The production of cost-effective novel materials for PV solar cells with long-term stability, high energy conversion efficiency, enhanced photon absorption, and easy electron transport has stimulated great interest in the research community over the last decades. In the presented work, Cu/Cu₂S-MWCNTs nanocomposites were produced and analyzed in the framework of potential applications for PV solar cells. Firstly, the surface of the produced one-dimensional Cu was covered by Cu₂S nanoflake. XRD data prove the formation of both Cu and Cu₂S structures. The length and diameter of the one-dimensional Cu wire were 5–15 µm and 80–200 nm, respectively. The thickness of the Cu₂S nanoflake layer on the surface of the Cu was up to 100 nm. In addition, the Cu/Cu₂S system was enriched with MWCNTs. MWCNs with a diameter of 50 nm interact by forming a conductive network around the Cu/Cu₂S system and facilitate quick electron transport. Raman spectra also prove good interfacial coupling between the Cu/Cu₂S system and MWCNTs, which is crucial for charge separation and electron transfer in PV solar cells. Furthermore, UV studies show that Cu/Cu₂S-MWCNTs nanocomposites have a wide absorption band. Thus, MWCNTs, Cu, and Cu₂S exhibit an intense absorption spectrum at 260 nm, 590 nm, and 972 nm, respectively. With a broad absorption band spanning the visible–infrared spectrum, the Cu/Cu₂S-MWCNTs combination can significantly boost PV solar cells’ power conversion efficiency. Furthermore, UV research demonstrates that the plasmonic character of the material is altered fundamentally when CuS covers the Cu surface. Additionally, MWCN-Cu/Cu2S nanocomposite exhibits hybrid plasmonic phenomena. The bandgap of Cu/Cu₂S NWs was found to be approximately 1.3 eV. Regarding electron transfer and electromagnetic radiation absorption, the collective oscillations in plasmonic metal-p-type semiconductor–conductor MWCNT contacts can thus greatly increase energy conversion efficiency. The Cu/Cu₂S-MWCNTs nanocomposite is therefore a promising new material for PV solar cell application. Full article

A wide-angle scanning phased array with dual circular polarization in the Ka-band is presented in this paper. To improve the scanning capability of the phased array, the microstrip element is modified by loading many metal posts at its center and periphery. In addition, a stripline coupler is designed to achieve dual circularly polarized (CP) radiation, and the inner conductor of the subminiature micro-push-on (SSMP) connectors for feeding the coupler is extended to the top layer of the multilayer element by introducing an open stub, which simplifies the assembly process between the SSMP connector and multilayer printed circuit board (PCB) due to through-hole soldering instead of blind-hole soldering. The proposed element can cover a frequency range from 28 GHz to 30.5 GHz with a relative bandwidth of 8.5% in the Ka-band. An 8 × 8 phased array is constructed based on this proposed element, and a wide-angle scanning range from −65° to +65° is obtained for the dual circular polarization. The proposed array has a gain fluctuation of 5.1 dB and an axial ratio (AR) of less than 3.3 dB during beam-steering. The prototype is fabricated and measured, with a good agreement between the measured and simulated results. The proposed phased array can be applied in a Ka-band millimeter-wave (MMW) communication system. Full article

The use of Yttria-stabilized tetragonal zirconia polycrystals (Y-TZP) in medicine has rapidly expanded over the past decade, driven by its advantageous properties, showing potential to overcome titanium alloy in implant fabrication. The release of metal ions and the aesthetic problems of titanium alloy implants are the main reasons for this trend. In addition to meeting expectations regarding its properties, an implant must possess intrinsic capacities such as auto-diagnostic and auto-treatment. Thus, based on the concept of smart implants, this work proposes a hybrid approach for printing a part of the communication system of a zirconia implant by resorting to laser technology, aiming to endow the implant with intrinsic capacities. Therefore, the antenna was designed and then printed on the zirconia surface. The laser was applied as a versatile tool, whether for preparing the surface of the material in a subtractive way, by creating the micro-cavity, or for printing the silver-based antenna in an additive way through laser technology. The silver powder was used as the conductor material of the antenna. The results revealed that the antenna is capable of communicating from inside the body with the outside world without needing to have an exterior antenna attached to the skin. Full article

High quality and long product life are two fundamental requirements for all circuit carriers, including molded interconnect devices (MID), to find application in various fields, such as automotive, sensor technology, medical technology, and communication technology. When developing a MID for a certain application, not only the design, but also the choice of material as well as the process parameters need to be carefully considered. A well-established method to evaluate the lifetime of such MID, respective of their conductor tracks, is the thermal shock test, which induces thermomechanical stresses upon cycling. Even though this method has numerous advantages, one major disadvantage is its long testing time, which impedes rapid developments. Addressing this disadvantage, this study focuses on the laser direct structuring of thermoplastic LCP Vectra E840i LDS substrates and the subsequent electroless metallization of the commonly used layer system Cu/Ni/Au to force differences in the conductor tracks’ structure and composition. Performing standardized thermal shock tests alongside with flexural fatigue tests, using a customized setup, allows comparison of both methods. Moreover, corresponding thermomechanical simulations provide a direct correlation. The flexural fatigue tests induce equivalent or even higher mechanical stresses at a much higher cycling rate, thus drastically shorten the testing time. Full article

This paper reviews the material properties, fabrication and functionalities of liquid metal-based devices. In modern wireless communication technology, adaptability and versatility have become attractive features of any communication device. Compared with traditional conductors such as copper, the flow characteristics and lack of elastic limit of conductive fluids make them ideal alternatives for applications such as flexible circuits, soft electronic devices, wearable stretch sensors, and reconfigurable antennas. These fluid properties also allow for innovative manufacturing techniques such as 3-D printing, injecting or spraying conductive fluids on rigid/flexible substrates. Compared with traditional high-frequency switching methods, liquid metal (LM) can easily use micropumps or an electrochemically controlled capillary method to achieve reconfigurability of the device. The movement of LM over a large physical dimension enhances the reconfigurable state of the antenna, without depending on nonlinear materials or mechanisms. When LM is applied to wearable devices and sensors such as electronic skins (e-skins) and strain sensors, it consistently exhibits mechanical fatigue resistance and can maintain good electrical stability under a certain degree of stretching. When LM is used in microwave devices and paired with elastic linings such as polydimethylsiloxane (PDMS), the shape and size of the devices can be changed according to actual needs to meet the requirements of flexibility and a multistate frequency band. In this work, we discuss the material properties, fabrication and functionalities of LM. Full article

As the stress–strain curve of standardized metal samples provides the basic details about mechanical properties of structural materials, the polarization curve or current–voltage characteristics of fuel cells are vitally important to explore the scientific mechanism of various solid oxide cells aiming at low operational temperatures (below 600 °C), ranging from protonic conductor ceramic cells (PCFC) to emerging Semiconductor ionic fuel cell (SIFC)/Semiconductor membrane fuel cells (SMFC). Thus far, worldwide efforts to achieve higher nominal peak power density (PPD) at a low operational temperature of over 0.1 s/cm ionic conductivity of electrolyte and super catalyst electrode is the key challenge for SIFCs. Thus, we illustrate an alternative approach to the present PPD concept and current–voltage characteristic. Case studies reveal that the holy grail of 1 W/cm² from journal publications is expected to be reconsidered and normalized, since partial cells may still remain in a transient state (TS) to some extent, which means that they are unable to fulfill the prerequisite of a steady state (SS) characteristic of polarization curve measurement. Depending on the testing parameters, the reported PPD value can arbitrarily exist between higher transient power density (TPD) and lower stable power density (SPD). Herein, a standardized procedure has been proposed by modifying a quasi-steady state (QSS) characterization based on stabilized cell and time-prolonged measurements of common I–V plots. The present study indicates, when compared with steady state value, that QSS power density itself still provides a better approximation for the real performance of fuel cells, and concurrently recalls a novel paradigm transformation from a transient to steady state perspective in the oxide solid fuel cell community. Full article

We have built a worker-safety monitoring system (WSMS) for use in the shipbuilding and offshore industry (S&OI). The WSMS combines metal-conductor communication wireless networks with location-estimation technology that uses ultrasound signals in the frequency band 18 to 22 kHz, which is above the normal range of hearing (<15 kHz) in human adults. This system can be used in environments that include many metal barriers. The developmental process included deriving stakeholder requirements, transforming system requirements, designing system architecture, and developing a prototype. The prototype WSMS was tested by applying it to H Company, a Korean S&OI. Use of the WSMS increased the productivity of workers and managers by reducing the cost of on-site patrols and handwritten input. As a result, the number of worker location information updates increased from 2/day to 20/min, and productivity increased by 30 min/day compared to the previous method. Therefore, shipyards that introduce worker-safety management systems may consider applying this method. Full article

This paper presents the design and realization of a compact ultra-wideband (UWB) antenna with a rectangular notch wireless area network (WLAN) band that has controllable notched bandwidth and center frequency. The UWB characteristics of the antenna are achieved by truncating the lower ends of the rectangular microstrip patch, and the notch characteristics are obtained by using electromagnetic bandgap (EBG) structures. EBGs consist of two rectangular metallic conductors loaded on the back of the radiator, which is connected to the patch by shorting pins. A rectangular notch at the WLAN band with high selectivity is realized by tuning the individual resonant frequencies of the EBGs and merging them. Furthermore, the results show that the bandwidth and frequency of the rectangular notch band could be controlled according to the on-demand rejection band applications. In the demonstration, the rectangular notch band was shifted to X-band satellite communication by tuning the EBG parameters. The simulated and measured results show that the proposed antenna has an operational bandwidth from 3.1–12.5 GHz for |S₁₁| < -10 with a rectangular notch band from 5–6 GHz, thus rejecting WLAN band signals. The antenna also has additional advantages: the overall size of the compact antenna is 16 × 25 × 1.52 mm³ and it has stable gain and radiation patterns. Full article

This work reviews design aspects of liquid metal antennas and their corresponding applications. In the age of modern wireless communication technologies, adaptability and versatility have become highly attractive features of any communication device. Compared to traditional conductors like copper, the flow property and lack of elasticity limit of conductive fluids, makes them an ideal alternative for applications demanding mechanically flexible antennas. These fluidic properties also allow innovative antenna fabrication techniques like 3D printing, injecting, or spraying the conductive fluid on rigid/flexible substrates. Such fluids can also be easily manipulated to implement reconfigurability in liquid antennas using methods like micro pumping or electrochemically controlled capillary action as compared to traditional approaches like high-frequency switching. In this work, we discuss attributes of widely used conductive fluids, their novel patterning/fabrication techniques, and their corresponding state-of-the-art applications. Full article

Patterned conformal conductive structures are used to realize flexible electronics for applications such as electronic skin, communication devices, and sensors. Thus, there is a demand for low-cost rapid fabrication techniques for flexible and stretchable conductors. Spray-coating of liquid metals is a prototyping method that is compatible with elastic substrates. In this work, UV-curable and polyimide masks were used to pattern sprayed liquid metal (LM). The effect of the spraying parameters on the thickness and conductivity of the LM was characterized. A minimum LM linewidth of 48 µm was achieved, along with a minimum gap width of 34 µm. A LM patch antenna and transmission line, which can potentially be used for communication systems, were demonstrated using this fabrication process. Full article
