Search Results (14)

High-aspect-ratio micro- and mesoscale metallic components (HAR-MMMCs) can play some unique roles in quite a few application fields, but their cost-efficient fabrication is significantly difficult to accomplish. To address this issue, this study proposes a necked-entrance through-mask (NTM) periodically lifting electroforming technology with an impinging jet electrolyte supply. The effects of the size of the necked entrance of the through-mask and the jet speed of the electrolyte on electrodeposition behaviors, including the thickness distribution of the growing top surface, deposition defect formation, geometrical accuracy, and electrodeposition rate, are investigated numerically and experimentally. Ensuring an appropriate size of the necked entrance can effectively improve the uniformity of deposition thickness, while higher electrolyte flow velocities help enhance the density of the components under higher current densities, reducing the formation of deposition defects. It was shown that several precision HAR-MMMCs with an AR of 3.65 and a surface roughness (Ra) of down to 36 nm can be achieved simultaneously with a relatively high deposition rate of 3.6 μm/min and thickness variation as low as 1.4%. Due to the high current density and excellent mass transfer effects in the electroforming conditions, the successful electroforming of components with a Vickers microhardness of up to 520.5 HV was achieved. Mesoscale precision columns with circular and Y-shaped cross-sections were fabricated by using this modified through-mask movable electroforming process. The proposed NTM periodic lifting electroforming method is promisingly advantageous in fabricating precision HAR-MMMCs cost-efficiently. Full article

With ever increasing integration density of electronic components, the demand for cooling solutions capable of removing the heat generated by such systems grows along with it. It has been shown that a viable answer to this demand is the use of direct liquid jet impingement. While this method can generally be scaled to the cooling of large areas, this is restricted by the necessity of coolant flow rate scaling. In this study, the benefits and restrictions of using increased nozzle pitch to remedy the increasing demand for overall flow rate are investigated. To this end, a model is validated against experimental findings and then used for computational fluid dynamics simulations, exploring effects of the pitch change for micro-scale nozzle diameters and nozzle-to-target spacings. It is found that while this method is efficient in adjusting the tradeoff between total coolant flow rate and pressure drop up to a certain pint, the occurrence of a hydraulic jump in the cavity causes a deterioration of its effect for large nozzle pitches. Full article

Micro-gas turbines are used for power generation and propulsion in unmanned aerial vehicles. Technological advancements to enhance their efficiency and fuel adaptability are continuously sought out. As part of a comprehensive study focused on understanding the fundamental performance and emission characteristics of a micro gas turbine model, with the aim of finding ways to enhance the operation of micro gas turbines, the current study uses a fully coupled whole-annulus simulation approach to systematically explore the combustor–turbine interaction without compromising the accuracy due to domain truncation. The numerical model is highly complex, spanning aerothermodynamics, fuel vaporization, combustion, and multi-species flow transport. Coupled with the realistic geometries of a representative micro-gas turbine, the proposed numerical model is highly accurate with the capability to capture the complex interaction between the flowfield and the aerothermodynamics and emission performances. The results show that unburnt gaseous Jet-A fuel is carried into the turbine domain through vortical flow structures originating from the combustion chamber. Notably, combustion processes persist within the turbine, leading to rapid Jet-A fuel concentration decay and linearly increasing soot concentration across the turbine domain. The relative circumferential positioning of the combustion chamber and turbine vane (i.e., clocking effects) profoundly influences micro-gas turbine aerothermodynamics and pollutant emissions. Leading-edge impingement hot-streak configurations enhance aerodynamic efficiency, while mid-passage hot-streak configurations mitigate aerothermal heat load and soot emissions. Clocking effects impact all parameters, indicating a complex interplay between the flowfield, aerothermal performance, and pollutant emissions. However, turbine vane heat load exhibits the most significant variations. Full article

Thermal management at a high heat flux is crucial for high-power electronic devices, and jet impingement cooling is a promising solution. In this paper, a hybrid heat sink combining a microchannel and jet impingement was designed, fabricated and tested in a closed-loop system with R134a as the working fluid. The thermal contact resistance was measured by using the steady-state method, and the thermal resistance of the heat sink was obtained at different heat fluxes and flow rates. The maximum heat dissipation of 400 W/cm² is achieved on a heater area of 210 mm², and the thermal resistance of the heat sink is 0.11 K/W with a pressure drop of 13.5 kPa under a flow rate of 1.90 L/min. Low thermal resistance can be achieved for the hybrid heat sink stemming from the highly-dense micro-jet array with separate inflow and outflow microchannels. Full article

Erosion–corrosion behavior of pipeline grade carbon steel alloy (AISI 1030) was investigated using a state-of-the-art jet impingement flow loop. Different impingement velocities (3 to 12 m/s) and angles (15°, 30°, 45°, 60°, and 90°) were employed (with/without sand particles) to study the degradation behavior of this pipeline grade steel in 0.2 M NaCl solution at room temperature. Experiments were conducted for a duration of 24 h at room temperature. The maximum erosion–corrosion (EC) rate was observed at an impingement angle of 45° at all velocities (3 to 12 m/s), as both the shear and normal impact stresses were of the same order of magnitude at this angle. At lower impingement angles, the effect of shear stress was more dominant and vice versa at higher impingement angles. The synergistic affect was found to be maximum at 45° due to enhancement of erosion by corrosion and/or corrosion by erosion. Ploughing, deep craters, raised lips, dimples, micro-forging/plastic deformation, and extrusion were the dominant erosion–corrosion mechanisms as observed by Field Emission Scanning Electron Microscopy (FE-SEM). The maximum corrosion wear scar depth was found to be 57 µm (average) at an impingement angle of 45°, as measured using an optical profilometer. The obtained results are very significant and can be used in process parameter optimizations to enhance infrastructure reliability. These results will also be the part of in-house database to develop a comprehensive erosion and erosion–corrosion model for erosion–corrosion prediction of different materials under various operational conditions. Full article

With the development in additive manufacturing, the use of surface treatments for gas turbine design applications has greatly expanded. An experimental investigation of the pressure loss and heat transfer characteristics within impingement jet arrays with arrays of target surface micro cooling units is presented. The discharge coefficient and Nusselt number are measured and determined for an evaluation of the pressure loss of the flow system and heat transfer level, respectively. Considered are effects of impingement jet Reynolds number ranging from 1000 to 15,000 and micro cooling units (square pin fin) height (h) with associated values of 0.01, 0.02, 0.05, 0.2, and 0.4 D, where D is the impingement hole diameter. Presented are variations of Nusselt number, and Nusselt number ratio, discharge coefficient, discharge coefficient ratio, discharge coefficient correlation. Depending upon the micro cooling unit height, discharge coefficient ratios slightly decrease with height, and the ratio values generally remain unit value (1.0). When Re_j = 1000 and 2500 for several cooling units height values, discharge coefficient ratios show the pressure loss decreases about 2–18% and 3–6%, respectively, when compared to the data of a baseline smooth target surface plate. The observed phenomenon is due to the effects of flow blockage of micro cooing units, local flow separation, and near-wall viscous sublayer reattachment. Results also show that heat transfer levels increase 20–300% for some of the tested toughened target surface plates when compared to smooth target surface plates. The heat transfer level enhancement is because of an increase in thermal transport and near-wall mixing, as well as the increased wetted area. In addition, micro cooling units elements break the viscous sublayer and cause greater turbulence intensity when compared to the smooth target surface. Overall, results demonstrate that the target surface micro cooling units do not result in a visible increment in pressure loss and reduce pressure loss of the flow system for some of the tested patterns. Moreover, results show the significant ability of micro cooling units to enhance the surface heat transfer capability of impingement cooling relative to smooth target surfaces. Full article

Oscillatory flow has many applications in micro-scaled devices. The methods of realizing microfluidic oscillators reported so far are typically based on the impinging-jet and Coanda effect, which usually require the flow Reynolds number to be at least at the order of unity. Another approach is to introduce elastomeric membrane into the microfluidic units; however, the manufacturing process is relatively complex, and the membrane will become soft after long-time operation, which leads to deviation from the design condition. From the perspective of the core requirement of a microfluidic circuit, i.e., nonlinearity, the oscillatory microfluidic flow can be realized via the nonlinear characteristics of viscoelastic fluid flow. In this paper, the flow characteristics of viscoelastic fluid (Boger-type) in a T-shaped channel and its modified structures are studied by two-dimensional direct numerical simulation (DNS). The main results obtained from the DNS study are as follows: (1) Both Weissenberg (Wi) number and viscosity ratio need to be within a certain range to achieve a periodic oscillating performance; (2) With the presence of the dynamic evolution of the pair of vortices in the upstream near the intersection, the oscillation intensity increases as the elasticity-dominated area in the junction enlarges; (3) Considering the simplicity of the T-type channel as a potential oscillator, the improved structure should have a groove carved toward the entrance near the upper wall. The maximum oscillation intensity measured by the standard deviation of flow rate at outlet is increased by 129% compared with that of the original standard T-shaped channel under the same condition. To sum up, with Wi number and viscosity ratio within a certain range, the regular periodic oscillation characteristics of Oldroyd-B type viscoelastic fluid flow in standard T-shaped and its modified channels can be obtained. This structure can serve as a passive microfluidic oscillator with great potential value at an extremely low Reynolds number, which has the advantages of simplicity, no moving parts and fan-out of two. Full article

In this paper, coating removal characteristics of water jet by micro jet flow affected by cleaning parameters is analyzed. Numerical simulation of fluid field calculates the velocity and pressure distribution of a water jet impinging on a rigid wall, which is used for design experiments of coating removal affected by jet pressure, traversal speed, and repeated impacting times. The removal width is used as a measure of water jet coating removal capability. Experiment results show that the coating removal width is constant, independent with traversal speed or repeated times when total exposure time of waterjet impingement is fixed. According to results of coating removal by a linear moving water jet, this study also analyzes characteristics of coating removal by rotating jet disc, especially residual coating affected by rotational and moving speed of the cleaning disc. The research is helpful to improve the coating removal efficiency of cleaning disc devices. Full article

One of the methods of heat transfer enhancement is utilization of the turbulent impinging jets, which were recently applied, for example, in the heat exchangers. Their positive impact on the heat transfer performance was proven, but many questions related to the origin of this impact are still unanswered. In general, the wall-jet interaction and the near-wall turbulence are supposed to be its main reason, but their accurate numerical analysis is still very challenging. The authors’ aim was to construct the numerical model which can represent the real phenomena with good or very good accuracy. Starting with an analysis of single jet and obtaining the agreement with experimental data, it will be possible to extend the model towards the whole minijets heat exchanger. The OpenFOAM software, Bracknell, UK was used for that purpose, with our own implementation of the ζ-f turbulence model. The most difficult area to model is the stagnation region, where the thermal effects are the most intensive and, at the same time, strongly affected by the conditions in the pipe/nozzle/orifice of various size (conventional, mini, micro), from which the jet is injected. In the following article, summary of authors’ findings, regarding significance of the velocity profile and turbulence intensity at the jet place of discharge are presented. In addition, qualitative analysis of the heat transfer enhancement is included, in relation to the inlet conditions. In the stagnation point, Nusselt number differences reached the 10%, while, in general, its discrepancy in relation to inlet conditions was up to 23%. Full article

The water hammer effect is the basis of technologies which is artificially responsible for the decay of continuous jets. A recently developed technique enhances the pressure fluctuations using an acoustic chamber, leading to enhanced erosion effects for various water volume flow rates. The optimum standoff distance for an ultrasonic enhanced water jet is not appropriately estimated using an inclined trajectory. The objective of this study is to comprehend the true nature of the interaction of the standoff distance following the stair trajectory and traverse speed of the nozzle on the erosion depth. Additionally, it also critically compares the new method (staircase trajectory) that obeys the variation in frequency of the impingements for defined volume flow rates with the inclined trajectory. In this study, at constant pressure (p = 70 MPa), the role of impingement distribution with the variation of traverse speed (v = 5–35 mm/s) along the centerline of the footprint was investigated. The maximum erosion depth corresponding to each traverse speed is observed at approximately same standoff distance (65 ± 5 mm) and decreases with the increment in traverse speed (h = 1042 and 47 µm at v = 5 and 35 mm/s, respectively). The results are attributed to the variation in the number of impingements per unit length. The surface and morphology analysis of the cross-section using SEM manifested the presence of erosion characteristics (micro-cracks, cavities, voids, and upheaved surface). By varying the water cluster, different impingement densities can be achieved that are suitable for technological operations such as surface peening, material disintegration, or surface roughening. Full article

An experimental study and mathematical modeling of micromixing in a microreactor with free impinging jets (MRFIJ) with a diameter of 1 mm was carried out. In the experimental part, the iodide-iodate technique was used (involving parallel competing Villermaux–Dushman reactions with the formation of I₃⁻). Theoretical assessment revealed that more than 50% of the introduced energy is dissipated in the jets collision region. Through the use of differentiated sampling, an uneven quality distribution of micro mixing in the central and peripheral zones of the reactor was found: at moderate flow rates (700–1000 mL/min, jets velocity of 15–21 m/s) the micromixing in the central part of reactor is up to 12 times better than that in the periphery. Furthermore, the weight fraction of the probes in the central zones of MRFIJ is reduced with increasing jet velocity; this effect is attributed to a more intense formation of ligaments and droplets upon collision of jets and their secondary mixing on the walls of the apparatus. In terms of the weighted average concentration, the best quality of micromixing in the samples is achieved at a flow rate of 300 mL/min. With an increase in the flow rate (and velocity) of the jets, the dependence of the I₃⁻ concentration on the flow rate has a nonmonotonic character, which is explained by a change in the nature of the flow in the collision zone of the jets: the transition from the formation of a liquid sheet to the intensive formation of ligaments and drops and secondary mixing of the liquid film formed on the walls of the reactor. The effect of “freshness” of solutions on the concentration of reaction products was studied. Full article

Jet electrochemical machining (Jet-ECM) is a significant prospective electrochemical machining process for the fabrication of micro-sized features. Traditionally and normally, the Jet-ECM process is carried out with its electrolytic jet being vertically impinged downstream against the workpiece. Therefore, other jet orientations, including a vertically upstream orientation and a horizontal orientation, have rarely been adopted. In this study, three jet orientations were applied to electrolytic jet machining, and the effect of jet orientations on machining characteristics was systemically investigated. Horizontal jet orientation is of great benefit in achieving accurate micro-sized features with excellent surface quality with either a static jet or a scanning jet for the Jet-ECM. On the other hand, the Jet-ECM with a horizontal jet orientation has a smaller material removal rate (MMR) than the ones with vertical jet orientations, which have almost the same MMR. It was found that an enhancement of machining localization and a reduction of MMR for horizontal jet electrochemical machining primarily results from an improvement of the mass-transfer field. The horizontal orientation of the jet is beneficial for the Jet-ECM processes to improve machining accuracy. Full article

This article presents a study which sought to enhance heat transfer by employing a twin jet impingement mechanism (TJIM) and investigating the impact of the distance between the nozzles and plate on the Nusselt number (Nu) and heat transfer coefficient. This investigation was additionally based on the measurements of the heat flux temperature micro foil sensor and IR thermal imaging. A computational study of the cooling heated plate, through simulating the electronic components by the TJIM, was investigated using the RNG k-ε turbulence model. The jet-plate position was changed at the different jet-to-plate distances S = 1, 6, and 11 cm, Reynolds number = 17,000. The main flow structure, the static pressure, local and average Nus and heat transfer coefficient, were also examined. The findings have yielded new information about TJIM, and represent a new contribution about the flow and heat transfer characteristics of TJIM, and means of improving the rate of heat transfer in the passive heat transfer technique. The results of the various positions of the TJIM determined that the first model is, in fact, the best model for the heat transfer coefficient and the highest Nu, when S = 1 cm and H = 1 cm. Furthermore, the irregular distribution of the local Nu and the local heat transfer coefficient (h) on the impinged surface are due to the increase or decrease in the turbulence of flow on the measured surface. Full article

This work reports results related to the “EU-FP7-HRC-Power” project aiming at developing micro-meso hybrid sources of power. One of the goals of the project is to achieve surface temperatures up to more than 1000 K, with a ∆T ≤ 100 K, in order to be compatible with a thermal/electrical conversion by thermo-photovoltaic cells. The authors investigate how to reach that goal adopting swirling chambers integrated in a thermally-conductive and emitting element. The converter consists of a small parallelepiped brick inside two separated swirling meso-combustion chambers, which heat up the parallelepiped, emitting material by the combustion of H₂ and air at ambient pressure. The overall dimension is of the order of cm. Nine combustion simulations have been carried out assuming detailed chemistry, several length/diameter ratios (Z/D = 3, 5 and 11) and equivalence ratios (0.4, 0.7 and 1); all are at 400 W of injected chemical power. Among the most important results are the converter surfaces temperatures, the heat loads, provided to the environment, and the chemical efficiency. The high chemical efficiency, h > 99.9%, is due to the relatively long average gas residence time coupled with the fairly good mixing due to the swirl motion and the impinging air/fuel jets that provide heat and radicals to the flame. Full article
