, and reasons for the ineffectiveness of the common prevention methods for preventing bolt failure were analyzed firstly. Then, dynamic stress of the bolt was simulated by innovatively adopting the linear method based on frequency response analysis. The stress simulation method was verified to be practical under the subharmonic resonance state by analyzing and comparing the experimental and numerical results of the bolted front cover. It was proved that the linear method was accurate enough to simulate the dynamic stress of bolts, which is of great engineering significance. In addition to the transverse resonance stress of bolts caused by drastic vertical vibration of the front cover, the tensile resonance stress at the root of the first engaged thread was too large to be neglected on account of the first-order bending modes of bolts. Next, equivalent stress amplitude of the multiaxial stresses was obtained by means of the octahedral shear stress criterion. Finally, fatigue life of bolts was predicted in terms of S-N curve suitable for bolt fatigue life analysis. It argued that the bolts were prone to multiaxial fatigue failure when the front cover was in subharmonic resonance for more than 26.8 h, and the fatigue life of bolts could be greatly improved when the wheel polygonization was eliminated by shortening the wheel reprofiling interval. Full article

As is well-known, non-proportional fatigue loading, such as asynchronous one, can have significant detrimental effects on the fatigue behavior of metallic materials by reducing the fatigue strength/fatigue limit and by leading to a fatigue damage accumulation increased with respect to that under proportional loading. In the present paper, the novel refined equivalent deformation (RED) criterion is applied for the first time to estimate the fatigue lifetime of materials, sensitive to non-proportionality, subjected to asynchronous loading under low-cycle fatigue regime. The present criterion is complete since it considers: (i) the strain path orientation, (ii) the degree of non-proportionality, and (iii) the changing of material cyclic properties under non-proportional loading. To evaluate its accuracy, this criterion is applied to examine two different metals (a 304 stainless steel and a 355 structural steel) whose experimental data under multiaxial asynchronous loading are available in the literature. More precisely, the parameters of the criterion are firstly determined by using experimental strain paths, and then the computed refined equivalent deformation amplitude is used to represent the experimental data with a satisfactory accuracy. Finally, a comparison with the results obtained through two other criteria available in the literature is performed, highlighting the good prediction of the present RED criterion. Full article

Rocket engine thrust chambers withstand very high temperatures and thermal gradients during service that induce multiple damaging phenomena such as plasticity, low-cycle-fatigue (LCF) and creep. Numerical models can be used during the design of these mechanical components in order to simulate the main mechanical damaging processes, accounting for complex material behavior as due to non-linear hardening phenomena and viscoplasticity. This work represents an improvement upon previous research by the authors, with particular reference to the addition of the Wang–Brown fatigue criterion, to consider the effects of multiaxiality and non-proportionality of loads, and the Voce model to account for non-linear isotropic hardening. A precipitation hardened copper alloy has been considered as the material of the thrust chamber internal structure. The most critical areas resulted to be on the internal surface of the chamber and in particular in correspondence of the throat region, consistently with experimental tests available in the literature conducted on similar geometries. Results demonstrated that low cycle fatigue and thermal ratcheting (plastic instability) are the dominant damaging phenomena for the considered test case. Full article

This paper presents the results of a stress analysis and fatigue life calculation of an HPDC mould core. The calculations were performed using Abaqus and fe-safe software. The numerical model of a core cooled by a conformal channel was based on an existing and working counterpart made of additively manufactured high-strength 1.2709 maraging steel. This study shows that the conformal channel results in a lower average core temperature as compared to the temperature of the same core shape cooled by the conventional method. The course of the stress changes during the mould cycle was also determined. It was found that stresses on the core surface caused the cyclic compression and tension of the material. The necessary strength tests of 1.2709 steel produced by selective laser melting (SLM) within a temperature range of 25 to 550 °C, which were necessary to define the fatigue coefficients by the Seeger approximation method, were also carried out in this study, along with metallographic tests of the fractures of the specimens. Based on the multiaxial fatigue criterion and using the maximum principal deformation hypothesis, the fatigue life of the core and channel surfaces was determined. Based on the calculations, it was shown that crack initiation on the channel surface can occur earlier than on the outer surface of the core. Full article

The goal of the present paper is to discuss the accuracy and reliability of a procedure for the fatigue strength estimation of defective metals by considering some experimental data available in the literature. In particular, the fatigue behaviour of three ductile cast irons (DCIs) containing solidification defects (i.e., micro-shrinkage porosity) is simulated through the above a procedure, based on the joined application of the $\sqrt{area}$-parameter model and the Carpinteri et al. multiaxial fatigue criterion. The fatigue strength of such DCIs subjected to both uniaxial (rotating bending or torsion) and biaxial (combined tension and torsion) cyclic loading is evaluated and compared with the experimental results. Full article

The crankshaft is one of the core components of a Rotate Vector (RV) reducer. The fatigue life of the RV reducer is severely hindered by fatigue failure on the eccentric cylindrical surface of the crankshaft. The hardness gradients and residual stress in the crankshaft, associated with machining operations, exert an enormous impact on the rolling contact fatigue (RCF). In this work, a finite element method (FEM)-based three-dimensional elasto-plastic contact model is established to calculate the stress–strain field by taking hardness gradients and initial residual stress into account. The RCF characteristics of an RV reducer crankshaft is investigated by applying modified Fatemi–Socie (FS) multiaxial fatigue criterion. The results indicate that initial residual stress plays an influential role in the fatigue damage by altering the distribution of the maximum normal stress near the contact surface. The modified FS fatigue criterion could better consider the effect of initial residual stress and the shear stress, which significantly improves the prediction accuracy of the contact fatigue life model. The contact fatigue performance could be considerably improved by designing appropriate shot peening parameters to obtain optimized residual stress distribution. Therefore, the technique presented may serve as an important guideline for the anti-fatigue design of an RV reducer crankshaft. Full article

Gears are one of the the most widespread mechanical components and their design is supported by standard calculation methods. Among all the possible failure modes of gears, tooth root bending is the most critical and could lead to catastrophic failures. In this regard, different surface treatments could be exploited to improve the gear strength. Among them, shot peening is the most common. The aim of this study is to evaluate the effectiveness of shot peening on improving the tooth root bending resistance. This is achieved by exploiting the Finite Element Method (FEM) in combination with advanced multiaxial fatigue criterion based on the critical plane concept. A standard Single Tooth Bending Fatigue test was reproduced numerically via FEM. Beside the wrought gears, shot peened ones were also simulated. The state of stress induced by the shot peening was obtained numerically by simulating the surface treatment itself with non-linear dynamic analyses. The results have shown quantitatively how the residual stresses promote an improvement in the resistance and how the local hardening could lead to different early paths of nucleation and propagation of cracks on the tooth fillet. Full article

The characterization of new materials for enabling gear design is definitely a fundamental objective in the gear industry and research. Single Tooth Bending Fatigue (STBF) tests can be performed to speed up this process. However, it is well known that STBF tests tend to overestimate material strength compared to tests performed directly on meshing gears (MG) which, in turn, require an excessively long test time. Therefore, it is common practice to use a constant correction factor $f_{korr}$ of 0.9 to translate STBF results for designing actual MG (e.g., via ISO 6336). Recent works involving a combination of Finite Element Models (FEM) and multiaxial (non-proportional) fatigue criteria based on the critical plane concept have highlighted that the assumption of considering $f_{korr}$ as a constant independent of the gear design parameters leads to inaccurate results. However, in previous studies, no correlation between $f_{korr}$ and gear design parameters has emerged. In the present paper, the influence of the normal pressure angle (${\alpha }_n$), the profile shift coefficient ($x^{*}$), and the normal module ($m_n$) on $f_{korr}$ was investigated by analyzing FEM simulations with the Findley fatigue criterion. 27 gear geometries were studied by varying the above 3 parameters in 3 levels (full factorial DOE). These geometries were simulated in both MG and STBF configurations. The results of the 54 FEM simulations were analyzed by applying the Findley fatigue criterion and the corresponding $f_{korr}$ were calculated. The correlation between $f_{korr}$ and ${\alpha }_n$, $x^{*}$ and $m_n$ was investigated using the Analysis of Variance (ANOVA) technique. The results show that the only gear design parameter influencing $f_{korr}$ is $x^{*}$ hence, a regression model for $f_{korr}$ including $x^{*}$ has been developed. This latter has been then adopted for calculating and comparing $f_{korr}$ values from other combination of the parameters found in literature, giving good correspondence. Full article

The paper presents a comparison of six recently introduced multiaxial fatigue strength estimation criteria to four methods, the large-scope validation of which has already been published. The results obtained for each newer method are analyzed and discussed. From the newer methods, only the criterion by Böhme reaches an estimation quality similar to the best performing criteria. The validation was performed on the FatLim data sets, but the primary focus of the paper is set to analyzing the validation on a smaller AMSD25 data set derived from it. The comparison shows that the application of AMSD25 for validation practice allows users to reduce the number of evaluated test cases, while generally preserving the worst cases showing the weaknesses of various estimation methods. Full article

In the present study, the authors attempted to predict the fatigue lifetime of a real-scale integral concrete bridge with H-shaped steel piles resulting from working and environmental conditions. In this regard, various types of nonproportional variable amplitude loads were applied on the bridge, such as temperature variations and sea waves clash. To this end, CATIA software was used to model the real-scale bridge with its accessories, such as a concrete deck, concrete anchors (walls), I-shaped concrete beams (Ribs), and steel piles. Subsequently, stress analysis was performed to determine the critical area apt to fail. The results showed that steel piles are the most critical bridge components. As a result, in future analysis, the purpose will be to study this critical area, and the effect of relative humidity on the fatigue properties of concrete was ignored. Subsequently, the time history of stress tensor components in the critical area was obtained by performing transient dynamic analysis. Various well-known equivalent stress fatigue theories (von Mises, Findley, Dang Van, McDiarmid, Carpinteri–Spagnoli, Modified Findley, Modified McDiarmid, and Liu–Zenner) were utilized to calculate the equivalent stress caused by the simultaneous effect of temperature variations and sea waves clash. Eventually, the fatigue life of the structure was predicted by employing the rainflow counting algorithm and the Palmgren–Miner damage accumulation rule. The results indicated a reduction in the multiaxial fatigue life of the structure under the simultaneous effects of two phenomena, the daily temperature variations and the sea waves clash, of approximately 87% and 66%, respectively, compared with the fatigue life of the structure under either the effect of temperature changes or the effect of sea waves clash, separately. Therefore, it was necessary to consider all the cyclic loads in the structural design step to estimate the fatigue life of the structure. Moreover, the findings of this case study revealed that the lowest value of multiaxial fatigue lifetime is related to the application of the Liu-Zenner criterion. In other words, this criterion is more conservative than the other used criteria. Full article

Mechanical components, such as gears, are usually subjected to variable loads that induce multiaxial non-proportional stress states, which in turn can lead to failure due to fatigue. However, the material properties are usually available in the forms of bending or shear fatigue limits. Multiaxial fatigue criteria can be used to bridge the gap between the available data and the actual loading conditions. However, different criteria could lead to different results. The main goal of this paper is to evaluate the accuracy of different criteria applied to real mechanical components. With respect to this, five different criteria based on the critical plane concept (i.e., Findley, Matake, McDiarmid, Papadopoulos, and Susmel) have been investigated. These criteria were selected because they not only assess the level of damage, but also predict the direction of crack propagation just after nucleation. Therefore, measurements (crack position and direction) on different fractured gear samples tested via Single Tooth Bending Fatigue (STBF) tests on two gear geometries were used as reference. The STBF configuration was numerically simulated via Finite Elements (FE) analyses. The results of FE were elaborated based on the above-mentioned criteria. The numerical results were compared with the experimental ones. The result of the comparison showed that all the fatigue criteria agree in identifying the most critical point. The Findley and Papadopulus criteria proved to be the most accurate in estimating the level of damage. The Susmel criterion turns out to be the most conservative one. With respect to the identification of the direction of early propagation of the crack, the Findley criterion revealed the most appropriate. Full article

In this paper, a life prediction model associated with maximum principal stress and equivalent shear amplitude based on twin-shear unified yield criterion for multiaxial high-cycle fatigue is proposed. The equivalent shear amplitude is the normalized format of the equivalent shear amplitude based on clusters of yield criteria embodying Tresca and the linearization of Huber-von Mises, extending the application to metallic materials. Simultaneously, the effect of mean stress on multiaxial high-cycle fatigue is considered in the proposed model. As an assessment of the new prediction model, the criterion is compared with experimental data of aluminum alloy LY12CZ and carbon structural steel SM45C published in the relevant literature, which shows that most of the data are located within an error range of less than two times the data and are in good agreement with the experiment. Moreover, the proposed model is also compared with other models, such as McDiarmid, Liu, and Freitas, to validate its competitiveness. Full article
