Search Results (9)

Search Parameters:
Keywords = matching electrical inductor

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
15 pages, 5452 KiB
Article
Suppression of Initial Charging Torque for Electric Drive-Reconfigured On-Board Charger
by Yang Xiao, Kangwei Wang, Zhi Geng, Kai Ni, Mingdi Fan and Yong Yang
World Electr. Veh. J. 2024, 15(5), 207; https://doi.org/10.3390/wevj15050207 - 9 May 2024
Viewed by 2014
Abstract
This paper presents a new electric drive-reconfigured on-board charger and initial electromagnetic torque suppression method. This proposed reconfigured on-board charger does not need many components added to the original electric drive system: only a connector is needed, which is easy to add. Specifically, [...] Read more.
This paper presents a new electric drive-reconfigured on-board charger and initial electromagnetic torque suppression method. This proposed reconfigured on-board charger does not need many components added to the original electric drive system: only a connector is needed, which is easy to add. Specifically, the inverter for propulsion is reconfigured as a buck chopper and a conduction path to match the reconfigured windings. Two of the machine phase windings serve as inductors, while the third phase winding is reutilized as a common-mode inductor. In addition, the initial charging torque is generated at the outset of the charging process, which may cause an instant shock or even rotational movement. In order to prevent vehicle movement, the reason for the charging torque and suppression method were analyzed. Further, predictive control of the model based on mutual inductance analysis was adopted, where the charging torque was directly used as a control object in the cost function. Finally, experimental performances were applied to verify the proposed reconfigured on-board charger under constant current and constant voltage charging. Full article
Show Figures

Figure 1

15 pages, 2313 KiB
Article
Pre-Matching Circuit for High-Frequency Ultrasound Transducers
by Hojong Choi
Sensors 2022, 22(22), 8861; https://doi.org/10.3390/s22228861 - 16 Nov 2022
Cited by 7 | Viewed by 5685
Abstract
High-frequency ultrasound transducers offer higher spatial resolution than low-frequency ultrasound transducers; however, their maximum sensitivity are lower. Matching circuits are commonly utilized to increase the amplitude of high-frequency ultrasound transducers because the size of the piezoelectric material decreases as the operating frequency of [...] Read more.
High-frequency ultrasound transducers offer higher spatial resolution than low-frequency ultrasound transducers; however, their maximum sensitivity are lower. Matching circuits are commonly utilized to increase the amplitude of high-frequency ultrasound transducers because the size of the piezoelectric material decreases as the operating frequency of the transducer increases. Thus, it lowers the limit of the applied voltage to the piezoelectric materials. Additionally, the electrical impedances of ultrasound transducers generally differ at the resonant-, center-, and anti-resonant-frequencies. The currently developed most-matching circuits provide electrical matching at the center frequency ranges for ultrasound transmitters and transducers. In addition, matching circuits with transmitters are more difficult to use to control the echo signal quality of the transducers because it is harder to control the bandwidth and gain of an ultrasound transmitter working in high-voltage operation. Therefore, we provide a novel pre-matching circuit method to improve the amplitude and bandwidth of high-frequency ultrasound transducers at the resonant-, center-, and anti-resonant-frequency ranges, with an ultrasound receiver and transducer. To verify the pre-matching circuit, pulse-echo response tests were conducted on the ultrasound transducers. The results show that the designed pre-matching circuits provide higher amplitude (5.63- and 2.02-times) and wider bandwidth (175.55% and 62.01%) for the high-frequency ultrasound transducer compared to the original circuit without a pre-matching circuit, and the parallel capacitor with a series-inductor circuit, respectively; therefore, the proposed pre-matching circuit is an appropriate solution for improving the amplitudes and bandwidths of high-frequency ultrasound transducers over wide frequency ranges. Full article
(This article belongs to the Section Nanosensors)
Show Figures

Figure 1

17 pages, 39511 KiB
Article
Shielded Capacitive Power Transfer (S-CPT) without Secondary Side Inductors
by Suziana Ahmad, Aam Muharam, Reiji Hattori, Anyu Uezu and Tarek M. Mostafa
Energies 2021, 14(15), 4590; https://doi.org/10.3390/en14154590 - 29 Jul 2021
Cited by 4 | Viewed by 2122
Abstract
In this study, we propose a four-plate structure with two shielding plates to produce shielded capacitive power transfer (S-CPT) at an operating frequency of 6.78 MHz for a 10 W system. By eliminating the inductors at the secondary side to form an asymmetrical [...] Read more.
In this study, we propose a four-plate structure with two shielding plates to produce shielded capacitive power transfer (S-CPT) at an operating frequency of 6.78 MHz for a 10 W system. By eliminating the inductors at the secondary side to form an asymmetrical topology, an S-CPT system was developed with a class-E power amplifier. Using MATLAB software, analysis was performed to obtain the parameters in the S-CPT system regarding resonance and impedance matching, and the proposed coupler structure was investigated through electric field simulation. The shield plate voltage stability was also investigated by analysing both the simulation and hardware experiment results. A prototype of S-CPT was established to validate the analysis results and to demonstrate the voltage at the shield plate of the proposed coupler structure. The experimental results are in good agreement with the simulation results. The proposed S-CPT exhibits an AC–AC efficiency of 84%, with a 56% voltage ground stability reduction because of implementing a balun. Full article
(This article belongs to the Special Issue Research on Wireless Power Transfer System)
Show Figures

Graphical abstract

10 pages, 4757 KiB
Article
Investigations about Al and Cu-Based Planar Spiral Inductors on Sapphire for GaN-Based RF Applications
by Chen Lin, Teng Zhan, Junxi Wang, Jinmin Li, Zhiqiang Liu and Xiaoyan Yi
Appl. Sci. 2021, 11(11), 5164; https://doi.org/10.3390/app11115164 - 2 Jun 2021
Cited by 3 | Viewed by 2913
Abstract
Conventionally, Cu is preferred over Al to fabricate integrated inductors with higher quality factors on either silicon or sapphire substrates, profiting from its lower resistivity. However, after investigating and comparing these two kinds of metal multilayers in terms of fabrication process, electrical conductivity, [...] Read more.
Conventionally, Cu is preferred over Al to fabricate integrated inductors with higher quality factors on either silicon or sapphire substrates, profiting from its lower resistivity. However, after investigating and comparing these two kinds of metal multilayers in terms of fabrication process, electrical conductivity, in-depth profile analysis and performance of actual inductors, the Al-based metal multilayer exhibits competitive ability in fabricating thin-film inductors on sapphire compared to Cu-based multilayers. This is attributed to the degradation in electrical conductivity out of oxidation of Cu-based metal sublayers or forming alloys between them. Furthermore, in order to avoid complicated de-embedding procedures in the characterization of the on-chip inductors, a six-element equivalent physical model, which takes the parasitic effect of radio-frequency (RF) test structures into account, is proposed and validated by matching well with embedded measurement results. Full article
Show Figures

Figure 1

15 pages, 6630 KiB
Article
Design and Characterization of VHF Band Small Antenna Using CRLH Transmission Line and Non-Foster Matching Circuit
by Soyeong Lee, Jonghyup Lee, Seongro Choi, Yong-Hyeok Lee, Jae-Young Chung, Keum Cheol Hwang and Yong Bae Park
Appl. Sci. 2020, 10(18), 6366; https://doi.org/10.3390/app10186366 - 12 Sep 2020
Cited by 4 | Viewed by 4964
Abstract
In this paper, we propose an electrically small antenna consisting of a composite right/left-handed (CRLH) transmission line (TL) and a non-Foster matching circuit. An interdigital capacitor (IDC) and spiral inductor are used to fabricate the very high frequency (VHF) band antenna based on [...] Read more.
In this paper, we propose an electrically small antenna consisting of a composite right/left-handed (CRLH) transmission line (TL) and a non-Foster matching circuit. An interdigital capacitor (IDC) and spiral inductor are used to fabricate the very high frequency (VHF) band antenna based on CRLH TL. The size of the proposed antenna is as small as 0.025 × 0.014 × 0.0008 λ at 145.5 MHz using the zeroth-order resonant generated by the CRLH TL. The antenna operation bandwidth is extended by the non-Foster circuit (NFC) consisting of a pair of transistors in a cross-coupled manner. An antenna prototype is fabricated and the input impedance, the received power, and gain of the proposed antenna are measured. The results show that the broadband characteristic is maintained while the form factor is extremely small compared to the wavelength. The average received power enhancement and increased bandwidth of antenna are 17.3 dB and 335.5 MHz (from 249.2–268.2 to 145.5–500 MHz), respectively. The calculated gain of the proposed antenna with the non-Foster is about −45 dBi at 155 MHz. The proposed antenna can be considered as a potential candidate of a low-profile antenna for military ground communications at the VHF band. Full article
(This article belongs to the Collection Electromagnetic Antennas for HF, VHF, and UHF Band Applications)
Show Figures

Figure 1

14 pages, 2302 KiB
Article
Nonsmooth Current-Constrained Control for a DC–DC Synchronous Buck Converter with Disturbances via Finite-Time-Convergent Extended State Observers
by Qiqing Miao, Zhenxing Sun and Xinghua Zhang
Electronics 2020, 9(1), 16; https://doi.org/10.3390/electronics9010016 - 23 Dec 2019
Cited by 2 | Viewed by 2893
Abstract
This study investigates the problem of overlarge current protection for a DC–DC synchronous buck converter with the existence of uncertainties and disturbances. Aiming to deal with the hardware damage in the electric circuit of a DC–DC buck that may be caused by overlarge [...] Read more.
This study investigates the problem of overlarge current protection for a DC–DC synchronous buck converter with the existence of uncertainties and disturbances. Aiming to deal with the hardware damage in the electric circuit of a DC–DC buck that may be caused by overlarge transient current, a new nonsmooth current-constrained control (NCC) algorithm is proposed to replace the traditional ones, which use conservative coefficients to satisfy current constraint, leading to a sacrifice of dynamic performance. Based on the homogeneous system technique, a nonsmooth state feedback controller is improved by adding a penalty term that prompts the adaptive gain of the controller according to the inductor current and current constraint. Then by using two finite-time extended state observers (FTESO), the unmatched disturbances and matched disturbances can be compensated to enhance the robustness of the DC–DC synchronous buck converter. The effect of proposed scheme has been verified by experimental results. Full article
Show Figures

Figure 1

17 pages, 5158 KiB
Article
Modelling of a Power Converter with Multiple Operating Modes
by Wang Feng and Luo Yutao
World Electr. Veh. J. 2018, 9(1), 7; https://doi.org/10.3390/wevj9010007 - 5 Jun 2018
Cited by 11 | Viewed by 4708
Abstract
In order to achieve DC voltage matching, on-board charging, and DC/AC power inversion, three independent power converters are often needed in traditional Distributed Power Converter (DPC) systems of electric vehicles (EVs): bidirectional DC/DC (Bi-DC/DC), AC/DC, and DC/AC. The requirement of electronic devices such [...] Read more.
In order to achieve DC voltage matching, on-board charging, and DC/AC power inversion, three independent power converters are often needed in traditional Distributed Power Converter (DPC) systems of electric vehicles (EVs): bidirectional DC/DC (Bi-DC/DC), AC/DC, and DC/AC. The requirement of electronic devices such as power switches, inductors, and capacitors make the converter costly and complicated in structure. In this paper, a power converter with multi-operating mode (PCMM) is presented. The proposed PCMM can work in Bi-DC/DC, AC/DC, and DC/AC modes. The state-space averaging model of PCMM considering resistance of Insulated Gate Bipolar Transistor (IGBT) and the inductor is presented. Based on this model, the transfer function of the system is derived and the controller is designed. The simulation and experimental results show that PCMM can meet the design target and verify the feasibility of the model. The measurement results show that the weight of PCMM proposed in this paper is reduced by 51.2% compared with the traditional structure. Full article
Show Figures

Graphical abstract

23 pages, 8154 KiB
Article
Insights into Dynamic Tuning of Magnetic-Resonant Wireless Power Transfer Receivers Based on Switch-Mode Gyrators
by Mohamed Saad and Eduard Alarcón
Energies 2018, 11(2), 453; https://doi.org/10.3390/en11020453 - 20 Feb 2018
Cited by 8 | Viewed by 5872
Abstract
Magnetic-resonant wireless power transfer (WPT) has become a reliable contactless source of power for a wide range of applications. WPT spans different power levels ranging from low-power implantable devices up to high-power electric vehicles (EV) battery charging. The transmission range and efficiency of [...] Read more.
Magnetic-resonant wireless power transfer (WPT) has become a reliable contactless source of power for a wide range of applications. WPT spans different power levels ranging from low-power implantable devices up to high-power electric vehicles (EV) battery charging. The transmission range and efficiency of WPT have been reasonably enhanced by resonating the transmitter and receiver coils at a common frequency. Nevertheless, matching between resonance in the transmitter and receiver is quite cumbersome, particularly in single-transmitter multi-receiver systems. The resonance frequency in transmitter and receiver tank circuits has to be perfectly matched, otherwise power transfer capability is greatly degraded. This paper discusses the mistuning effect of parallel-compensated receivers, and thereof a novel dynamic frequency tuning method and related circuit topology and control is proposed and characterized in the system application. The proposed method is based on the concept of switch-mode gyrator emulating variable lossless inductors oriented to enable self-tunability in WPT receivers. Full article
(This article belongs to the Special Issue Wireless Power Transfer and Energy Harvesting Technologies)
Show Figures

Figure 1

14 pages, 4786 KiB
Article
Effect of the Matching Circuit on the Electromechanical Characteristics of Sandwiched Piezoelectric Transducers
by Shuyu Lin and Jie Xu
Sensors 2017, 17(2), 329; https://doi.org/10.3390/s17020329 - 10 Feb 2017
Cited by 50 | Viewed by 8666
Abstract
The input electrical impedance behaves as a capacitive when a piezoelectric transducer is excited near its resonance frequency. In order to increase the energy transmission efficiency, a series or parallel inductor should be used to compensate the capacitive impedance of the piezoelectric transducer. [...] Read more.
The input electrical impedance behaves as a capacitive when a piezoelectric transducer is excited near its resonance frequency. In order to increase the energy transmission efficiency, a series or parallel inductor should be used to compensate the capacitive impedance of the piezoelectric transducer. In this paper, the effect of the series matching inductor on the electromechanical characteristics of the piezoelectric transducer is analyzed. The dependency of the resonance/anti-resonance frequency, the effective electromechanical coupling coefficient, the electrical quality factor and the electro-acoustical efficiency on the matching inductor is obtained. It is shown that apart from compensating the capacitive impedance of the piezoelectric transducer, the series matching inductor can also change the electromechanical characteristics of the piezoelectric transducer. When series matching inductor is increased, the resonance frequency is decreased and the anti-resonance unchanged; the effective electromechanical coupling coefficient is increased. For the electrical quality factor and the electroacoustic efficiency, the dependency on the matching inductor is different when the transducer is operated at the resonance and the anti-resonance frequency. The electromechanical characteristics of the piezoelectric transducer with series matching inductor are measured. It is shown that the theoretically predicted relationship between the electromechanical characteristics and the series matching inductor is in good agreement with the experimental results. Full article
(This article belongs to the Special Issue Self-Powered Sensors)
Show Figures

Figure 1
