Several studies suggest that shale sweet spots are likely associated with a low Poisson’s ratio in the shale layer. Compared with conventional geophysical techniques with active seismic data, it is straightforward and cost-effective to delineate the distribution of 3D Poisson’s ratios using microseismic data. In this study, an alternating method is proposed to determine microseismic event locations, 3D P-wave velocity, and Poisson’s ratio models with data recorded from downhole monitoring arrays. The method combines the improved 3D traveltime tomography, which inverts P and S arrivals for 3D P-wave velocity and Poisson’s ratio structures simultaneously, and a 3D grid search approach for event locations in an iterative fashion. The traveltime tomography directly inverts the Poisson’s ratio structure instead of calculating the Poisson’s ratios from P- and S-wave velocities (i.e., Vp and Vs) that are inverted by conventional traveltime tomography separately. The synthetic results and analysis suggest that the proposed method recovers the true Poisson’s ratio model reasonably. Additionally, we apply the method to a field dataset, which indicates that it may help delineate the reservoir structure and identify potential shale sweet spots. Full article

Three-section landslides are renowned for their immense size, concealed development process, and devastating impact. This study conducted physical model tests to simulate one special geological structure called a three-section-within landslide. The failure process and precursory characteristics of the tested samples were meticulously analyzed using video imagery, micro-seismic (MS) signals, and acoustic emission (AE) signals, with a focus on event activity, intensity, and frequency. A novel classification method based on AE waveform characteristics was proposed, categorizing AE signals into burst signals and continuous signals. The findings reveal distinct differences in the evolution of these signals. Burst signals appeared exclusively during the crack propagation and failure stages. During these stages, the cumulative AE hits of burst signals increased gradually, with amplitude rising and then declining. High-amplitude burst signals were predominantly distributed in the middle- and high-frequency bands. In contrast, cumulative AE hits of continuous signals escalated rapidly, with amplitude monotonously increasing, and high-amplitude continuous signals were primarily distributed in the low-frequency band. The emergence of burst signals and high-frequency AE signals indicated the generation of microcracks, serving as early-warning indicators. Notably, the early-warning points of AE signals were detected earlier than those of video imagery and MS signals. Furthermore, the early-warning point of burst signals occurred earlier than those of continuous signals, and the early-warning point of the classification method preceded that of overall AE signals. Full article

The advent of fiber optic technology in geophysics exploration has grown in its use in the exploration, production, and monitoring of subsurface environments, revolutionizing the way data are gathered and interpreted critically to speed up decision-making and reduce expense and time. Distributed Acoustic Sensing (DAS) has been increasingly utilized to build relationships in complex geophysics environments by utilizing continuous measurement along fiber optic cables with high spatial resolution and a frequency response of up to 10 KHz. DAS, as fiber optic technology examining backscattered light from a laser emitted inside the fiber and measuring strain changes, enables the performance of subsurface imaging in terms of real-time monitoring for Vertical Seismic Profiling (VSP), reservoir monitoring, and microseismic event detection. This review examines the most widely used fiber optic cables employed for DAS acquisition, namely Single-Mode Fiber (SMF) and Multi-Mode Fiber (MMF), with the different deployments and scopes of data used in geophysics exploration. Over the years, SMF has emerged as a preferred type of fiber optic cable utilized for DAS acquisition and, in most applications examined in this review, outperformed MMF. On the other side, MMF has proven to be preferable when used to measure distributed temperature. Finally, the fiber optic cable deployment technique and acquisition parameters constitute a pivotal preliminary step in DAS data preprocessing, offering a pathway to improve imaging resolution based on DAS measurement as a future scope of work. Full article

At present, assessment techniques for the fracability of shale reservoirs, which rely on the formation of an effective fracture network, are scarce. Hence, in order to assess the fracability, it is critical to establish a quantitative correlation between the pattern of fracture distribution after fracture and fracability. The present investigation utilizes three-dimensional digital core technology and triaxial compression experiments to simulate the fracturing process in typical domestic shale reservoir cores. In addition to utilizing the maximum ball algorithm to extract fracture images, a number of other techniques are employed to compute the spatial quantitative parameters of the fractures, including least squares fitting, image tracking algorithms, and three-dimensional image topology algorithms. The introduction of the notion of three-dimensional fracture complexity serves to delineate the degree of successful fracture network formation subsequent to fracturing. A quantitative fracability characterization model is developed by integrating the constraints of fracture network formation potential and fragmentation potential. The results of this study show that the quantitative characterization of the characteristic parameters of cracks can be achieved by establishing a method for extracting crack information as well as parameters after core compression and completing the construction of a three-dimensional complexity characterization model. Meanwhile, the three-dimensional post-compression fracture image validation shows that the core fracturability index can better reflect the actual fracturing situation, which is in line with the microseismic monitoring results, and significantly improves the accuracy of fracturability characterization, which is an important guideline for the fracturing design of shale gas reservoirs. Full article

The accurate detection of P-wave FAP (First-Arrival Picking) in seismic signals is crucial across various industrial domains, including coal and oil exploration, tunnel construction, hydraulic fracturing, and earthquake early warning systems. At present, P-wave FAP detection relies on manual identification by experts and automated methods using Short-Term Average to Long-Term Average algorithms. However, these approaches encounter significant performance challenges, especially in the presence of real-time background noise. To overcome this limitation, this study proposes a novel P-wave FAP detection method that employs the U-Net model and incorporates spectrogram transformation techniques for seismic signals. Seismic signals, similar to those encountered in South Korea, were generated using the stochastic model simulation program. Synthesized WGN (White Gaussian Noise) was added to replicate background noise. The resulting signals were transformed into 2D spectrogram images and used as input data for the U-Net model, ensuring precise P-wave FAP detection. In the experimental result, it demonstrated strong performance metrics, achieving an MSE of 0.0031 and an MAE of 0.0177, and an RMSE of 0.0195. Additionally, it exhibited precise FAP detection capabilities in image prediction. The developed U-Net-based model exhibited exceptional performance in accurately detecting P-wave FAP in seismic signals with varying amplitudes. Through the developed model, we aim to contribute to the advancement of microseismic monitoring technology used in various industrial fields. Full article

Microseismic event identification is of great significance for enhancing our understanding of underground phenomena and ensuring geological safety. This paper employs a literature review approach to summarize the research progress on microseismic signal identification methods and techniques over the past decade. The advantages and limitations of commonly used identification methods are systematically analyzed and summarized. Extensive discussions have been conducted on cutting-edge machine learning models, such as convolutional neural networks (CNNs), and their applications in waveform image processing. These models exhibit the ability to automatically extract relevant features and achieve precise event classification, surpassing traditional methods. Building upon existing research, a comprehensive analysis of the strengths, weaknesses, opportunities, and threats (SWOT) of deep learning in microseismic event analysis is presented. While emphasizing the potential of deep learning techniques in microseismic event waveform image recognition and classification, we also acknowledge the future challenges associated with data availability, resource requirements, and specialized knowledge. As machine learning continues to advance, the integration of deep learning with microseismic analysis holds promise for advancing the monitoring and early warning of geological engineering disasters. Full article

In microseismic monitoring, the reconstruction of a reliable velocity model is essential for precise seismic source localization and subsurface imaging. However, traditional methods for microseismic velocity inversion face challenges in terms of precision and computational efficiency. In this paper, we use deep learning (DL) algorithms to achieve precise and efficient real-time microseismic velocity modeling, which holds significant importance for ensuring engineering safety and preventing geological disasters in microseismic monitoring. Given that this task was approached as a non-linear regression problem, we adopted and modified the Attention U-Net network for inversion. Depending on the degree of coupling among microseismic events, we trained the network using both single-event and multi-event simulation records as feature datasets. This approach can achieve velocity modeling when dealing with inseparable microseismic records. Numerical tests demonstrate that the Attention U-Net can automatically uncover latent features and patterns between microseismic records and velocity models. It performs effectively in real time and achieves high precision in velocity modeling for Tilted Transverse Isotropy (TTI) velocity structures such as anticlines, synclines, and anomalous velocity models. Furthermore, it can provide reliable initial models for traditional methods. Full article

Efficient and accurate classification of the microseismic data obtained in coal mine production is of great significance for the guidance of coal mine production safety, disaster prevention and early warning. In the early stage, the classification of microseismic events relies on human experiences, which is not only inefficient but also often causes some misclassifications. In recent years, the neural network-based classification method has become more favored by people because of its advantages in modeling procedures. A microseismic signal is a kind of time-series signal and the application of the classification method is widely optimistic. The number and the balance of the training data samples have an important impact on the accuracy of the classification result. However, the quality of the training data set obtained from the production cannot be guaranteed. A long short-term memory (LSTM) network can analyze the time-series input data, where the image classification at the pixel level can be achieved by the fully convolutional network (FCN). The two structures in the network can not only use the advantages of the FCN for extracting signal details but also use the characteristics of LSTM for conveying and expressing the long time-series information effectively. In this paper, a time-series data enhancement combination process is proposed for the actual poor microseismic data. A hybrid FCN-LSTM network structure was built, the optimal network parameters were obtained by experiments, and finally a reasonable microseismic data classifier was obtained. Full article

We investigate an earthquake sequence involving an M_w = 4.6 mainshock on 2 December 2020, followed by a seismic swarm in July–October 2021 near Thiva, Central Greece, to identify the activated structures and understand its triggering mechanisms. For this purpose, we employ double-difference relocation to construct a high-resolution earthquake catalogue and examine in detail the distribution of hypocenters and the spatiotemporal evolution of the sequence. Furthermore, we apply instrumental and imaging geodesy to map the local deformation and identify long-term trends or anomalies that could have contributed to stress loading. The 2021 seismic swarm was hosted on a system of conjugate normal faults, including the eastward extension of the Yliki fault, with the main activated structures trending WNW–ESE and dipping south. No pre- or coseismic deformation could be associated with the 2021 swarm, while Coulomb stress transfer due to the M_w = 4.6 mainshock of December 2020 was found to be insufficient to trigger its nucleation. However, the evolution of the swarm is related to stress triggering by its major events and facilitated by pore-fluid pressure diffusion. The re-evaluated seismic history of the area reveals its potential to generate destructive M_w = 6.0 earthquakes; therefore, the continued monitoring of its microseismicity is considered important. Full article

We investigated the relationship between stratigraphy, stress, and microseismicity at the Hydraulic Fracture Test Site-1. The site comprises two sets of horizontal wells in the Wolfcamp shale and a deviated well drilled after hydraulic fracturing. Regional stresses indicate normal/strike-slip faulting with E-W compression. Stress measurements in vertical and horizontal wells show that the minimum principal stress varies with depth. Strata with high clay and organic content show high values of the least compressive stress, consistent with the theory of viscous stress relaxation. By integrating data from core, logs, and the hydraulic fracturing stages, we constructed a stress profile for the Wolfcamp sequence, which predicts how much pressure is required for hydraulic fracture growth. We applied the results to fracture orientation data from image logs to determine the population of pre-existing faults that are expected to slip during stimulation. We also determined microseismic focal plane mechanisms and found slip on steeply dipping planes striking NW, consistent with the orientations of potentially active faults predicted by the stress model. This case study represents a general approach for integrating stress measurements and rock properties to predict hydraulic fracture growth and the characteristics of injection-induced microseismicity. Full article

Locating underground microseismic events is important for monitoring subsurface activity and understanding the planetary subsurface evolution. Due to bandwidth limitations, especially in applications involving planetarily-distributed sensor networks, networks should be designed to perform the localization algorithm in-situ, so that only the source location information needs to be sent out, not the raw data. In this paper, we propose a decentralized Gaussian beam time-reverse imaging (GB-TRI) algorithm that can be incorporated to the distributed sensors to detect and locate underground microseismic events with reduced usage of computational resources and communication bandwidth of the network. After the in-situ distributed computation, the final real-time location result is generated and delivered. We used a real-time simulation platform to test the performance of the system. We also evaluated the stability and accuracy of our proposed GB-TRI localization algorithm using extensive experiments and tests. Full article

An important technical issue in the enhanced geothermal system (EGS) is the process of fracture shear and dilation, fracture network propagation and induced seismicity. EGS development requires an ability to reliably predict the fracture network’s permeability evolution. Laboratory and field studies such as EGS Collab and Utah FORGE, and modeling simulations provide valuable lessons for successful commercial EGS design. In this work we present a modeling analysis of EGS Collab Testbed Experiment 1 (May 24, Stim-II ≅ 164 Notch) and interpret the stimulation results in relation to the creation of a fracture network. In doing so, we use an improved 3D discrete fracture network model coupled with a 3D thermo-poroelastic finite element model (FEM) which can consider fracture network evolution and induced seismicity. A dual-scale semi-deterministic fracture network is generated by combining data from image logs, foliations/micro-fractures, and core. The natural fracture properties (e.g., length and asperity) follow a stochastic distribution. The fracture network propagation under injection is considered by an ultrafast analytical approach. This coupled method allows for multiple seismic events to occur on and around a natural fracture. The uncertainties of seismic event clouds are better constrained using the energy conservation law. Numerical simulations show that the simulated fracture pressure profiles reasonably follow the trend observed in the field test. The simulations support the concept that a natural fracture was propagated from the injection well connecting with the production well via intersection and coalescence with other natural fractures consistent with plausible flow paths observed on the field. The fracture propagation profiles from numerical modeling generally match the field observation. The distribution of simulated micro-seismicity have good agreement with the field-observed data. Full article

Seismic source location specifies the spatial and temporal coordinates of seismic sources and lays the foundation for advanced seismic monitoring at all scales. In this work, we firstly introduce the principles of diffraction stacking (DS) and cross-correlation stacking (CCS) for seismic location. The DS method utilizes the travel time from the source to receivers, while the CCS method considers the differential travel time from pairwise receivers to the source. Then, applications with three field datasets ranging from small-scale microseismicity to regional-scale induced seismicity are presented to investigate the feasibility, imaging resolution, and location reliability of the two stacking operators. Both of the two methods can focus the source energy by stacking the waveforms of the selected events. Multiscale examples demonstrate that the imaging resolution is not only determined by the inherent property of the stacking operator but also highly dependent on the acquisition geometry. By comparing to location results from other methods, we show that the location bias is consistent with the scale size, as well as the frequency contents of the seismograms and grid spacing values. Full article

The discrimination of micro-seismic events (events) and blasts is significant for monitoring and analyzing micro-seismicity in underground mines. To eliminate the negative effects of conventional discrimination methods, a waveform image discriminant method was proposed. Principal component analysis (PCA) was applied to extract the raw features of events and blasts through their waveform images that established by the recorded field data, and transform them into the new uncorrelated features. The amount of initial information retained in the derived features could be determined quantitatively by the contribution rate. The binary classification models were established by utilizing the support vector machine (SVM) algorithm and the PCA derived waveform image features. Results of four groups of cross validation show that the optimal values for the accuracy of events and blasts, total accuracy, and quality evaluation parameter MCC are 97.1%, 93.8%, 93.60%, and 0.8723, respectively. Moreover, the computation efficiency per accuracy (CEA) was introduced to quantitatively evaluate the effects of contribution rate on classification accuracy and computation efficiency. The optimal contribution rate was determined to be 0.90. The waveform image discriminant method can automatically classify events and blasts in underground mines, ensuring the efficient establishment of high-quality micro-seismic databases and providing adequate data for the subsequent seismicity analysis. Full article

Microseismic (MS) source location is a fundamental and critical task in mine MS monitoring. The traditional ray tracing-based location method can be easily affected by many factors, such as multi-ray path effects, waveform focusing and defocusing of wavefield propagation, and low picking precision of seismic phase arrival. By contrast, the Gaussian beam reverse-time migration (GBRTM) location method can effectively and correctly model the influences of multi-path effects and wavefield focusing and defocusing in complex 3D media, and it takes advantages of the maximum energy focusing point as the source location with the autocorrelation imaging condition, which drastically reduces the requirements of signal-to-noise ratio (SNR) and picking accuracy of P-wave arrival. The Gaussian beam technique has been successfully applied in locating natural earthquake events and hydraulic fracturing-induced MS events in one-dimensional (1D) or simple two-dimensional (2D) velocity models. The novelty of this study is that we attempted to introduce the GBRTM technique into a mine MS event location application and considered utilizing a high-resolution tomographic 3D velocity model for wavefield back propagation. Firstly, in the synthetic test, the GBRTM location results using the correct 2D velocity model and different homogeneous velocity models are compared to show the importance of velocity model accuracy. Then, it was applied and verified by eight location premeasured blasting events. The synthetic results show that the spectrum characteristics of the recorded blasting waveforms are more complicated than those generated by the ideal Ricker wavelet, which provides a pragmatic way to evaluate the effectiveness and robustness of the MS event location method. The GBRTM location method does not need a highly accurate picking of phase arrival, just a simple detection criterion that the first arrival waveform can meet the windowing requirements of wavefield back propagation, which is beneficial for highly accurate and automatic MS event location. The GBRTM location accuracy using an appropriate 3D velocity model is much higher than that of using a homogeneous or 1D velocity model, emphasizing that a high-resolution velocity model is very critical to the GBRTM location method. The average location error of the GBRTM location method for the eight blasting events is just 17.0 m, which is better than that of the ray tracing method using the same 3D velocity model (26.2 m). Full article
